- Page 1 USER’S OPERATION MANUAL Before operating this unit, please read this manual thoroughly, and retain for future reference HRBM417S HRBM417C HRBM418S English...
-
Page 2: Table Of Contents
Contents Safety and warning information……..2 Cleaning and care………………………18 Installing your new appliance…………7 Helpful hints and tips……………………20 Description of the appliance……………13 Troubleshooting………………………….22 Display controls…………………………14 Disposal of the appliance………………23 Using your appliance…………………… 17 Safety and warning information For your safety and correct usage, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. - Page 3 General safety WARNING —This appliance is intended to be used in household and similar applications such as -staff kitchen areas in shops, offices and other working environments; -farm houses and hotels, motels and other residential type environments; -bed and breakfast type environments; -catering and similar non-retail applications.
- Page 4 WARNING — Refrigerators contain refrigerant and gases in the insulation. Refrigerant and gases must be disposed of professionally as they may cause eye injuries or ignition. Ensure that tubing of the refrigerant circuit is not damage prior to proper disposal. It is hazardous for anyone other than an Authorized Service Person to service this appliance.
- Page 5 Do not place food products directly against the air outlet on the rear wall. Store pre-packed frozen food in accordance with the frozen food manufacture’s instructions. The appliances manufactures storage recommendations should be strictly adhered to relevant instructions for storage. ...
- Page 6 relevant to installation. Wherever possible, the back of the product should not be too close to a wall to avoid touching or catching warm parts (compressor, condenser) to prevent the risk of a fire, follow the instructions relevant to installation. ...
-
Page 7: Installing Your New Appliance
Installing your new appliance Before using the appliance for the first time, you should be informed of the following tips. Warning! For proper installation, this refrigerator must be placed on a level surface of hard material that is the same height as the rest of the flooring. - Page 8 The supporter lower should be fastened to Leveling of appliance the lower base cover to steady this For sufficient leveling and air circulating in appliance. Because when opening the door the lower rear section of the appliance, the about 90 degree, this refrigerator may take bottom feet may need to be adjusted.
- Page 9 Not provided Wrench(8mm) Philips Screw driver Thin-blade Monkey wrench screwdriver Additional parts (in the plastic bag) Caution! Please slightly squeeze the door rack from Allen Wrench(4mm) Supporter Lower two sides toward center and inside of door rack, and then move it upward when taking out the upper rack and lower rack.
- Page 10 smooth surface with its panel upwards. 4. Unscrew screw ③ and take down part ② and part ①, Install replacement door stopper-left ④ and stop block-left ⑤ (provided in the plastic accessory bag) to the left side with screw ③. Keep part ①...
- Page 11 7. Install screw hole cover-right ① (provided in the plastic accessory bag) to the right-top corner of cabinet. Remove screw hole cover-left ② from the left-top corner of cabinet with thin-blade screwdriver and Put the screw hole cover- left and upper hinge -right into the plastic accessory bag for future reference.
- Page 12 12. Carefully slot the upper door onto the 13. Install the temperature sensor part on middle hinge pin and hold in position. the upper hinge cover-left (provided in the Move the upper door to an appropriate plastic accessory bag). Assemble the position, adjust the upper hinge-left upper hinge cover-left to match the hinge.
-
Page 13: Description Of The Appliance
Description of the appliance Display panel Metal-Tech Cooling is not available for HRBM417C. HRBM418S Due to unceasing modification of our products, your refrigerator may be slightly different from this instruction manual, but its functions and using methods remain the same. -
Page 14: Display Controls
Display Controls Use your appliance according to the following control regulations, your appliance has the corresponding functions and modes as the display panels showed in the pictures below. When the appliance is powered on for the first time, the backlighting of the icons on display panel starts working. - Page 15 ③ Release the TEMP. Control when inside each compartment may vary from the temperature displayed on the panel, the desired temperature setting depending on how much food you store appears. and where you place them. Ambient 3. Super Cool temperature may also affect the actual temperature inside the appliance.
- Page 16 to -24°C to freeze food faster. ① Press MODE repeatedly until the Super Freeze icon appears. NOTE: When Super Freeze is on, is illuminated and -24°C appears in the temperature display. ② Press MODE or adjust freezer compartment temperature according to the step 2 to turn off Super Freeze manually and the freezer temperature will return to the previous...
-
Page 17: Using Your Appliance
Using your appliance Your appliance has the accessories as the“Description of the appliance” showed in general, with this part instruction you can have the right way to use them.. We recommend that you read through them carefully before using the appliance Door rack Freezer chamber It is suitable for the storage of canned... -
Page 18: Cleaning And Care
Cleaning and care hygienic reasons appliance You should clean the appliance interior (including exterior and interior accessories) regularly. It will be easier to clean when food should be cleaned regularly (at least every stocks are low. Wipe the inside of the fridge two months. - Page 19 Do not use sharp objects to remove frost from the freezer compartment. Only after the interior is completely dry should the appliance be switched back on and plugged back into the mains socket. Door seals cleaning Take care to keep door seals clean. Sticky food and drinks can cause seals to stick to the cabinet and tear when you open the door.
-
Page 20: Helpful Hints And Tips
Helpful hints and tips Energy saving tips drawer provided. We recommend that you follow the tips Butter and cheese: below to save energy. Should be wrapped in airtight foil or plastic film wrap. Try to avoid keeping the door open for long periods in order to conserve energy. - Page 21 2. Remove the power plug from the mains socket. 3. Clean and dry the interior thoroughly. 4. Ensure that all the doors are wedged open slightly to allow air to circulate.
-
Page 22: Troubleshooting
Troubleshooting If you experience a problem with your appliance or are concerned that the appliance is not functioning correctly, you can carry out some easy checks before calling for service, please see below. Warning! Don’t try to repair the appliance yourself. If the problem persists after you have made the checks mentioned below, contact a qualified electrician, authorized service engineer or the shop where you purchased the product. -
Page 23: Disposal Of The Appliance
Check that the air outlets are not blocked by food and ensure A layer of frost occurs in food is placed within the appliance to allow sufficient the compartment ventilation. Ensure that door is fully closed. To remove the frost, please refer to the“Cleaning and care” chapter. You may have left the doors open too long or too frequently;... - Page 24 To avoid contamination of food, please respect the following instructions - Opening the door for long periods can cause a significant in crease of the temperature in the compartments of the appliance. - Clean regularly surfaces that can come in contact with food and accessible drainage systems.
- Page 25 Fresh/frozen pork, beef, fish, chicken, freshwater aquatic prodects, etc.(7 days below 0°C and above 0°C is recommended Chill -2~+3 for consumption within that day, preferably no more than 2 days). Seafood(less than 0 for 15 days, it is not recommended to store above 0°C).
- Page 26 ４３１７３８８－Ｃ...
