DAIICIN
DAIKIN ROOM AIR CONDITIONER
OPERATION MANUAL
\.
MODELS:
F/G/MTKM35UV16W
F/G/MTKM50UV16U
F/G/MTKM60UV16U
FTKT35UV16W
FTKT50UV16V
FTKT60UV16U
FTKN35UV16W
FTKN50UV16V
A/D/F/G/MTKL35UV16W
A/D/F/G/MTKL50UV16V
A/D/F/G/MTKL50UV16U
A/D/F/GTKL60UV16U
F/GTKL71UV16T
A/F/G/MTKM50UV16VA
F/GTKC48UV16W
F/GTKC48UV16WA
A/F/M/GTKL35UV16WA
F/GTKU35UV16W
FTKF35UV16UA
�a ·
��
-
(!e,)
8
i,,.J
V
3P719813-1 P
3P719813-1 P
Advertisement
Table of Contents
Related Manuals for Daikin F
Summary of Contents for Daikin F
- Page 1 DAIICIN 3P719813-1 P DAIKIN ROOM AIR CONDITIONER OPERATION MANUAL �a · �� (!e,) i,,.J MODELS: F/G/MTKM35UV16W F/G/MTKM50UV16U F/G/MTKM60UV16U FTKT35UV16W FTKT50UV16V FTKT60UV16U FTKN35UV16W FTKN50UV16V A/D/F/G/MTKL35UV16W A/D/F/G/MTKL50UV16V A/D/F/G/MTKL50UV16U A/D/F/GTKL60UV16U F/GTKL71UV16T A/F/G/MTKM50UV16VA F/GTKC48UV16W F/GTKC48UV16WA A/F/M/GTKL35UV16WA 3P719813-1 P F/GTKU35UV16W FTKF35UV16UA...
-
Page 2: Safety Precautions
Safety Precautions &CAUTION • Keep this manual where the user can easily find it. • Read the precautions in this manual carefully before operating the unit. • Do not use the air conditioner for purposes other than • The precautions described herein are classified as WARNING ,::::\ those for which it is intended. -
Page 3: Name Of Parts
Read before Operation Name of Parts ■ Indoor Unit 1. Front panel 2.Air inlet 3. Air filter 4. Accessory filter* 5. Streamer unit * 6. Model name plate 7. Indoor temperature sensor: � • Detects the air temperature around the unit. , �... -
Page 4: Remote Controller
FTKl.71UV16T • Selects the operation mode. ARC484B16 GTKL71UV16T (DRY /COOUFAN) GTKL35/50/60UV16WN/U/U ARC484B33 GTKM35/50/60UV16W/U/U 9. ECONO button: FTKN35/50UV16WN ARC484835 A/F/MTKM50UV16VA ,FTKF35UV16UA ARC484B32 • ECONO operation. GTKM50UV16VA,GTKL35UV16WA ARC484B33 F/GTKC46UV16W ARC464B33 1 0.COANDA/STREAMER button: ARC484B33 F/GTKU35UV16W • COANDA/STREAMER operation. 11. TIMER CANCEL button: •... -
Page 5: Preparation Before Operation
Read before Operation Preparation before Operation &CAUTION Incorrect handling of batteries can result in injury from battery leakage, rupturing or heating, or lead to equipment failure. Please observe the following precautions and use safely. • If the solution from the batteries should get in the eyes, do not rub the eyes. Instead, immediately flush the eyes with tap water and seek the attention of a medical professional. - Page 6 Operation DRY. COOL. FAN STREAME� O�eration The air conditioner operates with the operation mode of your choice. From the next time on, the air conditioner will operate with the same operation mode. ■ To start operation 1. Press �ocE) and select an operation mode. • Each pressing of the button changes the mode setting in sequence. r-4:12:l-*-•7 L°...
- Page 7 • Press t;ECONO ) and � togetherfor about 5 seconds. • "wie" wie" will be displayed on the remote LCD.• I f a button is pressed while CHI L D LOCK is on,• blinks. □ To CANCEL the CHILD LOCK Press t;...
-
Page 8: Adjusting The Airflow Direction
• Automatic Right & Left airflow direction Control & The 3D airflow direction Control is not applicable for F /GTKC Series. - Page 9 Operation COANDA/POWER CHILL & ECONO Operations ECONO Operation COANDA Operation ECONO operation enables efficient operation Directs airflow upward.This function prevents air by limiting the maximum power consumption. from blowing directly at users. This function is useful to prevent the circuit ■...
- Page 10 Operation TIMER/GOOD SLEEP O peration Operation GOOD SLEEP Operations TIMER Timer functions are useful for automatically ■ To use GOOD SLEEP OFF TIMER operation. switching the air conditioner on or off in the 1. Press during COOL operation. •" ·c" morning or at night.
- Page 11 Note on the Inverter output and temperature dlsplay • • F.L. " displays as inverter output when the rated power consumption is exceeded. • • - - " may display for a short while after the air conditioner is turned on or at other times.
- Page 12 ■ Operation LED / 7 SEGMENT BRIGHTNESS Control Operation The brightness of the indicator lamp/ 7 Segment can be adjusted H(high), L(low), or OFF. To set the brightness setting mode. Press [<:•swiNG J for more than 5 second's. • is displayed on the LCD. ■...
-
Page 13: Care And Cleaning
Care Care and Cleaning &CAUTION • Before cleaning, be sure to stop the operation and turn off the circuit breaker. Units ■ Indoor unit and remote controller 1. Wipe them with a dry soft cloth. ■ Front panel 1. Open the front panel. •... -
Page 14: Air Filter
Care Care and Cleaning i'.hCAUTION • Do not touch the aluminium fins of the indoor unit. If you touch those parts, this may cause an injury. • When removing or attaching the front panel, use a robust and stable stool and watch your steps carefully. •... - Page 15 Care 1. Replace the old accessory filters with new � 's accessory filters. Accessory filter* Accessory Filter Filter type: Titanium apatite deodorizing air purifying filter/ Anti microbial filter a1n enance [M . The accessory filters can be renewed by washing them with water once every 6 months. We recommend replacing them once every 3 years.
-
Page 16: Troubleshooting
(OPERATION lamp is on) sudden large voltage fluctuations. It automatically resumes operation in about 3 minutes. Voltage range protection: 130V~285V Voltage range protection: 130V~265V for F/GTKL71 UV16T Models. ■ A sound is heard. A sound like flowing water • This sound is generated because the refrigerant in the air conditioner is flowing. -
Page 17: Check Again
Troubleshooting Troubleshooting Case Explanation The indoor unit gives out • The room odour absorbed in the unit is discharged with the airflow. We recommend you to have the indoor unit cleaned. Please consult your service centre. odour. ■ The outdoor fan rotates while Immediately after the air conditioner is stopped: •... -
Page 18: Disposal Requirements
Troubleshooting Troubleshooting Call your service centre immediately �WARNING--------------- ■ when an abnormality (such as a burning smell) occurs, stop operation and turn off the circuit breaker. Continued operation in an abnormal condition may result in problems, electric shock or fire. Consult your service centre. - Page 19 • A short beep indicates non-corresponding codes. • To cancel the code display, hold down (CANCEL) for about 5 seconds. The code display also cancels itself if the button is not pressed for 1 minute. DAIKIN INDUSTRIES, LTD. Head office: Osaka Umeda Twin Towers Sooth...
- Page 21 DAIKIN 3P719813-1 P DAIKIN ROOM AIR CONDITIONER INSTALLATION MANUAL ---- --_ r======= MODELS: F/G/MTKM35UV16W F/G/MTKM50UV16U F/G/MTKM60UV16U FTKT35UV16W FTKT50UV16V FTKT60UV16U FTKN35UV16W FTKN50UV16V A/D/F/G/MTKL35UV16W A/D/F/G/MTKL50UV16V A/D/F/G/MTKL50UV16U A/D/F/GTKL60UV16U F/GTKL71UV16T AJF/GIMTKM50UV16VA F/GTKC48UV16W F/GTKC48UV16WA A/F/M/GTKL35UV16WA 3P719813-1 P F/GTKU35UV16W FTKF35UV16UA...
- Page 22 Safety Precautions • The precautions described herein are classified as WARNING and CAUTION. They both contain important information regarding safety. Be sure to observe all precautions without fail. • Meaning of WARNING and CAUTION notices � WARNING Failure to follow these instructions proper1y may result in personal injury or loss of life. �...
-
Page 23: Precautions For Selecting A Location
Accessories ® ® ITEM ITEM QTY. Remarks Remarks QTY. ® ® Mounting plate Remote controller holder fixing screw (M3 x 20L 617" <D @ Mounting plate fixing screw (M4 x 25L) 4-Core wire (3. 7M) © ® Wireless Remote Controller Tie wrap ®... -
Page 24: Indoor/Outdoor Unit Installation Diagram
, Adlitioral relriger lllq �ral fir rufrlger nt 209' m makesurelllal pipe exaiedi� 10m in length conblll signals are <f 9.5 I propeny received by Gas pipe Diameter (mm) 12.7 15.9 Install the ® Accessory filter indoorunll. -
Page 25: Installation Tips
1) Remove the battery cover on the remote controller and cut the address jumper (J4). 2) Press � . � and ( J at the same time. MOOE f:::i , 3) Press select press ( MO DE (The indoor unit OPERATION lamp will blink for about 1 minute.) •... -
Page 26: Indoor Unit
Indoor Unit Installing The Mounting Plate • The mounting plate should be installed on a wall which can support the weight of the indoor unit. 1) Temporarily secure the mounting plate to the wall, make sure that the panel is completely level, and mark the boring points on the wall. -
Page 27: Installing The Indoor Unit
Indoor Unit Installing The Indoor Unit ( Ri g ht-Si d e, Ri g ht-Back or Ri g ht-Bottom Pi p i n g Open the front panel, open the Front grille (If Required), then open the service lid.(Refer to Installation Tips.) �... -
Page 28: Drain Piping
Indoor Unit Wiring 1) Strip wire ends (15mm). 2) Match wire colours with terminal numbers on indoor and outdoor unit's terminal blocks and firmly screw wires to the corresponding terminals with the screw. 3) Connect the earth wires to the corresponding terminals. Attach the earth wire so that it is not connected to the fan motor connector. - Page 29 Binding Of Insulation Pipe 1. The slit direction should be upward. Sectional view 2. It should be sealed with vinyl tape without any gap..,pipla,,,. � 3. Do not over tighten with vinyl tape. c, ..,,., ..&:.":'..
-
Page 30: Outdoor Unit
Outdoor Unit Installing The Outdoor Unit • When installing the outdoor unit, refer to "Precautions for Selecting a Location" and the "Outdoor Unit Installation Diagram". Flaring The Pipe End L'.t WARNING rrj1T CUI exactly at right angles. Remove burrs. /IJ+ll ':::, Incomplete flaring may result refrigerant gas leakage. -
Page 31: Drain Work
Outdoor Unit Pur g in g Air And Checkin g Gas Leaka g e � WARNING---------------------- • Do not mix any substance other than the specified refrigerant (R32) into the refrigeration cycle. • When refrigerant gas leaks occur, ventilate the room as soon and as much as possible. •... - Page 32 Trail Operation And Testing 1. Trial operation and testing • Check that the inter-unit wire is correctly connected. • Trial operation should be carried out in COOL operation. 1·1 Measure the supply voltage and make sure that It Is within the specified range. 1-2 Select the lowest programmable temperature.
- Page 33 210, 1st FLOOR, OKHLA INDUSTRIAL AREA, PHASE 3, DELHI-110020 Meaning of E-waste under E-Waste (Management) Rules,2022 (E-waste Rules) -Waste electrical and electronic equipment, whole or in part of reject from their manufacturing and repair process, which are intended to be discarded. Our product is RoHS compliant.
