Electrical connection - circular plug-in connector
14.3 Type 8793 - designation of the circular plug-in
connectors and contacts
Operating voltage
and diverse signals
2
3
4
5
X1 - M12, 8-pole
circular connector
(Description see
"Table 14")
Fig. 24: Type 8793; designation of the circular plug-in connectors and contacts
Location of the switch:
Symbols for
switch position
Switch on
right
Switch on left
Fig. 25: Location of the switch; symbols for switch position
Process actual value
1
8
7
3
6
4 2
X5 - M8, 4-pole
circular connector
(Description see
"Table 16"
Location of the switch
Binary outputs
1
1
2 4
X4 - M8, 4-pole
socket
(Description see
"Table 15")
3
Functional earth FE
