  • Page 1 • •...
  • Page 2 CONFIDENTIAL Phone GX30 Service Manual Service Manual Market SERVICING CONCERNS...
  • Page 3 Phone GX30 Service Manual Service Manual Market CP8 PATENT...

  • Page 5: Optional Accessories

    CONFIDENTIAL GX30 [3] Operation manual (Page numbers refer to the user guide) [Optional Accessories] Spare Lithium-ion battery (XN-1BT30) High capacity Lithium-ion battery (XN-1BT31) Cigarette lighter charger (XN-1CL30) USB data cable (USB cable: XN-1DC30) AC charger (XN-1QC30, XN-1QC31, XN-1QC32) Personal handsfree kit (XN-1ER20) The above accessories may not be available in all regions.
  • Page 9 Phone GX30 Service Manual Service Manual Market...
  • Page 11 CONFIDENTIAL Refer to the attachment 1 for the destination and operator name. Software version: A02-006-0184-GX30 Figure 4 Operator name Country Model name...
  • Page 12 RF calibration To adjust the device, click this button (Performance check adjustment). Temperature adjustment (Camera section) Temperature adjustment (Battery section) Main display flicker adjustment External display contrast adjustment White defect correction Black defect correction...
  • Page 16 →...
  • Page 20 Error screen Flash Loader 5.02 CORRESPONDENCE_ERROR Click the [OK] button.
  • Page 23 Flash Loader 5.02 XXXXXXXCommand...
  • Page 24 Flash Loader 5.02 SUM Check End SUM = 0xdb3d Error screen Flash Loader 5.02 FLASH_ERROR ERROR_ERASE ADR = 0x1000000 STR = 0xA0...
  • Page 27 RF cable Stabilized power supply GSM tester Handset Test battery GPIB cable Data cable...
  • Page 28 1) Select the COM port. 2) Set the GPIB No. 3) Select the test instrument. 4) Set the GPIB address. 5) Set the "Cable Offset" values. For cables with connector QCNWK0138AFZZ/ QCNWK0136AFZZ, set the values as follows: GSM 900: 0.60 DCS 1800: 0.95 PCS 1900: 0.96 GSM 850: 0.60...
  • Page 36 Hook Hook Hook Hook Hook Hook...
  • Page 37 GSM Tester Black (CMU 200) PWB repair jig Data Cable Points...
  • Page 38 Push...
  • Page 39 Input box Band selection Channel bar TX frequency of selected channels Current PCL (Read only) PCL bar TX ON/OFF button This indicator appears during Data patterns burst transmission.
  • Page 40 ° RX frequency of selected channels Current RX Gain (Read only) RX Gain Setting bar RX ON/OFF button This indicator appears while Sniff ON/OFF receiving burst signals.
  • Page 41 Measured power box Estimated Power Input box (Integer only) Measure button →...
  • Page 44 → → → Trouble found by SPST Troubleshooting (based on [3] Troubleshooting) (1) Speaker See "7. Speaker does not work." (2) Hands free Sound is heard in audio test. Parts between IC105 pin 10 and IC103 pin 93 are defective, or IC103 is defective. No sound is heard in audio test.
  • Page 45 Troubleshooting (based on [3] Troubleshooting) Trouble found by SPST (1) & (2): No voice is heard. See "Phone" in the section "2. Voice transmission/recording is impossible." Handset microphone Handset microphone (1): Voice is heard. See "Hands free kit (monaural headset)" in the section "3. No voice is heard Handset receiver Hands free receiver (2): No voice is heard.
  • Page 46 Correction value = (Setting temp.) --- (current temp.) + (displayed correction value) Enlarged view (A black line appears after each gradation line.) 8-level gradation pattern with alternate black and gradation lines (black and white)
  • Page 47 DEN: 8-level gradation pattern (black & white pattern)
  • Page 48 Attach the sheet to the handset firmly with clear scotch tape.
  • Page 52 MAIN PWB-A ( FRONT SIDE )
  • Page 53 MAIN PWB-A ( REAR SIDE ) TP718...
  • Page 54 KEY PWB-B ( FRONT SIDE ) TP536 TP526 TP535 TP524 TP523 TP103 TP152 TP151 TP515 TP150 TP149 TP118 TP125 TP108...
  • Page 55 KEY PWB-B ( REAR SIDE ) TP517 TP519 TP114 TP115 TP142 TP140 TP122 TP116 TP146 TP136 TP141 TP156...
  • Page 62 ±...
  • Page 66 → → → →...
  • Page 67 [Sender]...
  • Page 68 ± ± ± ± ± ± ±...
  • Page 69 → → ± ±...
  • Page 77 Phone GX30 Service Manual Service Manual Market Key PWB-B Shield Case, BB (Rear Side) The PWB is set The PWB is set ± into the hole 3 . into the holes 1 and 2 . ± The PWB is The PWB is out of the holes 1 and 2 .
  • Page 78 Key PWB-B Standard position Camera Relay FPC (Rear Side) PWB-F Standard position Sheet, Aerial Cushion, Connector Shield Case end SIM Connector end Standard position Standard position Sensor, Moisture Sheet, Section A-A Standard Hinge Cover position Front Cabinet, Cushion, Battery Standard position Key PWB-B (Rear Side)
  • Page 79 Standard position Standard position Shield Case, Standard position Standard Spacer, position Infrared Port Section B-B Insulator, BB Standard position Tape, Infrared Port Application range Standard position Camera FPC PWB-F Section A-A Standard position Be careful to avoid contact of AN501 (Bluetooth aerial) with the Camera Ground FPC.
  • Page 80 Back Cabinet (Key) Assembly (B1) x 1 SD Card Cover Unit Open the SD card cover and turn it as indicated by the arrow to release the stopper. Then pull out the cover downward. Remove the SD cover belt as instructed below. SD Card Cover (A1) x 1 SD Card Cover Belt...
  • Page 81 (D1) x 5 SD/SIM FPC PWB-G/ BB Shield Case (D3) x 1 (D2) x 1 (D3) x 2 (D1) x 2 Key PWB-B Side Keys Jack Cover (Hands Free) Key PWB-B Back Cabinet (Display) Assembly To unhook the key PWB-B, Hook insert a small flat head screwdriver Minus...
  • Page 82 Back Cabinet (Display) Front Cabinet (Display) (G2) x 2 1.7 x 5 mm OPEN (G1) x 1 (G2) x 2 1.7 x 5 mm (G1) x 2 Back Cabinet (Display) (G3) x 2 SLIDE CLOSE (G3) x 2 SLIDE (G4) x 1 Insert a jig into the gap and slightly lift up the back cabinet (display) assembly.
  • Page 83 External Display/ (I3) x 3 External Display Holder Assembly (I4) x 3 Main PWB-A (I2) x 2 (I2) x 1 (I3) x 4 (I1) x 1 Main Display/ Main Display Holder Minus Assembly Driver Main Display Be careful dirt and dust do not get inside when replacing the display.
  • Page 84 GX30 CONFIDENTIAL Phone GX30 Service Manual Service Manual Market CHAPTER 4. DIAGRAMS [1] Block diagram [Main] RF I/F CLKON, GPO_1 (TXON), GPO_18 (SYNTHEN) IC103 VBAT GPO_9 (BS3), GPO_11(BS4) GPO_20 (SYNTHDATA) AD6535 GPO_16 (BS1) GPO_17(BS2) GPO_21 (SYNTHCLK) AFCDAC, PA ANALOG BASEBAND...
  • Page 85 CONFIDENTIAL GX30 IC505 IC506 XC620930 UGNZ2 GPO_7 (Power_on/off) BLUETOOTH 3.0V MODULE GPIO_3(RTS), GPIO_4(CTS), GTDIO_B(RESET) THEN) GPIO_33(RXD), GPIO_34(TXD) RESET THDATA) GPIO_14(PCM_CLK), GPIO_15(PCM_DATAIN) THCLK) IC708 GPIO_16(PCM_SYNC), GPIO_17(PCM_DATAOUT) 3.0V TK11130C When JTAG=H, automaticaly GPO_18 X101 BOOTCTRL[1] 32kHz GPO_19 CLKIN CAMERA RELAY FPC AVDD...
  • Page 86 GX30 CONFIDENTIAL [RF] Rx LINE Tx LINE CONTROL LINE BS1 (D) (D): Digilal, (A): Analog BS2 (D) BS3 (D) BS4 (D) PA (A) VBAT TP802 Power TP801 TCXOEN (D) Supply VTCXO IC804 36,41,42 1,13,14,22,27,37,40,43,48 R5322N002B IP (A) IN (A) I&Q...
  • Page 87 CONFIDENTIAL GX30 IC805 NL17SZ32XV5T2 LOGIC Tx VCO GSM850 824.2 to 848.8 MHz LOOP VBAT GSM900 880.2 to 914.8 MHz FILTER IC802 DCS1800 1710.2 to 1784.8 MHz 3,6,13 17 2 PCS1900 1850.2 to 1909.8 MHz PF08141B PA MODULE 1800 / 1900...
  • Page 88 Phone GX30 Service Manual Service Manual Market VIEW VIEW VIEW VIEW VIEW 2SK3019 EC4301 C CPH6311 MCH6413 ECH8603 RT1N144 U EC4401 C TOP VIEW TOP VIEW TOP VIEW TOP VIEW 1SS388 HN2S01FU RSB6.8S GM56271A 1SS405 MA2SD31 MA2SD32 RB160M30 RB521S30 RB551V30...
  • Page 89 RF Test Tool RF Test Tool Tx test Tx test Data pattern...TSC 5 GSM850, GSM900 Band C811 C870 (IC801 23Pin) (FL803 10Pin) C811 C871 (IC801 24Pin) (FL803 6Pin) C812 C872 (IC801 25Pin) (FL803 12Pin) C812 C874 (IC801 26Pin) (FL803 14Pin) RF Test Tool RF Test Tool Rx Test...
  • Page 90 RF Test Tool 13M-IN (CLKIN) C833 (Stand-by) (IC106 142Pin) Rx test GSM900, DCS1800 Band C870 (FL803 10Pin) C871 (FL803 6Pin) C872 (FL803 12Pin) C874 (FL803 14Pin) 13M-OUT (CLKOUT) R166 (Stand-by) (IC106 84Pin) RF Test Tool Rx test PCS1900 Band C870 (FL803 10Pin) C871 (FL803 6Pin)
  • Page 91 VSYNC C760 (Stand-by) SUBFLM L711 1Pin (Stand-by) TCXOEN IC804 1Pin (Stand-by)
  • Page 93 IC701 R116025B IC703 2.5V REGULATOR R116018B 1.8V REGULATOR 3.0V TP709 VINT TP705 Vout Vout R756 R743 R705 IC702 TK11131C REGULATOR 5-11 (5-F) CAM_3V_CTL ) : Not Mount...
  • Page 94 MAIN PWB-A DATA[13] BTRESET DATA[14] USB_C_CNT USB_C_CNT DATA[15] DATA[11] LIGHT1 LIGHT1 DATA[10] REFOUT VCORE TEMP VBAT VBAT VBAT CN701 LED702 GM56271A MOBILE LIGHT D702 MA2SD31 TP728 NOTES ON SCHEMATIC DIAGRAM can be found on page 5-1.
  • Page 95 TP732 3.0V TP733 VINT C711 47P(CH) C712 47P(CH) C719 Q702 D702 MCH6413 56271A TRSW RSTB OBILE IC707 DATA SENSP BD6015 STRB SENSN POWER MANAGEMENT VPLUS2 TP737 TP734 TP729 TP735 LEDR TP730 LEDG TP731 BACK LIGHT FPC ERROUT LEDB TP710 PWB-C VPLUS11 LSO11 VPLUS12...
  • Page 96 MAIN PWB-A LCD001 EXTERNAL DISPLAY 1.8V R716 TP714 VLCD R723 VINT L749 FERRITE BEADS RESET_B R705A TP713 XOUT FL701 TP712 NA004 CAMCK IC704 VDDPLL LR38863 DISPLAY CONTROLLER VDDCORE VDDCORE VDDCORE VDDCORE VDDCORE VDDCORE 3.0V VDDCORE VINT VDDIO R717 VDDIO VDDIO VDDIO VDDIO VDDIO...
  • Page 97 CN703 IC706 TC7SZ08A LOGIC CN704 C770 T-COM T-COM TFT-COM L734 FERRITE COMC BEADS R740 COMC COMDC C784 VCOMH L735 FERRITE BEADS L736 FERRITE BEADS L733 FERRITE BEADS L714 60(100MHz) L715 60(100MHz) ) : Not Mount The number is waveform number shown in page 5-4.
  • Page 98 MAIN PWB-A VDDIO VDDIO VDDIO VDDIO VDDIO SCANEN PLLDIV0 PLLDIV1 PLLDIV2 PLLGND P(CH) P(CH) CAM_3V_CTL 5-6 (7-C) TP711 NOTES ON SCHEMATIC DIAGRAM can be found on page 5-1.
  • Page 99 L714 60(100MHz) L715 60(100MHz) R750 DCLK DCLK TP718 HSYNC HSYNC C760 VSYNC C758 VSYNC 10P(CH) 10P(CH) SE_DI/PORT7 TP719 SE_DO/PORT0 SCLK SE_CK/PORT1 SE_LD1/PORT2 RESET C774 R737 3.0V VINT EXCS_B0 EXCS_B1 C775 R738 R741 EXCS_B2 COM2 EXCS_B3 D710 D709 VCL AM 1SS405 RB521S30 DCS_B VSS2...
  • Page 100 MAIN PWB-A (FRONT SIDE) TP722 TP721 TP734 TP735 EP100 EARPIECE TP715 TP723 TP732 TP733 TP716 TP724 TP707 TP710 TP706 TP711 TP714 TP720 TP712 TP717 TP737 TP713 TP731 TP705 TP729 TP730 TP736 TP709 TP728 TP727 TP702 TP738 TP701 FS701 FS702 R760 5-31 (6-A) FROM CAMERA RELAY FPC...
  • Page 101 MAIN PWB-A (REAR SIDE) C760 C739 C734 R750 FL701 R705A C711 R717 C737 C758 C712 L715 C791 L714 5-31 (3-A) FROM BACK LIGHT FPC IC704 PWB-C R744 C771 R745 IC706 C770 C724 L746 C787 C772 R747 R740 C725 TP708 C773 C784 C766 C776...
  • Page 102 KEY PWB-B (1/3) KEY PWB-B (1/3) RECEPTION SIGNAL TRANSMISSION SIGNAL SPEAKER SIGNAL KEYPADCOL[0-4],KEYPADROW[0-4],POWONKEY 5-23 (6-B) MODESEL3 MODESEL3 5-23 (4-G) USB_D+ R292 R294 USB_D+ 150K 120K 5-23 USB_D- 5.2V USB_D- (6-E) 5-23 CHGIN USB_DET USB_DET (6-E) USB_PU 5-23 (6-E) USB_PU USC[0] R293 R295 USC[0]...
  • Page 103 C226 R278 0.047 C148 R142 0.047 C154 3.0V 220P VAPP R139 MO100 (CH) VBAT VINT VIBRATOR 2.85V VSIM C167 C168 C169 TP126 R135 5-22 SP1-1 SPOUT1 VREF TP127 R136 (11-C) SP2-1 SPOUT2 C171 R159 0.001 3.3K IC109 DATA[7] PLLC NJM2871F03 DATA[6] N.C.
  • Page 104 KEY PWB-B (1/3) BATTYPE 5-23 (6-C) 5-25 (2-D) 5-25 (3-A) AFCDAC AFCDAC 5-25 (2-F) RECIVER_OUTP AFCDAC 5-22 C116A (11-B) RECIVER_OUTP L107 RECIVER_OUTN FERRITE C120A C132 BEADS 47P(CH) VINT Q106 Q107 RECIVER_OUTN EC4401 C EC4301 C L108 VBAT FERRITE 3.01V BEADS C120 TP121 47P(CH)

  • Page 105: Analog Baseband

    USC[1] USC[2] R138 USC[3] USC[4] USC[5] USC[6] JTAGEN KEYON KEYOUT CRST TP164 C153 VABB VBACKSEL C158 2.85V VMEMSEL VSIM TP169 MC_CLK C159 MC_CMD 2.8V R153 VABB AFCDAC TP170 VMEM MC_DAT[0] VSIM C160 MC_DAT[1] 1.8V VMEM AIN3L TP171 VCORE MC_DAT[2] VMEM AIN3R 7P(CH) TP165...
  • Page 106 KEY PWB-B (1/3) 5-23 (5-B) 5-5 (3-A) FROM SD/SIM FPC PWB-G FROM CAMERA GROUND FPC PWB-D VBACK R156 3.0V VINT 3.0V C194 VINT 3.0V 3.0V VINT VAPP V102 TP125 100P TP149 R249 R157 IC107 EW6671 TP150 HALL TP151 TP152 R182 C193 1.8V 2.85V...
  • Page 107 Q104 UN101 3.8V EMD6 VMEM INFRARED PORT 2.95V 2.83V SGND C196 2.83V LEDA 3.0V VINT C197 R185 R183 470K 3.0V VINT TP181 CN102 ADD[1] C227 VINT FL207 VINT R273 EMI FILTER FL104 DATA[15] NOISE FILTER DATA[12] DATA[10] DATA[7] DATA[4] FL206 DATA[2] R274 EMI FILTER...

  • Page 108: Digital Baseband

    KEY PWB-B (1/3) 5 23 MODESEL2 USC[1] [RXD] [Modesel2 of Interface IC] GPIO_36 (5-G) VINT 3.0V TP157 USC[2] GPIO_37 [TXD] [Typhoon Interrupt] USC[3] R291 USC[3] [Sound IC Interrupt] GPIO_38 [Genie RX] 470K USB_PU USC[4] [USB pullup control of Interface IC] GPIO_39 [RTS / Genie RX] TP153...
  • Page 109 R226 BTRESET BT_RESET BUFOFF R225 5-24 (8-C) BUFOFF LCD_RSP R224 3.0V LCDRSP /LCD_WAIT L223 VINT LCDWAIT FERRITE BEADS /LCD_RESET R222 LCDRESET /LCD_INT L221 LCDINT FERRITE R296 BEADS AGND 470K RECIVER_OUTN AGND SCRAM1_/CS R234 5-17 RECEIVER- (2-B) RECEIVER+ R233 RECIVER_OUTP AGND AGND D_CS /LCD_CS...
  • Page 110 KEY PWB-B (2/3) KEY PWB-B (2/3) SD/SIM FPC PWB-G BAT100 RECEPTION SIGNAL BACK-UP BATTERY TRANSMISSION SIGNAL SD CARD CONNECTOR SPEAKER SIGNAL SIM CARD CONNECTOR SW_Side_UP SW_Side_DOWN BUCK-UP BATTERY HOLDER CN104 5-19 (2 5-A) KEYPADROW[0] KEYPADCOL[1] KEYPADCOL[2] TP521 SW522 KEYPADCOL[0-4],KEYPADROW[0-4],POWONKEY TP522 POWONKEY 5-15 (2-D) SW501...
  • Page 111 IC505 VINT XC620930 VBAT REGULATOR TP514 Vout R527 BT_POWER_ON 5-20 (9-G) IC506 UGNZ2 BLUETOOTH MODULE R543 SPIMOSI BT_TXD UARTTX R544 SPICLK BT_RXD UARTRX R545 SPIMISO 3.3K BT_PCMOUT SPICSB PCMOUT A B C D E F BT_PCMCLK PCMCLK 6 12 18 24 30 5-20 (9-G) PIO5 TP517...
  • Page 112 KEY PWB-B (3/3) KEY PWB-B (3/3) RECEPTION SIGNAL 5-17 (2-B) TRANSMISSION SIGNAL BATT BATT 5-23 (6-C) IC804 R5322N002B TXOUT_ POWER SUPPLY TCXOEN 5-15 VOUT1 (2-G) C801 VOUT2 VBAT 5-23 (6-D) VTCXO TXOU 5-17 (2-A,B) FL904 MATCHING DEVICE C832 GSM850 270P(CH) QOUT/QIN PLLOUT GSM850...
  • Page 113 R812 C861A 82P(CH) FL823 Pin2 Pin16 FERRITE BEADS HIGH HIGH HIGH HIGH C862 100P(CH) HIGH HIGH TXOUT_DCS/PCS C863 47P(CH) IC805 NL17SZ32XV5T2 LOGIC IC802 PF08141B PA MODULE 23 24 25 26 27 28 29 TXOUT_GSM This Parts is Supplied with Cabinet Parts C876 1P(CH) AERIAL...
  • Page 114 KEY PWB-B (FRONT SIDE) 5-31 (2-H) SOLDER FROM GROUND 5-31 (3-D) FPC PWB-E FROM CAMERA RELAY FPC PWB-F CN103 TP135 TP126 TP127 Q104 C196 TP183 TP170 TP182 TP184 TP113 TP514 TP181 LEFT RIGHT SOFT SOFT TP503 TP502 CENTRE END/ SEND POWER TP121 LED104...
  • Page 115 KEY PWB-B (REAR SIDE) 5-31 (4-D) FROM CAMERA RELAY (103-11) 5-31 (2-E) FPC PWB-F AERIAL SOLDER FROM CAMERA UN101 INFRARED PORT GROUND FPC PWB-D CN503 CN102 R884 BLUETOOTH 30 34 C831A AERIAL TERMINAL J801 C522 FL208 MO100 R135 R110A FL207 R101 C227 ANT801...
  • Page 116 CAMERA RELAY FPC PWB-F CA1001 OD15 CAMERA UNIT OD14 OD13 OD12 OD11 OD10 CN102 5-20 (12-D F) NOTES ON SCHEMATIC DIAGRAM can be found on page 5-1.
  • Page 117 5-20 (12-G,H) CN103 5-22 (12-A C) VBAT VBAT VBAT TEMP VCORE REFOUT DATA10 LIGHT1 DATA11 DATA15 USB_C_CNT DATA14 BTRESET DATA13 LCDRSP DATA12 BUFOFF DATA7 DATA6 DATA5 DATA4 VCCD DATA0 DATA1 DATA2 DATA3 CAMCLK LCDCLK +15V VDD6 DATA9 DATA8 /LCDWAIT /LCDRESET /LCDINT VINT VINT...
  • Page 118 5-13 (3-G) BACK LIGHT FPC MAIN PWB-A CN701 (FRONT SIDE) PWB-C CN705 5-14 (8-B) TO MAIN PWB-A (REAR SIDE) CA1001 CAMERA UNIT 5-14 (12-G) SOLDER TO MAIN PWB-A 5-14 (9-G) (REAR SIDE) TO MAIN PWB-A (REAR SIDE) CAMERA RELAY FPC PWB-F SOLDER 5-14 (12-G)
  • Page 119 Conditions: SIM card inserted, power on (battery=3.7V), in stand-by mode (opened) Measuring instrument: Digital multimeter : Unmeasurable IC105 IC111 IC502 IC505 IC508 IC801 IC802 PIN NO. VOLTAGE PIN NO. VOLTAGE PIN NO. VOLTAGE PIN NO. VOLTAGE PIN NO. VOLTAGE PIN NO. VOLTAGE PIN NO.
  • Page 121 Phone GX30 Service Manual Service Manual Market...
  • Page 123 (TOP VIEW) SF-RY/BY DQ15 S/SC-/WE DQ14 F-RY/-BY SF-/RE F-/WE SC2-CE2 DQ13 F/SF/SC-VCC /RST SC2-/CE1/NC DQ12 S/SC1-CE2 S-VCC F/SF/SC-VCC DQ11 SF/F/SC-VCC DQ10 SF-/WE SC1-/CE1 SF-/WP SF-/CE F-/CE S-/CE1 SF/F/SC-VCC A0~A17 128M (x16) bit F-RY/-BY A18~A20 NOR Flash memory F-/WE,/WP,/RST F-/CE SF-RY/BY SF-/WE,SF-/WP 128M (x16) bit Smartcombo...
  • Page 127 /RST /RST Timing Generator Vol R Vol L FiFO Mono Select 64 byte FM + Wave Table R-ch R-ch Synthesizer 16-bit L-ch FiFO L-ch Sequencer 512 byte 20 ~ 27 D0~D7 PCM/ADPCM Play back VREF Buffer Soft IRQ /IRQ 3 SPOUT1 LED 2 LED control...
  • Page 131 Pulse Regulator Reg. Output Amplifier OUTPUT stage Hall cell Schmitt trigger & Latch VREF...
  • Page 132 VOUT Thermal Protection CONT Bandgap Reference VOUT VREF CURRENT LIMIT (TOP VIEW)
  • Page 133 VOUT VOUT VREF VOUT VREF CURRENT LIMIT...
  • Page 134 MODE 0,1,2: ON MODE 3,5: OFF MODE 0,2,3: OFF MODE 0,1,2: ON MODE 1,5: ON MODE 3,5: OFF 14 GND1 USBD+/RXD MODE 0,2,3,5: OFF MODE 1: ON CPUVDD RXANAIN CPU_USB_D+ MODE 0,1,2: OFF MODE 3,5: ON TXANAOUT CPU_USB_D- CPUVDD MODE 0,2,3,5: L MODE 1: H MODESEL3 REG33...
  • Page 135 ON/OFF Each ciruit Control Current Limit 5 VOUT Voltage Reference...
  • Page 136 OUT Y (TOP VIEW) IN B IN A VOUT Reference Short-circuit voltage protection circuit...
  • Page 137 VOUT VREF CURRENT LIMIT VOUT Over Heat & Control Over Current Circuit Protection 320K Bandgap Reference 500K CONT...

  • Page 141: Memory Interface

    RESET_B Reset SE_LD2/PORT5 FULL Some MHz SE_LD3/PORT6 TEST Halt MasterClock (MCLK) ····· VRAM/HOST/HS/BS/ to 68 MHz Scan Some MHz to 33 MHz VDIF/VSPetc Ctrl PWM0/PORT3 LCDTimingClock (TCLK) PLLDIV[2:0] ····· TG/Pallet/LCD IF 5MHz~10MHz /CDE/BS PWMLCD/PORT4 SUBLCDTimingClock ····· SUB PWM1/PORT8 (STCK) XIN clock Clock LowSpeedClock (LCLK) ·····...
  • Page 143 :VPLUS11 :VBAT2 :GNDP :BLED :RSTB :CAMN :VNEG :SBD :GND2 :FLED :ERROUT :LEDCTL :VREF :IREF :FRP :DATA :CAMP :VPLUS12 :CLK :STRB :GND3 :CAPN2 :VPLUS2 :VIO :CAPP2 :CPIN :CAP3 :SENSN :SENSP :CAPN1 :CAPP1 :TRSW :LEDB :LEDR :TEST :WVOUT :LSO12 :LSO11 :VBAT1 :GND1 :LEDG VOUT Control...
  • Page 145 Vramp Vtxb Vdd2 Pout_DCS/PCS Pin_DCS/PCS control circuit Pout_GSM Pin_GSM VBAND Vdd IC Vdd1...
  • Page 146 6 VOUT 5 GND VOUT2 Vin1 5 Vcc Vin2 Vout...
  • Page 148 MAIN DISPLAY To Input Terminal...
  • Page 149 EXTERNAL DISPLAY To Input Terminal...
  • Page 150 GX30 CONFIDENTIAL – MEMO – 6 – 30...
  • Page 151 CONFIDENTIAL PARTS GUIDE DIGITAL MOBILE PHONE GX30 MODEL CONTENTS SHARP CORPORATION SHARP CORPORATION SHARP CORPORATION SHARP CORPORATION...
  • Page 152 CONFIDENTIAL [1] INTEGRATED CIRCUITS IC101 -------- IC103 -------- IC105 VHIYMU762C+-1L IC106 -------- IC107 VHIEW6671++-1R IC108 VHIR3112Q26-1L IC109 VHINJ287130-1L IC111 VHIR116030B-1L IC113 VHITC7SZ08A-1L IC114 RH-IXA007AFZZL IC115 VHIXC61CN27-1L IC116 VHIRQ5RW45B-1L IC502 VHIBU7870KN-1L IC503 VHITK73840B-1L IC504 VHIUSBUF2W6-1L IC505 VHIXC620930-1L IC506 RUNTZA005AFZZL IC507 VHITC7SET00FU- IC508 VHI817A30NB-1R IC509...
  • Page 153 CONFIDENTIAL [4] FILTERS FL101 RFILNA004AFZZN FL102 RFILNA004AFZZN FL103 RFILNA004AFZZN FL104 RFILNA004AFZZN FL701 RFILNA004AFZZN FL803 RFILRA006AFZZL FL823 RFILN0020AFZZN FL901 RFILRA004AFZZL FL902 RFILRA003AFZZL FL903 RFILRA005AFZZL FL904 RFILRA007AFZZL FL905 RFILR0256AFZZL [5] COILS L101 RCILZ1088YCZZ- L102 RCILZ1088YCZZ- L103 RCILZ0315AFZZT L105 RCILZ0315AFZZT L106 RCILZ0370AFZZN L107 RCILZ1088YCZZ- L108 RCILZ1088YCZZ-...
  • Page 154 CONFIDENTIAL [10] CAPACITORS C101 VCCCCZ1EH470JT µ C103 VCKYCZ1AB104KT C104 VCCCCZ1EH470JT µ C105 VCKYCZ1AB104KT µ C107 VCSAPR0GJ226M- µ C108 RC-KZ1315AFZZN µ C110 VCSAPR0GJ226M- C112 VCCCCZ1EH470JT µ C113 VCKYCZ1EB102KT C115 VCCCCZ1EH470JT C116 VCCCCZ1EH470JT µ C116A VCKYCZ0JB105KT µ C117 VCKYCZ1EB102KT µ C118 VCKYCZ1AB104KT C120 VCCCCZ1EH470JT µ...
  • Page 155 CONFIDENTIAL [10] CAPACITORS µ C214 VCKYCZ0JB105KT µ C215 VCKYCZ1AB104KT C216 VCCCCZ1EH270JT C217 VCCCCZ1EH120JT C218 VCCCCZ1EH270JT µ C219 VCKYCZ1AB104KT µ C220 VCKYCZ1AB104KT µ C221 VCKYCZ1AB104KT µ C222 VCKYCZ1AB104KT µ C223 VCKYCZ0JB105KT µ C224 VCKYCZ1AB104KT µ C226 VCKYCZ1AB473KT µ C227 VCKYCZ0JB105KT µ C228 VCKYCY0JB225KT µ...
  • Page 156 CONFIDENTIAL [10] CAPACITORS µ C770 RC-KZ1308AFZZT µ C771 RC-KZ1317AFZZN µ C772 VCKYCZ0JB105KT µ C773 RC-KZ1317AFZZN µ C774 VCKYCY0JB225KT µ C775 RC-KZ1308AFZZT µ C776 VCKYCY1AB105KT µ C777 VCKYCY1AB105KT µ C779 RC-KZ1308AFZZT µ C780 RC-SZ1165AFZZL µ C781 RC-KZ3021AFZZN µ C782 VCKYCY0JB225KT µ C783 RC-KZ1308AFZZT µ...
  • Page 157 CONFIDENTIAL [11] RESISTORS R124 VRS-CZ1JB000JT R125 VRS-CZ1JB222JT R126 VRS-CZ1JB000JT R127 VRS-CZ1JB474JT R128 VRS-CZ1JB913JT R129 VRS-CZ1JB222JT R130 VRS-CZ1JB222JT R131 VRS-CZ1JB271JT R132 VRS-CZ1JB104FT R133 RR-NZ1103AFZZN R134 VRS-CZ1JB101JT R135 VRS-CY1JB000JT R136 VRS-CY1JB000JT R137 VRS-CZ1JB000JT R138 VRS-CZ1JB000JT R139 VRS-CY1JB000JT R140 VRS-CZ1JB125JT R141 VRS-CZ1JB104JT R142 VRS-CZ1JB273JT R143 VRS-CZ1JB331JT...
  • Page 158 CONFIDENTIAL [11] RESISTORS R226 VRS-CZ1JB000JT R227 VRS-CZ1JB000JT R228 VRS-CZ1JB000JT R231 VRS-CZ1JB000JT R233 VRS-CZ1JB000JT R234 VRS-CZ1JB000JT R235 VRS-CZ1JB000JT R237 VRS-CZ1JB000JT R238 VRS-CZ1JB1R0JT R239 VRS-CZ1JB000JT R244 VRS-CZ1JB102JT R245 VRS-CZ1JB102JT R246 VRS-CZ1JB102JT R248 VRS-CZ1JB000JT R249 VRS-CZ1JB203JT R254 VRS-CZ1JB752JT R256 VRS-CZ1JB000JT R258 VRS-CZ1JB000JT R262 VRS-CZ1JB682JT R263 VRS-CZ1JB682JT...
  • Page 159 CONFIDENTIAL [11] RESISTORS R701 VRS-CZ1JB332JT R703 VRS-CZ1JB103DT R704 VRS-TV2ABR10JT R704A VRS-CZ1JB000JT R705 VRS-CZ1JB000JT R705A VRS-CZ1JB000JT R707 VRS-CZ1JB000JT R708 VRS-CZ1JB124DT R712 VRS-CZ1JB000JT R713 VRS-CZ1JB1R0JT R714 VRS-CZ1JB474JT R716 VRS-CZ1JB000JT R717 VRS-CZ1JB000JT R718 VRS-CZ1JB3R3JT R720 VRS-CZ1JB1R0JT R723 VRS-CZ1JB000JT R727 VRS-CZ1JB104JT R728 VRS-CZ1JB000JT R729 VRS-CZ1JB000JT R730 VRS-CZ1JB000JT...
  • Page 160 CONFIDENTIAL [13] CABINET PARTS 102-3 109x2 102-1 601x2 103-4 102-5 601x2 103-9 103-6 103-8 102-2 103-7x2 103-3 103-1 (SP100) 103-11 102-4 104-23 103-5 (LCD001) 103-2 104-6 103-10 104-17 104-1 (MO100) (PWB-A) (BAT100) 104-25 (PWB-G) 104-4 104-10 (CA1001) 104-20 104-20 104-18 104-14 (PWB-D) 104-5...
  • Page 161 CONFIDENTIAL [13] CABINET PARTS DCABAW108AFSM DCABAW108AFSP DCABAW108AFS1 101- 1 -------- 101- 2 GCABC7023AFSA 101- 3 GCOVH1356AFSA 101- 4 MHNG-0210AFSB 101- 5 PCUSSA019AFZZ 101- 6 PCUSS1033AFZZ 101- 7 PMAGZ0072AFZZ 101- 8 PSHEZA026AFZZ 101- 9 PSHEZA049AFZZ 101-10 PSHEZA166AFZZ 101-11 PSHEZA175AFZZ 101-12 TLABZ2783AFZZ DCABBW108AFSP DCABBW108AFSG DCABBW108AFSH...
  • Page 162 CONFIDENTIAL [13] CABINET PARTS GCOVA2569AFSA GCOVAA039AFZZ GCOVD1119AFSU GCOVH1358AFSA GCOVH1359AFSA JKNBPA002AFSA JKNBZ2371AFSA JKNBZ2372AFSA LHLDZ1952AFSA PCUSSA029AFZZ PSHEMA001AFZZ PSLDCA002AFZZ RDNTL0015AFZZ RMICC0213AFZZ RMOTV0557AFZZ RPHODA002AFZZ RSP-ZA001AFZZ TSPC-A088AFZZ TSPC-A089AFZZ TSPC-A090AFZZ PSHEZA204AFZZ -------- LX-EZ0195AFZZ...
  • Page 163 CONFIDENTIAL [14] ACCESSORIES/PACKING PARTS 24 ([EP] [H] [F] [C] 13, 14 ([T] Only), [K] [U] Only) 15, 16 ([B] Only), 17, 18, 19 9, 23 Handset 27 ([U] Only) 28 ([B] Only) 20 ([E] [B] [D] Only) AC Charger 26 ([G] Only) RADPAA001AF01 RADPAA002AF01 RADPAA003AF01...
  • Page 164 [14] ACCESSORIES/PACKING PARTS TCADHA018AFZZ TCADHA019AFZZ TCADHA020AFZZ TCADHA021AFZZ TCADHA022AFZZ TCADHA023AFZZ TCADZ0263AFZZ TCADZA006AFZZ TCADZA013AFZZ TCADZA014AFZZ TCADZA016AFZZ TCADZA017AFZZ TCADZA018AFZZ TCADZA019AFZZ TCADZA034AFZZ TCADZA042AFZZ TCADZA051AFZZ TCADZA053AFZZ TCADZA055AFZZ TCADZA057AFZZ TCADZA020AFZZ TCADZA022AFZZ TCADZA023AFZZ TCADZA024AFZZ TCADZA025AFZZ TCADZA026AFZZ TCADZA028AFZZ TCADZA038AFZZ TCADZA052AFZZ TCADZA054AFZZ TCADZA056AFZZ TCADZA058AFZZ TGANEA001AFZZ TGANEA009AFZZ TGANEA010AFZZ TGANEA011AFZZ TGANGA002AFZZ TGANIA002AFZZ TGANZA012AFZZ TGANZA013AFZZ...
  • Page 165 – MEMO –...
  • Page 166 CONFIDENTIAL GX30 © COPYRIGHT 2004 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
