SERVICE
LED TV
UE32J5000AK
LED TV
Chassis : UED51
Model
: UE32J5000AK
Manual
1. Precautions
2. Product specifications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
Contents

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UE32J5000AK and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung UE32J5000AK

Summary of Contents for Samsung UE32J5000AK

  • Page 1 LED TV Chassis : UED51 Model : UE32J5000AK SERVICE Manual LED TV Contents 1. Precautions 2. Product specifications 3. Disassembly and Reassembly 4. Troubleshooting 5. Wiring Diagram UE32J5000AK...

  • Page 2: Table Of Contents

    Contents 1. Precautions ......................1-1 1-1. Safety Precautions ......................1-1 1-1-1. Warnings ......................1-1 1-1-2. Servicing the LED TV ................... 1-1 1-1-3. Fire and Shock Hazard ..................1-1 1-1-4. Product Safety Notices ..................1-2 1-2. Servicing Precautions ..................... 1-3 1-2-1. General Servicing Precautions ................1-3 1-3.
  • Page 3 This Service Manual is a property of Samsung Electronics Co.,Ltd. © 2015 Samsung Electronics Co.,Ltd. Any unauthorized use of Manual can be punished under applicable All rights reserved. International and/or domestic law. Printed in Korea...

  • Page 4: Precautions

    1. Precautions 1. Precautions 1-1. Safety Precautions Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as electrical shock. 1-1-1. Warnings For continued safety, do not attempt to modify the circuit board. Disconnect the AC power and DC power jack before servicing.

  • Page 5: Product Safety Notices

    1. Precautions 1-1-4. Product Safety Notices Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from visual inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage, wattage, etc.

  • Page 6: Servicing Precautions

    1. Precautions 1-2. Servicing Precautions An electrolytic capacitor installed with the wrong polarity might explode. WARNING Before servicing units covered by this service manual, read and follow the Safety Precautions section of this manual. CAUTION If unforeseen circumstances create conflict between the following servicing precautions and any of the safety precautions, always follow the safety precautions.

  • Page 7: Static Electricity Precautions

    1. Precautions 1-3. Static Electricity Precautions Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some field-effect transistors. The following techniques will reduce the incidence of component damage caused by static electricity. Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your body by touching a known earth ground.

  • Page 8: Installation Precautions

    1. Precautions 1-4. Installation Precautions For safety reasons, more than a people are required for carrying the product. Keep the power cord away from any heat emitting devices, as a melted covering may cause fire or electric shock. Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature may cause fire.

  • Page 9: Product Specifications

    2. Product specifications 2. Product Specifications 2-1. Product information Model UE32J5000AK Front View * W : Width H : High D : Depth Detail View Color Front : BLACK(HAIR LINE) , Stand : MATT BLACK With Stand 741.0 x 460.2 x 150.5 mm / 29.2 x18.1 x 5.9 inches Dimensions 32"...

  • Page 10: Product Specification

    2. Product specifications 2-2. Product specification 2-2-1. Detailed Specifications NOTE Design and specifications are subject to change without prior notice. Item UE32J5000AKXZT General Information Product Series Country ITALY Display Screen Size 32" Resolution 1920 x 1080 Ultra Clear Panel Video Picture Engine HyperReal PQI (Picture Quality Index)
  • Page 11 2. Product specifications Item UE32J5000AKXZT Audio TV SoundConnect Smart TV Samsung SMART TV Apps Game Multi-Link Screen ACR (Advertisement) Info Widget Vertical Enhancement Connected EPG Smart Interaction Voice Interaction Voice Control Face recognition Motion control Convergence TV to Mobile - Mirroring...
  • Page 12 Bezel Type Slim Type Slim Front Color Black Light Effect (Deco) Stand Type Mini Arc Swivel (Left/Right) Additional Feature Samsung 3D 3D Converter Camera Built-in Instant On Processor 21:9 Immersive Picture Mode SCSA Support Accessibility Digital Clean View One Connect (Jack)
  • Page 13 Energy Efficiency Class Accessory 3D Active Glasses (Included) Remote Controller Model TM1240A Batteries (for Remote Control) Samsung Smart Touch Control (Included) Ultra Slim Wall Mount Supported Mini Wall Mount Supported Vesa Wall Mount Supported Floor Stand Support TV Camera (Included)

  • Page 14: Specifications

    2. Product specifications 2-2-2. Specifications Specifications „ Model UE32J5000AK Item Description Screen Size (Diagonal) 32 inches LCD Panel FHD 60Hz Display Resolution 1920 x 1080 Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω, internally terminated Input Sync Signal H/V Separate, TTL, P.

  • Page 15: Accessories

    2. Product specifications 2-3. Accessories NOTE • The items’ colors and shapes may vary depending on the model. • Cables not included in the package contents can be purchased separately. • The part code for some accessories may differ depending on your region. Product Description Code.

  • Page 16: Disassembly And Reassembly

    3. Disassembly and Reassemble 3. Disassembly and Reassembly This section of the service manual describes the disassembly and reassembly procedures for the LED TV. This LED TV contains electrostatically sensitive devices. Use caution when handling these components. WARNING 3-1. Disassembly and Reassembly Disconnect the LED TV from the power source before disassembly.
  • Page 17 3. Disassembly and Reassemble Description Picture Description Screws Remove ASSY STAND P-BASE (L/R). Remove Screws of COVER-REAR. Torque : 7~ 8Kgf.cm 6003-002755 Remove the COVER-REAR. Remove Screws of ASSY PCB MAIN. Torque : 7~ 8Kgf.cm 6001-003016 Remove the ASSY SPEAKER P (L/R). ASSY SPEAKER P (R/L)
  • Page 18 3. Disassembly and Reassemble Description Picture Description Screws Remove the LVDS Cable. LVDS Cable Completed disassembly. NOTE Reassembly procedures are in the reverse order of disassembly procedures.

  • Page 19: Disassembly And Reassembly_Cover-Rear

    3. Disassembly and Reassemble 3-2. Disassembly and Reassembly_COVER-REAR Description Picture Description Pull the Lower left(or right) corner of COVER- REAR. Opened that point. Pull the upper left(or right) corner of COVER-REAR. Opened that point. Don’t disassemble only using lower two point. It cause the breakage of RIB(panel).

  • Page 20: Troubleshooting

    4. Troubleshooting 4. Troubleshooting 4-1. Troubleshooting Previous Check „ Check the various cable connections first. Check to see if there is a burnt or damaged cable. Check to see if there is a disconnected or loose cable connection. Check to see if the cables are connected according to the connection diagram. Check the power input to the ASSY PCB MAIN.

  • Page 21: How To Check Fault Symptom

    4. Troubleshooting 4-2. How to Check Fault Symptom 4-2-1.No Power and No Video Power cord on. Cause : There did not supply the Check ‘Stand-By 13V’ power from Adapter. 13V appear at BD201? 0V to A19V (CN202 #1) Measure : Change adapter. Set On.
  • Page 22 4. Troubleshooting Location of Parts „ Main Board_Front Detail BD210 BD911 BD917 CN202 #1 PANEL_VCC...

  • Page 23: Factory Mode Adjustments

    4. Troubleshooting 4-3. Factory Mode Adjustments 4-3-1. Detail Factory Option NOTE If you replace the main board with new one, please change the factory option as well. The options you must change are "Type". UE32J5000AKXZT „ Model Name 32" Vendor Panel Code BN95-02130A...

  • Page 24: Entering Factory Mode

    4. Troubleshooting 4-3-2. Entering Factory Mode To enter ‘Service Mode’ Press the remote -control keys in this sequence : • If you do not have Factory remote control Power OFF INFO MENU MUTE Power On • If you have Factory remote control INFO Factory •...

  • Page 25: Factory Data

    4. Troubleshooting 4-3-3. Factory Data Option „ Factory Menu Name Data Range Factory Reset Type 32A6AF0JJ 32A6AF0JJ Local Set Select Local Local Set SW Model UJ4000 UJ4000/UJ5000/UJ4003 BOM Model 4000 4000/5000/4003 TUNER depending on the country (DVB-T/C) Ch Table NONE MRT Option Front Color Lvds Format...
  • Page 26 4. Troubleshooting Factory Menu Name Data Range CI Support ON/OFF OTA Support General General/OFF LEDMotionPlus Support ON/OFF Natural Mode Support ON/OFF Relax Mode Support ON/OFF HDMI/DVI SEL Select LCD/PDP LCD/PDP Wall Mount ON/OFF HV Flip HV Flip OFF/HV Flip/V Flip/H Flip FRC HV Flip Light Effect ON/OFF...
  • Page 27 4. Troubleshooting Factory Menu Name Data Range PEQ Inx WF Scale Num of Network Stream DP V Size Backend Device ECHO_FS ECHO_FS/PARMA BT_AUDIO_ON_OFF ON/OFF Config_AV_PATH V_HDMI IDENT TYPE 2134 V_HDMI PATH TYPE BACD V_EDID TYPE LCD_HD V_ATV CVBS_PORT_2 V_AV1 AV_COMP_G1 V_AV2 CVBS_PORT_3 V_COMP1...
  • Page 28 4. Troubleshooting Control „ Factory Menu Name Data Range EDID EDID ON/OFF ON/OFF EDID WRITE ALL Success EDID WRITE PC … EDID WRITE HDMI Success EDID WRITE HDMI1 … EDID WRITE HDMI2 … EDID WRITE HDMI3 … EDID WRITE HDMI4 …...
  • Page 29 4. Troubleshooting Factory Menu Name Data Range Num of ATV Num of SVIDEO Num of PC Num of DVI Num of OPTICAL Link Num of MEDIA Num of Tuner Num of PVR RECORD RF Remocon Support ON/OFF CDD mode … DPMS Support ON/OFF Num of IPTV CIP...
  • Page 30 4. Troubleshooting Factory Menu Name Data Range Cloning Shop Option Exhibition Mode ON/OFF 3D Cube ON/OFF Asia Option Sepco 120Hz ON/OFF Unbalance ON/OFF FMTransmitter Support ON/OFF FMTransmitter Carrier ON/OFF AF Level adjust TX Power Level Mono Last Memory ON/OFF H Shaking ON/OFF SOUND High Devi...
  • Page 31 4. Troubleshooting Factory Menu Name Data Range SPDIF PCM Gain -9dB FM M Prescale BTSC Mono Prescale BTSC stereo Prescale SAP Prescale A2 Ident High Thld A2 Ident Low Thld Carrier2 Amp High Thld Carrier2 Amp Low Thld Carrier2 SNR High THR Carrier2 SNR Low THR Audio-IP Test Ready...
  • Page 32 4. Troubleshooting Factory Menu Name Data Range FRC LVDS SSC MRR FRC LVDS SSC Period FRC LVDS SSC Modulation FRC DDR SSC ON/OFF ON/OFF FRC DDR SSC MFR FRC DDR SSC MRR FRC DDR SSC Period FRC DDR SSC Modulation DDR Margin A CTRL_OFFSET_0_3 A CTRL_OFFSET_D...
  • Page 33 4. Troubleshooting Factory Menu Name Data Range Signal Strength Bandwidth Frequency LNA Status Modulation Code Rate Hier Modulation Frequency Offset Timing Offset PLL Type DEMOD Type TPS Lock RS Lock Firmware Version ISDB-T FFT Size_1 Guard Interval_1 Freq.Offset_1 SNR_1 IF AGC_1 TMCC Lock_1 TS Packet_1 Master Lock_1...
  • Page 34 4. Troubleshooting Factory Menu Name Data Range B_BER_1 C_Modulation_1 C_Code Rate_1 C_Timer InterLeave_1 C_Segments Num_1 C_BER_1 „ Factory Menu Name Data Range Test Pattern Pattern Sel Logic Pattern Sel … Logic Level Sel … FRC Pre Test Pattern FRC Post Test Pattern SOC TCON Test Pattern SOC TCON Pattern Level SOC TCON FRC Pattern...
  • Page 35 4. Troubleshooting Factory Menu Name Data Range Jump Upgrade Failure Failure/Success MIC PROGRAM UPGRADE Failure Failure/Success Smart Hub Reset ER Count WD Count AR Count WIFI ER Count BT ER Count HDMI Stable Cnt Camera ER Count Power Fail Error Count Select Log Type MICOM Log View...
  • Page 36 4. Troubleshooting Factory Menu Name Data Range Tuner1 Sound AMP Failure Failure/Success HDMI Switch IC Failure Failure/Success USB HUB IC Failure Failure/Success WIFI Failure LVDS T-CON/FRC PCB Test Failure Failure/Success MOIP EcoSensor Voltage Device Self Test App Self Test EXT Sound Inspection Woofer Sound Inspection NONE ATV CH Inspection...
  • Page 37 4. Troubleshooting Factory Menu Name Data Range HDMI Sync DE/HV HDMI 3D DET HOT PLUG OFF HOLD TIME DVB CI TS Clock delay TC TS Clock delay S CI Control Buf ON TS Clock delay CPU CAL Data Backup_Copy … CAL Data Restore_Copy …...
  • Page 38 4. Troubleshooting Factory Menu Name Data Range 2nd_G_H 2nd_B_H White Balance R-Offset G-Offset B-Offset R-Gain G-Gain B-Gain WB-W2_R_Offset WB_W2_B_Offset WB_W2_R_Gain WB_W2_B_Gain WB-N_R_Offset WB_W2_N_Offset WB_W2_N_Gain WB_W2_N_Gain MGA On/Off R1_Gain G1_Gain B1_Gain R2_Gain G2_Gain B2_Gain R3_Gain G3_Gain B3_Gain R4_Gain G4_Gain B4_Gain R5_Gain G5_Gain B5_Gain R6_Gain...
  • Page 39 4. Troubleshooting Factory Menu Name Data Range G7_Gain B7_Gain R8_Gain G8_Gain B8_Gain R9_Gain G9_Gain B9_Gain R10_Gain G10_Gain B10_Gain Advanced „ 4-20...

  • Page 40: White Balance

    4. Troubleshooting 4-4. White Balance 4-4-1. MGA(Multipoint Grayscale Adjustment) MGA(Multipoint Grayscale Adjustment) DEVICES Type CA-210 32A6AF0VJ RGB Measurement Panel Inspection Spec. Levels Levels Code Check Check x(±) y(±) Gamma(±) 10 IRE 0.020 0.020 0.40 10 IRE 0x01 20 IRE 0.020 0.020 0.40 20 IRE...
  • Page 41 4. Troubleshooting Target Gamma 2.30 Panel Spec. ± Gamma 2.20 0.35 Contrast 20~128 Black 0.231 0.208 0.281 0.030 300000 Option 0.288 0.030 Target xy Auto 0.282 255 white 0.015 0.299 ACC x 26~255 0.015 ACC y x,y value Color Tone Target Spec.
  • Page 42 4. Troubleshooting DEVICES Type CA-310 32A6AF0VJ Panel Inspection Spec. RGB Measurement Levels Code Check Levels Check x(±) y(±) Gamma(±) 10 IRE 0.020 0.020 0.40 10 IRE 0x01 20 IRE 0.020 0.020 0.40 20 IRE 0x02 30 IRE 0.020 0.020 0.40 30 IRE 0x03 40 IRE...

  • Page 43: Software Upgrade

    4. Troubleshooting 4-5. Software Upgrade Software Upgrade can be performed by downloading the. latest firmware from samsung.com to a USB memory device. • Current Version - The software already installed in the TV. Software is represented as ‘Year/Month/Day_Version’. 4-5-1. How to Check the Software Version Use the Main Menu „...
  • Page 44 4. Troubleshooting Use the Factory Mode „ Access the factory mode T-N14LJDEUC-xxxx.x Option T-N14LJDEUC-xxxx.x Control T-N14LJDEUS-xxxx Debug E-Manual :NLDVBEU1H-xxxx EDID SUCCESS HDCP SUCCESS ADC/WB CALIB : AV/COMP/PC/HDMI/ Advanced Option : 32S6AH0JJ,EU_UK,4000,NONE DTP-SDAL-NT14L-xxxx-xxxx RFS:"NT14L xxxx" K/1 20xx-xx-xx KERNEL:xxx.xxxx,/Onboot: xxxx TCON Version:---- NSP-DTVTD-xxxx Model: UA32J4000 CIP SUCCESS...

  • Page 45: How To Upgade Software And Micom

    4-5-2. How to Upgade Software and Micom Insert a USB drive containing the firmware upgrade downloaded from samsung.com into the TV. Please be careful not to disconnect the power or remove the USB drive while upgrades are being applied. The TV will turn off and turn on automatically after completing the firmware upgrade.
  • Page 46 4. Troubleshooting Click the "ENTER" key. Click the "ENTER" key. Wait for upgrade complete. Check the Software Version. 4-27...

  • Page 47: Rear Cover Dimension

    4. Troubleshooting 4-6. Rear Cover Dimension DIMENSION 32J400* 32J500* 461.19 459.0 133.3 119.6 163.01 135.9 162.58 147.6 4-28...

  • Page 48: Wiring Diagram

    5. Wiring Diagram 5. Wiring Diagram 5-1. Wiring Diagram Main CN1401 Board CN202 CN302 Speaker T-CON Speaker FUNCTION& IR...

  • Page 49: Connector

    5. Wiring Diagram 5-2. Connector Main Board „ CN502 CN1101 CN401 CN501 CN1401 CN1301 OP301 CN1202_HD TU602_FN (TUNER) CN302 CN402 „ Main Board Pin Map CN1202_HD (to Panel) CN1401 (LED Driver) PANEL_13V_PW EVEN_TXCLK+_LVDS LED- PANEL_13V_PW EVEN_TXCLK-_LVDS LED+ PANEL_13V_PW DGND CN402 (FUNCTION) PANEL_13V_PW EVEN_TX2+_LVDS KEY_INPUT1...
  • Page 50 5. Wiring Diagram CN401_SC (SCART) CN1301_CI (PCMCIA) SC_SR_OUT SC_AV2_SR_IN PCM_DATA[3] PCM_CD1 SC_SL_OUT PCM_DATA[4] TSO_DATA[3] SC_R PCM_DATA[5] TSO_DATA[4] SC_FB PCM_DATA[6] TSO_DATA[5] SC_AV2_SL_IN PCM_DATA[7] TSO_DATA[6] SC_B PCM_CE1 TSO_DATA[7] IDENT_SC SC_CVBS_OUT PCM_ADDR[10] SC_AV2_CVBS_IN PCM_OE PCM_ADDR[11] PCM_IORD SC_G PCM_ADDR[9] PCM_IOWR PCM_ADDR[8] CH_START CN501_H1 (HDMI1) PCM_ADDR[13] CH_DATA[0] HDMI1_RX2+...

  • Page 51: Cables

    5. Wiring Diagram 5-3. Cables LVDS CABLE (Main - panel) FUNCTION ASSY CABLE P-FFC CABLE ASSY BOARD P Code 32" BN96-35462Y BN96-36076B Photo NOTE The code number of cable can be changed, see "Exploded Views and Parts List".

  • Page 52: Annex. Exploded View & Part List [Ue32J5000Akxzt Ts01]

    ANNEX. Exploded View & Part List ANNEX. Exploded View & Part List [UE32J5000AKXZT TS01] 1-1. Exploded View 1-1-1. Parts List Code No. Description & Specification Q’ty Remark BN95-02130A PRODUCT LCD-SDC; CY-JJ032BGLV1V/H,J5003,B BN96-37254A ASSY CHASSIS TOP P; Y15 J5003-32in,PC+ABS BN96-36076B ASSY BOARD P; J4003_Function_Assy BN61-12065A HOLDER-SIDE AV;...

  • Page 53: Electrical Parts List

    ANNEX. Exploded View & Part List 2-1. Electrical Parts List Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE) Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark UE32J5000AKXZT (TS01) R001A BN90-07497A ASSY COVER REAR;32J5003 SCREW 6001-002755 SCREW-MACHINE;BH,+,M3,L6,ZPC(BLK),SWRCH1 R001 BN63-13996D COVER-REAR;J5003 32"...
  • Page 54 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark TCON BN95-02146A ASSY T CON;LSF320HN05-K,F60Hz Flat Hybri ...4 BN97-09463A ASSY SMD;BN95-02146A ..5 0202-001830 SOLDER-CREAM;LFM-48W TM-HP,D20~38um,96.5 ..5 0404-001640 DIODE-SCHOTTKY;SS1060HEWS,60V,1000mA,SOD ..5 0406-001317 DIODE-TVS;SMAJ14A,15.6/-/17.2V,400W,SMA ..5 0406-001445 DIODE-TVS;RClamp7512N,2.7/2.8/2.9,300W,S ..5 0406-001578...
  • Page 55 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ..5 2011-001264 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,2..5 AD480 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,TP,1608 ..5 AD480 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,TP,1005 ..5 AD480 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 ..5 AD480 2203-001414 C-CER,CHIP;330nF,10%,50V,X7R,TP,2012 ..5 AD480 2203-002711 C-CER,CHIP;100nF,10%,25V,X7R,TP,1608 ..5 AD480 2203-005138...
  • Page 56 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...4 BN60-01060Z SPACER-TOP-UD;32J4003, CSOT,CONDUCTIVE F ...4 BN60-01214A SPACER-TOP-LR;32J4003, CSOT,CONDUCTIVE F ...4 AS080 BN63-07556X SHEET-COVER;F-LED 3D VE,PO-SHEET,T0.068, ...4 BN63-11875A SHEET-COVER;Y14 SF-LED,POLY*,0.068,W25,L ...4 AC157 BN64-03109A CHASSIS-TOP;Y15 J5003-32in,PC+ABS+MF15%, ..5 0103-010326...
  • Page 57 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...4 1203-008102 IC-POSI.FIXED REG.;S-13A1D12-E800,HSOP,8 ...4 1203-008103 IC-POSI.FIXED REG.;S-13A1D15-E800,HSOP,8 ...4 1203-008104 IC-POSI.FIXED REG.;S-13A1D18-E800,HSOP,8 ...4 1203-008105 IC-POSI.FIXED REG.;S-13A1D33-E800,HSOP,8 ...4 1203-008119 IC-DC/DC CONVERTER;SN1208017DDAR,SO Powe ...4 1203-008496 IC-BACKLIGHT DRIVER;BD9397EFV,HTSSOP-B40 ...4 1203-008498...
  • Page 58 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...4 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 ...4 2007-007132 R-CHIP;15Kohm,1%,1/16W,TP,1005 ...4 2007-007134 R-CHIP;39Kohm,1%,1/16W,TP,1005 ...4 2007-007137 R-CHIP;1.2Kohm,1%,1/16W,TP,1005 ...4 2007-007138 R-CHIP;27Kohm,1%,1/16W,TP,1005 ...4 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 ...4 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 ...4 2007-007231 R-CHIP;110Kohm,1%,1/10W,TP,1608 ...4 2007-007306...
  • Page 59 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark ...4 AD480 2203-001412 C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005 ...4 AD480 2203-001634 C-CER,CHIP;33nF,10%,50V,X7R,TP,1608 ...4 AD480 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,TP,1005 ...4 AD480 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608 ...4 AD480 2203-002443 C-CER,CHIP;0.33nF,10%,50V,X7R,TP,1005 ...4 AD480 2203-002711 C-CER,CHIP;100nF,10%,25V,X7R,TP,1608 ...4 AD480...
  • Page 60 ..5 0103-004609 RESIN ABS;HF-0680U,K21294,BK0007,1.5mm H BN96-35464M ASSY ACCESSORY MANUAL;UJ5* 6902-001964 BAG PE;LDPE,BIOBASED,T0.03,W200,L300,TRP BN68-00514K MANUAL FLYER-07,WARRANTY CARD;comm,Samsu BN68-02989A LABEL-PQS;ALL,ALL,Paper,30,65,WHITE,SEH BN68-04972E LEAFLET-04,REGULATORY GUIDE;ALL,SAMSUNG, BN68-07313U MANUAL USERS-01;UJ4003 UJ5003,ZT,ENG/DEU BN68-07382B LEAFLET-FICHE CARD;Europe,Europe,ENG,MOJ BN92-17212T ASSY LABEL;J5000,UJ5D BN68-06708E LABEL RATING;ALL,WW,PP,T0.05,93,73,Dark BN68-07035M LEAFLET-QSG;32" J5003,DTV,Europe,MOJO* BN92-18670C ASSY BOX;32J5003 BH68-00662A LABEL BOX-01;ALL MODEL,ART PAPER,60,110,...
  • Page 61 ANNEX. Exploded View & Part List Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark BN69-12339E BOX UNIT;32J5000-Arc,CB,A-01,SW2,W872,D1 BN92-18671A ASSY P/MATERIAL;32J5003 6902-002498 BAG ROLL;HDPE/PE FOAM,T0.5*,W650,L300M,T 6922-000013 BAND;PP,W18,L2300/L2900,TRP BN01-00039A FOIL-STRETCH-HOOD;LLDPE,T0.08,W930,L1400 AS080 BN63-10787F SHEET-COVER;UE22ES5000,PE,T4.0,W1020,L11 BN69-08447A PAD;COMM,CB,SW2,T3,W800,L1000,-,-,-,-,YE BN69-11348A CUSHION-SET;J5003,32in,EPS,KO 0103-005099 RESIN EPS;BASF303,Natural,Natural BN69-12515A PALLET-WOODEN;UE32J4000/5000/6200,WOOD,9 BN74-00008N...
