Dynex DX-IPDR3 User Manual

Ipod/iphone audio/video dock with remote control
Hide thumbs Also See for DX-IPDR3:
Table of Contents

Advertisement

Quick Links

See also: Manual
iPod®/iPhone® Audio/Video
Dock with Remote Control
DX-IPDR3
U S E R G U I D E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DX-IPDR3 and is the answer not in the manual?

Questions and answers

Related Manuals for Dynex DX-IPDR3

Summary of Contents for Dynex DX-IPDR3

  • Page 1 Audio/Video Dock with Remote Control DX-IPDR3 U S E R G U I D E...

  • Page 2: Table Of Contents

    Audio/Video Dock with Remote Control Dynex DX-IPDR3 iPod®/iPhone® Audio/Video Dock with Remote Control Contents Important safety instructions ........2 iPod/iPhone Audio Video dock components .....3 Setting up the iPod/iPhone dock ......7 Using the iPod/iPhone dock ........12 Specifications ............16 Legal notices ............16 One-year limited warranty ........19...

  • Page 3: Ipod/Iphone Audio Video Dock Components

    DX-IPDR3 iPod/iPhone Audio Video dock components Package contents • iPod/iPhone Audio Video dock • AC power adapter • USB sync cable • AV cable • Remote control • iPod/iPhone dock adapters (6) Jacks and connectors Front Component Description IR (remote) receiver Receives signals from your remote control.
  • Page 4 iPod®/iPhone® Audio/Video Dock with Remote Control Back Component Description 30-pin connector Plug your iPod/iPhone into this connector. AV jack Connect the included AV cable to this jack and to the composite connections on a television or home theater system. For more information, see “Connecting to a TV”...

  • Page 5: Dx-Ipdr3

    DX-IPDR3 iPod/iPhone adapters The iPod/iPhone dock comes with six adapters. Make sure that you select the correct adapter for your iPod/iPhone type. Note: The adapter numbers are near the top of the adapter back. iPod/iPhone model Adapter Touch 2G, Touch 3G...

  • Page 6: Iphone 4

    iPod®/iPhone® Audio/Video Dock with Remote Control Remote control Button Description MENU Press to go to the previous menu. (List up ) Press to go up in a list of songs, photos, or videos. + (Volume up) Press to increase the volume.

  • Page 7: Setting Up The Ipod/Iphone Dock

    DX-IPDR3 Button Description (previous) Press to go to the previous song or photo. Press and hold to fast reverse through the songs or videos. – (Volume down) Press to decrease the volume. (List down ) Press to go down in a list of songs, photos, or videos.
  • Page 8 Plug the standard USB connector on the USB cable into the AC power adapter. Plug the other end of the AC power adapter into an AC power outlet. Note: If the iPod/iPhone battery does not completely charge within eight hours, contact Dynex technical support.

  • Page 9: Connecting To A Computer

    DX-IPDR3 Connecting to a computer You can connect the dock to a computer so you can sync your iPod/iPhone with your computer and charge your iPod/iPhone at the same time. To connect to a computer: Connect the USB cable to the docking jack on the back of the dock.
  • Page 10 iPod®/iPhone® Audio/Video Dock with Remote Control Connecting to a TV You can connect a TV to the dock using the one-to-three composite audio/video cable. To connect a TV: Connect the end of the included one-to-three AV cable that has a single plug to the AV jack on the back of the dock.
  • Page 11 DX-IPDR3 Connecting a sound system To connect a sound system: Connect the end of the included one-to-three AV cable that has a single plug to the AV jack on the back of the dock. Connect the red and white plugs on the one-to-three AV cable to the audio jacks on the sound system.

  • Page 12: Using The Ipod/Iphone Dock

    iPod®/iPhone® Audio/Video Dock with Remote Control Using the iPod/iPhone dock Playing songs through a sound system To play songs through a sound system: Make sure that you have connected the iPod/iPhone dock to a sound system. For more information, see “Connecting a sound system”...

  • Page 13: Viewing Photos

    DX-IPDR3 To control playback: • Press to play or pause playback. • Press to go to the next song, or press to go to the previous song. • Press and hold to fast forward, or press and hold to fast reverse.
  • Page 14 iPod®/iPhone® Audio/Video Dock with Remote Control • Press (next) to go to the next photo, or press (previous) to go to the previous photo. The background music continues to play. • Press + to increase the volume, or press – to decrease the volume.

  • Page 15: Troubleshooting

    DX-IPDR3 Maintaining Replacing the remote control battery To replace the battery: Release the battery by inserting the tip of a pen or similar tool into the small hole at the top right of the battery compartment. Push the pen /tool into the mechanism, then slide it toward left and hold it.

  • Page 16: Specifications

    iPod®/iPhone® Audio/Video Dock with Remote Control Specifications AC Adapter Voltage input 100-240V AC, 0.5A, 50/60 Hz Voltage output DC 5V/1A AV Dock Voltage input DC 5V/1A Input interface Mini-B USB port Output interface Composite audio/video Available Def. NTSC/PAL Legal notices FCC Part 15 This device complies with Part 15 of the FCC Rules.

  • Page 17: Fcc Statement

    DX-IPDR3 FCC Statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses...
  • Page 18 iPod®/iPhone® Audio/Video Dock with Remote Control...

  • Page 19: One-Year Limited Warranty

    Products and parts replaced under this warranty become the property of Dynex and are not returned to you. If service of products and parts are required after the Warranty Period expires, you must pay all labor and parts charges.

  • Page 20: Where Is The Warranty Valid

    • Damage due to incorrect operation or maintenance • Connection to an incorrect voltage supply • Attempted repair by anyone other than a facility authorized by Dynex to service the Product • Products sold as is or with all faults •...
  • Page 21 7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2011 BBY Solutions, Inc. All rights reserved. DYNEX is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
  • Page 22 (800) 305-2204 © 2011 BBY Solutions, Inc. All rights reserved. DYNEX is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave.
