IXIA iBypass VHD IBYPVHD-CH-AC User Manual page 70

Using the Web UI
Go to SETTINGS > Utilities > Pop-Up Utils > Ping.
1. In the dialog box, enter the IP address you want to ping.
2. Click the Ping button.
3. Click the Done button when you have finished viewing the results.
Traceroute
The user has the ability to perform a traceroute on an IP address.
With the CLI
iBypass VHD # tools traceroute 10.61.0.35
Using the Web UI
Go to Settings > Tools > Traceroute.
1. In the dialog box, enter the IP address you want to trace.
2. Click the Trace button.
3. Click the Done button when you have finished viewing the results.
iBypass VHD Configuration and Status
The iBypass VHD Web UI presents in the top Navigation Bar, a set of menus you can
select from to access configuration or informational pages.
Chapter 5 Web UI and System Settings
62
iBypass VHD User Guide v1.0
iBypass VHD Configuration and Status
