Chewy frisco 507118 Instruction Manual

Part 3 - Operate Door, Base Locks And Door Latch
Figure 3-1 Figure 3-2
Step 1
Locate the base locks at the bottom of the
gate door. Turn one base lock to the horizon-
tal position to open the gate door. The base
Figure 3-3
lock on the side occupied by your pet should
be placed in the vertical position.
TIP: There are (2) base locks which allows
you to modify how the gate swings open.
To Open Door Inward And Outward
Leave all base locks in the horizontal position.
(Figure 3-1).
Step 2
To Open Door Inward Only
Turn the base lock on the inside of the gate
To open the gate door, locate the door latch.
(where your pet would be) horizontally
Press both side buttons on the latch and pull
(Figure 3-2).
up (Figure 3-3 & 3-4).
To Open Door Outward Only
Once the gate is opened, it will swing shut
Turn the base lock on the outside of the
and lock on its own.
gate horizontally.
Removing The Gate
To remove the gate, rotate the adjustment wheels on the (4) threaded
spindle rods to loosen. This will depressurize the gate so you can remove
it with a gentle pull or push.
Warning & Cautions
Please read all warnings and instructions
thoroughly before assembling.
FOR PET USE ONLY. NOT FOR USE WITH CHILDREN.
Never install this gate without the wall cups.
Only assemble as directed and using all required parts.
Never leave pet unattended. Stop using if/once your pet can climb over or push
the gate loose.
Use only with the locking/latching mechanism securely engaged.
Never use at top of stairs.
Do not use as a barrier to pool.
Use the wall cups for stability and safety. Wall cups and assembly hardware
are included.
Install according to assembly instructions. If installed improperly, the gate could
become unstable or dislodged from the doorway.
Always ensure the gate is resting against the floor before beginning installation.
Never use more than two extensions per side of gate.
If assembling onto a surface other than drywall or wood, please consult with a
professional for proper installation.
Do not assemble if any part is missing or damaged.
Check the gate regularly to ensure all hardware and mountings are tightened.
Keep these instructions handy for future use.
The gap between the gate and wall should not exceed more than 2.6 inches.
Figure 3-5
Keeping The Door Open
Swing
open (Figure 3-5).
Figure 3-4
Troubleshooting:
Gate Not Staying Closed
The locking handle is too close to the locking
housing. This can be corrected by loosening
the upper threaded spindle rods by turning
them outward, creating the proper gap.
Gate not staying open
The gate was not installed properly. Remove
and reinstall the gate, being careful to ensure
Care
& Maintenance
Always check the gate and discontinue use if any parts
are missing, worn or damaged. Check regularly to
make sure all hardware and mountings are tightened
securely. Wash with mild detergent. Don't use any
abrasive cleaners or bleach.
Questions
Questions? Call our friendly customer service anytime.
-
Outdoor Steel Arch
Extra Wide And Extra Tall Auto-close Dog Gate
Instruction Manual
Sku# 507118, 507102
FOR PET USE ONLY.
