- Page 1 Huawei OptiXstar HG8245X6-8Ne Quick Start for QR code Issue Date 2022-12-08 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
- Page 3 Huawei OptiXstar HG8245X6-8Ne Quick Start for QR code Contents Contents 1 Placing the Device........................1 2 Connecting Cables........................3 3 Indicator Description......................5 4 Technical Specifications......................7 5 FAQs............................8 Issue 01 (2022-12-08) Copyright © Huawei Technologies Co., Ltd.
- Page 4 The actual product prevails. Mounting an ONT onto the wall Mark two positions with the same spacing as that between the two mounting holes of the ONT using a marker on a wall. Issue 01 (2022-12-08) Copyright © Huawei Technologies Co., Ltd.
- Page 5 ONT onto the screws. NO TE It is recommended that the screw be about 4 mm in diameter and longer than 20 mm. The screw head should be between 6mm and 9mm in diameter. Issue 01 (2022-12-08) Copyright © Huawei Technologies Co., Ltd.
- Page 6 ● The fiber connector connected to the optical port on the wall varies depending on actual conditions. ● To ensure normal use of fibers, make sure that the fiber bending radius is larger than 30 Item Description On/Off Powers the ONT on or off. Issue 01 (2022-12-08) Copyright © Huawei Technologies Co., Ltd.
- Page 7 NOTE Reset Huawei ONTs with caution. Otherwise, the ONTs may fail to access the Internet. If an ONT cannot access the Internet after a reset, contact your Internet service provider.
- Page 8 Data is being transmitted on the USB port. The system is not powered on or the USB port is not connected. WLAN Steady on The WLAN function is enabled. Blinking Data is being transmitted over the WLAN port. Issue 01 (2022-12-08) Copyright © Huawei Technologies Co., Ltd.
- Page 9 The ONT is not connected to fibers or does once not receive optical signals. every 2 seconds Blinks once Blinks The hardware is faulty. every 2 once seconds every 2 seconds Issue 01 (2022-12-08) Copyright © Huawei Technologies Co., Ltd.
- Page 10 ● Dimensions (H x W x D): 40 mm x 230 mm x 160 mm (without external antenna and pads) ● Weight: About 680g ● Maximum system power consumption: 24 W Issue 01 (2022-12-08) Copyright © Huawei Technologies Co., Ltd.
- Page 11 ● Wireless login Connect your mobile phone, pad, or PC to the Wi-Fi network of the Huawei ONT. Enter the IP address in the address box of a browser and press Enter. On the displayed login page, enter the username and password.
- Page 12 ● Wired login Use a network cable to connect a PC to the Huawei ONT. Set the IP address of the PC in the same subnet as the web address of the For example, if the web address of the Huawei ONT is Huawei ONT.
- Page 13 How do I change the Wi-Fi password? Log in to the Huawei ONT web page using your mobile phone, pad, or PC. For details, see "How do I log in to the Huawei ONT web page?" Choose the Advanced Configuration > WLAN tab and choose 2.4G Basic Network Settings.
- Page 14 ONT positions or add new repeaters to enhance the Wi-Fi coverage. 3. Using the correct radio channel. Generally, the Huawei ONT automatically selects the optimal channel. If the network is slow or the quality turns poor from time to time, you can use a Wi-Fi scanner such as Wi-Fi Stumbler or Wi-Fi Analyzer to search for the optimal channel.
- Page 15 How do I restore the Huawei ONT to factory setting? Press Reset by using a needle-type object for longer than 10s to restore factory defaults and reset the Huawei ONT. If the indicator is off and then is lit, the system restarts successfully.
