MOTIF6 / MOTIF7 / MOTIF8
This document is printed on chlorine free (ECF) paper with soy ink.
SY
011580
MOTIF6 20010630-230000
MOTIF7 20010630-255000
MOTIF8 20010801-325000
MUSIC PRODUCTION SYNTHESIZER
SERVICE MANUAL
CONTENTS
SPECIFICATIONS .............................................................................. 3
CIRCUIT BOARD LAYOUT ................................................................. 5
PANEL LAYOUT .................................................................................. 8
WIRING ............................................................................................. 14
DISASSEMBLY PROCEDURE (MOTIF6, MOTIF7) ......................... 16
DISASSEMBLY PROCEDURE (MOTIF8) ........................................ 23
LSI PIN DESCRIPTION .................................................................... 37
IC BLOCK DIAGRAM ........................................................................ 43
CIRCUIT BOARDS ........................................................................... 47
TEST PROGRAM ....................................................................... 60, 76
ERROR MESSAGES .................................................................. 73, 90
OS VERSION UPDATE .............................................................. 75, 92
MIDI IMPLEMENTATION CHART
PARTS LIST
BLOCK DIAGRAM
OVERALL CIRCUIT DIAGRAM
MOTIF8
MOTIF7
MOTIF6
HAMAMATSU, JAPAN
1.498K-0053 K
Printed in Japan 2001.07
