KEY PART NUMBER
DESCRIPTION
01
5300275-95/4
GRIP
02
5300157-68/1
LOCKNUT
03
5300946-88/5
DRIVESHAFT HSG.
04
5300142-22/0
HANDLE ASSY
05
5300156-10/5
NUT
06
5300152-45/0
SCREW
07
5300109-59/1
THROTTLE LEVER ASSY
08
5300692-52/1
T HANDLE KIT
09
5300692-49/7
SHIELD KIT ASSY
10
5300153-37/5
SCREW
11
5300945-70/5
LINE LIMITER
12
5300156-53/5
LOCKNUT
13
5300936-53/0
SHIELD BRACKET
14
5300922-43/1
SCREW
MODEL
PRODUCT NO
QTY
KEYPART NUMBER
1
15
1
16
1
17
1
18
1
19
1
20
1
21
1
22
1
23
1
24
1
25
1
26
1
27
2
28
Maxi trim 430 Type II & Type III
.
DESCRIPTION
5300945-43/2
DUST CAP
5300946-71/1
DRIVESHAFT
5300311-11/4
HEX WRENCH 5/32
9520301-39/2
SHAFT LUBRICATION
9527155-26/2
CUTTING HEAD ASSY
5300948-78/2
HUB ASSY
5300948-30/3
SPRING
5300948-27/9
RELEASE BUTTON
5195197-00/8
SPOOL & LINE
5300948-28/7
COVER
5300291-59/7
SHAFT WARNING LABEL
5300947-42/0
CLAMP
5300947-83/4
THROTTLE GUARD
5300158-27/5
SPACER
9527152-79
2
QTY
1
1
1
1
1
1
1
1
1
1
1
1
1
2
