  • Page 1 MEG Series Motherboard MEG X870E GODLIKE User Guide...

  • Page 2: Table Of Contents

    Contents Quick Start ........................4 Specifications ........................17 Special Features ......................23 Package Contents ......................24 Back Panel Connectors ....................25 5Gbps LAN Port LED Status Table ................26 10Gbps LAN Port LED Status Table ................ 26 Audio Jacks Connection ..................27 Installing Antenna ....................29 Overview of Components ....................30 CPU Socket ......................
  • Page 3 JPWRLED1: LED power input ................. 73 LED_SW1: EZ LED Control ..................73 DYNAMIC DASHBOARD III ..................74 Installing OS, Drivers & MSI Center ................81 Installing Drivers with MSI Driver Utility Installer ..........82 UEFI BIOS ........................85 BIOS Setup ......................86 Entering BIOS Setup ....................87 Resetting BIOS ......................

  • Page 4: Quick Start

    Quick Start This Quick Start provides clear diagrams to help you install the motherboard. Video demonstrations are also available for some installations. Visit these videos by clicking the provided URL on your phone or tablet’ s web browser. Alternatively, you can scan the QR code to access the video directly.

  • Page 5: Safety Information

    Safety Information The components included in this package are prone to damage from electrostatic ● discharge (ESD). Please adhere to the following instructions to ensure successful computer assembly. Ensure that all components are securely connected. Loose connections may cause ● the computer to not recognize a component or fail to start.
  • Page 6 Case stand-off notification To prevent damage to the motherboard, any unnecessary mounting stand-off between the motherboard circuits and the computer case is prohibited. The Case standoff keep out zone signs will be marked on the backside of motherboard (as shown below) to serve as a warning to user.

  • Page 7: Installing A Processor

    Installing a Processor ⚽ https://msi.gm/SDBE5855 ●...
  • Page 8 ⚠ Important If you are installing the screw-type CPU heatsink, please follow the figure below to remove the retention module first and then install the heatsink.
  • Page 9 Installing DDR5 memory ⚽ https://msi.gm/S647FF99 ● DIMMA1 DIMMA2 DIMMA2 DIMMA2 DIMMB1 DIMMB2 DIMMB2...

  • Page 10: Connecting The Front Panel Header

    Connecting the Front Panel Header ⚽ https://msi.gm/S8EF7577 ● Power LED Power Switch JFP1 Reserved HDD LED Reset Switch JFP1 HDD LED - HDD LED HDD LED + POWER LED - POWER LED POWER LED +...

  • Page 11: Installing The Motherboard

    Installing the Motherboard ⚽ https://msi.gm/S4BA9046 ● ⚠ Notice EZ BRIDGE is magnetically attached. Please do not lift the motherboard by holding only EZ BRIDGE. Torque: 3 kgf·cm* *3 kgf·cm = 0.3 N·m = 2.6 lbf·in...

  • Page 12: Connecting The Power Connectors

    Connecting the Power Connectors ⚽ https://msi.gm/SD937E2C ● ATX_PWR1 PD_PWR1 & PCIE_PWR1 CPU_PWR1~2...

  • Page 13: Installing Sata Drives

    Installing SATA Drives ⚽ https://msi.gm/S9369131 ●...

  • Page 14: Installing A Graphics Card

    Installing a Graphics Card ⚽ https://msi.gm/S6B36811 ●...

  • Page 15: Connecting Peripheral Devices

    Connecting Peripheral Devices...
  • Page 16 Power On...

  • Page 17: Specifications

    Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop ● Processors* Processor socket AM5 ● * Please go to www.msi.com to get the newest support status as new processors are released. Chipset AMD X870E Chipset 4x DDR5 memory slots*, supporting up to 256GB** ●...
  • Page 18 Continued from previous column 5x M.2 slots (Key M) ● M2_1 slot (From CPU) ● Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 ● Series processors) Supports up to PCIe 4.0 x4(For Ryzen™ 8000 Series ● processors)s Supports 2260/ 2280 storage devices ●...
  • Page 19 Continued from previous column 1x Realtek® 8126 5Gbps LAN controller ● 1x Marvell® AQC113CS 10Gbps LAN controller ● Wi-Fi 7 The Wireless module is pre-installed in the M.2 (Key-E)slot ● Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (320MHz) ● up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Wi-Fi &...
  • Page 20 Continued from previous column 2x System panel connectors ● 2x 2-pin Thermal sensor connectors ● 1x Tuning controller connector ● 1x EZ Conn-Header V2 (JAF_2) ● 1x USB 2.0 Type-A connector (From Hub GL850G) EZ BRIDGE ● Supports additional 2 USB 2.0 ports ●...
  • Page 21 Continued from previous column 2x USB 10Gbps Type-A ports (From X870E chipset) ● 4x USB 10Gbps Type-A ports (From RTS5420 chipset) ● 2x USB 40Gbps Type-C ports */ ** (From ASM4242) ● Supports DisplayPort over USB Type-C® ● 3x USB 10Gbps Type-C ports (From CPU) ●...
  • Page 22 Continued from previous column Drivers ● MSI Center ● Acrobat ● Adobe Creative Cloud ● Software AIDA64 Extreme - MSI Edition ● CPU-Z MSI GAMING ● MSI App Player(BlueStacks) ● Norton 360 ● Voicemod ●...

  • Page 23: Special Features

    Special Features MSI Center M.2 Shield Frozr (Double-sided ● design) MSI AI Engine ● MOSFET thermal pad Game Highlights ● ● Extra choke pad Cooling Wizard ● ● Fan headers (CPU+ PUMP+ SYSTEM) Mystic Light ● ● Ambient Link Performance ●...

  • Page 24: Package Contents

    There is an ISO file in the supplied USB drive. Please do not delete it accidentally. For ● more information on installing drivers, please refer to Installing OS, Drivers & MSI Center chapter. If any of the above items are damaged or missing, please contact your retailer.

  • Page 25: Back Panel Connectors

    Back Panel Connectors Item Description USB 10Gbps Type-A port (From X870E chipset) Flash BIOS port ● USB 10Gbps Type-A port (From X870E chipset) USB 10Gbps Type-A ports (From RTS5420) Flash BIOS button - Please refer to page Flash BIOS button - Please refer to page 89 for details about updating BIOS for details about updating BIOS with Flash BIOS button.

  • Page 26: 5Gbps Lan Port Led Status Table

    Item Description USB 40Gbps Type-C ports (From ASM4242) Supports DisplayPort over USB Type-C® ● * USB 40Gbps Type-C ports on the back panel and M2_2 slot share PCIe 5.0 x4 bandwidth. Both run at PCIe 5.0 x2 when a device is installed in the M2_2 slot. You can switch M2_2 to PCIe 5.0 x4 in the BIOS, but this will disable the USB 40Gbps Type-C ports.

  • Page 27: Audio Jacks Connection

    Audio Jacks Connection Audio jacks to headphone and microphone diagram Audio jacks to stereo speakers diagram AUDIO INPUT...
  • Page 28 Audio jacks to 4-channel speakers diagram AUDIO INPUT Rear Front Front Panel Audio jacks to 5.1-channel speakers diagram AUDIO INPUT Rear Front Center/ Subwoofer Front Panel Audio jacks to 7.1-channel speakers diagram AUDIO INPUT Rear Front Side Center/ Subwoofer Front Panel...

  • Page 29: Installing Antenna

    Installing Antenna 1. Combine the antenna with the base. 2. Plug two antenna cables tight to the WiFi antenna connectors as shown. 3. Place the antenna as high as possible for a better signal.

  • Page 30: Overview Of Components

    Overview of Components JARGB_V2_1 CPU_FAN1 PUMP_SYS1 ATX_PWR1 PD_PWR1 JUSBC2 JUSBC1 PUMP_SYS2 M2_1 PCI_E1 JUSB3 M2_2 JUSB2 M2_3 JBAT1 PCIE_PWR1 M2_4 SATA▼_P3▲_P4 PCI_E2 JPWRLED1 JUSB1 PCI_E3 JAUD1...
  • Page 31 EZ BRIDGE JUSB_BRG_1 JAF_2 JDASH1 T_SEN1 T_SEN2 JBRG_HUB1 JFP2 POWER1 RESET1 JFP1 EZ PCIe Release Button ⚠ Important EZ BRIDGE does not support hot-swapping. Do not unplug the connection while it is powered on.
  • Page 32 EZ CONTROL HUB SYS_FAN1 JSATA_PWR1 JBRG_HUB1...

  • Page 33: Cpu Socket

    CPU Socket The AM5 socket is a modern CPU socket designed for AMD processors. It is a key component in contemporary computing systems, providing the foundation for powerful and efficient CPUs. Installing the CPU to the AM5 socket The surface of the AM5 CPU has two notches and a golden triangle to assist in correctly lining up the CPU for motherboard placement.
  • Page 34 ● disconnect the power cord from the power outlet before installing or removing the CPU. Please retain the CPU protective cap after installing the processor. MSI will deal with ● Return Merchandise Authorization (RMA) requests if only the motherboard comes with the protective cap on the CPU socket.

  • Page 35: Ddr5 Dimm Slots

    DDR5 DIMM Slots The DDR5 DIMM slot is a dedicated connector designed to accommodate DDR5 (Double Data Rate 5) memory modules. It represents the latest standard in computer memory, providing enhanced data transfer speeds and efficiency. DIMMA1 DIMMB1 DIMMA2 DIMMB2 Channel A Channel B Memory module installation recommendation...
  • Page 36 It is recommended to use a more efficient memory cooling system for full DIMMs ● installation or overclocking. The stability and compatibility of installed memory module depend on installed CPU ● and devices when overclocking. Please refer to www.msi.com for more information on compatible memory. ●...

  • Page 37: Pci_E1~3: Pcie Expansion Slots

    PCI_E3: PCIe 4.0 x4 (From Chipset) ⚠ Important If you install a large and heavy graphics card, you need to use a tool such as MSI ● Graphics Card Bolster to support its weight to prevent deformation of the slot.
  • Page 38 Installing a graphics card into PCI_E1 slot 1. Ensure that the EZ PCIe Release Button is in the locked position. If it is unlocked, press the button to lock it. 2. Insert the graphics card into the PCIe slot.
  • Page 39 Removing a graphics card from PCI_E1 slot 1. Ensure that the EZ PCIe Release Button is in the unlocked position. If it is locked, press the button to unlock it. 2. Gently pull the graphics card out of the PCIe slot.

  • Page 40: M2_1~5: M.2 Slots (Key M)

    M.2 Shield Frozr heatsink. M2_1 ⚽ M2_2 M2_3 M2_4 https://msi.gm/S7F5D000 ● M2_5 ⚠ Important If your M.2 SSD equips its own heatsink, please note the following: Remove the M.2 plate or rubber cube in the M.2 slot before installing M.2 SSD. Do not ●...
  • Page 41 Installing M.2 module into M2_1 slot 1. Press and hold the end button of Screwless M.2 Shield Frozr heatsink. 2. Slightly lift up the end part of Screwless M.2 Shield Frozr heatsink and move it forward to uninstall the heatsink. 3.
  • Page 42 4. If you install 2260 SSD, exchange the EZ M.2 Clip II and the plate screw. Please note that you have to use the EZ M.2 Chip II Remover to remove and install the EZ M.2 Clip II. Skip this step if you install 2280 SSD. plate screw EZ M.2 Clip II Remover EZ M.2 Clip II...
  • Page 43 7. Remove the protective films from the thermal pads under Screwless M.2 Shield Frozr heatsink. 8. Align the notches under Screwless M.2 Shield Frozr heatsink with the tenons, and then put the heatsink back in place. 9. Press the end side of Screwless M.2 Shield Frozr heatsink to lock it completely.
  • Page 44 Installing M.2 module into M2_2/ M2_3/ M2_4 slot 1. Press and hold the end button of Screwless M.2 Shield Frozr heatsink. 2. Slightly lift up the end part of Screwless M.2 Shield Frozr heatsink and move it forward to uninstall the heatsink.
  • Page 45 3. Remove the protective film from the M.2 thermal pads on the M.2 plate. 4. If you install 2260/ 22110 SSD, exchange the EZ M.2 Clip II and the plate screw. Please note that you have to use the EZ M.2 Chip II Remover to remove and install the EZ M.2 Clip II.
  • Page 46 5. Insert your M.2 SSD into the M.2 slot at a 30-degree angle. 6. Use the EZ M.2 Clip II to lock and secure the SSD. 30º 30º 7. Remove the protective films from the thermal pads under Screwless M.2 Shield Frozr heatsink.
  • Page 47 Installing M.2 module into M2_5 slot 1. Press and hold the end button of Screwless M.2 Shield Frozr heatsink. 2. Slightly lift up the end part of Screwless M.2 Shield Frozr heatsink and move it forward to uninstall the heatsink.
  • Page 48 3. Remove the protective film from the M.2 thermal pads on the M.2 plate. 4. If you install 2260 SSD, exchange the EZ M.2 Clip II and the plate screw. Please note that you have to use the EZ M.2 Chip II Remover to remove and install the EZ M.2 Clip II.
  • Page 49 7. Remove the protective films from the thermal pads under Screwless M.2 Shield Frozr heatsink. 8. Align the notches under Screwless M.2 Shield Frozr heatsink with the tenons, and then put the heatsink back in place. 9. Press the end side of Screwless M.2 Shield Frozr heatsink to lock it completely. Removing M.2 SSD using the EZ M.2 Clip II To remove M.2 SSD from the EZ M.2 Clip II, gently push the spring head on the top of the EZ M.2 Clip II outward while simultaneously pulling the M.2 SSD out.

  • Page 50: Sata_P3~P4 & Sata_S3~S4: Sata 6Gb/S Connectors

    SATA_P3~P4 & SATA_S3~S4: SATA 6Gb/s Connectors These connectors are SATA 6Gb/s interface ports. Each connector can connect to one SATA device. SATA_P4 SATA_P3 SATA_S4 SATA_S3 ⚠ Important Please do not fold the SATA cable at a 90-degree angle. Data loss may result during ●...

  • Page 51: Jfp1, Jfp2: Front Panel Connectors

    JFP1, JFP2: Front Panel Connectors The JFP1 connector controls the power on, power reset, and the LEDs on your PC case/ chassis. Power Switch/ Reset Switch headers allow you to connect power button/ reset button. Power LED header connects to LED light on the PC case, and HDD LED header indicates the activity of the hard disk.
  • Page 52 CPU_PWR1~2, ATX_PWR1, PCIE_PWR1, PD_PWR1, JSATA_PWR1: Power Connectors These power connectors allow you to connect an ATX power supply. EZ CONTROL HUB CPU_PWR1~2 Signal Name Signal Name Ground Ground Ground Ground CPU_PWR1~2 +12V +12V +12V +12V ATX_PWR1 Signal Name Signal Name +3.3V +3.3V Ground...
  • Page 53 PCIE_PWR1/ PD_PWR1 Signal Name Signal Name +12V +12V PCIE_PWR1/ PD_PWR1 +12V SENS1 Ground SENS0 Ground Ground JSATA_PWR1 JSATA_PWR1 Signal Name Signal Name +12V +12V +12V Ground Ground Ground Ground Ground ⚠ Important Make sure that all the power cables are securely connected to a proper ATX power supply to ensure stable operation of the motherboard.

  • Page 54: Jbrg_Hub1: Ez Link Connector

    EZ BRIDGE & EZ CONTROL HUB Connection JBRG_HUB1 header JBRG_HUB1 header of the EZ BRIDGE of the EZ CONTROL EZ Link cable Watch the video to learn how to connect the EZ BRIDGE and ⚽ EZ CONTROL HUB. https://msi.gm/S4099795 ●...

  • Page 55: Jci1: Chassis Intrusion Connector

    JCI1: Chassis Intrusion Connector This connector allows you to connect the chassis intrusion switch cable. Normal Trigger the chassis (default) intrusion event Using chassis intrusion detector 1. Connect the JCI1 connector to the chassis intrusion switch/ sensor on the chassis. 2.

  • Page 56: Jusbc1~C2: Usb Type-C® Front Panel Connectors

    JUSBC1~C2: USB Type-C® Front Panel Connectors This USB connectors allow you to connect to the USB Type-C® port on the front panel and supports data transfer speeds of up to 20Gbps (for JUSBC2)/ 10Gbps (for JUSBC1). It features a user-friendly design that ensures proper orientation when connecting the cable.

  • Page 57: Jusb1 & Jusb_Brg_1: Usb 2.0 Connector

    Ground Ground No Pin ⚠ Important Note that the VCC and Ground pins must be connected correctly to avoid possible ● damage. In order to recharge your iPad, iPhone and iPod through USB ports, please install MSI ● Center utility.

  • Page 58: Cpu_Fan1, Pump_Sys1~2, Sys_Fan1~7: Fan Connectors

    CPU_FAN1, PUMP_SYS1~2, SYS_FAN1~7: Fan Connectors Fan connectors can be divided into two categories: PWM Mode and DC Mode. PWM Mode fan connectors provide a constant 12V output and adjust fan speed with a speed control signal. DC Mode fan connectors control fan speed by changing voltage. Please refer to the following specification table for the fan connector mode of your motherboard.

  • Page 59: Jbat1: Clear Cmos (Reset Bios) Jumper

    JBAT1: Clear CMOS (Reset BIOS) Jumper There is CMOS memory onboard that is external powered from a battery located on the motherboard to save system configuration data. If you want to clear the system configuration, set the jumpers to clear the CMOS memory. Keep Data Clear CMOS/ (default)

  • Page 60: Jln1: Low Temperature Booting Jumper

    JLN1: Low Temperature Booting Jumper This jumper allows liquid nitrogen cooling system to boot at an extremely low temperature. Please try to enable the jumper to help the system boot successfully. Enabled Normal (Please enable this jumper (Default) during BIOS POST) ⚠...

  • Page 61: Jdash1 : Tuning Controller Connector

    JDASH1 : Tuning Controller connector This connector is used to connect an optional Tuning Controller module. EZ BRIDGE Signal Name Signal Name No Pin MCU_SMB_SCL_M MCU_SMB_SDA_M VCC5 Ground PSIN#_R FP_RST#_R OC_RETRY# OC_FS BLK+ BLK- CLRCMOS_EN POWER1, RESET1: Power Button, Reset Button The Power/ Reset button allows you to power on/ reset the computer.

  • Page 62: V-Check Points Lite

    V-Check Points Lite These voltage checkpoints are used to measure the current system voltages. A multimeter (not included) will be required to check voltages. To measure voltage, place test leads on the GND (screw mounting hole) and a specific V-Check Point. Please refer to the manual of your multimeter for more information.

  • Page 63: M.2 Xpander-Z Slider Gen5 Card

    M.2 XPANDER-Z SLIDER GEN5 card M2_1 LEDs M2_2 LEDs MB_FAN1 M2_2 FAN_SW1 PCIE_PWR1 M2_1 Specifications 2x M.2 slots (Key M) ● Supports up to PCIe 5.0 x 4* ● Supports 2280 M.2 SSD** Interface ● * The operating speed depends on the PCIe slot specification of your motherboard.
  • Page 64 4. Lift the cover and move it forward to uninstall it. 5. Remove the protective film from the thermal pad inside the M.2 enclosure. Watch the video to learn how to install the M.2 XPANDER-Z ⚽ SLIDER GEN5 card. https://msi.gm/SBC78842 ●...
  • Page 65 6. Please ensure the notch position of the M.2 SSD contacts to correctly install the M.2 SSD into the M.2 enclosure. ⚠ Important All contacts of the M.2 SSD must be fully exposed after you install the M.2 SSD. 7. Remove the protective film from the bottom of the top cover. 8.
  • Page 66 9. Align the alignment marks on the M.2 enclosure and M.2 bracket. Install the M.2 enclosure back into the slot until it is locked in place. 10. Push the M.2 side cover back to lock the M.2 enclosure. 11. Install the XPANDER-Z SLIDER GEN5 card into the PCIe slot on the motherboard. 12.

  • Page 67: Bios_Sw1: Multi-Bios Switch

    ⚠ Important Do not use the Multi-BIOS switch when system is booting up. ● You can also use the MSI Center or Flash BIOS Button to flash BIOS. Please refer to ● BIOS section for details. JDASH_SW1: Switch This switch is used to switch between EZ BRIDGE & Tuning Controller module.

  • Page 68: Jrgb1: Rgb Led Connector

    (12V/G/R/B) with the maximum power rating of 3A (12V). Always turn off the power supply and unplug the power cord from the power outlet ● before installing or removing the RGB LED strip. Please use MSI’ s software to control the extended LED strip. ●...

  • Page 69: Jargb_V2_1~3: A-Rainbow V2 (Argb Gen2) Led Connectors

    JARGB_V2_1~3: A-RAINBOW V2 (ARGB Gen2) LED connectors The JARGB_V2 connectors allow you to connect the ARGB Gen2 and the ARGB-based LED strips. The JARGB_V2 connector supports up to 180 individually addressable RGB LEDs with maximum power rating of 3A (5V). Signal Name Signal Name Data...
  • Page 70 Always turn off the power supply and unplug the power cord from the power outlet ● before installing or removing the addressable RGB LED strip. Please use MSI’ s software to control the extended LED strip. ●...

  • Page 71: Jaf_2: Ez Conn-Header V2

    JAF_2: EZ Conn-Header V2 This header allows you to connect the ARGB Gen1 and Gen2 LED strips, fans and USB 2.0 devices. It can also be used to connect MPG EZ120 ARGB fans. EZ BRIDGE Signal Name Signal Name Ground DATA Sense Ground...
  • Page 72 JAF_2 header is compatible with JAF_1 header since pins 1 to 7 carry the same ● signals. MPG EZ120 ARGB can be connected to the JAF_2 header. For more information on how to install MPG EZ120 ARGB, please refer to ● https://msi.gm/S5035E56.

  • Page 73: Jpwrled1: Led Power Input

    JPWRLED1: LED power input This connector is used by retailers to demonstrate onboard LED lights. LED_SW1: EZ LED Control This switch is used to switch on/ off all the LEDs on the motherboard. LED_ON LED_OFF (Default)

  • Page 74: Dynamic Dashboard Iii

    The DYNAMIC DASHBOARD III, a TFT LCD panel, is located on the EZ BRIDGE. It can display system status, temperatures, voltages, BIOS flash status and error messages. You can use MSI Center to configure and customize the displays of the DYNAMIC DASHBOARD III and even upload a .gif/ .bmp/ .png/ .jpg or .mp4 animation file.
  • Page 75 S3 (Suspend to Ram) ⚠ Important To take full advantage of DYNAMIC DASHBOARD III, you should to install MSI Center and then install the DYNAMIC DASHBOARD APP within MSI Center ( MSI Center > Feature Sets > DYNAMIC DASHBOARD).
  • Page 76 Debug Code LED Table The Debug Code LED displays progress and error codes during and after POST. Refer to the Debug Code LED table for details. SEC Progress Codes Power on. Reset type detection (soft/hard) AP initialization before microcode loading System Agent initialization before microcode loading PCH initialization before microcode loading Microcode loading...
  • Page 77 CPU post-memory initialization. System Management Mode (SMM) initialization Post-Memory System Agent initialization is started 38 - 3A Post-Memory System Agent initialization (System Agent module specific) Post-Memory PCH initialization is started 3C - 3E Post-Memory PCH initialization (PCH module specific) DXE IPL is started PEI Progress Codes Memory not installed DXE Progress Codes...
  • Page 78 Super IO Initialization USB initialization is started USB Reset USB Detect USB Enable Reserved for future AMI codes 9E -9F IDE initialization is started IDE Reset IDE Detect IDE Enable SCSI initialization is started SCSI Reset SCSI Detect SCSI Enable Setup Verifying Password Start of Setup Setup Input Wait...
  • Page 79 PCI resource allocation error. Out of Resources No Space for Legacy Option ROM No Console Output Devices are found No Console Input Devices are found Invalid password Error loading Boot Option (LoadImage returned error) Boot Option is failed (StartImage returned error) Flash update is failed Reset protocol is not available S3 Resume Progress Codes...
  • Page 80 ACPI States Codes The following codes appear after booting and the operating system into ACPI modes. System is entering S1 sleep state System is entering S2 sleep state System is entering S3 sleep state System is entering S4 sleep state System is entering S5 sleep state System is waking up from the S1 sleep state System is waking up from the S2 sleep state...

  • Page 81: Installing Os, Drivers & Msi Center

    Installing OS, Drivers & MSI Center Please download and update the latest utilities and drivers at www.msi.com Installing Windows 11 1. Power on the computer. 2. Insert the Windows 11 installation disc/ USB into your computer. 3. Press the Restart button on the computer case.

  • Page 82: Installing Drivers With Msi Driver Utility Installer

    2. Select Start > Settings > Windows Update, and then select Check for updates. 3. MSI Driver Utility Installer will pop up automatically. 4. Select the I have read and agree to the MSI Terms of Use check box, and then click Next.
  • Page 83 5. Check the Select All checkbox in the lower-left corner and click Install to install MSI Center and drivers. The installation progress will be shown at the bottom. 6. Once the progress has completed, click Finish.
  • Page 84 MSI Center is an application that helps you easily optimize game settings and smoothly use content creation softwares. It also allows you to control and synchronize LED light effects on PCs and other MSI products. With MSI Center, you can customize ideal modes, monitor system performance, and adjust fan speed.

  • Page 85: Uefi Bios

    UEFI has many new functions and advantages that traditional BIOS cannot achieve, and it will completely replace BIOS in the future. The MSI UEFI BIOS uses UEFI as the default boot mode to take full advantage of the new chipset’ s capabilities.

  • Page 86: Bios Setup

    ● have. BIOS User Guide If you’ d like to know more instructions on setting up the BIOS, please refer to https://msi.gm/S53FE767 or scan the QR code to access. ⚠ Important The appearance of the BIOS user guide may differ based on your motherboard model.

  • Page 87: Entering Bios Setup

    Entering BIOS Setup Press Delete key, when the Press DEL key to enter Setup Menu, F11 to enter Boot Menu message appears on the screen during the boot process. Function key +/ -: Increase / decrease the value Enter: Select the item ESC: Exit Tab:...

  • Page 88: Resetting Bios

    ● Please follow the steps below to update BIOS: 1. Download the latest BIOS file from the MSI website that matches your motherboard model, and save it to the USB flash drive. 2. If your motherboard has a Multi-BIOS switch, switch to the target BIOS ROM.
  • Page 89 1. Download the latest BIOS file from the MSI website that matches your motherboard model. 2. Rename the BIOS file to MSI.ROM, and save it to the root directory of a USB flash device. 3. Connect the power supply to CPU_PWR1 and ATX_PWR1. (You don’ t need to install the CPU and memory.)

  • Page 90: Block Diagram

    Block Diagram MEG X870E GODLIKE DDR5 PCI_E1 DIMM A1/A2 PCIe 5.0x16 DIMM B1/B2 PCI_E PCIe 5.0x8 M.2_1 GEN5 x4 (PCIe Only) USB3.2 Gen2 10Gbps USB4 40Gbps(Type-C) (Rear Type-C) ASM4242 M.2_2 GEN5 x4 (PCIe Only) SIO 6687 PCIE x4 USB3.2 Gen2 10Gbps...

  • Page 91: Regulatory Notices

    This device may not cause harmful interference. ● This device must accept any interference received, including interference that may ● cause undesired operation. MSI Computer Corp. 901 Canada Court, City of Industry, CA 91748, USA (626)913-0828 www.msi.com...
  • Page 92 ● Compliance with these directives is assessed using applicable European Harmonized Standards. The point of contact for regulatory matters is MSI-Europe: Eindhoven 5706 5692 ER Son. Products with Radio Functionality (EMF) This product incorporates a radio transmitting and receiving device. For computers in normal use, a separation distance of 20 cm ensures that radio frequency exposure levels comply with EU requirements.

  • Page 93: Australia And New Zealand Notice

    Wireless Radio Use This device is restricted to indoor use when operating in the 2.4GHz, 5GHz, 6GHz frequency band. Cet appareil doit être utilisé à l’ intérieur. 당해 무선설비는 운용중 전파혼신 가능성이 있음. この製品は 、 周波数帯域 2.4GHz, 5GHz, 6GHz で動作しているときは 、 屋内においてのみ使用 可能です...
  • Page 94 KC인증서 상호: (주)엠에스아이코리아 제품명: 메인보드 모델명: 10-7E48 제조년월: 2024년 R-R-MSI-10-7E48 제조자 및 제조국가: MSI/중국 상호: (주)엠에스아이코리아 제품명: USB FLASH DRIVE 모델명: USB3VR09 제조년월: 2024년 R-R-MSI-USB3VR09 제조자 및 제조국가: MSI/중국 상호: (주)엠에스아이코리아 제품명: EZ CONTROL HUB 모델명: 10-4491 제조년월: 2024년 R-R-MSI-10-4491 제조자...

  • Page 95: Battery Information

    Battery Information European Union: Batteries, battery packs, and accumulators should not be disposed of as unsorted household waste. Please use the public collection system to return, recycle, or treat them in compliance with the local regulations. BSMI: 廢電池請回收 For better environmental protection, waste batteries should be collected separately for recycling or special disposal.

  • Page 96: Chemical Substances Information

    MSI will comply with the product take back requirements at the end of life of MSI-branded products that are sold into the EU. You can return these products to local collection points.
  • Page 97 MSI će poštovati zahtev o preuzimanju ovakvih proizvoda kojima je istekao vek trajanja, koji imaju MSI oznaku i koji su prodati u EU. Ove proizvode možete vratiti na lokalnim mestima za prikupljanje.
  • Page 98 MSI si adeguerà a tale Direttiva ritirando tutti i prodotti marchiati MSI che sono stati venduti all’ interno dell’ Unione Europea alla fine del loro ciclo di vita.

  • Page 99: 日本Jis C 0950材質宣言

    2008 № 1057. Việt Nam RoHS Kể từ ngày 01/12/2012, tất cả các sản phẩm do công ty MSI sản xuất tuân thủ Thông tư số 30/2011/TT-BCT quy định tạm thời về giới hạn hàm lượng cho phép của một số hóa...
  • Page 100 MS-7E48主板产品中有害物质的名称及含量 有害物质 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板组件* ╳ ○ ○ ○ ○ ○ 纽扣电池 ○ ○ ○ ○ ○ ○ 外部信号连接头 ╳ ○ ○ ○ ○ ○ 其他 (例: 线材等) ╳ ○...
  • Page 101 限用物質含有情況標示聲明書 設備名稱 ： 電腦主機板 型號(型式) ： MS-7E48 限用物質及其化學符號 單元 鉛 汞 鎘 六價鉻 多溴聯苯 多溴二苯醚 (Pb) (Hg) (Cd) (PBB) (PBDE) 電路板 ○ ○ ○ ○ ○ ○ 電子元件 ─ ○ ○ ○ ○ ○ 金屬機構件 ─ ○ ○ ○ ○ ○...

  • Page 102: Copyright And Trademarks Notice

    Copyright and Trademarks Notice Copyright © Micro-Star Int’ l Co., Ltd. All rights reserved. The MSI logo used is a registered trademark of Micro-Star Int’ l Co., Ltd. All other marks and names mentioned may be trademarks of their respective owners. No warranty as to accuracy or completeness is expressed or implied.
