Introduction

The RUGGEDCOM RST2228 is a utility grade, fully managed, industrial Ethernet
switch designed to operate reliably in harsh environments. With a rugged metal
enclosure and an optional conformal coating, the RUGGEDCOM RST2228 provides a
high level of immunity to electromagnetic interference and heavy electrical surges,
and can withstand extreme temperatures.
Highly modular, the RUGGEDCOM RST2228 switch supports up to 28 electrical and/
or optical interfaces with data transfer rates of 10/100/1000 Mbps. This makes it the
ideal industry-standard switch for constructing electrical and/or optical line, ring, and
star topologies.
The RUGGEDCOM RST2228 switch is supported by RUGGEDCOM ROS, which provides
advanced Layer 2 networking functions, and advanced cyber security features.
1.1

Feature highlights

Extreme flexibility
•
•
•
•
Compact 1U form factor
•
Front loading modular design
•
Dual redundant smart power supplies
•
•
•
•
Reliability in harsh environments
•
•
RUGGEDCOM RST2228
Equipment Manual, 10/2023, C79000-G8976-1359-19
Hot swappable media modules
Support for up to a total of 28 non-blocking ports (six 4-port modules and four
fixed ports)
Mixture of fiber optic or copper Gigabit ports with up to 28 Gigabit Ethernet
ports, including 4 ports capable of 10 Gigabits.
Galvanized steel and aluminum construction
Space-saving design
Allows for simple, cost effective, in-field servicing and upgrading
HI voltage AC/DC: 88-300 VDC or 85-264 VAC
LO voltage DC: 10.5-15 VDC, 13-36 VDC or 36-72 VDC
Smart power supplies able to detect loss of input voltage
Load sharing of 45/55 percent during normal operation
Immunity to EMI and heavy electrical surges
Zero-Packet-Loss technology
