- Page 1 Operating Manual For Easy Clicker UR3-SR3 Universal Remote Control, Inc. www.universalremote.com...
-
Page 3: Replacing Batteries
Introduction This remote control is designed to operate most Digital and Analog Cable Boxes, as well as TVs, and a VCR or DVD player. Replacing Batteries Before you program or operate the remote control, you must install two new AAA alkaline batteries. STEP1 Remove the battery compartment cover from the back of your remote control. -
Page 4: Button Functions
Button Functions Programming the Remote Control. *Note : In this section, when you are instructed to press a [DEVICE] button, that means you should press either the CBL, TV, or DVD button, depending on which device you are programming the remote to operate. A. - Page 5 STEP1 Turn on the equipment that you want the remote control to operate Cable Box, TV and DVD(VCR). STEP2 Press the [DEVICE] button and the [OK/SEL] button simultaneously for three seconds. The corresponding device LED will turn on indicating that it is ready to be programmed. The LED will remain on for 20 seconds.
- Page 6 STEP2 Press the [DEVICE] button and the [OK/SEL] button simultaneously for three seconds. The device LED will turn on indicating that it is ready to be programmed. The LED will remain on for 20 seconds. The next step must be entered while the LED is on.
- Page 7 simultaneously for 3 seconds. The DVD LED will turn on for 20 seconds. The next step must be performed while the LED is on. STEP2 Press the [TV] button. STEP3 Point the remote control toward the TV and enter the three-digit code for your TV from the TV codes table.
- Page 8 To access the programmed channels, press the [MACRO] button once. This will bring up the first channel. Press once again and it will bring up the second channel. Press again and it will bring up the third channel. To erase the Macro programming and return to the original function: STEP1 Press the [CBL] button to select the CABLE mode.
- Page 9 Assigning the Channel keys to a Assigning the Channel keys to a ent Device ent Device By default, the CH+, CH-, NUMERIC and LAST keys operate through your Cable Box. If you would like those keys to operate those functions on a different device, follow these steps.
- Page 10 Set-up Code Tables CABLE TV CONVERTER CODE No MAKER(BRAND) NAME SCIENTIFIC ATLANTA EXPLORER Series 8600X 8600 8540,8570,8590 8500 IPN Series MOTOROLA DCT Series (DVR Model) VIP Series GENERAL INSTRUMENT DCT Series,DCH Series, CFT2200 JERROLD BMC9012/BMC9022 DSR470 CFT2000 DL4,DP(V),DQN(V),DPBB Some Model ADB Series 054 055 ADB5810WX...
- Page 11 MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST ADMIRAL 072 081 160 161 096 ADVENT AIWA 141 145 AKAI 070 146 004 148 124 226 104 108 AKIO ALARON AMARK 112 127 AMERICA ACTION 043 AMPRO 073 167 ANAM 043 054 056 080 112 131 058 070 004 112 APEX DIGITAL 015 150 037...
- Page 12 MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST DYNASTY DYNATECH FISHER 007 057 ELECTROBAND ELECTROHOME 024 076 127 ELEMENT 004 110 EMERSON 005 028 043 048 076 096 155 004 051 151 153 154 127 121 ENVISION EPSON FUJITSU 164 197 028 157 149 066 217 FUNAI 028 043 052 168 FUTURETECH...
- Page 13 MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST KENWOOD 070 001 KLEGG KLOSS 002 059 KREISEN 070 043 154 127 004 106 112 127 086 LODGENET LOEWE 196 164 LOGIK LUXMAN 007 015 052 081 160 164 MAGNAVOX 070 003 004 022 059 060 061 063 064 127 164 094 160 056 028 035 211 205 218 050 138 MAJESTIC MARANTZ...
- Page 14 MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST OPTONICA 019 081 ORION 096 201 203 204 205 028 PANASONIC 034 056 080 164 190 230 248 PHILCO 070 003 004 024 056 059 060 063 064 127 164 PHILIPS 164 005 038 093 127 070 003 004 059 199 218 161 PIONEER 023 025 135 176 004 018 070 183 191 208 214 182 POLAROID...
- Page 15 MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST 004 043 STARLITE SUPRE MACY SUPREME SYLVANIA 070 003 059 060 063 064 127 160 164 044 056 168 SYMPHONIC 052 168 SYNTAX OLEVIA 219 004 161 144 160 TANDY TATUNG 056 062 TECHNICS 034 080 TECHNOL ACE...
- Page 16 MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST ADMIRAL 025 053 AIKO AIWA 034 101 163 AKAI 016 043 046 124 142 146 AMERICA ACTION 117 AMERICAN HIGH AMPRO ANAM ASHA AUDIO DYNAMICS 012 023 039 043 AUDIOVOX BEAUMARK BROKSONIC 035 037 044 046 153 231 025 CALIX CANON 028 031...
- Page 17 MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST HUGHES INSTANTREPLAY JCPENNEY 012 013 040 101 156 066 031 234 JENSEN 048 050 043 130 060 012 031 047 055 158 101 117 KENWOOD 014 034 047 048 023 KODAK 031 101 101 123 012 013 114 LLOYD LOGIK...
- Page 18 MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST PHILIPS 031 067 034 101 054 071 PILOT PIONEER 021 013 048 PORTLAND PROFITRONIC PROTEC QUARTZ 002 014 QUASAR 070 133 161 031 066 160 234 RADIO SHACK 123 034 RADIX RANDEX 107 109 144 147 013 041 034 040 156 031 140 232 233 053 REALISTIC 003 008 010 014 031 034 040 053 054 101...
- Page 19 MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST VIDEO CONCEPTS 012 046 034 141 VIDEOSONIC WARDS 003 013 024 031 034 040 053 054 017 131 WESTING HOUSE 024 025 XR-1000 024 031 034 YAMAHA 012 043 034 039 ZENITH 072 080 001 048 034 101 058 025 *Note : For TV/VCR &...
- Page 20 DVD (VCR) MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST ADCOM AIWA 210 214 AKAI ALPINE APEX DIGITAL 240 197 247 248 196 ARCAM 165 148 AUDIOVOX BOSE 244 245 CAMBRIDGE AUDIO 224 145 CARY AUDIO DESIGN 249 149 CLASSE COBY CYBERHOME 170 212 DAEWOO...
- Page 21 DVD (VCR) MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST MITSUBISHI MYRYAD 198 182 ONKYO 207 236 128 OPTIMUS ORITRON PANASONIC 076 173 184 219 192 PARASOUND PHILIPS 074 164 176 177 191 195 209 PIONEER 175 180 187 221 223 POLAROID 075 084 085 PRIMARE...
- Page 24 OCE-0009D Rev 06...
