ROHL WARRANTY POLICY
All products supplied by ROHL carry warranties against manufacturing defects.
Perrin & Rowe products carry a Limited Lifetime Warranty.
ROHL LLC will provide free of charge, as its options, replacement part(s) or product (or a comparable alternative
product) to replace those which have proven defective in materials or workmanship.
For full ROHL LLC WARRANTY please contact ROHL or visit www.rohlhome.com
SPARES
9.01799*/Hot
9.01370*
9.01799*/Cold
9.13146
9.13145
Mixer Service Kit
9.54719
NON-RINSE
9.25552
9.20642*
9.17793*
9.18792*
U.6792
U.6793
* Where indicated please specify color
SPARE PARTS & SERVICE
Perrin & Rowe products are manufactured in the UK, using the latest
technology and built to the highest quality standards.
3 Parker
We would like to thank you for purchasing a Perrin & Rowe product and
Irvine
take this opportunity to invite you to look at other luxury products by us.
CA 92618
(714) 557-1933
Please contact us to recieve our latest catalogue.
www.rohlhome.com
Perrin & Rowe is a registered trademark.
RINSE
9.20763*
9.25552
9.17793*
9.13362
9.13146
9.19776
9.01776*
9.20174
9.18425*
9.28426
9.03272
9004718U
BRIDGE MIXERS
Rinse Seal Kit
9.54755
1"
Hole
1 /2"
• U.4788X • U.4789L
• U.4790X • U.4791L
Fitted With U.6793
Temp Range:
Min 1°C/34°F
Max 85°C/185°F
Recommended
Working Pressure:
Min 1bar/15psi
Max 5bar/75psi
Ideal performance obtained with equal hot & cold pressures.
Issue 5
The Traditional Kitchen Collection
Installation & User Guide
• U.4719L • U.4718X
1" Hole
1 /2"
1 9/16"
Max
HOT
IN
COLD
IN
1" Hole
1 /2" NPT
1 7/8"Max
• U.4790X • U.4791L
Fitted With U.6792
1 9/16"
Max
1 1/8"
Hole
Hose
Length
47"
