WELCOME
What's included
Signature Mini USB 2.0 Portable Drive
USB/AUX Power Cable
If any item is missing or damged, contact your local reseller or retailer for replacement.
Register now
Get free product support and updates. Register now at www.simpletech.com/registration
Visual Tour
CONNECTING
Secondary power
USB connector
Connecting Secondary Power
Signature Mini Portable USB 2.0 Drives are powered through your computer's USB port. If your drive is not
listed in My Computer (Windows) or on the desktop (Mac) it is most likely a power related problem. Connect
the provided cable to 2 USB ports directly on the computer and then connect the drive. This ensures proper
power is provided to the drive and should allow it to operate correctly.
signature mini
R E A D
Activity Light - Blue means drive
is reading and writing; Red
means drive is on.
Mini USB Socket - Connects
Mini Drive to your computer.
DC-IN Jack - (optional) Connects
AC power adapter (not
provided) to drive.
Connect the mini USB plug into a USB port on your computer.
Do not use the "power only" (
computer. This plug is only used when additional (secondary) power is
required to power the drive. See "connecting secondary" power below.
After connecting the drive, it is ready to use. MAC users please see
Formatting section.
Avoid using the USB port on Macintosh computer keyboards. This port
may not have enough power to adequately support the USB 2.0 interface.
M E
F I R S T
Quick Start Guide (this booklet)
Warranty Registration (online)
) USB plug to connect to your
Mini-B USB plug
Type A USB plug - Connects to
computer's USB port . Provides
signal and USB power.
Type A USB plug - (power only)
Connects to computer's USB
port. Provides secondary USB
power source.
