R32
INSTALLATION MANUAL
ENGLISH
AIR CONDITIONER (SPLIT TYPE)
Scan QR CODE to access installation and owner's manual on website.
https://www.toshiba-carrier.co.th/manuals/default.aspx
Manual are available in AR/BG/CZ/DA/DE/EL/EN/ES/ET/FI/FR/
HR/HU/IT/LT/LV/NL/NO/PL/PT/RO/RU/SK/SL/SV.
Indoor unit
RAS-B24B2KVG-E
Outdoor unit
RAS-24B2AVG-E
1133550134A
Advertisement
Table of Contents
Related Manuals for Toshiba RAS-B24B2KVG-E
Summary of Contents for Toshiba RAS-B24B2KVG-E
- Page 1 INSTALLATION MANUAL ENGLISH AIR CONDITIONER (SPLIT TYPE) Scan QR CODE to access installation and owner’s manual on website. https://www.toshiba-carrier.co.th/manuals/default.aspx Manual are available in AR/BG/CZ/DA/DE/EL/EN/ES/ET/FI/FR/ HR/HU/IT/LT/LV/NL/NO/PL/PT/RO/RU/SK/SL/SV. Indoor unit RAS-B24B2KVG-E Outdoor unit RAS-24B2AVG-E 1133550134A...
-
Page 2: Accessory Parts
ACCESSORY PARTS ACCESSORY PARTS Indoor Unit Part name Part name Installation plate × 1 Wireless remote control × 1 Battery × 2 Remote control holder × 1 Mounting screw × 6 Flat head wood screw × 2 Owner’s Manual × 1 Installation Manual ×... -
Page 3: Installation Diagram Of Indoor And Outdoor Units
INSTALLATION DIAGRAM OF INDOOR AND OUTDOOR UNITS INSTALLATION DIAGRAM OF INDOOR AND OUTDOOR UNITS For the rear left, bottom left and left piping Wall Hook Installation plate Cut out a piece of SPACER from indoor unit packaging box, roll it and insert between the indoor unit and wall to tilt the indoor unit for better operation. -
Page 4: Indoor Unit
INDOOR UNIT INDOOR UNIT • Space allows for moving range of the air inlet grille and horizontal louver in Installation Place operation above curtain rails, window cornice or other objects. (Unit : mm) • A place which provides the spaces around the indoor unit as shown in the diagram •... -
Page 5: Piping And Drain Hose Installation
Left-hand connection with piping Piping and Drain Hose Installation • Bend the connecting pipe so that it is laid within 43 mm above the wall surface. If the connecting pipe is laid exceeding 43 mm above the wall Piping and drain hose forming surface, the indoor unit may unstably be set on the wall. -
Page 6: Outdoor Unit
2. Put water in the drain pan and make sure that the water is drained out of Drainage doors. 3. When connecting extension drain hose, insulate the connecting part of extension drain hose with shield pipe. 1. Run the drain hose sloped downwards. Shield pipe NOTE •... -
Page 7: Refrigerant Piping Connection
Tightening connection Refrigerant Piping Connection Align the centers of the connecting pipes and tighten the fl are nut as far as possible with your fi ngers. Then tighten the nut with a spanner and torque Flaring wrench as shown in the fi gure. 1. - Page 8 Evacuating Packed valve handling precautions • Open the valve stem all the way out, but do not try to open it beyond the After the piping has been connected to the indoor unit, you can perform the stopper. air purge together at once. Pipe size of Packed Valve Size of Hexagon wrench AIR PURGE...
-
Page 9: Electrical Works
ELECTRICAL WORKS ELECTRICAL WORKS Model RAS-B24B2KVG-E Power source 50Hz, 220 – 240V / 60Hz, 220 – 230V Single phase Maximum running current 12.00 A Circuit breaker rating 20 A Power supply cable H07RN-F or 60245 IEC66 (2.0 mm or more) Connecting cable H07RN-F or 60245 IEC66 (0.75 mm2 or more) -
Page 10: Power Supply And Connecting Cable Connection
Power Supply and Connecting Cable Connection Power Supply Input at Outdoor Unit Terminal Block Indoor Unit Outdoor Unit Stripping length of the Connecting cable Connecting cable connect to 1 2 3 1 2 3 connecting cable Terminal block (L N 1 2 3) Earth line 50 mm 10 mm... -
Page 11: Gas Leak Test
OTHERS OTHERS Gas Leak Test Test Operation To switch the TEST RUN (COOL) mode, press [RESET] button for 10 seconds. (The beeper will make a short beep.) Check places for the indoor unit. OPERATION / RESET Button Check places for the outdoor unit.
