- Page 1 Latitude 5450 Owner's Manual Regulatory Model: P165G Regulatory Type: P165G002/P165G004/P165G005 February 2024 Rev. A00...
- Page 2 A WARNING indicates a potential for property damage, personal injury, or death. © 2024 Dell Inc. or its subsidiaries. All rights reserved. Dell Technologies, Dell, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.
-
Page 3: Table Of Contents
Contents Chapter 1: Set up your Latitude 5450.................... 7 Chapter 2: Views of Latitude 5450....................9 Right....................................... 9 Left......................................9 Top......................................11 Front......................................12 Bottom....................................13 Service Tag..................................13 Battery charge and status light .............................14 Chapter 3: Specifications of Latitude 5450.................. 15 Dimensions and weight..............................15 Processor..................................... -
Page 4: Chapter 1: Set Up Your Latitude 5450
Follow the on-screen instructions to complete the setup. For more information about installing and configuring Ubuntu, search in the Knowledge Base Resource at www.dell.com/support. For Windows: Follow the on-screen instructions to complete the setup. When setting up, Dell Technologies recommends that you: ● Connect to a network for Windows updates. NOTE: If connecting to a secured wireless network, enter the password for the wireless network access when prompted. - Page 5 SupportAssist proactively checks the health of your computer hardware and software. When an issue is detected, the necessary system state information is sent to Dell to begin troubleshooting. SupportAssist is preinstalled on most of the Dell devices running the Windows operating system. For more information, see SupportAssist for Business PCs manuals at www.dell.com/support/home/...
-
Page 6: Chapter 2: Views Of Latitude 5450
Views of Latitude 5450 Right Figure 2. Right view 1. Universal audio jack Connect headphones or a headset (headphone and microphone combo). 2. USB 3.2 Gen 1 port with PowerShare Connect devices such as external storage devices and printers. Provides data transfer speeds up to 5 Gbps. PowerShare enables you to charge your USB devices even when your computer is turned off. - Page 7 Supports USB4, DisplayPort 2.1, Thunderbolt 4 and also enables you to connect to an external display using a display adapter. Provides data transfer rates of up to 40 Gbps for USB4 and Thunderbolt 4. NOTE: You can connect a Dell Docking Station to the Thunderbolt 4 ports. For more information, search in the Knowledge Base Resource at www.dell.com/support. NOTE: A USB Type-C to DisplayPort adapter (sold separately) is required to connect a DisplayPort device.
-
Page 8: Top
10 seconds to force shut-down the computer. If the power button has a fingerprint reader, place your finger on the power button steadily to log in. NOTE: You can customize the power-button behavior in Windows. Views of Latitude 5450... -
Page 9: Front
Turns on when the camera is in use. 7. Ambient-light sensor The sensor detects the ambient light and automatically adjusts the display brightness. 8. Right microphone Provides digital sound input for audio recording and voice calls. Views of Latitude 5450... -
Page 10: Bottom
The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware components in your computer and access warranty information. Service Tag The service tag is a unique alphanumeric identifier that allows Dell service technicians to identify the hardware components in your computer and access warranty information. Views of Latitude 5450... -
Page 11: Battery Charge And Status Light
Figure 7. Service Tag location Battery charge and status light The following table lists the battery charge and status light behavior of your Latitude 5450. Table 2. Battery charge and status light behavior Power source LED behavior System power state... -
Page 12: Chapter 3: Specifications Of Latitude 5450
1.40 kg (3.09 lb) - minimum NOTE: The weight of your computer depends on the configuration that is ordered and manufacturing variability. Processor The following table lists the details of the processors that are supported for your Latitude 5450. Specifications of Latitude 5450... - Page 13 3.30 GHz 3.40 GHz 3.50 GHz 3.70 GHz frequency Processor cache 10 MB 12 MB 12 MB 12 MB Integrated graphics Intel UHD Graphics Intel Iris Xe Graphics Intel Iris Xe Graphics Intel Iris Xe Graphics Specifications of Latitude 5450...
- Page 14 0.70 GHz frequency Maximum turbo 3.90 GHz 3.60 GHz 3.60 GHz 3.60 GHz frequency Processor cache 12 MB 12 MB 12 MB 18 MB Integrated graphics Intel Iris Xe Graphics Intel Graphics Intel Graphics Intel Arc Graphics Specifications of Latitude 5450...
-
Page 15: Chipset
Integrated graphics Intel Arc Graphics Intel Graphics Intel Graphics Intel Arc Graphics Chipset The following table lists the details of the chipset that is supported for your Latitude 5450. Table 7. Chipset Description Values Chipset Integrated in the processor Processor ●... -
Page 16: Operating System
Your Latitude 5450 supports the following operating systems: ● Windows 11 Home ● Windows 11 Pro ● Ubuntu Linux 22.04 LTS Memory The following table lists the memory specifications of your Latitude 5450. Table 8. Memory specifications Description Values Memory slots... -
Page 17: External Ports
To learn more about the features of different types of M.2 cards, search in the Knowledge Base Resource at www.dell.com/support. Ethernet The following table lists the wired Ethernet Local Area Network (LAN) specifications of your Latitude 5450. Table 11. Ethernet specifications Description Values Model number ●... -
Page 18: Wireless Module
Table 11. Ethernet specifications (continued) Description Values Transfer rate 10/100/1000 Mbps Wireless module The following table lists the Wireless Local Area Network (WLAN) modules that are supported on your Latitude 5450. Table 12. Wireless module specifications Description Option one Option two Model number... -
Page 19: Audio
For instructions on how to find your computer's International Mobile Equipment Identity (IMEI) number, search in the Knowledge Base Resource at www.dell.com/support. Audio The following table lists the audio specifications of your Latitude 5450. Table 14. Audio specifications Description Values Audio controller Waves MaxxAudio Pro 13.0... -
Page 20: Storage
M.2 2230 Self-Encrypting solid state PCIe Gen4 NVMe, up to 64 Gbps 512 GB drive Keyboard The following table lists the keyboard specifications of your Latitude 5450. Table 16. Keyboard specifications Description Values Keyboard type ● Standard backlit AI hotkey keyboard ●... -
Page 21: Keyboard Function Keys
Launch Copilot in Windows NOTE: If Copilot in Windows is not available on your computer, the CoPilot key launches Windows Search. For more information about Copilot in Windows, search in the Knowledge Base Resource at www.dell.com/support. Specifications of Latitude 5450... -
Page 22: Camera
For example, if you press 2, 2 is displayed; if you press Shift and 2, @ is displayed. Camera The following table lists the camera specifications of your Latitude 5450. Table 19. Camera specifications Description... -
Page 23: Touchpad
For more information about touchpad gestures are available ● Windows, see the Microsoft Knowledge Base article at support.microsoft.com. ● Ubuntu, see ubuntu.com/support. Power adapter The following table lists the power adapter specifications of your Latitude 5450. Table 21. Power adapter specifications Description Option one Option two... -
Page 24: Battery
Operating and storage temperature ranges may differ among components, so operating or storing the device outside these ranges may impact the performance of specific components. Battery The following table lists the battery specifications of your Latitude 5450. Table 22. Battery specifications Description... - Page 25 0% to 0% to 100% RSOC time from 0% to time from 0% to on using the Dell Power 100% RSOC is 4 is 4 hours. 100% RSOC is 4 100% RSOC is 4 Manager application. For hours.
-
Page 26: Display
CAUTION: Dell recommends that you charge the battery regularly for optimal power consumption. If your battery charge is completely depleted, connect the power adapter, turn on your computer, and then restart your computer to reduce the power consumption. -
Page 27: Fingerprint Reader (Optional)
Accelerometer in the base: ST Micro LIS2DW12TR Accelerometer in the hinge-up (Upsell config with Emza/ALS/IR camera): ST Micro LNG2DMTR GPU—Integrated The following table lists the specifications of the integrated Graphics Processing Unit (GPU) supported by your Latitude 5450. Table 26. GPU—Integrated Controller... -
Page 28: Gpu-Discrete
GPU—Discrete The following table lists the specifications of the discrete Graphics Processing Unit (GPU) supported by your Latitude 5450. Table 27. GPU—Discrete Controller Memory size Memory type NVIDIA GeForce RTX 2050 4 GB GDDR6 External display support The following table lists the external display support for your Latitude 5450. -
Page 29: Smart-Card Reader
Smart-card reader Contactless smart-card reader This section lists the contactless smart-card reader specifications of your Latitude 5450. This module is only available in computers shipped with Smart-card readers. Table 30. Contactless smart-card reader specifications Title Description Dell ControlVault 3 Plus Contactless... - Page 30 DesFire D8P 1456CSGMN iCLASS MIFARE Px GM49Y 2623BNPGGBNAB iCLASS MIFARE Px 8M1L iClass SEOS JW 5006PGGMN Crescendo iCLASS Px G8H iCLASS Seos IY SEOS JMC4 J1Y 5806VNG1NNN4 SEOS Key FOB 5266PNNA SEOS Clamshell 5656PMSAV SEOS + Prox 5106RGGMNN Specifications of Latitude 5450...
- Page 31 TOP DL GX4 144K card Sony Felica RC-S962 Felica RC-S965 Felica RC-S966 PIVKey C910 PKI NIST PIV1 IDENTIV PIV programmed cards uTrust Transport cards Oyster (London) MIFARE DESFire T-Money (Korea) Octopus Card (Hong Kong) SUICA (Japan) Specifications of Latitude 5450...
-
Page 32: Contacted Smart-Card Reader
EV1Card 8K Tap and do - ISO 15693 - Tag-it Plus HID I-code ISO card Contacted smart-card reader The following table lists the contacted smart-card reader specifications of your Latitude 5450. Table 34. Contacted smart-card reader specifications Title Description Dell ControlVault 3 Plus Contacted... -
Page 33: Operating And Storage Environment
Dell ControlVault support Device connects to Dell ControlVault for usage and processing Operating and storage environment This table lists the operating and storage specifications of your Latitude 5450. Airborne contaminant level: G1 as defined by ISA-S71.04-1985 Table 35. Computer environment Description...
