Carry Out Configuration; Set Response Behavior - MiniMax UniVario FMX5000 IR Ex Instructions For Use Manual

Configuration
5.2

Carry out configuration

DIP switches 1 to 4: Configuration setup
DIP switch 12345678
-XXXXXXX
1XXXXXXX
X-XXXXXX
X2XXXXXX
XX-XXXXX
XX3XXXXX
XXX-XXXX
XXX4XXXX
5.3

Set response behavior

DIP switches 5 to 8: Set response behavior
DIP switch 12345678
XXXX----
XXXX5678
XXXX5---
XXXX-6--
XXXX56--
XXXX--7-
INFORMATION
An impermissible setting causes a fault signal. In this case fire sensitivity Class 1 is
activated.
32
Meaning
Reed switch active
Reed switch inactive
Alarm latching during limit value operation / Discovery
during loop operation
Alarm non-latching during limit value operation / XP95
during loop operation
Not currently used
Not currently used
Optics test is switched on or switched off via SMX5000
Optics test is switched off
Meaning
Fire sensitivity configuration via SMX5000
Fire sensitivity configuration via SMX5000
Fire sensitivity in accordance with EN54 class 1
Fire sensitivity in accordance with EN54 class 2
Fire sensitivity in accordance with EN54 class 3
Fire sensitivity in accordance with EN54 class X
(50 m)
Instructions for use / UniVario
®
FMX5000 IR Ex / 912311 / 07-2023 / en_US
