GENERAL FEATURES

Maximum log length
Diameter of the flue collar
Recommended connector pipe diameter
Recommended chimney diameter
Required type of chimney
Baffle material
Alcove installation
Mobile home installation
Weight (without option)
Shipping weight (without option)
PSC Blower: PA08581 (wood only)
ECM Blower: PA08582 (wood only)
Filter - dimensions (Width x Height x Depth)
(included with optional blower assembly)
Filter - quantity
Particulate emission standard
USA standard (safety)
Canadian standard (safety)
** East-west: through the door you see the longitudinal sides of the logs; north-south: through the door you see the tips of the logs.
‡
Mobile home (Canada) or manufactured home (U.S.): The U.S. Department of Housing and Urban Development describes
"prefabricated homes" better known as "mobile homes" as follows; buildings constructed on fixed wheels and those transported on
temporary wheels/axles installed on a permanent foundation. In Canada, a mobile home is a dwelling in which the assembly of each
component is completed or substantially completed before the dwelling is moved to a location to be placed on a foundation, connected
to service facilities and which meets the CAN/CSA-Z240 MH standard.
6
‡
21 in (533 mm) / north-south**
6 in (152 mm)
6 in (152 mm)
6 in (152 mm)
CAN/ULC S629, UL 103 HT (2100 °F)
C-Cast or equivalent
Not approved
Not approved
635 (288 kg)
705 lb (320 kg)
1/3 HP, direct drive, 1 speed, up to 875 CFM
1/2 HP, direct drive, 1 speed, up to 875 CFM
14 in x 25 in x 2 in (356 mm x 635 mm x 51 mm)
1
EPA / CSA B415.1-10
UL 391
CSA B366.1
