When AV3, AV4, AUDIO1 or AUDIO2 is selected as the
input source, a video signal input from an external
component connected to the HDMI1-4, AV1-6 or V-AUX
jack can be output to the video monitor. This feature is
useful when you connect a component such as the
following.
Example 1: A game console that outputs an analog audio
signal and a video signal via component
video jacks.
Example 2: A set-top box that does not output an audio
signal at the HDMI output jack.
To connect such a component, do the following
connection/setting.
Part 1: Connecting an external component
Part 2: Assigning the video input jacks
Part 1: Connecting an external
component
• HDMI jacks: Connect the HDMI output jack of the
external component to the available HDMI jack of this
unit (see next section).
• Audio output jacks: Connect the audio output jacks of
the external component to the AV3-4 or AUDIO1-2
audio input jacks.
• Video output jacks: Connect the video output jacks of
the external component to the AV1-6 or VIDEO AUX
video input jacks.
Note
• Make sure that this unit and other components are unplugged from the
AC wall outlets.
■
HDMI and audio connection
Audio output jacks
on the connected
source component
Analog audio output AUDIO1
AUDIO2
Coaxial digital output AV3 (CD)
Optical digital output AV4
■
Audio connection
Output jacks on the
connected source
component
Coaxial digital output
Optical digital output
Analog audio output
Addendum for audio/video connection
Available
Input sources/
HDMI
jacks of this unit
jack
AUDIO HDMI1
AUDIO HDMI2
COAXIAL HDMI3
OPTICAL HDMI4
Input sources/jacks of this unit
AV3 (CD) COAXIAL
AV4 OPTICAL
AUDIO1 AUDIO
AUDIO2 AUDIO
© 2009 Yamaha Corporation All rights reserved.
■
Video connection
Output jacks on the
connected source
component
Component video output
Composite video output
S-Video output
Note
• If the video monitor is connected to this unit via an analog video
connection (component video or composite video connection), connect
the external component to this unit via the same analog connection.
1
En
UABG
Printed in China WT92370
Jacks of this unit
AV1 (TV) COMPONENT
VIDEO
AV2 COMPONENT
VIDEO
AV3 (CD) VIDEO
AV4 VIDEO
AV5 VIDEO
AV6 VIDEO
VIDEO AUX VIDEO
(Front panel)
AV5 S-VIDEO*
* Some models only.
Continues to the back side
