Samsung HP-P5071 Manual

Remote Control Buttons

Remote Control
ΠPOWER button
Turns the PDP on and off.
´ ASPECT button
Press to change the screen size.
ˇ Number buttons
¨ +100 button
Press to select channels over 100. For example, to select
channel 121, press "+100", then press "2" and "1."
ˆ MUTE button
Press to mute the PDP sound.
Ø VOL (Volume) buttons
Use it to adjust volume.
∏ SLEEP button
Press to select a preset time interval for automatic shutoff.
" MENU button
Displays the main on-screen menu.
' ENTER button
Confirms a selection.
˝ PIP button
Activates picture in picture.
Ô STILL button
Press to pause the current screen.
 LCD Display
When you press a button, '
selected mode (TV, VCR, CATV, DVD or STB) and
the remote's battery charge status.
Ò P.MODE button
Adjust the PDP picture by selecting one of the preset
factory settings (or select your personal, customized
picture settings.)
Ú MODE button
Selects a target device to be controlled by the Samsung
remote control (i.e., VCR, Cable, DVD players or Samsung
STB). If you change modes, the new mode is momentarily
displayed on LCD.
Æ PRE-CH button
Tunes to the previous channel.
ı SOURCE button
Press to display all of the available video sources
(TV, AV1, AV2, AV3, S-VIDEO1, S-VIDEO2, COMPONENT1,
COMPONENT2, PC, DVI).
˜ CH (Channel) buttons
Use it to switch channels.
¯ INFO button
Press to display information on the PDP screen.
˘ EXIT button
Press to exit the menu.
¿ Up/Down Left/Right buttons
Control the cursor in the menu.
' appears along with
