  • Page 1 Actros, Arocs, Antos Operating Instructions...
  • Page 2 Symbols WARNING Warning notes make you aware dangers which could pose a threat to your health or life, or to the health and life of others. Environmental note Environmental notes provide you with infor- mation on environmentally aware actions or disposal.
  • Page 3 Welcome to the world of Mercedes-Benz You can also use the smartphone App, Mercedes-Benz Guide for Actros, Antos or Familiarise yourself with your vehicle and Arocs: read the Operating Instructions before you start driving. This will give you greater driving pleasure and help you to avoid endangering yourself or others.

  • Page 5: Table Of Contents

    Contents Index ............4 At a glance ........... 33 Introduction ......... 26 Safety ........... 49 Opening and closing ......59 Driver's workstation ......77 Climate control ......... 123 On-board computer and displays ..137 ® FleetBoard ........203 Audio systems ........209 Driving mode ........
  • Page 6 Index AdBlue® tank ........306 1, 2, 3 ... Additional axle 4-wheel parking brake not applied Leading axle ........291 (display message) Leading/trailing axle (steerable) ..292 Yellow event window ..... 180 Starting-off aid ....... 291 9 gear transmission Trailing axle ........291 General notes ........

  • Page 7: Index

    Index Applying the parking brake (dis- Setting the switch-on time ..... 132 play message) Switch ..........132 Auxiliary heating Red event window ......195 Articulation angle ......308 Engine preheating ......133 General safety instructions .... 133 Ashtray ..........113 Immediate heating mode ....
  • Page 8 Index Brake lamp Beacon ..........41 Beds in the L cab Replacing bulbs ......105 Brake pads completely worn (dis- Climbing aids ........82 play message) Lower ..........85 Yellow event window ..... 178 Seat/berth combination ....86 Brake supply pressure too low (dis- SoloStar Concept ......
  • Page 9 Index Central locking system Flat tyre ......... 377 Important safety notes ....365 Exterior door lock ......64 Jack ..........366 Internal door lock ......65 Pump lever ........367 Problems (malfunction) ....70 Changing a bulb Reflective safety jacket ....366 Releasing the spring-loaded park- Foglamp (variant 1) ......
  • Page 10 Index After driving off-road or on con- Cold start ........... 322 struction sites ........ 298 Cold-climate package ....... 322 Automatic car wash ....... 347 Combination switch ......95 cleaning seat covers ...... 342 Overview .......... 47 Cleaning the exterior ..... 343 Compressed-air brake system Cleaning the interior ......
  • Page 11 Index Additive without antifreeze pro- Cup holders ........119 tection ........... 338 Cyclone dust prefilter ....... 352 Checking coolant level and top- ping up ........... 349 Coolant level low (display mes- Daytime driving lights sage) Automatic headlamp mode ....94 Yellow event window .....
  • Page 12 Index Dipped-beam headlamp Distance sensor Switching on/off ......94 Cleaning ......... 346 Dipped-beam headlamps Dirty (display message in the yel- Replacing bulbs ......102 low event window) ......180 Display Door lock ..........64 On-board computer ....... 144 Doors Outside temperature ...... 140 Access steps (entering and exit- Radio/navigation ......
  • Page 13 Index Driving systems Stopping ........237 Active Brake Assist 3 ..... 278 Technical data ....... 415 Cruise control ........ 269 Engine brake ........246 Distance control assistant ..... 271 Engine cooling faulty (display mes- sage) Introduction ........267 Lane Keeping Assist ...... 283 Yellow event window .....
  • Page 14 Index ESP deactivated, set normal level Hydraulic clutch actuation sys- (display message) tem ..........351 Foglamp Yellow event window ..... 180 ESP not available (display mes- Replacing bulbs (variant 1) .... 104 sage) Replacing bulbs (variant 2) .... 104 Foglamps Yellow event window .....
  • Page 15 Hydraulic clutch actuation system .. 351 (display message) Hydrodynamic clutch Yellow event window ..... 185 General notes ........ 259 Genuine Mercedes-Benz parts ... 27 Manoeuvring mode ......260 Green light Pulling away ........259 see Nightlight Yellow event window ..... 177...
  • Page 16 Index Reading lamp ........97 Manoeuvring level ......290 Replacing bulbs ......106 Operating with the multifunction Switch ..........96 key ........... 61 Operation (on-board computer) ..157 Raised (vehicles for large-capacity transport, level control) ....290 Jack Raised vehicle level (vehicles for Vehicle tool kit .......
  • Page 17 Transmission mode selection ..251 Introduction ........348 Mercedes star Malfunction Switching the illumination on/off ..98 Display (on-board computer) ..160 Mercedes-Benz Service Centre Malfunction message see Qualified specialist workshop Display (on-board computer) ..160 Minimum tyre tread depth ....398 Manoeuvring level Mirrors Level control ........
  • Page 18 Index Multifunction lever Oil change .......... 337 Overview .......... 47 Oil level Multifunction lever and gear indi- Checking (engine) ......354 cator On-board computer General notes ........ 249 Activating backup drive mode Multifunction lever ......249 (transmission shift system) .... 151 Multifunction steering wheel Activating/deactivating ATTEN- Adjusting .........
  • Page 19 Index Lane markings display (Lane Outside temperature display ... 140 Keeping Assist) ......150 Layout ..........144 Menus at a glance ......146 Panic alarm .......... 68 Monitoring info ......159 Parking brake Notes on messages ....... 163 Four-wheel parking brake ....243 Operating level control ....
  • Page 20 Index Press the shunting switch briefly Replacing bulbs (driver's/co-driv- (display message) er's) ..........106 Grey event window ......165 Switching on/off (berth) ....97 Proper use ..........30 Switching on/off (driver's/co- Protection of the environment driver's) ........... 97 Switching on/off (front General notes ........
  • Page 21 Index Reducing agent Residual engine heat utilisation see AdBlue® Switching on/off ......130 Refill washer fluid reservoir (dis- Rest period play message) Checking (on-board computer) ..148 Restraint system Grey event window ......169 Reflective safety vest ....... 366 Introduction ........50 Refuelling Warning lamp (function) ....
  • Page 22 Index Semitrailer coupling sensor faulty Static seat ........79 Seat belt (display message) Correct usage ........52 Red event window ......193 Seat belts Sensor-monitored semitrailer cou- pling Cleaning ......... 342 Fastening ......... 53 Operation/notes ......310 Service Important safety guidelines ..... 51 Introduction ........
  • Page 23 Index Smoke detector Starting-off aid Function test ......... 114 Operation ........291 Starting-off aid active (trailer) (dis- General information ....... 114 play message) Replacing the battery ..... 115 Temporarily deactivating ....114 Yellow event window ..... 178 Snow chains Steer. characteristics of add. axle changed (display message) Checking the tyre clearance ..
  • Page 24 Index Symbols Tipper operation Radio/navigation ......214 After tipping ........333 Before tipping ........ 333 Tipping ........... 333 Tool kit compartment Technical data Vehicle tool kit and emergency Brake system ......... 415 equipment ........364 Compressed-air reservoir ....417 Topping up washer fluid ....351 Compressed-air system ....
  • Page 25 Index Transmission oil Monitoring (on-board computer) ..155 General notes ........ 338 Permissible difference in pres- Quality ........... 338 sure ..........416 Transmission shift system Pressure loss warning ....156 Activating backup drive mode (on- Table (single tyres) ......402 board computer) ......
  • Page 26 Index Tyre speed rating ......399 Warning triangle ........ 366 Warning/indicator lamps Engine diagnostics (BlueTec®5 vehicles) ........141 Underride guard (collapsible) ..293 Engine diagnostics (BlueTec®6 Undervoltage vehicles) ........142 Yellow event window ..... 185 Instrument cluster ......39 Unit of measurement Warnings Setting (on-board computer) ..
  • Page 27 Index Working-area lamp (upper) Driving and braking characteris- Replacing bulbs ......107 tics affected, visit workshop ..180 Wrench for cab tilting pump .... 367 Engine cooling faulty ...... 175 Engine faulty ........175 Engine maintenance due immedi- ately ..........174 Xenon headlamps Engine power output reduced ..
  • Page 28 You should Contact a Mercedes-Benz Service Centre if therefore adhere to the service intervals. you have any questions about equipment or all maintenance work should be carried out operation.

  • Page 29: Introduction

    Mercedes-Benz accepts no responsibility for for your vehicle may be rendered invalid. the use of such parts in Mercedes-Benz vehi- cles, even if they have been independently or Declarations of conformity officially approved.
  • Page 30 1999/5/EC. The operating safety of the engine cannot You can obtain further information from any be guaranteed in all situations. Mercedes-Benz Service Centre. Any tampering with the engine management Electromagnetic compatibility system in order to increase the engine power output will lead to the loss of warranty enti- The electromagnetic compatibility of the vehi- tlements.
  • Page 31 300). Mercedes-Benz in the event of deviations The on-board computer warns you in good from approved body/equipment mount- time about emissions-relevant malfunctions ing directives.

  • Page 32: Safety

    Introduction Mercedes-Benz recommends genuine Always have the following work on the vehicle Mercedes-Benz parts as well as conversion carried out at a qualified specialist workshop: parts and accessories that have been work relevant to safety approved by Mercedes-Benz expressly for the service and maintenance work respective type of vehicle.
  • Page 33 Introduction This data memory temporarily or permanently warranties saves technical information about: quality assurance the vehicle's operating state Using special diagnostic testers, the Service- Network employees (including manufacturer) events read out the data. If required, you can also faults receive additional information. In general, this technical information docu- After troubleshooting, the information in the ments the state of a component, of a module,...
  • Page 35 Cockpit ..........34 Overhead control panel ...... 36 Instrument cluster ......38 Switch units ......... 41 Multifunction steering wheel ..... 45 Combination switch and multi- function lever ........47...

  • Page 36: Climate Control

    Cockpit Cockpit Overview, left-hand-drive vehicle Function Page Function Page Switch units Folding table Air vents 24 V socket Light switch Parking brake Instrument cluster Main fuse carrier covering Multifunction steering Trays wheel Ashtray Multifunction lever Cup holder Climate control panel Ignition lock Radio and/or navigation Horn (air horn)
  • Page 37 Cockpit Overview, right-hand-drive vehicle Function Page Function Page Switch units Instrument cluster Air vents Light switch Folding table Multifunction lever Stowage spaces Horn (air horn) Climbing aids Ignition lock Lane Keeping/Attention Adjusts the multifunction Assist camera and rain/ steering wheel light sensor Cup holder Cigarette lighter...

  • Page 38: Fleetboard

    Overhead control panel Overhead control panel Overview, left-hand-drive vehicle Function Page Function Page Two-way radio, see the sep- Stowage compartments arate operating instruc- Smoke detector tions Digital tachograph, see the Stowage spaces separate operating instruc- Switch units tions ® FleetBoard DIN slot for:...
  • Page 39 Overhead control panel Overview, right-hand-drive vehicle Function Page Function Page Digital tachograph, see the Smoke detector separate operating instruc- Stowage compartments tions ® FleetBoard DIN slot for: Radio, see the separate Switch units operating instructions Stowage spaces Two-way radio, see the sep- arate operating instruc- tions...
  • Page 40 Instrument cluster Instrument cluster Displays Example: instrument cluster Function Page Function Page Speedometer Clock and outside temper- ature display On-board computer Fuel level Rev counter ® AdBlue level Total distance and trip dis- tance On vehicles without display A and B, scroll in the on-board computer to the Truck info menu window in the ß...
  • Page 41 Instrument cluster Indicator lamps Example: instrument cluster Function Page Function Page Warning and indicator l Active Brake Assist lamps in the speedome- k Stability Control Assist deactivated ; Engine diagnostics Á Stability Control Assist º Cab tilt lock À ASR (acceleration skid con- ¸...
  • Page 42 Instrument cluster Function Page Function Page K Main-beam headlamps U Side lamps à Continuous brake X Hydrodynamic clutch ! Parking brake An overview of the warning and indicator lamps in the status area of the on-board computer can be found in the "On-board computer and displays"...
  • Page 43 Switch units Switch units Cockpit Driver's workstation Function Page Function Page Switch units ¨ Panic alarm ã Active Brake Assist n Coolbox m Lane Keeping Assist þ Battery isolator switch Ø Level control: driving level q Anti-lock braking system ê Level control: raised driving â...
  • Page 44 Switch units Function Page Function Page 1 Manoeuvring mode z Windscreen heating à ASR (acceleration skid con- Switch unit trol system) D Loading tailgate, see the k Stability Control Assist separate operating instruc- tions £ Hazard warning lamps i Working-area lamp i Differential locks (switches off automatically after pulling away)
  • Page 45 Switch units Above the windscreen Driver's door Function Page Function Page Switch units Switch unit ¤ Opens the left-hand roller | Exterior mirror, left sunblind ~ Exterior mirror, right ¥ Closes the left-hand roller Í Adjusts the external mir- sunblind rors ¦...
  • Page 46 Switch units Co-driver's door Berth Function Page Switch unit p Co-driver's reading lamp c Interior lamps Function Page W Opens/closes co-driver's Reading lamp: bed/berth side window Switch panel: bed/berth Ë Locks the doors ÷ Auxiliary heating Ì Unlocks the doors Æ...
  • Page 47 Multifunction steering wheel Multifunction steering wheel Right-hand button group on the multifunction steering wheel Left group of buttons on the multifunction steering Function Page wheel Operating the driving Function Page systems: Operating the on-board computer: é Selects cruise control Selects the distance con- u To select the next main trol assistant menu/next entry in the...
  • Page 48 Multifunction steering wheel Function Page Operating the telephone: ; Makes or accepts a Telephone call/displays menu window = Ends or rejects a call/ activates voice control...
  • Page 49 Combination switch and multifunction lever Combination switch and multifunction lever Function Page Function Page Combination switch Automatic gearshift – transmission mode selec- Main-beam headlamps off tion o (when dipped-beam head- Automatic drive program lamps are switched on) with the economy, power, fleet, offroad fire-...
  • Page 51 Useful information ......50 Occupant safety ........50 Children in the vehicle ......55 Pets in the vehicle ......57...

  • Page 52: Useful Information

    If it is necessary to modify an airbag system deploy their protective function if all vehicle for a person with physical disabilities, contact occupants always: a Mercedes-Benz Service Centre for details. fasten their seat belts correctly page 52) adjust their seat properly ( page 78).

  • Page 53: Occupant Safety

    If a child younger than 12 years old and under 1.50 m in height is travelling in the vehicle: always secure the child in a child restraint system suitable for this Mercedes-Benz vehicle. The child restraint system must be...
  • Page 54 Mercedes-Benz recommends that you only Infants and children must never travel sit- use seat belts which have been approved ting on the lap of a vehicle occupant. In the...
  • Page 55 Occupant safety Fastening seat belts Observe the safety notes on seat belts page 51) and the notes on the correct use of the seat belt ( page 52). Press release button :, hold belt tongue ; firmly and guide it back towards belt outlet =.
  • Page 56 Occupant safety Important safety notes Objects in the vehicle interior may pre- vent the airbag from functioning cor- WARNING rectly. Before starting your journey and to If you deviate from the correct seat position, avoid risks resulting from the speed of the the airbag cannot perform its intended pro- airbag as it deploys, make sure that: tective function and can even cause addi-...

  • Page 57: Children In The Vehicle

    The cab deceleration and the direction of the replaced at a qualified specialist workshop. force are basically determined by: Mercedes-Benz recommends that after an the distribution of the force during the accident, you have your vehicle towed to a impact qualified specialist workshop.
  • Page 58 Children in the vehicle Child restraint system WARNING If you leave children unattended in the vehi- WARNING cle, they could set the vehicle in motion by, for If the child restraint system is incorrectly fit- example: ted on the seat position suitable for this pur- releasing the parking brake pose, it cannot perform its intended protec- shifting the transmission into neutral...

  • Page 59: Pets In The Vehicle

    Mercedes-Benz Service Centre. Observe the warning labels on the child restraint system. Pets in the vehicle If children are travelling in the vehicle, be sure to observe the notes on "Children in the Vehi-...
  • Page 61 Useful information ......60 Locking system ........60 Getting into/out of the vehicle ..70 Side windows ........71 Roof ............72 Roller sunblind ........75...

  • Page 62: Useful Information

    If a vehicle key is lost, obtaining a replace- ment is a time-consuming process. This key without remote control can only be done through a Mercedes-Benz key with remote control Service Centre. multifunction key Mercedes-Benz therefore recommends You can use the % and &...

  • Page 63: Locking System

    Locking system Multifunction key There is a rechargeable battery in the multi- function key. The rechargeable battery is Operating the multifunction key charged automatically when the ignition lock is in the driving position. Replace the rechargeable battery if it is malfunctioning page 68).
  • Page 64 Locking system To select a menu bar: press up or down on ß Vehicle check navigation button =. ® The display shows the levels of AdBlue To change a value or select an entry: Ø and fuel 6. Further information on press left or right on navigation button =.
  • Page 65 Locking system â Operation ö Comfort The display shows the axle loads and the The display shows h. Interior lighting, gross weight if: nightlight and ambient lighting can be switched on/off. Refer to the "On-board the vehicle is stationary computer and displays" section the driving level is active page 160) for further information on the ignition lock is in driving position,...
  • Page 66 Locking system Insert the integrated key into the lock of ä Multifunction key settings left-hand door d or right hand door e in position 2. The display shows Ì. You can adjust the standby and switch-off times. To unlock: turn the key to position 1. The corresponding door is unlocked.
  • Page 67 Locking system Interior door lock Observe the complete closing procedure when the convenience closing feature is oper- Unlocking using the door handle ating. When closing make sure that no parts of the body are in the closing area. WARNING Limbs could get trapped if they are in the sweep of the sliding sunroof/pop-up roof when opening and closing.
  • Page 68 Locking system Vehicles without ATA: press and hold the ATA monitors: & button on the remote control/multi- on the tractor vehicle: function key for approximately 2 seconds. the doors the exterior flaps Vehicles with ATA: press the & button the power supply on the remote control/multifunction key.
  • Page 69 Locking system Before ATA is primed Close the roof hatch, sliding sunroof or pop- up roof. Close the windows. Draw back the curtains. Close the exterior flaps. Detach/remove any loose objects in the cab, e.g. mascots or coat hangers. Priming and deactivating ATA ATA button with indicator lamp and panic alarm Remove the key from the ignition lock.
  • Page 70 Locking system WARNING Press the upper section of the , button While closing the side windows, body parts in for more than 2 seconds. (Not for the Neth- the closing area could become trapped. There erlands.) is a risk of injury. The vehicle is locked and all the turn signals When closing make sure that no parts of the flash three times.
  • Page 71 Replacing the battery The multifunction key battery is charged auto- matically via the ignition lock. A new rechargeable battery can be ordered at a Mercedes-Benz Service Centre. Remove integrated key ;( page 60). Insert integrated key ; into the multifunc-...

  • Page 72: Getting Into/Out Of The Vehicle

    Getting into/out of the vehicle Problems with the locking system Problem Possible causes/consequences and M Solutions When the ATA (anti- One of the monitored components has not been locked correctly. theft alarm system) is Switch off ATA ( page 66). primed, there is no Check that the monitored components are locked, e.g.: acknowledgement...

  • Page 73: Side Windows

    Side windows Use the EASY-ENTRY/EXIT system of the Opening/closing the side windows suspension seat ( page 79). Use grab handles : and steps ; when getting in and out of the vehicle. Side windows Important safety notes WARNING While opening the side windows, body parts could become trapped between the side win- Switch panel (example: driver's door) dow and the door frame as the side window...
  • Page 74 Roof Resetting the side windows Reset the side window after a voltage supply interruption or if a side window no longer closes or opens completely. Switch the ignition lock to the radio posi- tion. Press button : and/or ; until the corre- sponding side window is open.

  • Page 75: Roof

    Roof Closing the sliding sunroof manually During a malfunction or after the battery has been disconnected, you can also close the sliding sunroof or pop-up roof manually – slid- ing sunroof ( page 73), pop-up roof page 74). Reset the sliding sunroof after a malfunction or voltage supply interruption ( page 74).
  • Page 76 Roof Closing the pop-up roof manually the opposite end of the roof frame, then release it. Vehicles with BigSpace/GigaSpace cab: press the insect screen against the sliding sunroof until opening becomes visible. Pass Allen key = through the opening and insert it into the actuator.

  • Page 77: Roller Sunblind

    Roller sunblind Remove flat-blade screwdriver ; and Switch the ignition lock to the drive posi- replace it in the vehicle tool kit. tion. Vehicles with ClassicSpace cab: refit pro- To extend: briefly press the ¥ or § tective cap :. button downwards.
  • Page 79 Useful information ......78 Seats ............ 78 Beds in an L cab ........82 Berths in an M cab ......90 Adjusting the multifunction steer- ing wheel ..........91 Adjusting the external mirrors ..92 Lighting system ........93 Good visibility ........109 Voltage supply ........

  • Page 80: Useful Information

    Seats Useful information poses an increased risk of injury or even fatal injury. These Operating Instructions describe all the Adjust the seat properly before beginning models and standard and optional equipment your journey. Always ensure that the backrest of your vehicle that were available at the time is in an almost vertical position and that the of going to print.
  • Page 81 Seats Your vehicle may be equipped with different ! To prevent damage to the seats and the types of seats depending on the cab and the seat heating, observe the following notes: vehicle's equipment: Do not pour any fluid on the seats. If fluid static seat without suspension is poured on the seats, dry it as quickly as possible.
  • Page 82 Seats Observe the following instructions, as you Release the press studs. could otherwise damage the seat heating/ To set the belt height: press and hold the ventilation: button on belt sash guide :. do not leave any objects on the seat. Adjust belt sash guide : accordingly to suit your height.
  • Page 83 Seats Push the seat cushion forwards or back- Release levers E and F. wards in order to move it into the desired In setting the seat fore-and-aft adjustment, position. you can slide the seat forwards into the driving position again and engage it in Release lever H.
  • Page 84 Beds in an L cab Function seat Upper bed (car transporter with two beds) page 84) Foldable upper bed ( page 84) Lower bed ( page 85) Seat/berth combination ( page 86) SoloStar Concept ( page 88) Upper bed Climbing aids Before adjusting the seat, read the important safety notes about the seats.

  • Page 85: Beds In An L Cab

    Beds in an L cab Upper bed, wide fold the backrests of the driver's and co- driver's seats forward or adjust the seats WARNING further forward. The bed can otherwise hit A vehicle occupant on the bed while the vehi- the seats and damage both components.
  • Page 86 Beds in an L cab Adjust or fold the driver's and co-driver seat backrests forward. If necessary, move the driver's and co- driver seats sufficiently forward. To fold down: lift the bed up slightly, hold it in place and press release buttons on both buckles ;.
  • Page 87 Beds in an L cab wall brackets in the event of an accident. The bed folds down and may be damaged or may damage other components. Example: lower bed Folding up Adjust or fold the driver's and co-driver seat backrests forward. If necessary, move the driver's and co- driver seats sufficiently forward.
  • Page 88 Beds in an L cab Example: lower bed with safety net Place a maximum load of 500 N (50 kg) on the adjustable backrest. During your journey, only use the lower bed in conjunction with the safety net. Before using Pull up the adjustable backrest by loop : the bed, make sure you take notice of the and engage it in place.
  • Page 89 Beds in an L cab Lower berth Make sure that the seat backrest swinging range is not obstructed and that no one could become trapped. WARNING If you do not hold the seat backrest in place when folding it up or down, it will fall down. It could strike a vehicle occupant and cause body parts to become trapped.
  • Page 90 Beds in an L cab Upper berth Clip belt tongues B into seat belt buckles A on the right and left. Folding the seat backrest up to the fully reclined position Folding the seat backrest down to the upright position Lift up backrest ;...
  • Page 91 Beds in an L cab Folding the bed down/up WARNING A vehicle occupant on the bed while the vehi- cle is in motion cannot be restrained. There is a risk of serious or even fatal injuries. Only use the bed when the vehicle is station- ary.

  • Page 92: Berths In An M Cab

    Berths in an M cab Pull loop = on co-driver's seat :. Berths in an M cab The co-driver seat backrest is unlocked. Overview Fold down the backrest. The following berths may be fitted in the M cab: Standard berth, lower/padded stowage space ( page 90) Lower standard berth, split (...

  • Page 93: Adjusting The Multifunction Steering Wheel

    Adjusting the multifunction steering wheel Turn hook : 90° and unhook it from wall Turn hook : 90° and unhook it from wall retainer ;. bracket ;. Fold the berth down. Slide locking catch A down. Front ? and rear = berth sections are no To fold up: fold up the berth and press and longer engaged.

  • Page 94: Adjusting The External Mirrors

    Adjusting the external mirrors you when changing lanes, for instance. There is a risk of an accident. You should therefore always look over your shoulder to determine the actual distance from road users driving behind you. An incorrectly adjusted exterior mirror may impair visibility.

  • Page 95: Lighting System

    Lighting system Press the Í button forwards or back- If mirror heating is switched on and you wards, right or left, until the exterior mirror swing the exterior mirrors into the manoeu- is correctly set. vring position, mirror heating will be deac- tivated.
  • Page 96 Lighting system The light switch can be used to switch the causes of poor visibility such as spray. There vehicle lighting on or off. The main-beam is a risk of an accident. headlamps and the headlamp flasher are In such situations, turn the light switch to operated using the combination switch page 95).
  • Page 97 Lighting system The cornering lights switch on automatically Headlamp range control you are driving slower than 25 km/h and you indicate a turn or turn the multifunction steering wheel. you are driving between 25 and 40 km/h and turn the multifunction steering wheel. The cornering lights may briefly remain lit, however they will be automatically switched off after approximately 3 seconds at the lat-...
  • Page 98 Lighting system Turn signals Interior lighting Interior lighting switch To indicate: press and engage the combi- nation switch upwards to indicate right : Switch panel above the windscreen or downwards to indicate left ;. The appropriate turn signal lamps and the , or .
  • Page 99 Lighting system If you manually switch on the interior To switch the automatic control of the lights while the automatic control is interior lighting on/off switched on, the interior lights remain on To switch the nightlight (green) on/off until: To switch on/off or to dim the co-driver's reading lamp you open/close a door (delayed shut-off) To switch off all interior lights...
  • Page 100 Lighting system Switching the nightlight (green) on/off To switch on: press the upper section of the Ú switch. The nightlight is used as non-dazzle courtesy The indicator lamp in the Ú switch lighting while driving. comes on. To switch on/off: press button A. To switch off: press the lower section of the Ú...
  • Page 101 Dipped-beam head- H7 24 V time. Mercedes-Benz recommends that you lamps (halogen use Mercedes-Benz longlife bulbs for this pur- headlamps) pose. To prevent a short circuit, switch the light- Side turn signals, P 21/5 W 24 V...
  • Page 102 Interior lighting Mercedes-Benz recommends that you have headlamp bulbs replaced at a quali- Roof lamp: interior P 18 W24 V fied specialist workshop. lighting Swinging out the headlamps: variant 1...
  • Page 103 Lighting system If your vehicle is equipped with protective grilles in front of the headlamps, loosen screws : and swing the protective grille outwards in the direction of the arrow. Remove screw ;. Swing section of bumper : outwards in the direction of the arrow.
  • Page 104 Lighting system Dipped-beam headlamps and navigation Main-beam headlamps lights (halogen headlamps) Headlamp, variant 1 Halogen headlamps: variant 1 Headlamp, variant 2 Halogen headlamps: variant 2 Observe the notes on replacing bulbs Observe the notes on replacing bulbs page 99). page 99). Swing out the headlamps –...
  • Page 105 Lighting system Daytime driving lights Turn signal lamps Headlamp, variant 1 Headlamp, variant 1 Headlamp, variant 2 Headlamp, variant 2 Observe the notes on replacing bulbs Observe the notes on replacing bulbs page 99). page 99). Swing out the headlamps – variant 1 Swing out the headlamps –...
  • Page 106 Antos) Front foglamp (example: front foglamp with LED If you remove the front foglamp with the LED daytime running lamps, Actros) daytime running lamp, do not replace the bulb If you remove front foglamp : with LED day- for the LED daytime running lamp.
  • Page 107 Lighting system Rear bulbs Observe the notes on replacing bulbs page 99). Swinging away the protective grille Swing out the headlamp ( page 101). Remove the plug connector from bulb : of the front foglamp. Unscrew bulb : from the reflector anti- clockwise.
  • Page 108 Lighting system Reading lamp: bed/berth Brake lamp Reversing lamp Rear lamps Rear foglamp The licence plate lamp is behind the reflector unit. If the vehicle lamp cluster unit has LED mod- ules, do not replace the bulbs in the turn sig- nals, tail lamps, brake lamps or perimeter lamps.
  • Page 109 Lighting system Lower working-area lamp Semitrailer tractor vehicle: swing the side panel out before replacing the side marker lamp ( page 320). Upper working-area lamp Example: semitrailer tractor vehicle, working-area lamp Observe the notes on replacing bulbs page 99). Example: semitrailer tractor vehicle, working-area Loosen screws :.
  • Page 110 Lighting system traffic from being dazzled. Masked head- lamps do not illuminate as large an area of the edge of the carriageway. When using the vehicle in other countries observe the legal requirements for the coun- try you are currently in. The driver is responsible for the vehicle light- ing at all times.

  • Page 111: Good Visibility

    Good visibility Good visibility Windscreen wipers ! Vehicles with rain/light sensor: In dry weather conditions, switch the wind- screen wipers off. Otherwise, dirt or optical effects may cause undesired windscreen wiper sweeps. This could then damage the windscreen wiper blades or scratch the windscreen.
  • Page 112 Good visibility Vehicles with rain and light sensor: if the Windscreen heating Ä or Å setting is used, an appropriate wipe frequency is set according to rainfall. In the Å position, the rain and light sensor is more sensitive than in the Ä position, causing the windscreen wipers to wipe more frequently.

  • Page 113: Voltage Supply

    Voltage supply ing on the ADR classification, vehicles for the Voltage supply transport of hazardous goods can be equip- Battery isolator switch ped with 2 battery isolator switches. When you have safely parked the vehicle, you WARNING can use the battery isolator switch, e.g. when If the power supply is interrupted with the loading the vehicle in a hazardous goods area.
  • Page 114 Voltage supply Sockets Overview Example: 24 V socket Example: power sockets on the dashboard Example: power socket by the bed/berth 24 V socket 15 A (max. 360 W) Optional 24 V socket 15 A (360 W) or 12 V socket 15 A (180 W) Example: power socket in the stowage compart- ment 24 V power socket 25 A (600 W)

  • Page 115: Practical Tips

    The voltage transformer supplies both the 12 (25 A). To use 24 V power socket = V socket and the 12 V auxiliary consumers Mercedes-Benz recommends that you have with a maximum of 15 A. adapter plug ? fitted at a qualified specialist Vehicles with a 12 V connection point for workshop.
  • Page 116 Practical tips Cigarette lighter Smoke detector General notes WARNING You can burn yourself if you touch the hot heating element or the socket of the cigarette lighter. In addition, flammable materials can ignite if: the hot cigarette lighter falls a child holds the hot cigarette lighter to objects, for example There is a risk of fire and injury.
  • Page 117 Practical tips Check the smoke detector for functionality WARNING once a week. If the maximum permissible load of the stow- Press and hold button :. age compartment is exceeded, the cover can- If the smoke detector is working correctly, not restrain the objects. Objects could be the alarm sounds.
  • Page 118 Practical tips Stowage compartments above the windscreen Small items and spectacles holder in the drawer (example: insert on the right) You can remove the holder and attach it to the To open: pull handle : and swing the lid left or right side of the drawer or to another upwards.
  • Page 119 Practical tips To open/close: pull out or push in stowage The drawer under the berth may also be equipped with a coolbox. Notes on the oper- tray ; in the desired direction as far as it ation and settings for the coolbox can be will go.
  • Page 120 Practical tips flaps beneath the berth and from the outside Swing stowage compartment exterior flap via the exterior flaps. = forwards. To close the exterior flap: close stowage Fold up and secure the lower berth. compartment exterior flap = so that it To open the stowage compartment flap: engages audibly in the lock.
  • Page 121 Practical tips Fold upper cover : down. Fold lower cover ; upwards. Cup holder Swing out folded folding table = as far as it will go. Fold upper cover : down. Fold out folding table half ?. Door (example: left side of the vehicle) Cup holder Bottle holder Only place containers of an appropriate size...
  • Page 122 While cleaning the cab with compressed air, General notes always wear a dust protection mask, protec- tive eyewear and ear protectors. If you have fitted Mercedes-Benz audio equip- ment, you can operate your audio equipment: WARNING using the buttons on the multifunction...

  • Page 123: Communications

    To charge the ® Bluetooth mobile phone in the vehicle, you need a suitable charger bracket. These are available from retailers of Mercedes-Benz accessories. You can operate the mobile phone using the 6 and ~ buttons on the multifunction Front steering wheel ( page 152).
  • Page 124 Communications You can also use laptop holder : as a writing support. Only use laptop holder : when the vehicle is stationary. Stow laptop holder : in a stow- age compartment while driving. To secure the laptop: place laptop holder : on the steering wheel and hang it on the steering wheel using upper clip A.
  • Page 125 Useful information ......124 General notes ........124 Overview of climate control sys- tem functions ........124 Switching the cooling with air dehumidification function on/off ... 127 Setting climate control to auto- matic ..........127 Setting the temperature ....128 Adjusting the air vents .....

  • Page 126: Useful Information

    Overview of climate control system functions blocked filter reduces the amount of air sup- Useful information plied to the cab. The interval for replacing the filter depends on environmental influences. It These Operating Instructions describe all the may be shorter than that indicated in the Ser- models and standard and optional equipment vice Booklet.

  • Page 127: Overview Of Climate Control System Functions

    Overview of climate control system functions neys. The indicator lamp in the Ì button the stationary vehicle. The indicator lamp in lights up. the Á button lights up. Only use demisting mode until the misted Only use demisting mode until the misted up windscreen is clear again ( page 129).
  • Page 128 Overview of climate control system functions Heating with auxiliary heating is a heating and Ï Sets the programmed times for: ventilation system without a cooling system. y auxiliary heating ( page 134), Æ auxiliary air conditioning The air-conditioning system with auxiliary page 132), ü...

  • Page 129: Switching The Cooling With Air Dehumidification Function On/Off

    Setting climate control to automatic Only use demisting mode until the misted Automatic climate control windscreen is clear again. Press button Á. Only use air-recirculation mode briefly, e.g. If the indicator lamp in the button lights up, if there are unpleasant odours or in dusty the cooling with air dehumidification func- conditions.

  • Page 130: Setting The Temperature

    Adjusting the air vents adopts the current settings. Cooling with Centre air vents air dehumidification remains on. Driver's workstation Setting the temperature Heating/air-conditioning system Turn temperature selector = clockwise to increase or anti-clockwise to reduce the temperature. Start in the centre position or at 22 †.

  • Page 131: Setting The Air Distribution

    Demisting the windscreen and windows Side air vents Heating/air-conditioning system with auxiliary heating Set air-distribution control for heating/air conditioning ? to the corresponding sym- bol ( page 124). Automatic climate control Set air-distribution control B to the corre- sponding symbol ( page 124).

  • Page 132: Switching Air Recirculation Mode On/Off

    Switching residual engine heat utilisation on/off Heating/air-conditioning system Switching air recirculation mode on/off Only use the following settings until the wind- screen and windows are clear again. If you switch the air-recirculation mode on, Set temperature control = to z the windscreens may mist up more quickly, page 124).

  • Page 133: Switching The Auxiliary Ventilation On/Off

    Auxiliary air conditioning Press the Ì or Á button. Auxiliary air conditioning can be activated/ If the indicator lamp in the button lights up, deactivated manually (immediate cooling residual engine heat utilisation is activated. mode) or up to 2 switch-on times can be defined.
  • Page 134 Auxiliary air conditioning is activated. The airflow is controlled auto- Charging the refrigerant reservoir matically. The refrigerant reservoir can only be charged If necessary, adjust the airflow manually on when the engine is running. the automatic air conditioning control Press the q switch on the automatic panel.

  • Page 135: Auxiliary Heating

    Auxiliary heating Press the s or r button to select the vehicle clear of snow. To guarantee a suffi- day. cient supply of fresh air, open a window on the Press button ù. side of the vehicle away from the wind. Press the s or r button to set the WARNING hour.
  • Page 136 Auxiliary heating Set the temperature, airflow, air distribu- Mandatory switch-off tion and air vents as desired. ! Only use the battery isolator switch when The automatic air conditioning system the auxiliary heating is running if there is a automatically switches to automatic mode risk of danger.
  • Page 137 Auxiliary heating Switch the ignition lock to the drive posi- Switch the ignition lock to position 0 and tion. remove the key. Auxiliary heating and/or engine preheating Press button ù on the control panel of switch on automatically at the set switch- the heating, air-conditioning system or on times.
  • Page 139 Useful information ......138 Instrument cluster ......138 On-board computer ......144 On-board computer event window .. 163 Indicator lamps in the status area of the display ........200...

  • Page 140: Useful Information

    Instrument cluster wise, you could cause an accident by driving Useful information an unsafe vehicle. If your vehicle is not oper- ating safely, stop immediately, paying atten- These Operating Instructions describe all the tion to the road and traffic conditions. models and standard and optional equipment of your vehicle that were available at the time of going to print.

  • Page 141: Instrument Cluster

    Instrument cluster In some situations, it may make sense to consequence of this is that the vehicle may no operate the engine outside economical longer be operated on public roads. engine speed range :, e.g. on uphill gra- Range In the menu window of the ß...
  • Page 142 Instrument cluster Range In the menu window of the ß trip data Odometer menu, you can display your vehicle's range based on the current fuel tank content page 149). Clock and outside temperature Instrument cluster (example: display in rev coun- ter) Switch the ignition lock to the drive posi- tion.
  • Page 143 Instrument cluster Engine diagnostics indicator lamp ® BlueTec 5 vehicles Problem Possible causes/consequences and M Solutions The ; indicator If there are no malfunctions, the indicator lamp lights up briefly lamp lights up, then during the instrument cluster's display check and then goes out goes off again after after the engine starts.
  • Page 144 Instrument cluster ® BlueTec 6 vehicles Problem Possible causes/consequences and M Solutions The ; indicator After you have switched the ignition lock into drive position, the indicator lamp indicates the system's status by means of a lamp flashes. sequence of flashes. If there are no malfunctions, the indicator lamp goes out after the engine is started ( page 143).
  • Page 145 Instrument cluster Problem Possible causes/consequences and M Solutions The ; indicator You have not rectified a detected emissions-related malfunction. lamp lights up. Follow the instructions in the event window. The engine power out- Drive carefully to the nearest qualified specialist workshop and put is reduced.
  • Page 146 On-board computer 5 seconds. Subsequently, it goes out for 5 play. You should therefore make sure your seconds. vehicle is operating safely at all times. Other- wise, you could cause an accident by driving In the third phase, the indicator lamp indi- an unsafe vehicle.

  • Page 147: On-Board Computer

    On-board computer Switch the ignition lock to the radio posi- To save a favourite menu window: call tion. up the desired menu window and press the The on-board computer shows the wel- Ú button for approximately 2 seconds. come display (Mercedes star). After a short A tone sounds and the menu window is time the display also shows the date and saved.
  • Page 148 On-board computer den. An indicator lamp that lights up in status page 148) Tour data ß area = of the on-board computer or in the instrument cluster does not go out after the Truck info Displays the time and event window is confirmed. outside temperature, displays/resets the trip Status area: status area = shows the selec-...
  • Page 149 On-board computer Audio and page 152) Operation and page 154) communica- maintenance tions á â Trailer Alarm clock Displaying trailer/semi- Displays the alarm trailer data time Sets the alarm clock Information on braking Switches off the alarm Axle loads Tyre pressures Telephone Displays the telephone Reservoir pressure...
  • Page 150 On-board computer Use the u or t button to scroll to ß page 160) Settings ä trip data. Service Displays/sets service To display the driving and rest times: products product values use the r or s button to scroll to the Tachograph menu window.
  • Page 151 On-board computer FleetBoard EcoSupport menu window To reset the trip data: press 9. The input window shows, for example, The on-board computer detects your driving Reset values for: Since start - all style in 8 categories, evaluates it and displays No/Yes.
  • Page 152 On-board computer Stop The on-board computer evaluates If you do not carry out a scheduled the braking phases that lead to the vehi- regeneration of the diesel particle fil- ter, you receive a negative evaluation. cle coming to a standstill. If you drive carefully and therefore avoid having to the maintenance of the air filter bring the vehicle to a standstill, you...
  • Page 153 On-board computer Selecting a shift position puter displays warnings and the status of the driving systems in colour. Please read the Apply the parking brake. operating instructions on the distance control Start the engine. assistant ( page 271) and Lane Keeping Use the u or t button to scroll to à...
  • Page 154 Further information on suitable mobile The input window shows: phones and on connecting mobile phones Alarm clock 1/Alarm the alarm clock ® via Bluetooth can be obtained: clock 2 Audio/Buzzer/Off the alarm mode at your Mercedes-Benz Service Centre on the Internet at http:// www.mercedes-benz.com/connectivity...
  • Page 155 Audio menu window is available on vehi- telephone book or the missed calls list. cles with Mercedes-Benz audio equipment. Switch on the audio equipment To call the number in the telephone book page 212).
  • Page 156 On-board computer Setting the volume the name of the audio source the station or frequency when in radio mode ® the title when in CD, USB or Bluetooth mode the AUX source when in audio AUX mode the waveband when in radio mode the MP3 browser when in CD or USB mode Select the desired menu bar with the r...
  • Page 157 On-board computer Setting the axle load indicator before embarking on a longer journey You can adjust the axle load indicator if there for changed operating conditions, e.g. off- is a notable difference between the axle load road driving. indicator and the weighbridge results. If necessary, correct the tyre pressure.
  • Page 158 On-board computer Example: checkers show higher pressures than the on- board computer. If this is the case, do not room temperature is approximately reduce the tyre pressure. 20 † The tyre pressure monitor automatically rec- outside temperature is approximately ognises new wheels or tyre pressure sensors. 0 †...
  • Page 159 On-board computer Level control menu window Important safety notes When driving with a lowered or raised chassis, the driving and braking characteristics may be affected. Additionally, the maximum per- mitted vehicle height may be exceeded when the chassis is raised. Observe the legally per- missible vehicle heights for the country you are currently in.
  • Page 160 Using the r or s button, scroll to the If the maintenance work is carried out at a Trailer menu window. Mercedes-Benz Service Centre, the fact that Press the 9 button. the work has been carried out professionally The display shows the first input window,...
  • Page 161 On-board computer Engine menu window Engine the maintenance point 23.09.2014 the maintenance due date Engine In the menu window, you can check 2000 km the remaining distance the engine oil level and display the engine's operating hours. Check the engine oil level If no prediction for the maintenance due before the start of every journey.
  • Page 162 (systems) installed in the vehicle. You can obtain further Lighting menu window information from any Mercedes-Benz Service Centre. You can set the brightness of the instrument cluster, the switch and the audio display as Use the u or t button to scroll to ã...
  • Page 163 Mercedes-Benz Service Centre. fuel used. Use the u or t button to scroll to ä The following values can be set: settings.
  • Page 164 You can obtain information about service products that have been tested by Set the service product value of the service Mercedes-Benz and approved for your vehi- product added using the u or t but- cle on the Internet at: http:// ton.

  • Page 165: On-Board Computer Event Window

    On-board computer event window Use the r or s button to select and contact a qualified specialist work- Crawler mode, EcoRoll mode, PPC, shop. If the qualified specialist workshop ATTENTION ASSIST Video popup. determines it is possible to continue driv- ing, adapt your driving style accordingly.
  • Page 166 On-board computer event window Grey event window Notes Important safety notes If you ignore warning and indicator lamps and the event window, you will not be able to rec- ognise failures and malfunctions in components or systems. Driving/braking characteristics may be affected and the operating and road safety of your vehicle may be limited. Have the affected system checked and repaired at a qualified specialist workshop.
  • Page 167 On-board computer event window Transmission and clutch Display messages Possible causes/consequences and M Solutions The clutch is under a heavy load but not overloaded. You should Ô only pull away in first gear. Clutch under heavy Keep the pulling away or manoeuvring procedure as brief as strain possible.
  • Page 168 On-board computer event window Driving systems Display messages Possible causes/consequences and M Solutions ABS may be switched off. There may be a fault in Active Brake È Assist or a fault with the vehicle's brake system Active Brake WARNING Assist cannot be activated If Active Brake Assist cannot be switched on, you will not receive any collision warnings.
  • Page 169 On-board computer event window Electrical system and key Display messages Possible causes/consequences and M Solutions The battery charge level of the batteries is decreasing. When the engine is switched off, the following electrical consum- Consumer shutoff ers are automatically deactivated: active Audio equipment 24 V power sockets...
  • Page 170 On-board computer event window Tyres Display messages Possible causes/consequences and M Solutions ÛCheck and correct tyre pressure. Additional text In addition to the event window, the h indicator lamp lights up Tyre pressure in in grey in the status area of the on-board computer. The tyre pres- spare wheel too low sure of the spare wheel is too low.
  • Page 171 On-board computer event window Service products and maintenance Display messages Possible causes/consequences and M Solutions The washer fluid level in the washer fluid reservoir for the wind- ¥ screen washer/headlamp cleaning system has fallen to approx- imately 1 litre. Top up the washer fluid ( page 351).
  • Page 172 On-board computer event window Yellow event window Notes Important safety notes If you ignore warning and indicator lamps and the event window, you will not be able to rec- ognise failures and malfunctions in components or systems. Driving/braking characteristics may be affected and the operating and road safety of your vehicle may be limited. Have the affected system checked and repaired at a qualified specialist workshop.
  • Page 173 On-board computer event window ® BlueTec Display messages Possible causes/consequences and M Solutions Please top up AdBlue. Supplementary text Û: Ø ® The AdBlue level has dropped to approximately 10%. AdBlue reserve ® Top up the AdBlue tank immediately ( page 306).
  • Page 174 On-board computer event window Display messages Possible causes/consequences and M Solutions Please top up with AdBlue Risk Supplementary text Û: · of limit speed Engine power Additionally, the on-board computer displays the · indicator reduced ® lamp in the status area. The AdBlue level has dropped to approx- imately 2.5%.
  • Page 175 On-board computer event window Diesel particle filter Display messages Possible causes/consequences and M Solutions Please start regeneration Supplementary text Û:  Please observe Operating Instructions Diesel part. fil‐ The  indicator lamp also lights up yellow in the instrument ter: fluid level cluster.
  • Page 176 On-board computer event window Service products and maintenance Display messages Possible causes/consequences and M Solutions The fuel has dropped to the reserve level. Refill the fuel tank ( page 305). The ¯ indicator lamp lights up yellow in the status area of the ¯...
  • Page 177 On-board computer event window Compressed-air system, engine and cooling system Display messages Possible causes/consequences and M Solutions The compressed-air dryer is malfunctioning. Have the compressed-air dryer checked at a qualified specialist Condensation in workshop. compressed-air reservoir The reservoir pressure in the transmission/clutch is too low. WARNING Transmission/ clutch reserve...
  • Page 178 On-board computer event window Display messages Possible causes/consequences and M Solutions The coolant temperature is too high. Engine power output is auto- matically reduced. Coolant tempera‐ Reduce the speed. ture too high Shift to a lower gear. Stop the vehicle, paying attention to road and traffic conditions. Switch off the engine.
  • Page 179 On-board computer event window Transmission and clutch Display messages Possible causes/consequences and M Solutions Visit workshop. Supplementary text Û: Ú WARNING Transmission faulty The transmission gearshift system is malfunctioning. The journey can be continued, but with restrictions. Have the transmission checked at a qualified specialist work- shop.
  • Page 180 On-board computer event window Trailers/semitrailers Display messages Possible causes/consequences and M Solutions Adapt your driving style. Supplementary text Û: The temperature of one of the drum brakes/disc brakes on the Wheel brake over‐ tractor vehicle is too high. The drum brake/disc brake may over- load heat.
  • Page 181 On-board computer event window Display messages Possible causes/consequences and M Solutions On at least one of the trailer/semitrailer tyres, the tyre pressure is too low. Check tyre pressure WARNING Driving/braking characteristics may change. Also observe the information in the separate operating instructions provided by the trailer/semitrailer manufacturer.
  • Page 182 On-board computer event window Braking and driving systems Display messages Possible causes/consequences and M Solutions Visit workshop. Supplementary text Û: Õ In addition, the Á warning lamp lights up in the instrument ESP not available cluster. Stability Control Assist is malfunctioning. WARNING Driving/braking characteristics may change.
  • Page 183 On-board computer event window Display messages Possible causes/consequences and M Solutions Visit workshop. Supplementary text Û: In addition, the J warning lamp lights up yellow in the instru- Driving and brak‐ ment cluster. ing characteris‐ The vehicle's brake system is malfunctioning. tics changed WARNING Driving and braking characteristics may change.
  • Page 184 On-board computer event window Display messages Possible causes/consequences and M Solutions When giving an automatic collision warning, the on-board com- · puter shows the yellow · event window and a double warning tone sounds. WARNING Distance control assistant warns you if there is a risk of crashing. There is a risk of an accident.
  • Page 185 On-board computer event window Display messages Possible causes/consequences and M Solutions Active steering wheel return Supplementary text Û: inoperative Please have rectified at next mainte‐ Do not turn the nance. steering wheel to A fault has occurred in the steering control unit. The vehicle's the stop driving characteristics (feel) may change.
  • Page 186 On-board computer event window Display messages Possible causes/consequences and M Solutions Visit workshop. Supplementary text Û: The steerable trailing axle is malfunctioning and is either only Steer. character‐ steering passively or is centred. Stability Control Assist may also istics of add. have been deactivated as a result.
  • Page 187 On-board computer event window Lighting system, electrical system and key Display messages Possible causes/consequences and M Solutions Please have rectified at next Supplementary text Û: maintenance. Battery charge The measured values for the battery charge level are unavailable. level not available You will not be warned when the battery charge level is critical.
  • Page 188 On-board computer event window Display messages Possible causes/consequences and M Solutions The entire exterior lighting of the vehicle is electronically moni- tored. When the event window is shown, a bulb has failed. The event window contains information about fault location and fault Replace light bulb.
  • Page 189 On-board computer event window Display messages Possible causes/consequences and M Solutions Please consult service centre Supplementary text Û: and have the key replaced. Key invalid The key is malfunctioning or faulty. The key must be replaced. Consult a qualified specialist workshop. Please consult service centre Supplementary text Û: and have the key replaced.
  • Page 190 On-board computer event window Display messages Possible causes/consequences and M Solutions Replace tyre pressure sensor Supplementary text Û: The h indicator lamp lights up yellow in the status area of the Tyre pressure sen‐ on-board computer as well as in the event window. The battery of sor battery low a tyre pressure sensor is discharged.
  • Page 191 On-board computer event window Red event window Notes Important safety notes If you ignore warning and indicator lamps and the event window, you will not be able to rec- ognise failures and malfunctions in components or systems. Driving/braking characteristics may be different and the operating and road safety of your vehicle may be limited. Have the affected system checked and repaired at a qualified specialist workshop.
  • Page 192 On-board computer event window Compressed-air system Display messages Possible causes/consequences and M Solutions In addition, the J warning lamp lights up red in the instrument cluster. Example: Brake sup‐ The reservoir pressure in brake circuit 1 \ or 2 ^ is too low. ply pressure in If the reservoir pressure in the spring actuator and the trailer's circuit 1 too low...
  • Page 193 On-board computer event window Engine and cooling Display messages Possible causes/consequences and M Solutions Stop vehicle. Switch off Supplementary text Û: engine. Eng. oil press. The 5 indicator lamp lights up red in the status area of the on- too low board computer as well as in the event window.
  • Page 194 On-board computer event window Transmission and clutch Display messages Possible causes/consequences and M Solutions Stop vehicle. Contact service Supplementary text Û: Ø centre. Clutch faulty WARNING The transmission no longer changes gear. The reservoir pressure in the transmission/clutch may be too low. Stop the vehicle at once, paying attention to road traffic condi- tions.
  • Page 195 On-board computer event window Semitrailers Display messages Possible causes/consequences and M Solutions The £ indicator lamp lights up red in the status area of the on- £ board computer as well as in the event window. Open semitrailer If the on-board computer displays a warning and a warning tone coupling.
  • Page 196 On-board computer event window Display messages Possible causes/consequences and M Solutions The ¤ indicator lamp lights up red in the status area of the on- ¤ board computer as well as in the event window. Check semitrailer If the on-board computer displays a warning and a warning tone coupling.
  • Page 197 On-board computer event window Braking and driving systems Display messages Possible causes/consequences and M Solutions · WARNING Active Brake Assist warns you of a risk of colliding with the vehicle in front. There is a risk of an accident. When an automatic collision warning is being given, you must brake the vehicle using the service brake if: the on-board computer displays the ·...
  • Page 198 On-board computer event window Display messages Possible causes/consequences and M Solutions Vehicles with a programmable special module: the parking brake is not applied. Engage parking The parking brake has not been applied before engaging the power brake. take-off. WARNING The parked vehicle could roll away. You could endanger yourself and others.
  • Page 199 On-board computer event window Display messages Possible causes/consequences and M Solutions Stop vehicle Check hydraulic Supplementary text Û: steering during shunting Consult service centre Power steering: In addition, the D warning lamp lights up red in the instrument function not cluster.
  • Page 200 On-board computer event window Display messages Possible causes/consequences and M Solutions Stop vehicle. Contact service Supplementary text Û: centre. Power steering: In addition, the D warning lamp lights up red in the instrument function not cluster. assured A fault has occurred in the electric power steering. WARNING Power steering function cannot be assured.
  • Page 201 On-board computer event window Tyres Display messages Possible causes/consequences and M Solutions Change tyre. Supplementary text Û: The h indicator lamp lights up red in the status area of the on- Flat tyre board computer as well as in the event window. The tyre pressure has suddenly dropped in one or more tyres.

  • Page 202: Indicator Lamps In The Status Area Of The Display

    Indicator lamps in the status area of the display Indicator lamps in the status area of Warning and indicator lamps the display Driver's airbag ( page 54) Important safety notes Seat belt warning ( page 53) If you ignore warning and indicator lamps, you An emissions-relevant malfunc- ·...
  • Page 203 Indicator lamps in the status area of the display Warning and indicator lamps Sensor-monitored semitrailer î coupling malfunction page 193) Loading tailgate, see the separate ¬ operating instructions Power take-off ( page 328) Continuous brake malfunction page 245) Tyre pressure monitor warning, see the corresponding event win- Tyre pressure monitor ¨...
  • Page 204 Indicator lamps in the status area of the display Yellow warning or indicator lamp Problem Possible causes/consequences and M Solutions The Û indicator Risk of accident lamp in the status area The trailer's/semitrailer's brake system is malfunctioning. Driv- of the on-board com- ing/braking characteristics may change.
  • Page 205 Useful information ......204 Overview and functions ....204...
  • Page 206 ® tact FleetBoard Support; see contact details in the imprint. You can obtain information on ® FleetBoard from any Mercedes-Benz Ser- vice Centre. ® FleetBoard vehicle management enables unlimited access to consumption figures and information about vehicle parts that are sub-...
  • Page 207 Overview and functions ® Avoid touching the contact surface points of FleetBoard functions memory chip : with your fingers. Otherwise, ® FleetBoard TiiRec allows you to carry out the errors could occur when reading memory following functions: chip :. Analyse and calculate the driving style Switch the ignition lock to the drive posi- Record journey and rest periods tion.
  • Page 208 The roadside assistance chip. data is now available to Mercedes-Benz Service. Reading out and sending driver data Switch the ignition lock to position 0. Switch the ignition lock to the drive posi- Contact Mercedes-Benz Service (Customer tion.
  • Page 209 Overview and functions Driver card read-out error Problem Possible causes/consequences and M Solutions The LED indicator lamp ® The FleetBoard has not detected a valid driver card. glows green and a con- There could be several reasons for this: tinuous warning tone an incorrect driver card has been inserted.
  • Page 211 Important safety notes ....210 General notes ........210 Anti-theft protection ......211 Operating system ......212 Audio mode ........219 ® Bluetooth settings ......220 Navigation ......... 222 Digital Operating Instructions ..224...

  • Page 212: Important Safety Notes

    General notes Important safety notes WARNING Operating or handling mobile audio/video WARNING sources while driving will distract you from traffic conditions. You could then lose control The CD/DVD drive is a class 1 laser product. of the vehicle. There is a risk of an accident. If you open the housing of the CD/DVD drive, invisible laser beams may be released.

  • Page 213: Anti-Theft Protection

    Anti-theft protection All further information on the individual func- tions can be found on the Internet at www.mercedes-benz.de/betriebsanleitung- lkw or in the Digital Operating Instructions (radio/navigation system only). Anti-theft protection When switching on for the first time or after Disa‐...
  • Page 214 Operating system Operating system Radio/navigation system overview Function Page Function Page Display Turn 3 the controller: To select a station Number pad To select a list item To set a station via the sta- To adjust the map scale tion presets To change the adjustment To store stations manually value...
  • Page 215 Operating system Function Page Function Page =; Horizontal arrow F Press briefly: buttons: To select stations using the To select a main function station search function To move the map horizon- To select the next track tally (in full-screen display) F Press and hold: To select a DVD menu item To fast forward...
  • Page 216 Operating system Radio/navigation system function Radio/navigation system menu over- overview view You can use the radio/navigation system to Main function audio ¦ operate the following main functions: Radio ¨ the audio function with the radio, audio u CD/DVD playback CD/DVD and MP3 mode, USB audio, Blue- ©...
  • Page 217 Operating system CD radio overview Function Page Function Page Press V the controller: Display To confirm your selection Number keypad: To display stored stations To set a station via the sta- To display playback options tion presets =; Horizontal arrow To store stations manually buttons: To enter a passkey...
  • Page 218 Operating system Function Page Function Page j Press the delete but- E Press briefly: ton briefly: To select stations using the To delete characters station search function j Press and hold: To select the previous track To delete an entry E Press and hold: Manual station search Hands-free microphone...

  • Page 219: Operating System

    Operating system Radio/navigation system and CD The currently active option is marked with radio controller Submenus CD radio menu overview Main function radio ´ Switching FM stations/traffic announce- ment priority on/off Switching automatically stored FM sta- tions/traffic announcement priority on/off Switching between AM stations/wave- bands Example: operating the controller...
  • Page 220 Operating system Radio overview Function Page Function Page ´· Scroll buttons: To select a menu In radio mode: to change waveband In CD/USB mode: to switch to the track time display In MP3 mode (CD or USB): to change folder In AUX mode: to switch To select the sound menu between FRONT and REAR...

  • Page 221: Audio Mode

    Audio mode Function Page Function Page 8 Mute button: Mini USB socket and AUX jack To end the current traffic message Number pad Equipment with CD drive: In radio mode: Press briefly: Press briefly: to select a To mute the audio source station from the station (mute/pause) memory...
  • Page 222 Bluetooth -capable mobile phones with the audio system can be obtained: ® Connecting Bluetooth devices at your Mercedes-Benz Service Centre or General notes on the Internet at www.mercedes- benz.com/connectivity ® Before using your Bluetooth device with the audio system for the first time, you will need to connect it.

  • Page 223: Bluetooth ® Settings

    ® Bluetooth settings Authorising (registering) the Blue- ® Calling up the Bluetooth device list ® tooth device List of Turn 3 the controller to select BT cell phones/Phone list List Turn 3 the controller to select the of BT audio players/Audio device device that has not yet been authorised in list ®...
  • Page 224 Navigation Connecting a device to the CD radio: You must observe the legal requirements for the country in which you are currently driving In the telephone or audio device list, turn when operating the system. 3 the controller to select the desired The driver is responsible for the safety of the device.

  • Page 225: Navigation

    Navigation Calling up the destination entry menu Turn 3 the controller to select the desired list entry. Press the = or ; button repeatedly To confirm your selection: press V the until ¡ (navigation) is selected in the controller. main function bar. The address input menu appears.

  • Page 226: Digital Operating Instructions

    Digital Operating Instructions Cancelling route guidance Preparation phase The radio/navigation system prepares you Cancel Turn 3 the controller to select for the upcoming change of direction. The route guidance from the function menu. Pre‐ announcement is made with the words To confirm your selection: press V the pare to turn right soon..
  • Page 227 Digital Operating Instructions Opening the Digital Operating Instruc- tions Entry screen Press the = or ; button until n (Digital Operating Instructions) is selected in the main function bar. The entry screen appears. Turn V the controller to select More. To confirm your selection: press V the controller.
  • Page 228 Digital Operating Instructions Overview of Digital Operating Instructions Example: radio/navigation system with Digital Operating Instructions open Navigation bar with path for the current topic Main function bar, main menu n Digital Operating Instructions selected Keypad V Controller % Back button j Delete button s How to use the digital Operating Instructions r Article page (contents of the Operating Instructions)
  • Page 229 Digital Operating Instructions you can return to the reference page by pressing the : button. To expand warnings, environmental notes and damage warnings: when scrolling through text, the cursor jumps automatically to expandable warnings, environmental notes and damage warn- ings. When the note is selected, press V the controller.
  • Page 231 Useful information ......230 Driving ..........230 Brakes ..........238 Manual transmission ......246 Automated transmission ....249 Operation ........... 259 Driving systems ........ 267 Level control ........286 Additional axles ........ 291 Driving tips ........293 Refuelling ........... 305 Trailers/semitrailers ......

  • Page 232: Useful Information

    Driving Useful information These Operating Instructions describe all the models and standard and optional equipment of your vehicle that were available at the time of going to print. Country-specific differences are possible. Bear in mind that your vehicle may not be equipped with all the functions described.
  • Page 233 Driving Observe the separate instructions issued When carrying emergency equipment, e.g. a by the manufacturer for the operation, care breathalyser, observe the legal requirements and maintenance of the semitrailer/trailer of the country in which you are currently driv- coupling. ing. Have all faults and damage rectified.
  • Page 234 Driving The multifunction key is secured against Do not switch off the ignition while the vehicle turning. The multifunction key can only be is in motion. inserted into the key slot in one position. WARNING The key may heat up in the key slot. If you leave children unattended in the vehi- The ignition lock has the following switch cle, they could set the vehicle in motion by, for...
  • Page 235 Driving ignition lock. This means, for example, that the pedals. Do not lay several floormats or you can lock the cab and use power take-off carpets on top of one another. or level control in working mode. WARNING Stop the vehicle. If you load the vehicle unevenly, driving char- Push Start/Stop button : in to the first acteristics such as steering and braking...
  • Page 236 Driving ment is present and whether there are any Repeat the starting procedure. faults with their functions. If the engine still fails to start, contact a The immobiliser is deactivated and the qualified specialist workshop. engine can be started. If you use an invalid key, the on-board computer will show an Safety inspection event window.
  • Page 237 Driving Condensation in compressed- low + ing away, e.g. with the parking brake. Have air reservoir event window. In this case, the compressed-air system repaired at a have the compressed-air brake system qualified specialist workshop. checked at a qualified specialist workshop. If The reservoir pressure in the transmission/ your vehicle is equipped with a condensation clutch circuit is supplied once brake circuits 1...
  • Page 238 Driving compressed-air reservoir event win- There is a delay in displaying a change in out- dow is displayed in the on-board computer. side temperature. In this case, check the compressed-air If the brake system is defective, braking behaviour may change or the brake system dryer more frequently.
  • Page 239 Driving Engage a gear, see Automated transmis- restricted or not available. This can affect the sion ( page 249) or Manual transmission power steering function and the brake boost- page 246). ing effect, for example. You will then require Release the brake pedal or parking brake considerably more force to steer and brake.
  • Page 240 Brakes the coolant temperature is above approx- Hill holder imately 100 † BAS (Brake Assist) full engine power has been used, e.g. while The electronic control is able to relieve the driving in mountainous terrain or during load on the service brake by activating the combined operation continuous brake, depending on the vehicle To switch off the engine: press the Start/...

  • Page 241: Brakes

    Brakes minute, the compressed-air brake system Do not pull away until the required reservoir is free from leaks. pressures have been reached. If a significant loss of pressure is detected, In the event of loss of pressure while driving, the compressed-air brake system is leak- immediately bring the vehicle to a halt in ing.
  • Page 242 Brakes the on-board computer for approximately If ABS is deactivated or if there is a malfunc- 3 seconds. The ! indicator lamp is sup- tion in the vehicle's brake system, Active plemented with the s, r or u Brake Assist is automatically deactivated. indicator lamps for towing vehicles and/or When ABS is intervening: trailers/semitrailers.
  • Page 243 Press the upper section of the q button. When the ! indicator lamp in the instru- ment cluster lights up, ABS is deactivated. Independent trailer brake lever (example: Actros BAS (Brake Assist) GigaSpace) The independent trailer brake can be used...
  • Page 244 3 back to fully applied position 2 and engage it. Releasing the parking brake Parking brake lever (example: Actros GigaSpace) Pull parking brake lever ? upwards from Secure the parked vehicle against rolling fully applied position 2 and swing it up away by applying the parking brake.
  • Page 245 Brakes Four-wheel parking brake Frequent-stop brake WARNING When securing the vehicle against rolling away with the frequent-stop brake, the brak- ing pressure may be too low. The vehicle could roll away even though the frequent-stop brake is engaged. There is a risk of an accident. Never leave the driver's seat with the fre- quent-stop brake activated and be prepared to apply the brakes.
  • Page 246 Brakes the frequent-stop brake if you frequently pull WARNING away and stop for short periods of time, e.g. in If you do not stop the vehicle using the service refuse collection operation. The frequent- brake, e.g. when coasting to a stop, the hill stop brake does not replace the service brake holder will not be activated.
  • Page 247 Brakes If you then apply the parking brake, the hill WARNING holder is deactivated and the ¿ indicator If there is a retarder or retarder control mal- lamp in the instrument cluster goes out. The function, braking characteristics can change. vehicle is then held by the parking brake.
  • Page 248 Manual transmission Retarder If the à indicator lamp flashes in the instrument cluster, the retarder's braking power is reduced. Shift down in good time. The engine braking effect and the engine cooling effect are increased. Manual transmission Example: multifunction lever Important safety notes Vehicles without a retarder are equipped with 3 brake stages (1 - 3).

  • Page 249: Manual Transmission

    Manual transmission tion. As a result, more force is required When in neutral position, the gear lever is in when shifting gear. the gate between the 3rd and 4th gear and the 5th and 6th gear. The engine has delayed throttle response if: The shift ranges of the transmission are divi- the vehicle is stationary ded into:...
  • Page 250 Manual transmission Changing the shift range 16-speed transmission ! Observe the following maximum permis- General notes sible speed when changing shift range from the fast to the slow group. When driving in the off-road gear of the transfer case, do not exceed the maximum speed of 15 km/h when changing gear.

  • Page 251: Automated Transmission

    Automated transmission Multifunction lever the lower position for low-range splitter group ;. Depress and hold the clutch pedal until the splitter group is engaged. Release the clutch pedal. Automated transmission Important safety notes WARNING If there is a loss of pressure or insufficient To select the direction of travel: reservoir pressure in the transmission/clutch h Drive (...
  • Page 252 Automated transmission Gear indicator Drive programs and drive functions Automatic The transmission control shifts gears depend- ing on a number of factors including: engine speed accelerator pedal position application of the continuous brake load status of the vehicle condition of the road surface In addition, EcoRoll mode and crawler mode can be deactivated and activated as drive Systems...
  • Page 253 Automated transmission speeds. EcoRoll mode cannot be switched on In particularly difficult driving conditions, in these gearshift programs. switch to the manual driving program. This will enable you to avoid any undesired inter- In the offroad gearshift program, the crawler ruptions to the tractive power that may occur mode adapted for road use is deactivated.
  • Page 254 Automated transmission You can switch between the drive programs (default setting) or the road speed toler- at any time. ance that you have set is exceeded a programmed maximum speed is excee- To activate the manual drive program: ded by approximately 4 km/h press and hold o button :.
  • Page 255 Automated transmission Crawler mode is deactivated automatically if: In the offroad gearshift program, the crawler mode tuned for road driving is always deacti- you shift the transmission to neutral posi- vated. The crawler mode tuned specially for tion i for longer than approximately off-road driving can be activated and deacti- 2 seconds vated using the í...
  • Page 256 Automated transmission If you want to drive down a gradient slowly: ted. The indicator lamp in the í button turn direction switch to k ( page 249). lights up. To descend slowly: release the service Activating brake. Select a pulling-away gear. Do not depress the accelerator.
  • Page 257 Automated transmission You can use the rocking-free drive function in Pulling away and stopping the vehicle all permissible pulling-away gears to rock the Pulling away vehicle out of a depression in the terrain. If you release the accelerator pedal when rock- ing free, the dry clutch is immediately disen- gaged and the vehicle rolls back.
  • Page 258 Automated transmission Shifting into neutral The gear change is complete when the dis- play shows the selected gear. Vehicles with 12/16-speed transmission: pull the multifunction lever up and hold (to shift up) ; or push it down and hold (to shift down) =.
  • Page 259 Automated transmission Kickdown gear shifting driving speed is too high. The gear is not selected. The transmission control only Use kickdown for maximum acceleration of selects permissible gears. the vehicle. Pull the multifunction lever up briefly (to You can increase performance when pulling shift up) : or push it down briefly (to shift away using the kickdown function if required, down) ;.
  • Page 260 Automated transmission Shift up Z or down ¬ according to the gear- shifts up or down at least one gear to a shift recommendation. suitable gear. The gear change is complete when the display shows the selected gear. Changing gear while driving is only possible at suitable engine speeds or at suitable driving speeds.

  • Page 261: Operation

    Operation You can shift up or down by single reverse From a higher forward gear, gears in succession while reversing: 1st reverse gear is preselected. From the 3rd or 4th reverse gear, a suitable Pull the multifunction lever up briefly (to pulling away gear is preselected.
  • Page 262 Operation vring mode to continue driving. The starting The transmission does not change gear power is higher in the power, heavy and off- when driving in clutch mode. road gearshift programs. Level ground In manoeuvring mode, the vehicle starts up as Select a gear.
  • Page 263 Operation Deactivating manoeuvring mode always adapt your driving style to suit pre- vailing road and weather conditions. Press the lower section of the switch. ASR considerably improves traction, i.e. power transmission between the tyres and Depress the accelerator pedal past the the road surface, and therefore also improves pressure point to the stop (kickdown).
  • Page 264 Operation vice brake or continuous brake. If Stability Control Assist intervenes, the Á indicator lamp in the instrument cluster flashes. If you fail to adapt your driving style or if you are inattentive, Stability Control Assist can neither reduce the risk of an accident nor override the laws of physics.
  • Page 265 Operation Only deactivate Stability Control Assist in the ability of the vehicle is severely impaired. You situations described in the following. could lose control of the vehicle, especially when engaging on a bend. There is a risk of an Only drive with Stability Control Assist deac- accident.
  • Page 266 Operation ential lock has not yet engaged/disengaged. The conditions for engaging/disengaging have not been fulfilled, e.g. due to differing wheel rotational speeds. The differential lock is automatically engaged as soon as all gear- shift conditions have been fulfilled. Engage the differential locks to improve trac- tion, e.g.
  • Page 267 Operation Deactivating Transfer case Turn the differential lock switch to position Engaging off-road gear The differential locks are disengaged. The differential lock indicators in the display go out. Press the lower section of the i switch. The differential lock is disengaged. The indicator for the differential lock in the dis- play goes out.
  • Page 268 Operation Press the upper section of the m switch. gaged when all conditions for engaging/ When all engagement conditions are met, disengaging are fulfilled. the off-road gear is engaged and the m When you engage the front axle, the transfer symbol is shown in the display.

  • Page 269: Driving Systems

    Driving systems depending on the engine or on vehicles with Driving systems power take-off. Introduction to driving systems For the engines OM 470, OM 471 and OM 473, the engine idling speed can be set The vehicle may be equipped with the follow- between approximately 500 and 800 rpm.
  • Page 270 Driving systems Overview Selecting the speed limiter Press the È button. The on-board computer shows the È symbol in grey. Activating when driving Select the speed limiter. Drive at the desired speed and briefly press the Ñ button. The speed limiter is activated and the cur- rent vehicle speed is stored as the limit speed.
  • Page 271 Driving systems Driving ! Do not exceed the maximum speed of the individual gears. Keep an eye on the rev It is possible to exceed the set limit speed, counter. e.g. when overtaking: If you fail to adapt your driving style or fail to Briefly depress the accelerator pedal pay attention to your surroundings, cruise beyond the point of resistance (kickdown).
  • Page 272 Driving systems The on-board computer shows the é Selects the speed limiter ( page 268) È symbol and the set speed in white. Deactivates cruise control Release the accelerator pedal. The é symbol in the on-board computer In order to maintain the set speed, cruise shows the status of cruise control in colour: control automatically brakes or acceler- Grey symbol: cruise control is selected, but...
  • Page 273 Driving systems If the continuous brake is deactivated, the vehicle will accelerate to the last stored Select the speed limiter with the È but- speed. ton. If cruise control is decelerating the vehicle The on-board computer shows the È using the continuous brake and you simulta- symbol in grey.
  • Page 274 Driving systems Do not use the distance control assistant WARNING Distance control assistant brakes your vehi- on slippery roads. The drive wheels may lose their grip when braking or accelerating cle with up to 30% of the maximum possible and the vehicle may skid. deceleration.
  • Page 275 Driving systems When a vehicle in front has been detected, The distance control assistant cannot be acti- the on-board computer also displays the vated or is deactivated automatically if: speed of the detected vehicle and the dis- you are driving slower than 15 km/h on tance to the detected vehicle.
  • Page 276 Driving systems play. The distance control assistant is activa- The on-board computer shows the "Apply ted. The vehicle adapts its speed to that of the parking brake" event window when the vehi- vehicle in front, but only up to the desired and cle is stationary, the distance control assis- set speed.
  • Page 277 Driving systems The minimum distance for the distance con- the accelerator pedal is depressed, e.g. by trol assistant can be set to 5 levels. If you a vehicle occupant restart the engine, the mean specified dis- the q button is pressed, e.g. by a vehicle tance is available for selection.
  • Page 278 Driving systems Overtaking PPC (Predictive Powertrain Control) It is possible to exceed the set speed, e.g. when overtaking: Maintain a sufficient distance to the vehicle in front. Depress the accelerator pedal. When the overtaking manoeuvre is fin- ished, release the accelerator pedal again. The distance control assistant adjusts the speed to the set speed.
  • Page 279 Driving systems Upper speed tolerance The on-board computer shows the status of PPC by colour: The Ä upper speed tolerance helps to bet- Grey symbol é: cruise control is deac- ter utilise momentum from downhill gradients tivated. and thus save fuel. The upper speed tolerance White symbol é...
  • Page 280 Driving systems which the stored speed may be fallen short In such cases, ABA may: give an unnecessary warning and then To optimise fuel consumption, PPC may brake the vehicle exceed or fall below the speed tolerance by neither give a warning nor intervene a few km/h.
  • Page 281 Driving systems Activating/deactivating Active Brake Active Brake Assist does not automatically Assist adapt to road and traffic conditions. Brake the vehicle using the service brake if: a red event window with the · symbol appears in the on-board computer an intermittent warning tone sounds an intermittent warning tone sounds and automatic partial braking was initiated If no visual and/or acoustic warning is issued...
  • Page 282 Driving systems Collision warning and emergency braking Overview Distance control assistant preliminary warning ( page 275) Active Brake Assist warning Active Brake Assist partial braking Emergency stop (full brake application) Emergency stop completed If a collision warning appears in the on-board computer when the vehicle is in motion: Pay particular attention to the traffic situation.
  • Page 283 Driving systems Emergency Driving on a different line and stationary After emergency braking, the braking finished vehicles message appears in the grey event window in the on-board computer. After emergency braking, the vehicle is held by the service brake for another 5 seconds to prevent it from rolling away.
  • Page 284 Driving systems Overtaking The ability of Active Brake Assist and the dis- tance control assistant to detect vehicles When you are passing, Active Brake Assist pulling into your lane without maintaining a and the distance control assistant may unex- safe distance is limited. It does not detect pectedly issue warnings or brake your vehicle vehicles until they are within the system's if you:...
  • Page 285 Driving systems Obstacles and stationary vehicles Lane Keeping Assist Important safety notes WARNING Lane Keeping Assist cannot always clearly identify lane markings. In these cases, Lane Keeping Assist may: give an unnecessary warning not give a warning There is a risk of an accident. Always pay particular attention to the traffic Active Brake Assist and the distance control situation and keep in lane, especially if Lane...
  • Page 286 Driving systems Functions and activation conditions only an aid. You are responsible for the dis- tance to the vehicle in front, for vehicle speed, Lane Keeping Assist monitors the area in braking in good time and remaining in lane. front of your vehicle with a camera that is Make sure that the windscreen is always kept located at the base of the windscreen.
  • Page 287 Driving systems Press the m button. and trunk roads. Attention Assist is active at If Lane Keeping Assist is deactivated, the speeds above approximately 60 km/h. indicator lamp in the m button lights up. If Attention Assist detects typical indicators The lane marking appears black in the sta- of fatigue or increasing lapses in concentra- tus area of the on-board computer and in...
  • Page 288 Level control Deactivating/activating frame. Driving with a lowered chassis frame increases wear and tear on the vehicle and After starting the engine, Attention Assist is reduces driving comfort. always activated. You can deactivate/acti- Systems vate Attention Assist using the menu window in the settings menu Activating/deactivating the control page 162).

  • Page 289: Level Control

    Level control Activating the control panel Preselection: to raise/lower the rear axle Control panel on the driver's seat: briefly Buttons press the u, t, r, s or T button. To activate the control panel, make a preselection for the front/rear axle, entire vehicle or driving level External control panel on the vehicle body: To activate the control panel, make a...
  • Page 290 Level control Press the u or t button to select Setting the driving level front axle :, entire vehicle ; or rear axle ?. The LEDs for the selected preselection light Press the r button to lower the chassis or the s button to raise it. If the chassis is not at driving level, the ¸...
  • Page 291 Level control Road paver operation removed. This could damage the shock absorbers. Store a constant chassis height for loading and unloading the vehicle. Vehicles with a trailing axle: lower the trail- ing axle ( page 291). If required, raise/lower the chassis to the desired height.
  • Page 292 Level control axles are raised above driving level. The rear Raised vehicle level (vehicles for axle is raised higher than the front axle. This large-capacity transport) allows you to improve the articulation angle whilst manoeuvring, for example. If you drive too fast at shunting level, a yellow event window appears in the on-board com- puter.

  • Page 293: Additional Axles

    Additional axles Additional axles Leading/trailing axle Starting-off aid Environmental note When the leading/trailing axle is raised, roll resistance is reduced. This reduces tyre wear and fuel consumption. Only activate the starting-off aid on snow and ice-covered roads. The vehicle's starting-off aid has either a speed limiter or a time limit (switch-on inter- The leading/trailing axle is lowered just lock).
  • Page 294 Additional axles When loading or unloading the vehicle, Switch the ignition lock to the drive posi- lower the leading/trailing axle. tion. To raise/lower: press the â button. To centre manually: press the upper sec- When the leading/trailing axle is raised, the tion of the Õ...

  • Page 295: Driving Tips

    Driving tips Driving tips become trapped underneath the frame. There is a risk of fatal injury for the occupants of the General notes on driving vehicle in front. Fold the underride guard down and lock it in WARNING place when driving on public roads. If you switch off the ignition while the vehicle is in motion, safety-relevant functions are You can achieve a higher approach/depar-...
  • Page 296 Driving tips Hold underride guard : in position. If you swing underride guard : into road finishing machine operation position r, Swing both levers ; to position 2. leave both levers ; in position 2. Underride guard : is released. Swing underride guard : into the desired Road paver operation position and hold it in place.
  • Page 297 Driving tips Do not use the parking brake in overrun mode The vehicle's level will be adjusted auto- and only perform slight adaptive braking with matically. If the road paver rollers do not the service brake. touch the centre of the approach plate, a different driving level can be set before Notes on the road paver –...
  • Page 298 Driving tips Rules for off-road driving When driving off-road, substances such as dirt, sand, mud and water or water mixed with WARNING oil may get into the brakes. This may lead to a If you drive over obstacles or in ruts, the steer- reduction in braking performance or total ing wheel may jerk out of your grip, causing brake failure as a result of increased wear.
  • Page 299 Driving tips Driving on inclines Secure bulk material (e.g. sand or gravel) with slip-on walls or covers to prevent it WARNING slipping. If you drive up a steep incline at an angle or Secure add-on and attached equipment, turn on a steep incline, the vehicle could slip such as tipper bodies or loading cranes, sideways, tip and overturn.
  • Page 300 Driving tips Replace buckled or damaged wheels. on public roads. Remove any trapped foreign bodies. Replace missing valve caps and valve extensions. Dirt and mud on the tyres and on the road surface reduce road grip, particularly if the Check and adjust the tyre pressure road surface is wet.
  • Page 301 Driving tips stages in the vehicle's operating life as a Economical and environmentally result of the teach-in process aware driving General notes Maintenance Fuel consumption depends on: The fuel consumption and assembly wear depend on regular maintenance. Regular the vehicle version maintenance of the vehicle increases road the operating conditions safety and lowers fuel consumption.
  • Page 302 Driving tips load distribution, e.g. even load distribution Do not warm up the engine while station- increases not only driving safety, but also ary. tyre life Switch off the engine when waiting in sta- Observe the notes on the permissible tionary traffic.
  • Page 303 Driving tips If too many particles collect in the diesel par- ticle filter, the  indicator lamp in the instrument cluster lights up. The on-board computer then instructs you with a yellow event window to start manual regeneration page 170). Manual regeneration lasts approximately 30 minutes up to a maximum of 60 minutes ( page 301).
  • Page 304 Driving tips Stop the vehicle, paying attention to road If you park the vehicle without regenerat- and traffic conditions, and keep the engine ing, you can only begin manual regenera- running. tion after the engine warming-up phase. While doing so, maintain a distance of at Start the manual regeneration after a thaw- least 1 metre to other vehicles, other ing time of up to 60 minutes if:...
  • Page 305 Driving tips Engine oil consumption After running-in the engine, oil consumption may reach 0.2 % of the vehicle's fuel con- sumption. Increased distance covered and more ardu- ous operating conditions could result in vehi- cles exceeding this value. Limiting the speed The reverse warning feature is a system WARNING designed to assist you in ensuring the safety...
  • Page 306 Driving tips 2 minutes. The reverse warning device is the vehicle is stationary for approximately then loud again. 9 minutes with the engine running and a gear selected you select the reverse gear Reverse gear lock you shift the ignition lock to the 0 position or remove the key when the frequent-stop Refuse-collection vehicles only: brake is activated and the parking brake is...

  • Page 307: Refuelling

    0.05% by weight are permissible. However, If fuel is swallowed, seek immediate medi- Mercedes-Benz only recommends fuel that cal attention. Do not induce vomiting. complies with the European standard EN 590 as of 2010 (max. 0.001% sulphur by Change any clothing that has come into weight).
  • Page 308 Refuelling The following fuel types are not permitted: case, twist or tip it before attempting to remove the fuel pump nozzle. sulphurous fuel with a sulphur content greater than 0.05% by volume You will find further information on fuel in the "Service products"...
  • Page 309 Refuelling immediately. Consult a doctor without ® ! Only use AdBlue /DEF in accordance delay. with DIN 70070/ISO 22241. Do not use any additives. ® If you have swallowed AdBlue , immedi- ® ately rinse your mouth with water and drink If AdBlue /DEF comes into contact with plenty of water.
  • Page 310 Trailers/semitrailers Switch off the auxiliary heating system Driving tips for trailers/semitrailers page 133). General notes ® Unlock cap : on AdBlue tank ; with the separate key. ! Always observe the following safety instructions for driving with trailers and Depending on the vehicle's equipment semitrailers: ®...

  • Page 311: Trailers/Semitrailers

    Trailers/semitrailers angle at the front ; or the rear : changes. If the articulation angle between the trac- tor/trailer combination is reduced, the clearance between the tractor vehicle and the trailer/semitrailer is reduced. The articulation angles are dependent on the particular tractor vehicle and trailer/semi- trailer and are influenced by: wheelbase...
  • Page 312 Trailers/semitrailers Information on semitrailer coupling Important safety notes WARNING If the semitrailer coupling is damaged or not correctly engaged, you could lose the semi- trailer. There is a risk of an accident. Always check that the semitrailer coupling is free of damage and properly engaged after coupling-up.
  • Page 313 Trailers/semitrailers The sensor-monitored semitrailer coupling has sensors which, during the attaching/ detaching process or once the ignition has been switched on, perform the following: monitor the semitrailer, the semitrailer coupling pin and the clasp display the status of the locking mecha- nism of the sensor-monitored semitrailer coupling in the display of the on-board com- puter...
  • Page 314 Trailers/semitrailers Tractor/trailer combination When using mudguard centre parts ?, observe the legal requirements for the WARNING country you are currently in. If the trailer coupling has too much longitudi- Release rubber retainers = of mudguard nal play, the trailer can tear away. You could centre parts ? on the left and the right- lose the semitrailer as a result.
  • Page 315 Trailers/semitrailers After coupling up: Cables and compressed-air lines Check that the coupling pin on securing Important safety notes knob : is in the correct position or check the control pin of the trailer coupling. WARNING Connect the cable and compressed-air If you climb onto or down from the vehicle in lines ( page 313).
  • Page 316 Trailers/semitrailers Arrangement of connections Connecting cables and compressed-air lines ! Arrange the cables and compressed-air lines in such a way that they easily yield to all movements without tension, kinking or friction when cornering, etc. Before con- necting the cable, make sure the voltage rating of the consumer equipment on the trailer is correct.
  • Page 317 Trailers/semitrailers Semitrailer tractor vehicles: if the semi- With dual coupling head: push down and trailer tractor vehicle is being driven with a hold the lever at dual coupling head B. semitrailer without ABS, insert the plug of With dual coupling head: remove the the connection cable into empty socket A.

  • Page 318: Wind Deflector

    Example: wind deflector adjustment trailer symbol in red. Mercedes-Benz recommends that you have If the distance to the detected obstacle is the wind deflector adjusted at a qualified spe- less than approximately 0.70 m, a warning cialist workshop.
  • Page 319 Wind deflector Diagrams Example: semitrailer tractor vehicle/platform truck, ClassicSpace cab S = 100 - 700 mm: semitrailer tractor vehicle/platform truck with ClassicSpace cab and an add-on height of 420, 600 or 765 mm Example: semitrailer tractor vehicle/platform truck, CompactSpace cab S = 50 - 700 mm: semitrailer tractor vehicle/platform truck with CompactSpace cab and an add-on height of 420, 600 or 765 mm S = 580 - 700 mm: semitrailer tractor vehicle with CompactSpace cab, side air deflector and...
  • Page 320 Wind deflector Example: semitrailer tractor vehicle/platform truck, StreamSpace cab S = 50 - 700 mm: semitrailer tractor vehicle/platform truck with StreamSpace cab and an add- on height of 420 or 600 mm S = 580 - 700 mm: semitrailer tractor vehicle with StreamSpace cab, side air deflector and an add-on height of 420 or 600 mm Example: semitrailer tractor vehicle/platform truck, StreamSpace cab S = 50 - 700 mm: semitrailer tractor vehicle/platform truck with Stream or BigSpace cab and...
  • Page 321 Wind deflector Example: semitrailer tractor vehicle, StreamSpace cab S = 580 - 700 mm: semitrailer tractor vehicle with Stream or BigSpace cab, side air deflector and an add-on height of 765 mm Example: platform truck, StreamSpace cab S = 50 - 700 mm: semitrailer tractor vehicle with Stream or BigSpace cab and an add-on height of 765 mm...
  • Page 322 Winter operation Example: semitrailer tractor vehicle/platform truck, GigaSpace cab S = 50 - 700 mm: semitrailer tractor vehicle/platform truck with GigaSpace cab and an add- on height of 765 mm S = 580 - 700 mm: semitrailer tractor vehicle/platform truck with GigaSpace cab, side air deflectors and an add-on height of 765 mm Winter operation Winter driving...

  • Page 323: Winter Operation

    Notes on driving ! Vehicles without acceleration skid con- Side panelling with screws (example: Actros sem- trol (ASR): quick changes from slippery to itrailer tractor vehicle) high grip surfaces whilst the drive wheels...
  • Page 324 If you have ques- tions, consult a qualified specialist work- shop. ! Mercedes-Benz recommends that you fit snow chains to all drive wheels. If your vehi- cle has permanent all-wheel drive and you do not fit snow chains to all drive wheels, activate the inter-axle lock.
  • Page 325 Mercedes-Benz Specifications for Service Products. The use of the hydraulic fluid is not permitted in vehicles with a steered leading/trailing axle. A list of approved service products can be found in the Mercedes-Benz Specifications for Service Products.
  • Page 326 Winter operation If the engine does not start: ! The lubricity of the engine oil and trans- mission oil may be reduced at very low out- The starting procedure is automatically side temperatures. Driving a cold vehicle interrupted: may result in damage to the drivetrain and after approximately 60 seconds on vehi- assemblies.
  • Page 327 If the vehicle is parked at outside tempera- tures of below −30 †, it cannot be guaran- teed that the engine will start, even with the cold climate package. Mercedes-Benz advi- ses against parking the vehicle outdoors at outside temperatures of below −30 †.
  • Page 329 Useful information ......328 Power take-offs ......... 328 Tipper operation ....... 333...
  • Page 330 Power take-offs The display of the on-board computer shows Useful information the activation state of power take-off: These Operating Instructions describe all the / Power take-off disengaged models and standard and optional equipment 0 Power take-off engaged of your vehicle that were available at the time Vehicles with transmission-driven power of going to print.
  • Page 331 Power take-offs Preselecting the working speed Engaging power take-off General notes General notes On vehicles with transmission-driven power take-off it is possible to preselect the working speed. Vehicles with Mercedes PowerShift You can preselect the working speed using the multifunction lever. Turn the direction switch to position i.
  • Page 332 Power take-offs play of the on-board computer. The indica- from automatic regeneration also when tor lamp in the U switch then lights up. operating the power take-off on the engine or NMV. Vehicles with manual transmission: when the display shows the engaged power take- Disengaging power take-off off, release the clutch pedal.
  • Page 333 Power take-offs To engage power take-off manually: apply the parking brake. Shift into neutral. Switch off the ignition. Take the adapter, wrench, screwdriver and hammer out of the vehicle tool kit. Remove covering cap : with a screwdriver and a hammer. Place the adapter and wrench at position 2 on the shaft.
  • Page 334 Power take-offs N4W or N4X: turn the wrench to position Press the 9 button to exit the input win- dow. Remove the wrench and adapter. Attach covering cap :. Wait for approximately 3 seconds. The setting is stored automatically. Start the engine. If power take-off is disengaged, / Deactivating the engine-speed setting appears in the display of the on-board com-...
  • Page 335 Tipper operation the selected gear. You may not change gear Tipper operation while driving. On vehicles with an automated Before tipping manual transmission, the transmission changes automatically when the tipper pump WARNING is switched to manual drive program M. The rear exterior lighting is concealed when Park the vehicle on a firm and level surface.
  • Page 336 Tipper operation See the manufacturer's separate operating instructions. Switch off the tipper pump (power take-off) page 328). Raise the chassis frame to driving level page 286). The Û symbol for chassis frames below driving level goes out in the display.
  • Page 337 Useful information ......336 Service products ....... 336 Cleaning and care ......342 Maintenance ........348...

  • Page 338: Useful Information

    Additives may cause damage to able, especially for older vehicles. Informa- major assemblies. Therefore, do not mix tion is available from any Mercedes-Benz Ser- any additives with service products. You vice Centre. are responsible for the results of using fuel additives.

  • Page 339: Service Products

    ! If you mix engine oils with differing oil high quality in accordance with Sheet No. grades, the change interval for the engine 228.51 of the Mercedes-Benz Specifications oil is reduced in comparison to mixtures of for Service Products. The on-board computer engine oil of identical grade.
  • Page 340 Service products Miscibility of engine oils Transmission oil grade The benefits of high-quality engine oils are The quality grade (Sheet No.) of the transmis- diminished if you mix them. sion oil used can be checked and changed in the on-board computer ( page 162).
  • Page 341 Observe the Mercedes-Benz Specifications 0.05% by weight are permissible. However, for Service Products, Sheet No. 310.1. Mercedes-Benz only recommends fuel that Further information about operational and complies with the European standard EN road safety can be obtained from any 590 as of 2010 (max.
  • Page 342 "Euro diesel". Information regarding the current country- ® AdBlue specific sulphur content of fuel can be obtained from any Mercedes-Benz Service ® AdBlue notes Centre or found on Sheet No. 136.2. of the ®...
  • Page 343 Service products unalloyed steel ® If you come into contact with AdBlue observe the following: galvanised steel ® If AdBlue is stored in these types of con- ® Immediately wash AdBlue from your skin tainer, constituents of these metals may with water and soap.
  • Page 344 Mercedes-Benz recommends that you only use care products that have been approved genuine leather covers carefully with a for Mercedes-Benz. You can obtain these damp cloth, then wipe the covers down care products from any Mercedes-Benz Ser- with a dry cloth. Make sure that the vice Centre.

  • Page 345: Cleaning And Care

    Always switch off the windscreen wipers and the ignition before cleaning the windscreen or ! If the vehicle has Mercedes-Benz protec- wiper blades. tive chassis sealing: do not use high-pressure cleaners or pul- WARNING sating circular-jet nozzles.
  • Page 346 Therefore, fold up the step before driving off. Do not drive with the step folded down. Example: Actros L cab, steps and grab handles...
  • Page 347 Steps for semitrailer tractor vehicles Example: large folding step, front To fold down: push step ; up a little, pull Steps and grab handle (example: Actros tractor/ semitrailer combination without side trim panel) out retainer : and swing step ; down to the stop.
  • Page 348 Com- ponents damaged in this way can unexpect- edly fail. There is a risk of an accident. Distance sensor (example: Actros) Do not use high-pressure cleaners with circu- lar-jet nozzles to clean the vehicle. Have dam-...
  • Page 349 Make sure that no water enters the air ! If your vehicle has Mercedes-Benz pro- intake and ventilation openings. tective chassis sealing, do not use a high- Treat the engine with preservative pressure cleaner. You could otherwise agents after it has been cleaned.
  • Page 350 Maintenance ing these Operating Instructions. Always have Maintenance this work and maintenance work carried out Important safety notes by a qualified specialist workshop. Environmental note If circumstances require you to do some main- MS (maintenance system) tenance work yourself, you must observe the Introduction environmental protection requirements.

  • Page 351: Maintenance

    Wear gloves and protective eyewear when opening. Slowly turn the cap half a turn to allow pressure to escape. Maintenance flap (example: Actros) WARNING Service product can be poisonous and haz- ardous to health. There is a risk of injury.
  • Page 352 Maintenance system checked at a qualified specialist work- Observe the instructions on the respective shop. original container when using, storing and dis- If the coolant level in the coolant expansion posing off service products. Always store ser- tank is too low, the on-board computer dis- vice products in the sealed original container.
  • Page 353 The hydraulic fluid for the clutch actuation symbol ( page 169). system must meet the specifications in Sheet No. 345.0 of the Mercedes-Benz Specifica- Add a washer fluid concentrate according to tions for Service Products. Mercedes-Benz Specifications for Service It is not necessary to renew the hydraulic fluid Products Sheet No.
  • Page 354 Maintenance Twist open black cap : of the washer fluid Coarse filter for heating and climate reservoir and remove it. control Refill the washer fluid reservoir. ! The combination filter and pollen filter Replace black cap : and tighten it. may not be cleaned.
  • Page 355 Maintenance Attach air intake slot :. Slide catch ; on air intake slot : in the direction of &. Replacing the wiper blades WARNING If you use the steps and grab handles at the front of the cab when replacing the wiper blades, you could slip and/or fall.
  • Page 356 Maintenance Example: cap To fit a wiper blade: slide the hinge piece of the wiper blade into the bend of wiper Do not add the topping-up quantity shown in arm = in the direction of arrow B. the on-board computer until the menu win- dow shows the 4 symbol.
  • Page 357 Seek medical attention The vehicle can be provided with Mercedes- without delay. Benz protective chassis sealing. The Mercedes-Benz protective chassis sealing is Environmental note a transparent anti-corrosion wax with out- Batteries contain pollutants. standing protective qualities.
  • Page 358 Operating Instructions when han- dling the battery. For safety reasons, Mercedes-Benz recom- mends that you only use batteries which have Examples: batteries in the chassis frame been tested and approved for your vehicle by Mercedes-Benz.
  • Page 359 Maintenance Disconnecting and connecting the bat- Connecting teries Connect the negative terminal clamp first, and then connect the positive terminal WARNING clamp. During the charging process, a battery produ- Do not interchange the battery terminals. ces hydrogen gas. If a short circuit occurs or Replace the battery compartment cover.
  • Page 360 Maintenance Batteries fitted one above the other Screw screws : into the lower battery carrier. Insert the upper battery carrier. Place the battery on the upper battery car- rier. Position upper securing frame = and screw in screws ;. Insert the upper battery carrier. Screw in screws : to the upper battery carrier.
  • Page 361 Maintenance Screw screws : into brackets ;. weekend, there will be a total fuel con- sumption of approximately 60 Ah. Connect the connecting cables between the batteries. To ensure the ability to start the vehicle, observe the notes and instructions in the Connect the negative terminal clamp first, following event windows: and then connect the positive terminal...
  • Page 362 Make sure keeping the batteries adequately charged. that the charging voltage is correct. Do not Mercedes-Benz recommends the following charge new batteries with rapid charging. when replacing the batteries: The charge current of used batteries should...
  • Page 363 When parking up the vehicle, special meas- Observe the safety notes on handling batter- ures according to Mercedes-Benz Specifica- ies. tions for Service Products Sheet No. 382.0 Check the battery fluid level as regularly as need to be taken.
  • Page 365 Useful information ......364 Telediagnosis ........364 Where will I find...? ......364 Cab ............. 368 Engine ..........372 Flat tyre ..........377 Electrical fuses ......... 383 Charging the compressed-air sys- tem ............. 389 Jump-starting, tow-starting and towing away ........389...

  • Page 366: Useful Information

    The tool kit compartment is at the side of the With telediagnosis, you can provide cab above the wheel arch and only accessible Mercedes-Benz Service 24h with detailed from the outside. technical information on your vehicle in the Opening the tool kit compartment event of a breakdown.
  • Page 367 Where will I find...? Vehicle tool kit and emergency equip- ment Important safety notes When working on the vehicle, comply with all safety regulations, such as the operating instructions, regulations concerning hazard- ous materials, environmental protection measures, work safety and accident preven- tion regulations.
  • Page 368 Where will I find...? Overview Stowage compartments and tool kit compartment (Example: tractor/semitrailer combination with L cab) The vehicle tools and emergency equipment are divided into two packages: Spare bulbs Towing eye Fire extinguisher Spare wheel spacer Tyre pressure gauge Vehicle tool kit Tyre inflater hose Hand crank...

  • Page 369: Where Will I Find

    Where will I find...? On vehicles with 2 fire extinguishers, the second fire extinguisher may be in the following storage locations, depending on the vehicle version: in stowage compartment : on the co-driver's side in tool kit compartment = ( page 364) in a protective box on the exterior of the cab rear wall on the driver's side On L cab as car transporter: with lowered berth or seat/berth combination, the fire extin-...
  • Page 370 Wheel chock Tilting area of the cab (example: Actros) Before tilting the cab, carry out the following Example: tractor/semitrailer combination, wheel steps: chock For safety reasons, keep the area in front of Depending on the vehicle version and equip- the cab unobstructed.

  • Page 371: Cab

    There is a risk of an accident and injury. Before every journey, make sure that: Cab tilting pump, in doorway on the right-hand side (example: Actros) the cab is locked Drive position the cab is engaged in driving position and...
  • Page 372 The indicator lamp in the C button goes out. Make sure that the º indicator lamp in the instrument cluster goes out after you start the engine. Remote control (example: Actros) When the º indicator lamp goes out, the cab is locked. If the º indicator lamp...
  • Page 373 does not go out, repeat the process and tip the cab back again.
  • Page 374 Engine Problems when tilting the cab Mechanical-hydraulic cab tilting unit Problem Possible causes/consequences and M Solutions The cab cannot be til- The valve lever of the mechanical-hydraulic cab tilting pump is in ted. the "Tilt back in driving position". Turn the valve lever of the mechanical-hydraulic cab tilting pump so that it points towards the "Tilt forward"...

  • Page 375: Engine

    Engine Stopping the engine WARNING Certain engine components can become very Press external engine start/engine stop : again. hot. There is a risk of injury when carrying out work at the engine. Tilt the cab back to the driving position. Where possible, allow the engine to cool down and only touch the components described below.
  • Page 376 Engine If the fuel pressure was built up using hand pump = on the main filter, you must start the engine within 5 seconds. Otherwise, the fuel pressure decreases and you will have to repeat the procedure. Press the handle of hand pump = on the main filter approximately 250 times in approximately 3 minutes or until there is noticeable resistance.
  • Page 377 Vehicles with OM 936: if the engine does not start, hold the Start/Stop button pressed down to the stop again. Air regulation system Function Upper air regulation system (example: Actros) Environmental note Step If the air regulation system is malfunctioning, Released fuel consumption may increase.
  • Page 378 Engine To open and lock: to open slats ; of the lower air regulation system, carefully fold up one of the middle slats. Turn locking screw = with the Torx key (vehicle tool kit) approximately Ö a turn. The locking lever is unscrewed and locks the lower air regulation system.
  • Page 379 Flat tyre Engine does not start Problem Possible causes/consequences and M Solutions Engine fails to start The flow properties of the diesel fuel are inadequate due to paraffin when the outside tem- separation. perature is low. Malfunctions resulting from paraffin separation can be correc- ted by warming the entire fuel system, e.g.
  • Page 380 Flat tyre then raise the vehicle using the jack, the pneu- You must observe the correct wheel and matic suspension attempts to compensate tyre dimensions as well as the wheel type. the vehicle level. The jack could tip over. ! Do not raise vehicles equipped with a There is a danger of injury.

  • Page 381: Flat Tyre

    Flat tyre not exceed 30 mm. The vehicle could oth- erwise slip off the jack or tip over. do not change a wheel on a slope. The vehi- cle could otherwise slip off the jack. do not place your hands or feet under the raised vehicle.
  • Page 382 Flat tyre Unscrew the spare wheel from the spare Flat tyre on the left-hand side of the vehicle: wheel bracket. turn the multifunction steering wheel to the left as far as it will go. Remove the retaining plate through the centre hole of the wheel rim.
  • Page 383 Flat tyre Position the jack under the jack mounting Position the jack under the jack mounting point on the axle tube. point on the air spring carrier. Air-sprung rear axle Steered trailing axle Example: steered trailing axle Position the jack under the jack mounting point on the air spring carrier.
  • Page 384 Flat tyre Before fitting a wheel Remove any corrosion and dirt from the contact areas of the wheel hub, rim and wheel nuts. Lightly oil the friction contact surfaces between the pressure plate and the wheel nut. Fitting a steel wheel Single tyres: fit the wheel in place and screw on 2 to 3 wheel nuts.

  • Page 385: Electrical Fuses

    The wheels could work loose if the wheel nuts obtain further information from any and bolts are not tightened to the specified Mercedes-Benz Service Centre. tightening torque. There is a risk of accident. The fuse allocation chart is on the inside of Have the tightening torque immediately the main fuse carrier cover.
  • Page 386 Electrical fuses Fuses in base module (GM) for SCA: Layout of the fuses Consumer Brake system 20 A (terminal 30.1) Control unit on the driver's 20 A door Control unit on the passeng- 20 A er's door Drive control, speedometer 20 A (terminal 30) Main fuse carrier...
  • Page 387 Electrical fuses Consumer Consumer Body manufacturer 10 A Drive control, programmable 10 A (terminal 30) special module (terminal 15) Trailer (terminal 30) 20 A Driver assistance system, 10 A adaptive route calculator Trailer ABS (terminal 30) 20 A control unit, reversing cam- era terminal 15 Ignition lock, central gateway Retarder, electronic air pro-...
  • Page 388 Electrical fuses Consumer Consumer Auxiliary heating, adaptive 15 A Loading tailgate 15 A route calculator control unit, Seat heating 15 A voltage transformer 24 V/ 12 V, 10 A terminal 30 Non-MB body electrical sys- 15 A Tyre pressure monitor, rear 10 A stowage compartment lamp, 24 V power socket...
  • Page 389 Electrical fuses Consumer Consumer Brake system 20 A Trailer brake lamp (terminal 30.2) Amplifier (terminal 15) Driver assistance system, 10 A Bi-stable relay reversing camera, exchange dropside body terminal 15 Bi-stable relay Transmission control 15 A Diodes in base module (GM): (terminal 30.2) Drive control, programmable 10 A...
  • Page 390 Electrical fuses Consumer Consumer Illuminated Mercedes star, 10 A Unassigned power socket for hand lamp Unassigned Non-MB body electrical sys- 15 A Unassigned Windscreen heating 25 A Checking and replacing a safety fuse Windscreen heating 25 A Pull the fuse out of the module using the Oil cooling transfer case, 10 A pliers and carry out a visual inspection.

  • Page 391: Charging The Compressed-Air System

    Jump-starting, tow-starting and towing away Press pin ? into ON position 1 and refit the circuit-breaker. Switch on consumers and check that they function correctly. If the automatic circuit-breaker is triggered again, have the electrical system checked at a qualified specialist workshop. Charging the compressed-air system Connection 28 on the electronic air processing unit ! If the supply pressure of the external...
  • Page 392 Jump-starting, tow-starting and towing away ! When you remove the jump leads, let the apron. Do not lean over the battery. Keep bat- engine of the vehicle being jump-started teries out of the reach of children. idle. This avoids damage being caused to If you come into contact with battery acid, the vehicle electronics.
  • Page 393 Jump-starting, tow-starting and towing away Assisting vehicle: run the engine at a high First, connect the negative terminal clamp speed. of the jump lead to the negative terminal of the other vehicle's battery. Start the engine and leave it running at idling speed.
  • Page 394 You can obtain further information from any currently in. Mercedes-Benz Service Centre. If the rear of the vehicle is raised for towing away, fold back the wind deflectors. Manoeuvring/tow-starting and tow-...
  • Page 395 Jump-starting, tow-starting and towing away vehicle driver must adapt your driving styles Grasp licence plate holder ; at the sides to the more difficult conditions. and swing it down. Information on charging the compressed-air Turn CAMLOC pin ? 90° anti-clockwise system using an external compressed-air and remove it.
  • Page 396 You will need a second towing eye in order to lift the vehicle at the front. The person towing away the vehicle should bring one with them or you can purchase one at a Mercedes-Benz Service Centre. The vehicle can thus be raised and towed away.
  • Page 397 Jump-starting, tow-starting and towing away Manually releasing the spring-loaded Positioning on the front axle(s) parking brake cylinder ! Undo the release bolt with a maximum — 4, 5 torque of 70 Nm. Do not use an impact wrench. You could otherwise damage the —...
  • Page 398 Jump-starting, tow-starting and towing away or with a release indicator. Release all the spring-loaded parking brake cylinders on the vehicle. Use chocks to safeguard the vehicle against rolling away. Turn release screw ; of spring-loaded parking brake cylinder : anti-clockwise until the stop in release position 4.
  • Page 399 Useful information ......398 Operating and road safety ....398 Tyre pressures ........400 Tyre pressure table for single tyres ............. 402 Tyre pressure table for twin tyres .. 407...

  • Page 400: Useful Information

    For this reason, avoid tyre ruts and brake tyre condition carefully. A tyre dealer, a qualified specialist workshop or any Mercedes-Benz Service Centre will be able to provide further information about the: tyre load-bearing capacity (LI, Load Index) speed rating (maximum permissible tyre...

  • Page 401: Operating And Road Safety

    Operating and road safety The less tyre tread depth remaining, the Tyre age poorer the road grip and handling character- istics of the vehicle, particularly if the road surface is wet or snow-covered. A tyre has reached the minimum tread depth when the tread wear indicator (arrow) is flush with the tyre tread.
  • Page 402 Mercedes-Benz Service Centre will be able to There is a risk of an accident. provide further information. Observe the recommended tyre pressure and...

  • Page 403: Tyre Pressures

    Tyre pressures Example: room temperature is approximately 20 †. outside temperature is approximately 0 †. set the tyre pressure to around 60 to 80 kPa (0.6 to 0.8 bar/8.7 to 11.6 psi) above that prescribed in the tyre pressure table. The tyre pressures are specified according to E.T.R.T.O.

  • Page 404: Tyre Pressure Table For Single Tyres

    Tyre pressure table for single tyres Tyre pressure table for single tyres Tyres 215/75 R 17.5 Load bearing index 135 Axle load 4,300 kg: 850 kPa (8.5 bar/123 psi) Tyres 12 R 20 Load bearing index 154 Axle load 6,300 kg: 725 kPa (7.25 bar/105 psi) Axle load 6,700 kg: 775 kPa (7.75 bar/112 psi) Axle load 7,100 kg: 800 kPa (8.0 bar/116 psi) Axle load 7,500 kg: 850 kPa (8.5 bar/123 psi)
  • Page 405 Tyre pressure table for single tyres Load bearing index 148 Axle load 6,300 kg: 850 kPa (8.5 bar/123 psi) Tyres 12 R 22.5 Load bearing index 152 Axle load 6,300 kg: 750 kPa (7.5 bar/109 psi) Axle load 6,700 kg: 800 kPa (8.0 bar/116 psi) Axle load 7,100 kg: 850 kPa (8.5 bar/123 psi) Tyres 13 R 22.5 Load bearing index 154...
  • Page 406 Tyre pressure table for single tyres Tyres 305/70 R 22.5 Load bearing index 150 Axle load 6,300 kg: 800 kPa (8.0 bar/116 psi) Axle load 6,700 kg: 850 kPa (8.5 bar/123 psi) Load bearing index 152 Axle load 6,300 kg: 775 kPa (7.75 bar/112 psi) Axle load 6,700 kg: 850 kPa (8.5 bar/123 psi) Axle load 7,100 kg: 900 kPa (9.0 bar/131 psi) Tyres 315/60 R 22.5...
  • Page 407 Tyre pressure table for single tyres Axle load 7,100 kg: 750 kPa (7.5 bar/109 psi) Axle load 7,500 kg: 800 kPa (8.0 bar/116 psi) Axle load 8,000 kg: 850 kPa (8.5 bar/123 psi) Tyres 355/50 R 22.5 Load bearing index 154 Axle load 6,300 kg: 725 kPa (7.25 bar/105 psi) Axle load 6,700 kg: 800 kPa (8.0 bar/116 psi) Axle load 7,100 kg: 850 kPa (8.5 bar/123 psi)
  • Page 408 Tyre pressure table for single tyres Load bearing index 160 Axle load 6,300 kg: 600 kPa (6.0 bar/87 psi) Axle load 6,700 kg: 625 kPa (6.25 bar/91 psi) Axle load 7,100 kg: 675 kPa (6.75 bar/98 psi) Axle load 7,500 kg: 725 kPa (7.25 bar/105 psi) Axle load 8,000 kg: 800 kPa (8.0 bar/116 psi) Axle load 9,000 kg: 900 kPa (9.0 bar/131 psi) Tyres 385/65 R 22.5...

  • Page 409: Tyre Pressure Table For Twin Tyres

    Tyre pressure table for twin tyres Tyres 495/45 R 22.5 Load bearing index 169 Axle load 9,500 kg: 725 kPa (7.25 bar/105 psi) Axle load 10,000 kg: 750 kPa (7.5 bar/109 psi) Axle load 10,500 kg: 800 kPa (8.0 bar/116 psi) Axle load 11,500 kg: 900 kPa (9.0 bar/131 psi) Tyres 12 R 24 Load bearing index 160...
  • Page 410 Tyre pressure table for twin tyres Load bearing index 157 Axle load 9,500 kg: 350 kPa (3.5 bar/51 psi) Axle load 10,000 kg: 375 kPa (3.75 bar/54 psi) Axle load 10,500 kg: 400 kPa (4.0 bar/58 psi) Axle load 11,500 kg: 450 kPa (4.5 bar/65 psi) Axle load 12,000 kg: 475 kPa (4.75 bar/69 psi) Axle load 12,300 kg: 475 kPa (4.75 bar/69 psi) Axle load 12,600 kg: 500 kPa (5.0 bar/72 psi)
  • Page 411 Tyre pressure table for twin tyres Load bearing index 150 Axle load 9,500 kg: 575 kPa (5.75 bar/83 psi) Axle load 10,000 kg: 625 kPa (6.25 bar/91 psi) Axle load 10,500 kg: 650 kPa (6.5 bar/94 psi) Axle load 11,500 kg: 725 kPa (7.25 bar/105 psi) Axle load 12,000 kg: 775 kPa (7.75 bar/112 psi) Axle load 12,300 kg: 800 kPa (8.0 bar/116 psi) Axle load 12,600 kg: 825 kPa (8.25 bar/120 psi)
  • Page 412 Tyre pressure table for twin tyres Axle load 10,500 kg: 725 kPa (7.25 bar/105 psi) Axle load 11,500 kg: 800 kPa (8.0 bar/116 psi) Load bearing index 148 Axle load 9,500 kg: 600 kPa (6.0 bar/87 psi) Axle load 10,000 kg: 650 kPa (6.5 bar/94 psi) Axle load 10,500 kg: 700 kPa (7.0 bar/102 psi) Axle load 11,500 kg: 775 kPa (7.75 bar/112 psi) Axle load 12,000 kg: 800 kPa (8.0 bar/116 psi)
  • Page 413 Tyre pressure table for twin tyres Axle load 10,500 kg: 800 kPa (8.0 bar/116 psi) Axle load 11,500 kg: 900 kPa (9.0 bar/131 psi) Tyres 315/60 R 22.5 Load bearing index 148 Axle load 9,500 kg: 650 kPa (6.5 bar/94 psi) Axle load 10,000 kg: 675 kPa (6.75 bar/98 psi) Axle load 10,500 kg: 725 kPa (7.25 bar/105 psi) Axle load 11,500 kg: 825 kPa (8.25 bar/120 psi)
  • Page 414 Tyre pressure table for twin tyres Axle load 13,000 kg: 825 kPa (8.25 bar/120 psi) Axle load 13,400 kg: 850 kPa (8.5 bar/123 psi) Tyres 12 R 24 Load bearing index 156 Axle load 9,500 kg: 450 kPa (4.5 bar/65 psi) Axle load 10,000 kg: 475 kPa (4.75 bar/69 psi) Axle load 10,500 kg: 500 kPa (5.0 bar/72 psi) Axle load 11,500 kg: 575 kPa (5.75 bar/83 psi)
  • Page 415 Useful information ......414 Vehicle identification plate/axle loads ..........414 Engine data plate ......415 Operating data ........415 Compressed-air reservoir ....417...

  • Page 416: Useful Information

    Vehicle identification number (VIN) and vehicle set by the continuous brake effect of the vehi- identification plate (example: Actros cab with flat floor) cle. You will find this value in your ADR cer- tification. If you require further assistance, Vehicle identification plate : is located in consult a Mercedes-Benz Service Centre.

  • Page 417: Engine Data Plate

    Operating data Engine data plate Reservoir pressures in bar External compressed-air 11.0 - 12.5 source (charging the compressed-air system) Remaining pressure circuits 7.0 - 8.7 Engine OM 936 engine with 7698 cm Idling speed Approx- Example: OM 471 engine imately 600 rpm Engine data plate : is located at the rear of the crankcase on the left-hand side when...
  • Page 418 Operating data OM 473 engine with 15569 cm Tyre pressures Idling speed Approx- Tyre pressure table for sin- page imately gle tyres 402) 500 rpm Tyre pressure table for twin page Engine brake (operating Approx- tyres 407) range) imately Permissible difference in 20 kPa 1000 - pressure between tyres on...

  • Page 419: Compressed-Air Reservoir

    Compressed-air reservoir — only to be cleaned using non-alkaline Level control cleaning agents (aluminium reservoirs). Fill the air suspension via Maximum — to have the interior visible through the connection 28 on the elec- 12.5 bar threaded connections. tronic air processing unit —...
  • Page 420 Compressed-air reservoir Steel reservoir Example: identification plate on the steel reservoir Manufacturer: frauenthal automotive Erhard MB part number Maximum operating pressure (bar) Volume (litres) Year of construction Testing establishment code number...
  • Page 423 Imprint Internet Further information on Mercedes-Benz vehi- cles and Daimler AG can be found on the Internet at: http://www.mercedes-benz.com http://www.daimler.com ® FleetBoard Support If you have questions concerning your Fleet- ® Board TiiRec or DispoPilot.mobile/DispoPi- ® lot.guide, contact FleetBoard Support:...
  • Page 424 É96058489963ËÍ 9605848996 Order no. 6462 9519 02 Part no. 960 584 89 96 Edition 04-14...

This manual is also suitable for:

ArocsAntos

Table of Contents

Save PDF
