- Page 1 INSTALLATION & OPERATING 41001.601 Form No. 3107225.025 11/97 Replaces 3107225.017) (French 3108628.003...
-
Page 2: Specifications
Your heat pump is designed to be easy to The Dometic Corporation will not be liable for any operate and to provide plenty of comfort. damages or injury incurred due to failure in following these instructions. -
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS NOTE: An under-counter compartment MUST BE pro- 4. Remove the heat pump from its carton. Inspect for vided for the heat pump installation. This compartment shipping damage. SHOULD ONLY BE USED FOR INSTALLING THE HEAT PUMP. 5. Locate the discharge air plenum. (FIG. 3). Using the template, cut the require hole or holes for your instal- 1. -
Page 4: Electrical Wiring
7. Now that your compartment is heat pump ready with all GRILLES AND REGISTERS holes cut, carefully slide the heat pump into position. For inside conditioned air supply, Dometic's discharge Using the hold-down clamps supplied, clip the clamps air kit must be used. -
Page 5: Thermostat Location
LOW VOLTAGE WIRING THERMOSTAT FACE PLATE 1. Route a four (4) conductor thermostat cable from the electrical box to the thermostat location. HEAT PUMP LOW VOLTAGE WIRES AND THERMOSTAT CONNECTIONS HEAT PUMP LEADS THERMOSTAT TERMINALS RC (12V DC) YELLOW COOL BLUE VIOLET HEAT PUMP... -
Page 6: Wiring Diagram
WIRING DIAGRAM...
