Sony CDP-X55ES Service Manual

AR CONVERTER
He se
US Model
Canadian Model
AEP Model
UK Model
E Model
Australian Model
Pusy onan
Sonshose
Model Name Using Similar Mechanism CDP-338ESD/608ESD
CD Mechanism Name CDM11E-6C
SPECIFICATIONS
Compact disc player
Frequency response 2 Hz —20 kHz +0.3 dB
Signal to noise ratio More than 115 dB
More than 100 dB
Less than 0.0018%
More than 110 dB
Outputs
LINE OUT
(FIXED)
(phono jacks)
LINE OUT
(VARIABLE)
(phono jacks)
DIGITAL OUT
(OPTICAL) (optical
output connector)
HEADPHONES
(stereo phone
jack)
Output level 2 V (at 50 kiloohms)
Load impedance over 10 kiloohms
Output level max. 2 V (at 50 kiloohms)
Load impedance over 50 kiloohms
Wave length 660 nm
Output level — 18 dBm
Output level max. 28 mW
Load impedance 32 ohms
General
AEP Model
220 V AC (or 240 V AC adjustable by
Sony personnel), 50/60 Hz
UK Model
240 V AC (or 220 V AC adjustable by
Sony personnel), 50/60 Hz
Australian Model
240 V AC, 50/60 Hz
US, Canadian Models
120 V AC, 60 Hz
E Model
110, 120, 220 or 240 V AC adjustable,
50/60 Hz
Power
requirements
Power
consumption
Dimensions
(approx., including
projections)
470 X 125375 mm (w/h/d)
(185/—5 X 147/, inches)
UK Model *
430 x 125375 mm (w/h/d)
(17x 5x 147/, inches)
Weight (approx.) 12.5 kg (27 Ibs 9 0z)
UK, E Models
11.5 kg (25 Ibs 6 0z)
* UK model is not equipped with the side panels.
Remote commander (RM-D590)
Remote control Infrared contro!
system
Power 3 V DC with two batteries size AA
requirements (IEC designation R6)
Dimensions 67 X18 175 mm (w/h/d)
(23/4 23/35 x7 inches)
Weight 150 g (5.3 oz)
Including batteries
Supplied accessories
Connecting cord 1
(2 phono plugs <» 2 phono plugs)
Remote
commander
R6 (size AA)
batteries
Screws
(Except UK model)
Optional accessory
Audio optical connecting cord POC-15
Design and specifications subject to change without notice.
COMPACT DISC PLAYER
ONY.
