In addition to the operating mode parameters, a dedicated parameter section is proposed for the protection
feature configuration. The default configuration is also given.
DPC_VDCHV_OVP
DPC_VDCHV_UV
DPC_VDCHV_UVLO
DPC_VDCHV_MIN
DPC_IDCHV_OCP
DPC_IDCLV_OCP
DPC_VDCLV_OVP
The STSW-DABBIDIR source code firmware package represents the control section of STDES-DABBIDIR. By
using hardware section configuration of the FW, different hardware configuration proposed by the CTMs can also
be supported. The main parameters such as switching frequency, dead time, sensing parameters, and magnetics
section can be customized.
Parameters
TRAFO_TURN_RATIO
INDUCTANCE
PWM_FREQ
DPC_DT_DAB1
DPC_DT_DAB2
G_VDC1
B_VDC1
G_IDC1
B_IDC1
G_VDC2
B_VDC2
G_IDC2
B_IDC2
7.6

How to operate the STDES-DABBIDIR

This section provides examples of operating modes. Several setups are proposed to help evaluate and become
familiar with the various features of the reference design.
7.6.1 Mode 1 – open loop, driving check
This test is for the driving section of the application. PWM signals are generated by HRTIM according to the
STM32CubeMX peripheral configuration.
Dead time and switching frequency are managed by "PWM_FREQ", "DPC_DT_DAB1" and "DPC_DT_DAB2" of
"DPC_Appplication_Conf.h" file.
No high-power equipment is required during this test.
MCU and gate driver section phase shift between primary and secondary can be verified during this test.
UM3198 - Rev 1
Table 21. Hardware protection firmware configuration defines
Parameters
Table 22. Hardware parameters firmware configuration defines
Value type Min Default Max
float -
float - 28e-6
Uint16_t - 100000
float - 0.4e-6
float - 0.4e-6
float - 3.901
float -
float - 42.67
float - 2048
float - 6.296
float -
float - 24.948
float - 2048
How to manage the STDES-DABBIDIR reference design
Value type Min
float -
float -
float -
float -
float -
float -
float -
Unit
1.78 - N1/N2
-
- Switching Frequency of converter expressed in [Hz]
-
-
- Gain terms of the DC input voltage sensing
0 - Bias terms of the DC input voltage sensing
- Gain terms of the DC input current sensing
- Bias terms of the DC input current sensing
- Gain terms of the DC output voltage sensing
0 - Bias terms of the DC output voltage sensing
- Gain terms of the DC output current sensing
- Bias terms of the DC output current sensing
UM3198
Default Max
900 -
40 -
30 -
20 -
50 -
550 -
100 -
Comments
Transformer turn ratio
Auxiliary inductance
Dead Time [Expressed in sec]
Dead Time [Expressed in sec]
V
Unit
V
V
V
A
A
V
page 45/83
