Table 12. Polarity Options
Input
High
Low
5.3

Eaton Power Management Software Suite

Each Eaton 9130 UPS ships with Eaton Power Management Software Suite. To begin installing, see the
instructions accompanying the Software Suite CD.
When installing software, select serial port installation. For the UPS manufacturer and model,
select Eaton and Eaton 9130. If the Eaton brand options are not available in your version of the
software, select Generic UPSs for the manufacturer and Generic XCP for the model.
Eaton software suite provides up-to-date graphics of UPS power and system data and power flow.
It also gives you a complete record of critical power events, and it notifies you of important UPS or
power information.
If there is a power outage and the Eaton 9130 UPS battery power becomes low, Eaton Sofwtare suite
can automatically shut down your computer system to protect your data before the UPS shutdown
occurs.
9130 UPS-EN
Description
Active state on high voltage (+Udc) level
Active state on low voltage (GND or -Udc) level
5. Communication
Page 25
