This product is intended for household use only.
Please use this product in the right way to save power.
Please read these operating instructions and warranty card thoroughly and keep
them for future reference.
Please read the "Safety precautions" before use.
Thank you for purchasing the Panasonic product.
The appearance, color and pattern of the refrigerator are subject to the actual product.
Operating Instructions
Household Refrigerator
(Frost- Free Refrigerator)
Model NR-W631VC-TP
Advertisement
Table of Contents
Related Manuals for Panasonic NR-W631VC-TP
Summary of Contents for Panasonic NR-W631VC-TP
- Page 1 Please read these operating instructions and warranty card thoroughly and keep them for future reference. Please read the “Safety precautions” before use. Thank you for purchasing the Panasonic product. The appearance, color and pattern of the refrigerator are subject to the actual product. ...
-
Page 2: Table Of Contents
Content Features .....................3 Safety precautions ................4 Installation ..................7 Food storage ..................11 Name and function of control panel ..........12 Temperature control .................13 Function setting ................15 Warning ....................17 How to use refrigerator room.............18 How to use Prime Fresh Room, wide variable case ......20 How to use freezer room ..............21 Removing spare parts .............. -
Page 3: Features
Energy-saving navigation function, through the memory intelligent conversion of three operating modes, effectively achieve energy saving and power saving. Overhead compressor Panasonic's unique design moves the traditional bottom compressor to the top of the refrigerator, effectively optimizing the internal use of space. Wide variable case Upon your own living habits and seasonal changes, the temperature can be adjusted between 4˚C~-3˚C and -8˚C~-18˚C to keep the freshness and nutrition of... -
Page 4: Safety Precautions
Safety precautions Please be sure to follow these instructions In order to prevent the risk of serious injury and damage to property, please comply with the following important safety instructions. ■ The extent of possible harm caused by wrong usage is described by the following symbol. - Page 5 ■ Immediately disconnect power plug if you detect burning smell. ■ Please contact Panasonic service center if the LED is damaged and do not repair by your self. ■ Do not touch broken or cracked glass door, please contact Panasonic service center.
- Page 6 When disposing this product ■ Before taking the refrigerator to be disposed, please remove all the doors and opening seal to prevent locking a child inside. ■ This unit uses flammable refrigerant, and Cyclo-Pentane insulation, please discard it by proper method to avoid environmental impact or MUST other hazards.
-
Page 7: Installation
Installation Please install the refrigerator properly and safely to save electricity bills and suppress noise. Unpacking Remove the packing box, foam base and all fixing tapes. Proper installing location Do not locate the refrigerator exposing to direct sunlight and hot air which can suppress the decline in cooling capacity and electricity bill saving. - Page 8 Area around the installed unit Refer to the figure below for the size of the refrigerator and the required installation space. (Unit: mm)
- Page 9 Panasonic service center for door is lower door is lower adjusting by a qualified person. * For the first use, let the refrigerator standby after installation and leveling for more than 30 minutes before turning on the power to ensure the normal operation.
- Page 10 Moving or shifting Remove the ice tray, water or ice from the ice box. Unplug the power. Water outlet Remove front panel, adjusting foot and pull the refrigerator forward. Drain the water from the back drain tray. Place a ...
-
Page 11: Food Storage
Food storage After installing Clean the inside of the refrigerator Put the food when the refrigerator is cool enough. (Even if the refrigerator is plugged in, it is impossible to cool down immediately. It takes 4 hours for the refrigerator to cool down in hot summer) When storing food Clean the food... -
Page 12: Name And Function Of Control Panel
Name and function of control panel Starting use When the refrigerator is powered on for the first time, the control panel lights up, temperature display zone shows temperature for refrigerator room of 8°C, wide variable case of 8°C, freezer room of -12°C, left and right Prime Fresh Room of 8°C respectively, also corresponding display icons are fully bright and nanoe icon lights up until temperature display zone stops flashing for about 3-4 hours. -
Page 13: Temperature Control
Temperature control When the refrigerator leaves the factory, set temperature of the refrigerator room, left and right Prime Fresh Room, wide variable case, and freezer are respectively 4°C, 0°C, 0°C -3°C, -20°C. If you want to change the cooling capacity, you can adjust the temperature setting. - Page 14 Setting wide variable case temperature After unlocking, corresponding room display icon lights up when the wide variable case is selected and the temperature display zone flashes to display the set temperature. Press temperature setting button to set the Prime Fresh Room temperature. Each time you press the temperature setting button, the temperature drops by 1°C.
-
Page 15: Function Setting
Function setting Unlock the control panel Touch the control panel to light up the lamp, temperature display zone shall sequentially show temperature of refrigerator room, wide variable case, freezer room, Prime Fresh Room and such room icon shall be highlighted and nanoe X mode icon also lights up. - Page 16 nanoe X mode After unlocking, select nanoe X mode button, corresponding icon will display and nanoe X mode is selected. Nanoe water ions produced from nanoe X mode are very fine and created by moisture in cool air. Air outlet for Nanoe water ion is located at the back of Prime Fresh Room. ...
-
Page 17: Warning
Displaying cooling level standard: (compressor speed) Cooling level standard: (Compressor speed): ● Stop cooling ● Minimum cooling ● Medium cooling ● High cooling ● Maximum cooling (The compressor capacity capacity capacity capacity stops) (The compressor (The compressor (The compressor (The compressor runs at low speed) runs at medium... -
Page 18: How To Use Refrigerator Room
How to use refrigerator room LED lamp Glass tray LED lamp Door seal Door seal Rotating shelf Door rack Door rack Egg tray Egg tray Ag anti-bacterial Vegetable case device Left Prime Right Prime Fresh room Fresh room Bottle shelf Bottle shelf LED lamp for LED lamp... - Page 19 ROTATING SHELF Rotating shelf Open the rotating shelf Closing rotating shelf It is impossible to close the refrigerator door until the rotating shelf is closed. Note Please push the vegetable case back to the original place after usage (fully pushing until it sounds “click”). Smelly food should be store in airtight container or nylon wrap.
-
Page 20: How To Use Prime Fresh Room, Wide Variable Case
How to use Prime Fresh room, wide variable case LEFT AND RIGHT PRIME FRESH ROOM TRAY Left Prime Fresh room Right Prime Fresh room Temperature setting range of the left and right Prime Fresh Room is 4˚C~-3˚C. Left and right Prime Fresh Room are independent and you can set different temperature for them. -
Page 21: How To Use Freezer Room
How to use freezer room FREEZER ROOM Upper freezer drawer Middle freezer drawer Lower freezer drawer The temperature range of freezer room is between -17˚C~-25˚C. The upper freezer drawer is suitable for storing small food. The lower freezer drawer is suitable for storing big food. The food stored in the drawer does not exceed certain height, otherwise the drawer cannot be closed normally. -
Page 22: Removing Spare Parts
Removing spare parts Refrigerator room, Left and right Prime Fresh Room Glass tray Door rack, bottle shelf Vegetable case, drawers of left and right Prime Fresh Room Gently lift up the tray Gently push forward Pull the vegetable case, edge and remove it. and then pull it out. -
Page 23: Defrosting And Cleaning
2 to 3 days to dry the inside to avoid peculiar smell or mold. Note As the temperature in the freezer compartment rises during maintenance or cleaning, the preservation time of frozen food will be shortened. Please contact Panasonic service center if you have any query. ... -
Page 24: Q & A
Q & A After checking the following items, the refrigerator is still abnormal, please unplug the power plug and contact the Panasonic Service Center. The refrigerant flowing in the pipeline makes a sound, but this is a normal The refrigerator makes phenomenon. - Page 25 “H” and “[number]” at the minutes before plugging again) same time For example: H 01 Using the refrigerator when there is no abnormality. After following the above operations, the refrigerator is still abnormal, please contact the Panasonic Service Center.
- Page 26 Does ECONAVI mode operate normally? (This function is set to OFF at the factory) Is light sensor covered? Is it in a period of frequent use? ECONAVI Energy-saving Due to the learning and memory function, navigation mode has the ECONAVI mode will be automatically problem.
-
Page 27: List Of Accessories
List of accessories Quantity Number NR-W631VC-TP Part name Refrigerator Glass tray Vegetable case Left Prime Fresh room Right Prime Fresh room Door rack Bottle shelf Egg tray Ice tray Ice tray lid Upper freezer drawer Middle freezer drawer Lower freezer drawer... -
Page 28: Specification
Contact Center: E-mail: pmpc_csdcic@ph.panasonic.com Tel. No.: (02) 8706-7603 Text hotline: Globe/TM Users: Panasonic<space>message to 21584703 Smart/Sun/Talk’NText Users: Panasonic<space>message to 225654703 Website: www.panasonic.com/ph Panasonic Home Appliances Refrigerator (Wuxi) Co.,Ltd. 2021 All Rights Reserved. Issuance date: 4/2021 Printed in China W0420-1 ARAK0A207570...
