- Page 1 LS - C 9 1 Smart Lock User Manual www.locstar.com 400-8833-566 [Tuya Version] SHENZHEN LOCSTARTECHNOLOGY CO.,LTD Reserves the right to interpret this manual...
-
Page 2: Product Parameters
Ⅰ、Product introduction 1、Product parameters 500DPI Powersupply 4.5~6.5v (4AAA batteries) Resolution Static current Rejection rate ≤0.15% ＜55 Ma Working current False recognition rate ≤0.00004% ＜250 Ma Fingerprint Capacity ≤100 Working temperature -10℃~60℃ Cards Capacity ≤300 Relative humidity 20%RH~93%RH Password Capacity ≤300 2、Product dimensions 147.33 68.00... -
Page 3: Installation Tool
Ⅱ、Installation Guide 1、installation conditions 1.1、Door thickness Door lock border ≥110 mm (thickness of inconsistent doors) 45mm≤door thickness ≤120mm( custom accessories are required when size exceeded) 1.2、Opening direction indoor indoor indoor indoor wall wall door door Left outside Right outside Left inside Right inside door door... -
Page 4: Installation Notes
4、Lock mortise open direction change According to their actual needs, the internal and external opening directions of the lock are changed as follows Oblique tongue reversing pick ①Pull the oblique tongue reversing pick to the other end. ②Push the oblique tongue into the locking body and turn it 180 degrees. -
Page 5: Installation Steps
7、Installation steps Ⅱ、Opening Ⅰ、Line drawing Open the panel and lock 1. draw a horizontal center line cor e mo untin g ho l es 1m from the ground on both sides of the door. according to the require- me nt s of the o pen i ng 2.Fold the opening template in template. - Page 6 Ⅲ、Function and Operation 3.1Function menu topology diagram 1.Add User Please enter in unlock ways(Fingerprint/Password/Card) 2.Delete User Enter in the series number you would delete. Press *+ # and then 3. Mute mode Turn ON/OFF enter ADMIN password+# 4.Add Admin Enter in unlock ways(Fingerprint/Password/Card) 3.2 Function and Operation 1.
- Page 7 Delete administrator information ◆ After entering the door lock function menu, select "Delete user" and enter the number to be deleted and operate according to the display and voice prompts. As shown in the figure: Please verify the To delete number 002, Please enter the administrator please press the #...
- Page 8 8.Other instructions ◆If you enter an incorrect password for more than 5 consecutive times within 5 minutes, the keyboard is locked and the system does not respond to any operations in 90 seconds. You can press the setting key on the rear panel to enter the administrator and unlock the password. ◆Password anti-prying function: Enter the password as follows when opening the password :XXX password XXX: you can add some irrelevant codes before and after the password, and then press # to confirm.
- Page 9 3.11 To open the battery cover There is a small gap on the left bottom of the back cover, from where you can open the battery cover. Grip position Ⅳ 、Work with TUYA APP 5.1 APP download Search “Tuya Smart" in play store / App Store or scan the QR code below to downloadthe APP 5.2 Register /Login /Forget password 5.3 Add graffiti door locks Enter *+# in the door lock - Enter "Administrator password"...
- Page 10 ② Select the lock type you need, enter the distribution mode, and turn on Bluetooth tosearch for the required device. After discovering the device, click Add, enter the WlFl youwant to connect, and then wait for the connection to succeed. 5.4 APP user method ①...
- Page 11 ③Smart linkage can set conditions, and when the set conditions are met, the APP message push will be triggered. ④Remote door opening request: Enter 9# on the lock panel. When someone presses the doorbell, a remote door unlocking request will be pushed. The user can remotely unlock the door or refuse to unlcok the door through the APP. The APP will also have a doorbell record afterwards.
-
Page 12: Warranty Card
Warranty Card 1. The manual and warranty card are included in the factory default packaging for each product. After installation, please fill in the warranty card and keep it properly as the warranty certificate. 2. Full grantee: 1 year 3. The following are not covered by the warranty: A. -
Page 13: Fcc Warning
FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference... - Page 14 particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna.
