Giant BOULDER Datasheet

110
BOULDER
Specifications
SIZES 12.5(2XS),14(XS),16(S),18(M),20(L),22(XL)
COLORS Blue, White
FRAME Supersize Steel
FORK Spinner Grind 1, 80mm travel
SHOCK N/A
HANDLEBAR Steel, 50mm rise
STEM Alloy
SEATPOST Alloy, 30.9mm
SADDLE Giant Sport MTB
PEDALS Nylon Platform
SHIFTERS Shimano EF-50
FRONT DERAILLEUR Shimano C-102
REAR DERAILLEUR Shimano Altus
BRAKES Alloy Direct-Pull Cantilever
BRAKE LEVERS Shimano EF-50
CASSETTE Shimano 14x34, 7-speed
CHAIN KMC Z51
CRANKSET Suntour XCC T-208, 28/38/48
BOTTOM BRACKET SR Cartridge
RIMS Alloy, Brushed Sidewall
HUBS Alloy, 36h
SPOKES Stainless Steel, 14g
MTB Trail 26x2.1 (Blue) Kenda K-Rad
TIRES
26x2.1 (White)
EXTRAS
Specifications and availability subject to change without notice.
THE DIRT PATH AT THE END OF THE STREET IS
JUST WAITING TO BE EXPLORED. WHAT ARE YOU
WAITING FOR?
Frame Technology
Comfortable geometry and a sturdy steel frame make the Boulder an all-around user-friendly bike
that's ready for anything. Streets, bike paths or dirt—Boulder does it all.
features
— Spinner Grind 1, 80mm suspension fork
— Shimano trigger shifting, Shimano Altus rear derailleur
— Alloy direct-pull brakes
— Alloy rim/alloy disc hub wheelset
frame geometry
Actual Part Part Head
Frame Size Numbear Numbear Angle
inches Blue White degrees
XXS 12.5 330061 330161 70.5
XS 14 330062 330162 70.5
S 16 330063 330163 70.5
M 18 330064 330164 70.5
L 20 330065 330165 70.5
XL 22 330066 330166 70.5
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
Seat
Toptube** Headtube Chainstay
Angle*
degrees inches inches inches
75.0 20.5 4.6 16.7
74.0 21.3 4.6 16.7
73.0 22.4 4.6 16.7
73.0 22.9 5.7 16.7
73.0 23.8 6.3 16.7
73.0 24.3 7.5 16.7
Standover
Wheelbase
Height***
inches inches
39.7 24.2
40.2 25.3
41.2 28.1
41.8 29.4
42.3 30.9
43.1 32.9
