THE CONTROL PANEL

3 4 5
1
14.a
10 12
14
11 13
1. On/Off button
2. Start/Standby button
3. Half Load button
4. Programme button
5. Tablet Detergent button
6. Extra Drying button
7. Delay button
8. Extra Hygiene button
9. Programme Display
10. Half Load symbol
11. Tablet Detergent symbol
12. Salt Lack Warning symbol
13. Rinse Aid Lack Warning symbol
14. Programme Status Display
a- Washing Phase symbol
b- Rinse Phase symbol
c- Drying Phase symbol
d- End symbol
15. Remaining Time/Delay Time/
Programme Time Display
16. Delay symbol
17. Extra Drying button
18. Child Lock symbol
19. Extra Drying symbol
6 7 8
P P P P P P P P
2
9
N
14.b
14.c 14.d
16
15
17
Starting the Machine and Selecting a
Programme
Press the Power On/Off button (1), the
display (15) will show the most recently
used programme.
Select the programme most suitable for
your dishes using the Programme button
(4).
Additional functions (3, 5, 6, 7, 8) can also
be selected.
NOTE: Press the Half Load button
(3) to select the area of the dishwasher
containing dishes to be washed. You can
select both baskets, the upper basket only,
or the lower basket only. Press the button
until the symbol corresponding to the
basket contaning the dishes to be washed
illuminates. Dishes placed in other areas
18
will not be washed.
19
NOTE: Press the Tablet Detergent
button (5) when using a combined
detergent that contains salt, rinse aid or
other extras. The Tablet Detergent symbol
(11) will remain illuminated for as long as it
is selected.
NOTE: Press the Extra Drying
button (6) to add extra drying steps to the
programme. The Extra Drying symbol (19)
will illuminate.
NOTE: Press the Delay button (7)
before a programme starts, to delay the
programme start time. The Delay symbol
(16) will illuminate.
NOTE: Press the Extra Hygiene
button (8) to increase the temperature of a
wash. The Extra Hygiene symbol (17) will
illuminate.
Press the Start/Standby button (2) to start
the selected programme.
The display (14) will show the symbols
corresponding to the status of the
programme in operation. While the drying
symbol is displayed, the machine will
remain silent for 45 to 50 minutes.
EN - 17
