Updating Adapter Firmware

Each adapter card is shipped with the latest version of qualified firmware at the time of
manufacturing. However, NVIDIA issues firmware updates occasionally that provide new features and
bug fixes. To check that your card is programmed with the latest available firmware version,
download the mlxup firmware update and query utility. The utility can query for available NVIDIA
adapters and indicate which adapters require a firmware update. If the user confirms, mlxup
upgrades the firmware using embedded images. The latest mlxup executable and documentation are
available from http://www.nvidia.com > Products > Software > Firmware Tools.
Firmware Update Example
[server1]# ./mlxup
Querying Mellanox devices firmware ...
Device Type: ConnectX-5
Part Number: MCX545M-ECAN
Description: ConnectX®-5 VPI network interface card for OCP with Multi-Host, with host management, EDR IB
(100Gb/s) and 100GbE, single-port QSFP28, PCIe3.0 x16, no bracket.
PSID: MT_2190110032
PCI Device Name: 0000:06:00.0
Base GUID: e41d2d0300fd8b8a
Versions: Current
FW 16.00.0000
Status: Up to date
Device Type: ConnectX-5
Part Number: MCX545M-ECAN
Description: ConnectX®-5 VPI network interface card for OCP with Multi-Host, with host management, EDR IB
(100Gb/s) and 100GbE, single-port QSFP28, PCIe3.0 x16, no bracket.
PSID: MT_2170110021
PCI Device Name: 0000:07:00.0
Base MAC: 0000e41d2da206d4
Versions: Current
FW 16.20.1000
Status: Update required
Perform FW update? [y/N]: y
Device #1: Up to date
Device #2: Updating FW ... Done
Restart needed for updates to take effect.
Log File: /var/log/mlxup/mlxup-yyyymmdd.log
Available
16.00.0000
Available
16.24.1000
