ADS Instant Music
Quick Start
Guide for hardware and software installation and
basic use in Microsoft Windows.
Some procedural details will vary depending on your Windows version.
Section 1 – Hardware installation and configuration
1)
Connect it up.
a)
Connect the output on your source (LP preamp, power amp, stereo receiver etc.) to the L/R
inputs on the back of the Instant Music. If your source has an optical digital output you can use
that to connect to the Instant Music.
If your source does not have a set of RCA outputs (boom boxes, some shelf systems with only speaker-wire out) then
you can use an adapter to connect from the headphone jack to the L/R in on the back of the Instant Music.
b)
Run a USB cable from the USB port on the back of the Instant Music to an available USB port on
your PC.
c)
Windows will detect that new hardware has been connected to the PC. If you receive a "Found
New Hardware Wizard" have Windows search
automatically
Drivers for USB Audio are built into every
current Windows version.
Depending on your own Windows Installation, you may
be asked to provide the Windows CD. You must do this;
the only drivers available are part of the Windows
operating system and as such are legal property of
Microsoft Corporation and cannot be distributed outside
of the Windows CD.
2)
Confirm proper driver installation.
a)
Right-click "Computer" and select "Properties."
b)
Click Device Manager on the side pane.
Windows 2K/XP, click the Hardware tab first, then click
the "Device Manager" button.
c)
Locate "USB Audio Device" under the "Sound,
video
and
Assuming you have no other USB Sound
devices connected to your system, that is the
Instant Music.
Revision 070717
for
the
appropriate
game
controllers"
drivers.
In
category.
Advertisement
Related Manuals for ADS Technologies ADS INSTANT MUSIC
Summary of Contents for ADS Technologies ADS INSTANT MUSIC
-
Page 1: Section 1 - Hardware Installation And Configuration
ADS Instant Music Quick Start Revision 070717 Guide for hardware and software installation and basic use in Microsoft Windows. Some procedural details will vary depending on your Windows version. Section 1 – Hardware installation and configuration Connect it up. Connect the output on your source (LP preamp, power amp, stereo receiver etc.) to the L/R inputs on the back of the Instant Music. -
Page 2: Section 2 - Software Installation
Set the correct input and output devices. Click the “Start” menu then to “Control Panel.” Select “Hardware and Sound” then click “Sound.” WinXP, select “Sounds, Speech, and Audio Devices” followed by “Sounds and Audio Devices.” In Win2K, open “Sounds and Multimedia.”... -
Page 3: Section 3 - Recording Your First Cd
Section 3 – Recording your first CD Setup After initially running the Spin It Again program, it is recommended that you check on some initial setup items before you start recording. Click on the “Settings…” button. On the “Recording” tab, you can check and change the location of the recording folder. - Page 4 On the first screen of the Recording Wizard is where you’ll begin recording. Make sure that the “Monitor” box is checked or you will not be able to hear your recording. In order to begin recording, you simply click the record button. You can stop and resume the recording as well if you wish to not record certain segments.
- Page 5 Finishing Your Project You’re ready to burn your project to a CD On the “Burn A CD and/or Create Audio Files” screen, select “Burn Audio CD.” You also have the option to create audio files from your project (each track becomes its own file). The program can create uncompressed WAV files (.wav), Windows Media (.wma), and Ogg Vorbis (.ogg, a high-quality free format made to...
