Assembly Sheet
BiG400 HALF-DEPTH WORKSTATION
COMPONENTS CHECK LIST:
A
UPRIGHT 1677mm H
Quantity: 2
F
SIDE BEAM
(for base)
(varies according to width)
Quantity: 2
K
CHIPBOARD
(for worktop)
Quantity: 1
If you have any missing components please take note of the part name and contact your supplier.
Workstations are safe when used responsibly. If in doubt, contact the supplier.
B
UPRIGHT 915mm H
Quantity: 2
G
FRONT & BACK BEAM
WORKTOP CENTRE SUPPORT
(varies according to depth)
Quantity: 7
L
CHIPBOARD
(for base)
Quantity: 1
C
Upright 746mm H
SIDE BEAM 305mm W
Quantity: 2
H
BASE CENTRE SUPPORT
(varies according to depth)
Quantity: 1
M
CHIPBOARD
JOINER
Quantity: 2
D
(for top shelf)
Quantity: 4
I
Quantity: 1
N
PLASTIC
PROTECTIVE FOOT
Quantity: 6
E
SIDE BEAM
(for worktop)
Quantity: 2
J
CHIPBOARD
(for top shelves)
Quantity: 2
O
PLASTIC
TOP CAP
Quantity: 6
1
