- Page 1 DIGITAL INSTRUMENTS S507 Series TECHNICAL MANUAL STEIEL Elettronica S.r.l. – Viale Europa, 24 – 35020 Ponte San Nicolò – PADOVA ITALY Tel. +39 049.8961488 – Fax +39 049.8960184 – www.steiel.it – info@steiel.it Certified Company, according to UNI EN ISO 9001 standards...
- Page 2 The manufacturer can modify the instrument or the technical manual without advanced notice. Warranty All STEIEL products are warranted for a period of 12 months from the delivery date. Warranty is not valid if all instructions of installation, maintenance, and use, are not strictly followed by the user.
-
Page 3: Table Of Contents
TABLE OF CONTENTS PACKING LIST ..........................4 INTRODUCTION AND PRINCIPLE OF OPERATION ............... 4 TECHNICAL DATA ........................... 5 MECHANICAL DIMENSIONS ......................6 KEYBOARD, LED AND DISPLAY ..................... 6 ELECTRICAL CONNECTIONS ......................7 START-UP ............................8 CONFIGURATION ..........................9 LIST OF PARAMETERS ........................9 MEANING OF PARAMETERS ...................... -
Page 4: Packing List
Errors and alarms are shown directly on the display, and configuration and calibration data are stored in the non-volatile memory for at least 10 years. The S507 series includes several models for measuring the following parameters: pH/redox chlorine with open amperometric cell (CLE11 / CLE12) ... -
Page 5: Technical Data
TECHNICAL DATA Common characteristics for all models Power Supply 230 V~ ±10% 50-60 Hz (115 or 24 Vac ±10% 50-60 Hz, or 24 V- ±10% upon request) Power Consumption 7 VA max (models with relay output) 70 VA (models with K1 configured as “dosing-shot”) Protections PTC fuse appropriate to the power supply voltage;... -
Page 6: Mechanical Dimensions
MECHANICAL DIMENSIONS Note: all dimensions are in mm. KEYBOARD, LED AND DISPLAY START/STOP key Enable / disable all outputs (relays, pump magnet, mA output) CAL/MENU key Allow to enter configuration and calibration modes [+] key While in normal mode, show the "GAIN" value (amplification factor); in calibration mode increase the displayed value [-] key While in normal mode, show the "OFFSET"... -
Page 7: Electrical Connections
ELECTRICAL CONNECTIONS For correct electrical connections always refer to the rear panel pad printing, specific for each model. The above figure represents the pH/RX model version. The difference among different models is the input signal terminal block (pins 20 to 23), while the remaining connections are the same for all models. -
Page 8: Start-Up
Notes: • The maximum load for relay outputs is 3 A and 250 Vac resistive; with inductive load the maximum current is 1 A (with a 230 Vac power supply voltage it is possible to directly drive pumps or solenoid valves up to 200 VA). •... -
Page 9: Configuration
CONFIGURATION This section describes the operating procedure for configuring editable parameters from the keyboard. 1) Press and hold the CAL/MENU key for at C A L I B R A T . least 2 seconds to enter the configuration / ... - Page 10 PAR. Description Min value Max value Default Set value Energizing delay for K2 relay 0 sec (or hold time after cleaning, seconds) De-energizing relay for K2 relay 0 sec Starting delay 0 min mA output type Starting value for mA output -1000 2000 0.00 pH...
-
Page 11: Meaning Of Parameters
PAR. Description Min value Max value Default Set value 00.0 µS Starting value for mA output -1000 2000 199.9 µS Full scale value for mA output -1000 2000 Fault mA value 21.0 21.0 mA RS485 address Password Language UR/OR functioning Minimum threshold for K3 alarm -1000 4000... - Page 12 P02 (pH / RX / T, mA, chlorine) Reserved parameter, for future use. P02 (conductivity) TEMP. COMPENSATION COEFFICIENT αT S507 performs the temperature compensation accordingly with the following equation: αT C(t) = C(tref) * 1 + ─── * (t – tref) where: t = measured (or set) temperature, °C tref = reference temperature, °C (typically set at 25°C, parameter P03) αT = temperature compensation coefficient, %/°C (parameter P02)
- Page 13 threshold (P08), then starts to pulse slowly till the maximum injection frequency (P05) when the maximum threshold value (P09) is reached. This mode allows a gradual reagent injection and avoids big rushes. 4 = Downwards proportional control (dosage decreases as measurement value increases); the K1 relay energizing time is at its maximum (or always ON if measurement is below the minimum threshold (P08), and decreases gradually to its minimum (or always OFF) when the maximum threshold (P09) is exceeded;...
- Page 14 In case of proportional control (PWM), this parameter is used to enter the period (base time), in seconds. If P07=5, this parameter allows to set the washing time (minutes). DE-ENERGIZING DELAY FOR RELAY K1 This parameter allows to enter a delay time (in seconds) for de-energizing relay K1 if it is configured with working type option 1 or 2.
- Page 15 The below diagrams show the functioning of the two automatic cleaning modes. Measure hold P12=5 Parameter Pause Cleaning Measure Pause Cleaning Measure time time frozen time time frozen IN AUX Measure P12=6 hold Parameter Cleaning Measure Cleaning Measure time frozen time frozen MIN THRESHOLD FOR RELAY K2...
- Page 16 RS485 ADDRESS This parameter is used only for special models featuring an RS485 port and identifies each device with a unique address for being recognized within an RS485 network, including several S507 controllers and a PC with proper management software. PASSWORD The user can enter a protection password to avoid intervention by non-authorized personnel.
-
Page 17: Control Examples
(P31) FULL SCALE VALUE FOR MEASURE 1 This parameter is available only for model with mA input and represents the value corresponding to the full scale (20 mA). The parameter is factory set accordingly with customer indications and should not be modified! (P32) DECIMAL POINT AND MEASURE UNIT FOR MEAS. -
Page 18: Additional Visualizations
ADDITIONAL VISUALIZATIONS Pressing the [+] and [-] keys while in normal mode, the following values are displayed: pH meter key [+] gain factor (0.667 to 1.428) key [-] offset, pH units at 25°C (-1.50 to 1.50) redox meter key [+] gain factor (1.000 –... -
Page 19: Errors
ERRORS When an error is detected (including START/STOP key pressed), the LED ON starts blinking, the mA output provides the fault current value set in P21, and the display shows the corresponding error message, as listed here below: WARNING 1 - RELAY K1 DISABLED No working mode has been configured for K1 output, but the instrument works normally. -
Page 20: Ph Input Specifications
pH INPUT SPECIFICATIONS ELECTRICAL CONNECTIONS FOR pH-METER The signal comes from the electrode through a coaxial cable, with maximum recommended length of 20 meters (for longer cables, please contact the manufacturer). The electrode input is on removable terminal block: connect the coaxial cable core to terminal 22, and the shield to terminal 23 (Note: remove any black conductive plastic between the core and shield of the cable). -
Page 21: Redox Input Specifications
Note: If you attempt to calibrate the offset at a pH value too different from pH 7, or to calibrate the gain with a buffer solution too close to pH neutrality, the instrument shows the “CALIBRATION ERROR!” message and does not save the calibration data. REDOX INPUT SPECIFICATIONS ELECTRICAL CONNECTIONS FOR REDOX METER The signal comes from the electrode through a coaxial cable, with maximum recommended length of... -
Page 22: Residual Chlorine Input Specifications
RESIDUAL CHLORINE INPUT SPECIFICATIONS ELECTRICAL CONNECTIONS The signal comes from the amperometric cell (other cells upon request) through a 2-pole cable, with maximum recommended length of 5 meters (for longer cables, please contact the manufacturer). The cell input is on removable terminal block: connect the Pt (or Au) cell terminal to the device terminal 22, and the Cu cell terminal to the device terminal 23. -
Page 23: Cac (Or Cp) Cell Input Specifications
7) Wait for stable reading (approx. 5 minutes) 8) Use the colorimeter for measuring the chlorine concentration in the water exiting from the probe- holder. 9) Press and hold CAL for at least 2 seconds C A L I B R A T . -
Page 24: Calibration Of The Cell
CALIBRATION OF THE CELL To calibrate the cell, a colorimeter for measuring the chlorine concentration in aqueous solutions is needed (with DPD1 method). If the electrochemical calibration is also required, a carbon filter is needed. Run instrument and cell for at least 6 hours with chlorinated water, containing an average chlorine working concentration. -
Page 25: Conductivity / Resistivity Input Specifications
CONDUCTIVITY / RESISTIVITY INPUT SPECIFICATIONS ADDITIONAL TECHNICAL INFO The electronic precision of the conductivity measurements is better than 1%, and the repeatability is better than 0.2% FS, without temperature compensation (resistive calibration). The temperature compensation introduces an additional error of 0.3% FS and is performed through the PT100 input. The temperature sensor may be a probe separated from the conductivity cell (e.g. -
Page 26: Electrochemical Calibration Of Conductivity Meter
ELECTROCHEMICAL CALIBRATION OF CONDUCTIVITY METER The electrochemical calibration allows to compensate errors due to the cell-instrument connection cable and to the mechanical error of the cell constant. If the temperature compensation feature is used, immerse the Pt100 sensor into the solution close to the cell, or anyway at the same temperature. -
Page 27: Standardized Input Specifications
STANDARDIZED INPUT SPECIFICATIONS ELECTRICAL CONNECTIONS FOR STANDARDIZED INPUT The signal comes from the transmitter (or transducer) through a 2 or 3-pole cable, that must be shielded if longer than 25 meters. Connections are made on removable terminal block as follows: 1. -
Page 28: Turbidity Meter Specifications
TURBIDITY METER SPECIFICATIONS ELECTRICAL CONNECTIONS FOR TURBIDITY CELL The signal comes from the CTS07 (or CTS96) cell through a 2-pole cable, that must be shielded if longer than 25 meters. Connections are made on removable terminal block as follows (also see instrument rear panel): o terminal 21 (IN-), negative input = terminal (-) of the CTS07 cell o terminal 22 (IN+), positive input = terminal (+) of the CTS07 cell If a shielded cable is used, connect the shield to the terminal 21 on the instrument side, and leave it... -
Page 29: Temperature Input Specifications
TEMPERATURE INPUT SPECIFICATIONS ELECTRICAL CONNECTIONS FOR TEMPERATURE INPUT The signal comes from a Pt100 sensor through a 2 or 3-wire cable, that must be shielded if longer than 15 meters. Connections are made on removable terminal block, at pins 24 and 25. If a sensor with 3-wire cable is used, connect to the same terminal the two wires of the same colour (internally short-circuited). -
Page 30: Troubleshooting
TROUBLESHOOTING Error Message Problem Solution ADVERT.1 Relay K1 disabled; the relay Set parameters from P07 to P11 has not been configured, but (see “Configuration” section) the instrument continues to operate ADVERT.2 Relay K2 disabled; the relay Set parameters from P12 to P16 has not been configured, but (see “Configuration”...
