Summary of Contents for ROUTE 66 BT-GPS

  • Page 2: Gps Receiver

    ROUTE 66 Bluetooth GPS Receiver User Guide ROUTE 66 Bluetooth GPS Receiver User Guide ROUTE 66 Geographic Information Services B.V. Haaksbergweg 9 NL-1101 BP AMSTERDAM ZUIDOOST The Netherlands Telephone: +31-(0)20 452 92 98 Fax: +31 (0)20-312 30 61 E-Mail: info@66.com URL: www.66.com...

  • Page 3: Table Of Contents

    ROUTE 66 Bluetooth GPS Receiver User Guide CONTENT OVERVIEW ----------------------------------------------------------------------------------- 4 UNPACKING --------------------------------------------------------------------------------- 5 MAIN FEATURES --------------------------------------------------------------------------- 6 TECHNICAL SPECIFICATIONS--------------------------------------------------------- 7 4.1. General Specifications ------------------------------------------------------------------------7 4.2. Acquisition Time (Average) * --------------------------------------------------------------7 4.3. Accuracy * ------------------------------------------------------------------------------------7 4.4. Usage * ---------------------------------------------------------------------------------------7 4.5.

  • Page 4: Overview

    (Figure 1) The ROUTE 66 Bluetooth GPS Receiver has a built-in rechargeable Lithium-ion battery. Powered by the SiRF Star III, the ROUTE 66 Bluetooth GPS Receiver is a dual- purpose GPS receiver that communicates with other systems via Bluetooth technology. The SiRF Star III architecture packs the GPS receiver with a...

  • Page 5: Unpacking

    ROUTE 66 Bluetooth GPS Receiver User Guide 2. Unpacking Congratulations on your purchase of the GPS Receiver. We hope it will be useful to you for a long time. Before you begin, make sure that your package includes the following items. If any of these items are missing, please contact your local ROUTE 66 dealer or distributor.

  • Page 6: Main Features

    ROUTE 66 Bluetooth GPS Receiver User Guide 3. Main Features In addition to providing a set of user-friendly functions, the ROUTE 66 Bluetooth GPS Receiver WELL suits integration with other systems. • Comes with SiRF Star III for low power consumption.

  • Page 7: Technical Specifications

    ROUTE 66 Bluetooth GPS Receiver User Guide 4. Technical Specifications 4.1. General Specifications • GPS Chip: low power consumption SiRF Star III Chip. • Channels: Tracks up to 20 satellites. • Satellite broadband: 1 Hz. • Receiver signal: L1, C/A Code.

  • Page 8: Power Supply

    ROUTE 66 Bluetooth GPS Receiver User Guide 4.5. Power Supply • External power source: 5V DC +/- 5% • Battery: Main battery: Rechargeable Lithium-ion-ion battery. Backup battery: Rechargeable 3V Lithium-ion-ion battery for RTC and satellite data storage. • Working current: 75-85 mA (under Continuous mode) •...

  • Page 9: Dimensions And Weight

    ROUTE 66 Bluetooth GPS Receiver User Guide 4.7. Dimensions and Weight • Dimensions: 70 (W) × 24(L) × 16(H) millimeters • Weight: < 35 grams • Operating temperature: from -10℃ to + 60℃ (when not battery charging); from 0℃ to 45℃ (when battery charging).

  • Page 10: Getting Started

    ROUTE 66 Bluetooth GPS Receiver User Guide 5. Getting Started Step 1. Battery Charging Before using the GPS receiver for the first time charge the battery until the battery LED indicator goes out. This indicates that the battery is fully charged.

  • Page 11: Nomenclature

    ROUTE 66 Bluetooth GPS Receiver User Guide 5.1. Nomenclature 1). The features of the ROUTE 66 Bluetooth GPS Receiver are as shown in Figure 2. Battery Indicator Bluetooth Indicator GPS Indicator Power Socket and Data Port (Figure 2) 2). LED indicator status...
  • Page 12 Power and signal ground. Data transmission. To transmit data to peripheral devices. (CMOS 3.0V Level) Data receipt. From peripheral devices to the ROUTE 66 Bluetooth GPS Receiver. (CMOS 3.0V Level) Positive terminal of the DC adaptor that powers the internal VCHARG charging circuit of Lithium-ion battery.
  • Page 13 ROUTE 66 Bluetooth GPS Receiver User Guide 5). The ROUTE 66 Bluetooth GPS Receiver optional accessories and connector description are as shown in Figure 4. PC/Notebook USB port USB cable Mini USB (Figure 4)

  • Page 14: Bluetooth Installation

    ROUTE 66 Bluetooth GPS Receiver User Guide Bluetooth Installation 5.2. Follow the instructions below to link your ROUTE 66 Bluetooth GPS Receiver to a PDA (Personal Digital Assistant). 1. Activate “Bluetooth Manager” on your pocket PC. Tap New, Connect, to access other devices via Bluetooth.
  • Page 15 ROUTE 66 Bluetooth GPS Receiver User Guide 3. Search for the Bluetooth device. Tap Next, and then select ROUTE 66 BT-GPS. 4. To establish Bluetooth link, select Connect to SPP Slave, tap Next and then Finish.
  • Page 16 ROUTE 66 Bluetooth GPS Receiver User Guide 5. Tap ROUTE 66 BT-GPS: SPP slave, and select Connect from the dropdown menu. The installation has been completed.

  • Page 17: Installing The Testing Program

    ROUTE 66 Bluetooth GPS Receiver User Guide Installing the Testing Program 5.3. You can install the GPS viewer program from the supplied CD to check current positioning and satellite signal reception. To install Microsoft Active Sync to your PC, refer to your Pocket PC manual for installation procedures.
  • Page 18 ROUTE 66 Bluetooth GPS Receiver User Guide 3. Click Start, Programs, GPSViewer on your PDA.
  • Page 19 ROUTE 66 Bluetooth GPS Receiver User Guide 4. The following screen appears after GPS Viewer is opened. 5. Set Baud rate to 38400. Click the Scan button to scan for COM Port. Select your COM Port (COM1~COM10), and click Open GPS.
  • Page 20 ROUTE 66 Bluetooth GPS Receiver User Guide 6. Select GPS Status to view the satellite diagrams as shown below.

  • Page 21: Accessories

    To cater to customers’ different uses and needs, the ROUTE 66 Bluetooth GPS Receiver comes with a range of accessories. When using these accessories, your device will not only have the capability to transfer via Bluetooth, but the ROUTE 66 Bluetooth GPS Receiver will also connect and transmit signals to PDAs, Notebooks and other devices.

  • Page 22: Usb Cable Driver Installation

    USB-V2.1.0.exe from the CD to the hard disk. 2) Execute USB-V2.1.0.exe 3) Connect the ROUTE 66 Bluetooth GPS Receiver USB cable to the computer. The system will automatically search for the plug-and-play device and then automatically start the installation. This step completes the entire USB Driver installation.

  • Page 23: Limited Warranty

    2) The Limited Warranty does not apply to normal wear and tear, does not apply when the Hardware is opened or repaired by someone not authorized by ROUTE 66 and does not cover repair or replacement of any Hardware or part thereof damaged by:...
  • Page 24 ROUTE 66 Bluetooth GPS Receiver User Guide 3) In order to make a claim of a Defect, you must contact ROUTE 66 by email during the Warranty Period via www.66.com to explain the Defect and to obtain an RMA number (Return Materials Authorization) if necessary. You must return the Hardware during the Warranty Period, along with an explanation of the Defect, to the address provided to you by ROUTE 66.
  • Page 25 ROUTE 66 Bluetooth GPS Receiver User Guide 9) Neither ROUTE 66 nor its suppliers shall be liable to you or to any third party for any damages either direct, indirect, incidental, consequential or otherwise (including in each case, but not limited to, damages for the inability to use the equipment or...

  • Page 26: Troubleshooting

    ROUTE 66 Bluetooth GPS Receiver User Guide 9. Troubleshooting Problem Reasons Method Either no GPS signals or weak signals. Place the ROUTE 66 Bluetooth GPS Receiver No signal output Signals blocked by tall buildings, outdoors. vehicle roof, or anti-heat film on the vehicle windows.
  • Page 27 ROUTE 66 Bluetooth GPS Receiver User Guide Disposal of old electrical appliances The European Directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE), requires that old household electrical appliances must not be disposed of in the normal unsorted municipal waste stream. Old appliances must be collected separately in order to optimise the recovery and recycling of the materials they contain and reduce the impact on human health and the environment.
