Technical details
Mechanical data
Conductor cross section with screw terminals
1 core flexible
2 core with the same cross section, flexible with
crimp connectors, no plastic sleeve
2 core with the same cross section, flexible without
crimp connectors or with TWIN crimp connectors
Torque setting with screw terminals
Stripping length with screw terminals
Dimensions
Height
Width
Depth
Weight
Where standards are undated, the 2022-09 latest editions shall apply.

Safety characteristic data

Operating EN ISO
mode 13849-1:
2015
PL
– PL e
Explanatory notes for the safety-related characteristic data:
}
Safety characteristic data in accordance with EN IEC 62061 and EN/IEC 61511 was cal-
culated based on EN/IEC 61508.
}
T is the maximum mission time in accordance with EN ISO 13849-1. The value also ap-
M
plies as the retest interval in accordance with EN/IEC 61508-6 and EN/IEC 61511 and as
the proof test interval and mission time in accordance with EN IEC 62061.
All the units used within a safety function must be considered when calculating the safety
characteristic data.
Operating instructions SE-SR2
826002434-EN-Rev.E
NOTICE
You must comply with the safety characteristic data in order to achieve the
required safety level for your plant/machine.
EN ISO EN IEC
13849-1: 62061
2015
SIL CL/
Category maximum
SIL
Cat. 4 SIL 3
INFORMATION
A safety function's SIL/PL values are not identical to the SIL/PL values of
the units that are used and may be different. We recommend that you use
the PAScal software tool to calculate the safety function's SIL/PL values.
0,25 - 2,5 mm², 24 - 12 AWG
0,25 - 1 mm², 24 - 16 AWG
0,2 - 1,5 mm², 24 - 16 AWG
0,5 Nm
8 mm
94 mm
22,5 mm
121 mm
180 g
EN IEC EN/IEC
62061 61511
PFH [1/h] SIL
D
2,31E-09 SIL 3
EN/IEC EN ISO
61511 13849-1:
2015
PFD
T [year]
M
2,03E-06 20
