BBE SUPA-CHARGER Owner's Manual

High performance pedal power supply
Hide thumbs
Table of Contents

Advertisement

Quick Links

Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUPA-CHARGER and is the answer not in the manual?

Questions and answers

Summary of Contents for BBE SUPA-CHARGER

  • Page 1 Owner’s Manual...

  • Page 2: Features Include

    • Toroidal transformer with selectable AC input voltage (120V-240V) • Fuse Protected • Hum-Free operation • 5 Year warranty We recommend reading this manual to familiarize yourself with all of the features of the Supa-Charger before using. Should you have any questions, please contact BBE at 800-233-8346.

  • Page 3: Contents Checklist

    • 2.5 mm Angled to 2.1mm Straight “red” barreled reverse polar- ity power cable (2) (Line 6 type) Angled end into effect unit only. • IEC Power cable (1) • Supa-Charger Owner’s Manual (1) • Warranty Card If any of these items are found to be damaged or missing, please contact the dealer from which the unit was purchased.

  • Page 4: Getting Started

    Getting Started 1.Input Voltage Selector – 2.AC Power Inlet (IEC con- The Supa-Charger can nector) – Please plug the handle voltages between connector 120V(US)-240V(Europe). Supa-Charger securely For the safety of you and before plugging into a your equipment please power source.
  • Page 5 Only replace with Outputs 5&6 provide = another compatible 1/2 9volts/16 volts* amp Slo-blow fuse. *Please refer to page 4 for 4.LED Power Indicator – detailed description of Output When Blue LED is illumi- Voltage Selection functions nated the Supa-Charger is operating.
  • Page 6 Getting Started (Continued) 6.Output Voltage Selection • In the down position: outputs 1–8 will deliver 9 DIP Switches- The DIP Volts switches dictate amount of voltage that is • In the up position: supplied to its coordinat- outputs 1–4 and 7–8 will ing output.
  • Page 7 Dip Switch Compatibility List Below are some of the more common compatibility settings: • For Boss effect units that require a PSA power supply please position the Dip Switch DOWN. • For Boss effect units that require a ACA power supply please position the Dip Switch UP.
  • Page 8 Service There are no user serviceable parts inside. Should the Supa-Charger require service please contact our Service Department for a Return Authorization at: BBE Sound, Inc. 800-233-8346 Ext.116 For service outside of North America please contact your local distributor. For a listing of BBE Distributors log on to:...

  • Page 9: Technical Specifications

    Technical Specifications Input: ––––––––––––––––––––120v-240v 50/60Hz Outputs: ––––––––––––––––––––Six 9VDC 100mA regulated (1-4 & 7-8) Two 9VDC 200mA regulated (5-6) Fuse Protected:––––––––––––––Yes Dimensions: ––––––––––––––––6" (W) x 3.5" (D) x 1.6" (H) Shipping Weight: ––––––––––––2 lbs. Note: Due to continuing product improvement, specifications and design are subject to change without notice.

  • Page 10: Warranty

    Inc. is not necessary. It is strongly recommended This warranty will be consider null and void by that you retain a copy of the bill of sale for future BBE Sound, Inc. if any of the following is found: reference. 1. The equipment has been physically damaged.

  • Page 11: Important Safeguards

    Important Safeguards For your protection, please read these safety instructions com- pletely before operating the appliance, and keep this manual for future reference. Carefully observe all warnings, precautions and instructions on the appliance and described in the operating instructions sup- plied with the appliance.
  • Page 12 5381 Production Drive Huntington Beach, CA 92649 714-897-6766 • FAX 714-896-0736 bbesound.com BBE is the registered trademark of BBE Sound, Inc. rev.1 7-07...
