Related Manuals for Hoover H-DRY 300 LITE HLE C10DG-80
Summary of Contents for Hoover H-DRY 300 LITE HLE C10DG-80
- Page 2 Thank you for choosing this product. WEEE contains both polluting substances (which We are proud to offer the ideal product for can cause negative consequences for the you and the best complete range of home environment) and basic components (which can appliances for your daily routine.
- Page 3 1. GENERAL SAFETY in a safe way and understand the hazards involved. RULES Children shall not play with the This appliance is intended to appliance. Cleaning and user be used in household and maintenance shall not be made similar applications such as: by children without supervision.
- Page 4 Do not continue to use this The final part of a tumble dryer machine if it appears to be faulty. cycle occurs without heat (cool down cycle) to ensure that the items are left at a temperature The tumble dryer is not to be ...
- Page 5 In cases where the dryer is Once the machine is in place installed on top of a washing the feet should be adjusted to machine, a suitable stacking kit ensure that the machine is must be used according to the level.
- Page 6 Do not use adapters, multiple Prevent items from falling or connectors and/or extensions. collecting behind the dryer as these may obstruct the air inlet The plug should be accessible and outlet. disconnection after appliance has been installed. Exhaust must ...
- Page 7 Fabric softeners, or similar Items that have been soiled products, should be used as with substances such as cooking specified by the fabric softener oil, acetone, alcohol, petrol, instructions. kerosene, spot removers, turpentine, waxes and wax Do not dry unwashed items in ...
- Page 8 2. WATER CONTAINERS ONLY FOR MODELS WITH DRAIN HOSE KIT The water removed from the laundry during If you have the option of drainage the drying cycle is collected in a container. near to the dryer you can use the When the container is full, an indicator light, discharge kit to provide a permanent or on some models a message on the...
- Page 9 3. DOOR, FILTER AND If the laundry is not drying check that the filter is not clogged. CONDENSER If you clean filter under water, remember Door to dry it. Pull on handle to open the door. To restart the appliance, close the door WARNING ...
- Page 10 To clean the condenser 1. Remove the kickplate. 2. Turn the locking levers clockwise and pull out the condenser. 3. Pull out the condenser unit. 4. Gently remove any dust or fluff with a cloth, then wash the unit by holding it under a running tap turning it so that water flows between the plates, to remove any dust or fluff.
- Page 11 4. PRACTICAL HINTS ALWAYS Check that the filter is clean before every Before using the tumble dryer for the first drying cycle. time: Please read this instruction book NEVER thoroughly. Put dripping wet items into the tumble dryer, this may damage the appliance.
- Page 12 Cleaning the dryer WARNING The drum, door and load may be very Clean the filter and empty the water hot. container after every drying cycle. Regularly clean the condenser. After each period of use, wipe the inside WARNING of the drum and leave the door open for a Always switch off and remove the plug...
- Page 13 5. QUICK USER GUIDE 6. CONTROLS AND PROGRAMMES 1. Open the door and load the drum with laundry. Ensure that garments do not hinder closure of the door. 2. Gently close the door pushing it slowly until you hear the door 'click' shut. 3.
- Page 14 Once the programme has started you will WARNING be kept informed constantly of the time remaining to the end of the drying cycle. Don’t touch the buttons while inserting plug because machines The appliance calculates the time to the calibrates the systems during the first ...
- Page 15 DELAY START button DRYING SELECTION button This button allows to set the desired This button allows to delay the start of the dryness level editable option up to 3 programme from 30 minutes (1 hour on minutes after the starting of the cycle: some models) to 24 hours in 30 minutes intervals (1 hour on some models).
- Page 16 3) FILTER CLEANING INDICATOR LIGHT KEY LOCK It lights up when the cleaning of the filter is requested. Pressing simultaneously the buttons "E" and "F" for about 2 seconds, the machine allows you to lock the keys. In 4) ANTI CREASE INDICATOR LIGHT this way, you can avoid making accidental or The indicator light shows the selection of unwanted changes if a button on the...
- Page 17 Open the App, create the user profile and register appliance following instructions on the phone display or the The Hoover Wizard App is available "Quick Guide" attached on the machine. for devices running both Android and iOS, both tablets smartphones.
- Page 18 NOTES: Thick cases or metallic stickers on your smartphone could affect or Place your smartphone so that the prevent the transmission of data NFC antenna on its back matches between machine and telephone. If the position of the One Touch logo necessary, remove them.
- Page 19 Drying Guide Information for Test Laboratory EN 61121 - Programme To Use The standard cycle COTTON DRY ( is the most energy efficient and best suited - STANDARD DRY COTTON for drying normal wet cotton laundry. - IRON DRY COTTON table last page...
- Page 20 Table of programmes Selectable Options PROGRAMMES SMALL Max 220’ Full ECO COTTON Full WHITES MIX&DRY DARKS & COLOURED SHIRTS SYNTHETICS JEANS SPORT PLUS WOOLMARK 70’ ANTIALLERGY Max 220’ PRE IRON ANTI ODOURS Customizable setting that interacts with the App on your smartphone and to download the cycles (see the dedicated section).
- Page 21 JEANS Description of programmes Dedicated to dry uniformly fabrics like jeans or denim. It’s recommended flip over the To dry different types of fabrics and colors, the garments before drying. tumble dryer has specific programs to meet every need of drying (see table of programmes). SPORT PLUS Dedicated to technical garments for sport One Touch...
- Page 22 PRE IRON ANTI ODOURS This is a warm cycle that in only 12 minutes The perfect cycle to remove the smells from helps to relax folds and creases. the linens smoothing creases.
- Page 23 7. TROUBLESHOOTING Is the dryer switched on, both at the mains supply and at the machine? AND WARRANTY Has the drying time or the programme What might be the cause of... been selected? Defects you can remedy yourself Has the machine been switched on again ...
- Page 24 Service By placing the mark on this product, we are confirming compliance To ensure the continued safe and efficient to all relevant European safety, health operation of this appliance we recommend and environmental requirements which that any servicing or repairs are only carried are applicable in legislation for this out by an Authorised Service engineer.
- Page 25 fk hldsk...
- Page 26 fk hldsk...
- Page 27 fk hldsk...
- Page 28 Capacity Energy Time Capacity (kg) Class Energy 4,43 5,04 5,64 6,22 6,84 Whites Time Min. Energy 4,17 4,75 5,31 5,85 6,44 Whites Time Min. Energy 3,69 4,20 4,70 5,18 5,70 Cotton Time Min. Energy 2,05 2,31 2,56 2,80 3,01 Cotton ½ Time Min.
