- Page 1 USER MANUAL VENUS SERIES AC COUPLED ESS MST-BIE2.5-2500//MST-BIE5-2500 P111...
- Page 2 The products, services or features you purchase shall be subject to the commercial contract and terms of Marstek Energy Co., Limited. All or part of the products, services or features described in this document may not be within the scope of your purchase or use. Unless otherwise agreed in the contract, Marstek Energy Co., Limited.
- Page 3 The following symbols may appear in this document and their meanings SYMBOL CONVENTION are as follows: This symbol indicates a dangerous situation that could cause a fatal Danger electrocution hazard, serious personal injury, or fire. This symbol indicates instructions that must be followed carefully to avoid Warning potential safety hazards.
-
Page 4: Table Of Contents
Content Safety Precautions 1.1 Personal Safety 1.2 Electrical Safety Product Introduction 2.1 Product Model 2.2 Product Description 2.3 Box Marking 2.4 Appearance Description 2.5 Working Mode Installation Instructions 3.1 Pre-installation inspection 3.2 Select Installation location 3.3 Installing Tools 3.4 Equipment Installation 3.5 Installation And Debugging Stop Debugging 4.1 Stop Debugging... -
Page 5: Safety Precautions
Safety Precautions The Venus series AC COUPLED ESS has been designed and tested according to international safety requirements. However, safety regulations must still be followed when installing and operating this series of AC COUPLED ESS. Installers must carefully read, fully understand and strictly comply with all instructions, precautions and warnings in this installation manual. -
Page 6: General Requirements
Special insulating tools must be used during the operation to avoid electric shock or short circuit failure. The insulation withstand voltage level must meet the requirements of local laws, regulations, standards and specifications. Special protective equipment must be used during the operation, such as protective clothing, insulating shoes, goggles, safety helmets, insulating gloves, etc. - Page 7 If the equipment needs to be repaired, please be sure to use qualified and compliant parts for repair. The relevant parts must be installed by an authorized contractor or an authorized service representative of Marstek Energy Co., Limited. and the relevant parts can only be used for their intended purpose.
-
Page 8: Product Introduction
Product Introduction 2.1 Product Model Model Description This article mainly covers the Venus-C and Venus-E product models. Model Identification Company MST: Marstek Energy Co., Limited. name MST-BIEXX-XX Series name BIE: AC COUPLED ESS Power XX: 2.5 means 2.5kWH, 5 means 5kWH... -
Page 9: Communication Method
Installation is simple and convenient by using standard installation tools. Grid-connected Applications The main function of the VENUS series AC COUPLED ESS is to temporarily store grid energy in the battery through a bidirectional inverter. System data is transmitted to the mobile client via a router connection. -
Page 10: Appearance Description
CE Marking The AC COUPLED ESS complies with the EU low voltag directive. View Please read the user manual before installation. Instructions 2.4 Appearance Description Appearance Backup Switch WIFI RS485 Grid Product Dimensions 550mm 220mm 450mm 200mm 650mm 560mm Venus-C Venus-E... -
Page 11: Working Mode
2.5 Working Mode The VENUS series AC COUPLED ESS has three operating methods, which are: In this method, the device will automatically search for CT equipment connected to the same home Anti-reverse network. Based on the household electricity consumption information collected by the CT... -
Page 12: Installation Instructions
Installation Instructions 3.1 Pre-installation inspection Before unpacking the device, check the packaging for visible damage, such as holes, cracks, or other signs of possible internal damage, and check the model number of the device. If there are any abnormalities in the packaging or the energy storage model does not match, do not unpack it and contact your dealer as soon as possible. -
Page 13: Equipment Installation
Tool knife Protective glasses Wire strippers Marker pen 3.4 Equipment Installation There are two method for installation：Floor installation and wall-mounted installation. Step 1: Dimensions There needs to be at least 150mm of space between the top and rear of the machine to ensure that there are no other devices around and no obstructions to meet the requirements of heat dissipation and safety isolation. -
Page 14: Installation And Debugging
Step 3: Wiring 1. Insert the plug of the AC line into the socket and connect it to the local power grid. 2. Connect the antenna to the position shown in the figure and tighten the threads. 3. Backup terminal，for supplying power to the load. Antenna Backup terminal AC power outlet... -
Page 15: Device Shutdown
Device shutdown Press and hold the power off button on the back of the device, and release it after 3 seconds (or release it after the button flashes 3 times). The LED light will go out and the device will enter the power off state. -
Page 16: Stop Debugging
4.2 Storage And Transportation The storage temperature of the AC COUPLED ESS is -30°C to 80°C. To facilitate transportation and subsequent handling, MARSTEK packaging is specially designed to protect the components. When transporting equipment, especially by road, it is necessary to Correct methods must be adopted to protect components (especially electronic devices) to prevent them from being affected by severe impact, moisture, vibration and other factors. -
Page 17: Troubleshooting
Troubleshooting 5.1 Troubleshooting Checklist Codes Alarm range Alarm status Suggested treatments 1. Check whether the ventilation of the inverter installation location is good and whether the ambient temperature exceeds the maximum allowable ambient temperature range. Inverter Side Overheat Protection 2. If there is no ventilation or the ambient temperature is too high, please improve its ventilation and heat dissipation conditions. - Page 18 If the fault is triggered frequently, please contact the technical BAT Side Battery overcurrent team. 1. Please connect the grid-connected interface. BAT Side Battery undervoltage 2. If the fault is triggered frequently, please contact the technical team. 1. Grid fluctuations and loose lines may trigger this fault. 440/441 Grid Side Grid overvoltage...
- Page 19 DCV protection/grid 1. Grid fluctuations and loose lines may trigger this fault. voltage direct Inverter Side component 2. Check whether the grid is connected correctly and wait for protection the grid to return to normal. 1. Check whether the ventilation of the inverter installation location is good and whether the ambient temperature exceeds the maximum allowable ambient temperature range.
-
Page 20: On-Site Inspection
1. It will occasionally be triggered when the household load fluctuates too much or the network fluctuates, and will Line sequence automatically disappear after a period of time. detection failed 2. Check whether the CT sensor is connected normally. Restart method: Put the device into sleep mode and unplug the power connector. Wait for 2 minutes, then wake up the device and plug it back into the power connector. -
Page 21: Equipment Replacement
Do not dismantle the AC COUPLED ESS without authorization! To ensure safety and insulation Danger performance, users are prohibited from repairing internal parts! The AC output harness (AC tapping cable on the AC COUPLED ESS) must not be replaced. If the Warn wires are damaged, the device should be scrapped.
