- Page 1 Technical Manual Counting Scale...
- Page 2 AHC/QHC series technical manual - 2 -...
-
Page 3: Table Of Contents
AHC/QHC series technical manual Contents 1. Precautions………………………………………………………………………3 2. Installation………………………………………………………………………..4 3. Name and functions…………………………………………………………….6 Key board………………………………………………………………………...6 Display……………………………………………………………………………8 4. Operation………………………………………………………………………...9 Power ON/OFF ……………………………………………………………….9 Zero……………………………………………………………………………….9 Tare……………………………………………………………………………….9 5. Parts Counting . ………………………………………………………………..10 Setting unit weight………………………………………………………………10 Entering a known unit weight…………………………………………………..10 Parts counting……………………………………………………………………10 Automatic part weight updates………………………………………………...10 Setting high / low limits ……………………………………………………………11 Checking Alarm………………………………………………………………..11 Accumulation…………………………………………………………………...11... -
Page 4: Precautions
AHC/QHC series technical manual 1. Precautions Read this manual before operating or servicing this equipment. Follow these instructions carefully. Disconnect this equipment from the power source before cleaning of performing maintenance. Keep the manual for your future reference. ... -
Page 5: Installation
AHC/QHC series technical manual 2. Installation Unpacking Carefully take the balance out of its package, make it sure its not damaged and all accessories are included. Accessories, 1. Balance 2. Adaptor 3. Stainless steel pan 4. Product manual Keep the packaging material for your future use. Level Adjusting Place the scale on a table. - Page 6 AHC/QHC series technical manual the LED is green, the battery has a full charge. If it is red, the battery is nearly discharged and if yellow, the battery is being charged. Do not use any other type of power adaptor than the one supplied with the scale.
-
Page 7: Names And Functions
AHC/QHC series technical manual 3. NAMES AND FUNCTIONS Overall View Key Board - 7 -... - Page 8 AHC/QHC series technical manual Keys Press this key to Enter individual unit weights and the present tare Clear incorrect entries and error conditions Returns the display to zero. Enter the clear tare weights, Storing the current weight as tare value. Subtracting the tare value from the total weight and displays the result as net weight.
-
Page 9: Display
AHC/QHC series technical manual Display Overlay : Battery indicator. When it‟s illuminated, battery should be recharge. BATT : Net weight indicator. When the scale has been tared and the display is in NET mode Stable : Stable indicator. When it‟s illuminated, the scale is stable. : Zero indicator. -
Page 10: Operation
AHC/QHC series technical manual 4. OPERATION Initial Start-Up Warm-up time of 15 minutes stabilizes the measured values after switching on. 1. Power ON/OFF Power switch is located below the right side of the scale. Switch on the scale by pressing on/off. The display is switched on and the self test is started. If you want to switch off press again the key. -
Page 11: Parts Counting
AHC/QHC series technical manual 5. PARTS COUNTING 1. Setting Unit Weight For this function you need to know the average weight of objects to count. This value can be obtained by weighing a known number of pieces so that the balance calculation, the average unit weight or manually entered through the keyword. -
Page 12: Setting High / Low Limits
AHC/QHC series technical manual 5. Setting High / Low limits. Pressing Pst the user can select count or weigh and set limits. For example: Press Pst will display "Hi Cnt" pass counting by weighing Press Tare “Hi cnt” “1.999” appears at the upper limit current count, press the CE to cancel and change if necessary. -
Page 13: Parameter
AHC/QHC series technical manual 6. PARAMETER PARAMETER BLOCK STEP DESCRIPTION DEFAULT FI CAL Calibration F2 dI Set Division d 3000 F3 Cnt A/D Count F4 AU Auto Accumulation AU oFF F5 AZn Auto Zero Range F6 Pin Set New Pin No 0000 SPd 7.5 F7 SPd... - Page 14 AHC/QHC series technical manual Display will show „Pin‟ briefly if PIN is activated. Press the PIN number to get into the parameter menu. The default PIN number is “0000”. Press the “0” key four times. The display will show “Pin - - - - “, then press the Tare key.
- Page 15 AHC/QHC series technical manual F2 SET DIVISION Set the scale increment F2 di d 3000 d 6000 d 15000 d 30000 Press to select. F3 A/D COUNT Showing internal counts F3 Cnt XXXXX Return to menu. F4 AU ACCUMULATION Set the Accumulation F4 AU AU oFF Manual Accumulation manually...
- Page 16 AHC/QHC series technical manual P Cont Data Send to RS232 continues Press to select. F5 AZn AUTO ZERO RANGE Set the Auto Zero Range. F5 AZn 0.5d Press to select. F6 Pin PASSWORD Set the new password (pin number). F6 Pin Pin 1 ---- Enter the new four digit pin number...
- Page 17 AHC/QHC series technical manual P6 Pin Press F7 SPd SENSING SPEED Set the weighing speed F7 SPd SPd 7.5 SPd 15 SPd 30 SPd 60 Press to select. F8 oFF AUTO POWER Set the Automatic power off F8 oFF oF 0 No Off When display is stable and not in use, oF 3...
- Page 18 AHC/QHC series technical manual F9 Grv GRAVITY Set the local gravity. F9 Grv 9.79400 Enter the local gravity by using numeric keys. Press to select. F10 bEP BEEP Set the beep sound F10 bEP When the value is in the limit When the value is lover than the low limit When the value is in the out of...
-
Page 19: Rs232 Protocol
AHC/QHC series technical manual 7. RS232 PROTOCOL The AHC/QHC Series of scales can be ordered with an option RS-232 output. Specifications: RS-232 output of weighing data ASCII code 4800 Baud 8 data bits No Parity Connector: 9 pin socket Pin 2 Output Pin 3 Input Pin 5 Signal Ground Commands:... - Page 20 AHC/QHC series technical manual The 6. package shows the accumulated values in the memory and the loaded scale The 7. package shows the accumulated values in the memory and the empty scale. Now the software sends the command MC to clear the memory. The 8.
- Page 21 AHC/QHC series technical manual <CR><LF> <CR><LF> 5.[RX] ST,GS, 3.4760,kg<CR><LF> TARE 0.0000,kg<CR><LF> U.W. 86.9018 g<CR><LF> PCS 40pcs<CR><LF> T.NO. 1<CR><LF> T.WGT. 1.7380,kg <CR><LF> T.PCS. 20pcs <CR><LF> [TX] M+<CR><LF> 6.[RX] ST,GS, 3.4760,kg<CR><LF> TARE 0.0000,kg<CR><LF> U.W. 86.9018 g<CR><LF> PCS 40pcs<CR><LF> T.NO. 2<CR><LF> T.WGT. 5.2140,kg <CR><LF> T.PCS.
-
Page 22: Error Codes
AHC/QHC series technical manual 8. ERROR CODES Error Display Description Possible Causes Err 4 Zero setting error Out of the auto zero setting range. (4% of capacity) check the platform empty and re try again. Do the calibration Err 5 Key board error Improper operation. -
Page 23: Drawing
AHC/QHC series technical manual 9. DRAWING - 23 -... -
Page 24: Parts List
AHC/QHC series technical manual PARTS LIST Parts Name Material Spec 230mmX300mm 230mmX300mm Battery Cover Rear Overlay Name Plate Battery Lead Acid 6V/4AH Foam Load cell upper bracket Aluminum Load Cell Hexagon Screw 20Mn M4x16 Load cell lower bracket Aluminum Hexagon Nut DB9 Connector Optional Hexagon nut for D connector... -
Page 25: Dimension
AHC/QHC series technical manual 10. DIMENSION 11. SPECIFICATIONS MODEL AHC/QHC AHC/QHC AHC/QHC AHC/QHC 3000g 6000g 15kg 30kg Capacity 15kg 30kg Readability 0.05g 0.1g 0.2g Tare Range -3kg -6kg -10kg -30kg Minimum Repeatability 0.05g 0.1g 0.2g 0.5g Resolution Up to 60000 Weighing Units Housing ABC Plastic and Stainless Steel platform... -
Page 26: Load Cell Specifications
AHC/QHC series technical manual Load cell specifications Model No NA22 C2X1 Rated Capacity 6~40 (kg) 6~50 (kg) Rated Out put 2.0mV/V± 0.2 mV/V 2.0 mV/V±0.2 mV/V Excitation 15 VDC 20 VDC Voltage IP Level IP65 IP64 Material Aluminium Alloy Aluminium Alloy Φ... - Page 27 Hand push and pull gauge. Customize auto weighing systems. TSCALE and their distributors offer a full range of technical services such as on site and workshop repair, preventative maintenance and calibration facilities. TSCALE operates an approved quality management system and is certified to ISO9001:2000.
