Sencor SFH 7020WH Original Manual page 7

Hot Air Fan Heater
EN
User's manual
• Thank you for purchasing a SENCOR brand product and we hope that
you will be happy with it.
• Prior to using this appliance, please read the user's manual
thoroughly, even in cases, when one has already familiarised
themselves with previous use of similar types of appliances. Only use
the appliance in the manner described in this user's manual. Keep
this user's manual in a safe place where it can be easily retrieved for
future use.
• We recommend saving the original cardboard box, packaging
material, purchase receipt and responsibility statement of the vendor
or warranty card for at least the duration of the legal liability for
unsatisfactory performance or quality. In the event of transportation,
we recommend that you pack the appliance in the original box from
the manufacturer.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DESCRIPTION OF THE APPLIANCE
A1
Power indicator light
A2 Temperature control knob
A3 Turn switch for starting just
the fan, for setting the power
level I or II and for turning off
the appliance.
A4 Air outlet grill
A5 Fan and heating elements
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OPERATING THE APPLIANCE
• Before first use, remove all packaging materials including promotional
stickers and labels from the appliance.
• Locate the appliance in a suitable location in accordance with the
safety instructions. Make sure that the inflow or outflow vents A7
or A4 are not blocked, that the temperature control knob A2 is set
to minimum and the switch A3 is in position 0 (off). Connect the
appliance to a power socket. After connecting the appliance to a power
socket, indicator light A1 will be lit.
1. SETTING AN OPERATING MODE
• Set the temperature control knob A2 to maximum and select the
desired operating mode using switch A3.
Setting switch A3 Description of operating mode
0 Off
Air ventilation without heating.
Only the fan is running. Heating elements are
turned off.
Power is set to a low level (1 200 W).
The fan and one of the two heating elements
I are running.
The heating element heats the air and the fan
ensures its flow into the room.
Power is set to a high level (2 000 W). The fan
and both the heating elements are running.
II
The heating elements heat the air and the fan
ensures its flow into the room.
Note:
Upon first use or after it has not been used for an
extended period of time, a slight odour may be
sensed from the appliance. This is completely normal
and will quickly disappear.
2025,
These parts are hidden
underneath the grill.
A6 Integrated carry handle (not
shown) it is located at the rear
of the appliance.
A7 Air inlet grill (not shown) it
is located at the rear of the
appliance.
.
2. TEMPERATURE CONTROL KNOB SETTING
• The appliance is equipped with a thermostat that serves to maintain
the desired temperature in the room.
• To heat up the air in the room as fast as possible, set switch A3 to the
high power level and the temperature control knob A2 to maximum.
When the desired temperature has been reached, slowly turn the
temperature control knob A2 anticlockwise until you hear a click.
The set thermostat will automatically switch the heater and heating
elements A5 on and off to maintain the desired temperature.
3. TURNING OFF
• When you have finished using it, set the temperature control knob
A2 to minimum, set switch A3 to position 0 (off ) and disconnect the
power cord from the power socket.
After disconnecting the appliance from the power socket, indicator
light A1 will turn off. Allow the appliance to cool down.
AUTOMATIC SHUT-OFF FUNCTION
• The appliance is equipped with a safety mechanism that
automatically turns it off when it is accidentally knocked over. After
returning the appliance back to the operating position, it will start
running again.
THERMAL PROTECTION
• The appliance is equipped with a thermal fuse that turns it off upon
overheating. Should such a situation occur, turn the appliance off and
disconnect it from the power socket. Make sure that the air inlet and
outlet openings A7 or A4 are not blocked. Allow the appliance to cool
down before attempting to put it back into operation as this will give
the thermal fuse time to reset.
• If you are unable to put the appliance back into operation, contact an
authorised service centre.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CLEANING AND MAINTENANCE
• Before cleaning it, make sure that the appliance is turned off and
disconnected from the power socket. If the surface of the appliance is
hot, allow it to cool down.
• Use a dry or lightly dampened wiping cloth to clean the surface of the
appliance. Then thoroughly wipe everything dry. Dust that has settled
inside the appliance can be vacuumed out using a vacuum cleaner
through the air inlet and outlet grills A7 and A4.
• For cleaning, do not use cleaning products with an abrasive effect,
solvents, etc. Otherwise, outer surface of the appliance may be
damaged. Do not submerge the appliance or its power cord in water
or any other liquids.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TECHNICAL SPECIFICATIONS
Rated voltage range .............................................................................220−240 V~
Rated frequency ...................................................................................................50 Hz
Rated power .................................................................................................... 2 000 W
Power input settings ..................................................................1 200 W / 2 000 W
Electrical shock protection class ............................................................................... II
Noise level ....................................................................................................... 55 dB(A)
The declared noise emission level is 55 dB(A), which represents a level A
of sound power with respect to a reference sound power of 1 pW.
We reserve the right to change text and technical specifications.
- 4 -
01/2025
