ASSEMBLY & OPERATING INSTRUCTIONS
WARNING:
Read this Owner's manual carefully and be sure
your gas grill is properly assembled, installed and
maintained. Failure to follow these instructions
could result in serious injury and/or property
damage. This gas grill is intended for outdoor use
only and is not intended to be installed in or on
recreational vehicles or boats.
Note to Installer
Leave this Owner's Manual with the customer
after delivery and/or installation.
Liquid Propane Gas Grill
Note to Consumer
Leave this Owner's Manual in a convenient place
for future reference.
Customer Service Helpline:
For parts ordering, call:
1-800-530-9133
Model No：
5506270 (K2114M1BAGA2S-1) / M405BZ
Please make sure the cylinder valve connection
device shall properly and safely mate with the
connection device attached to the inlet of the
pressure regulator.
405BZ
• Parts
• Assembly
• Safety Rules
• Use and Care
• Troubleshooting
C1110800031A-A1
Advertisement
Table of Contents
Related Manuals for Monument Grills Mesa 405BZ
Summary of Contents for Monument Grills Mesa 405BZ
- Page 1 ASSEMBLY & OPERATING INSTRUCTIONS 405BZ Liquid Propane Gas Grill • Parts • Assembly • Safety Rules • Use and Care • Troubleshooting WARNING: Note to Consumer Read this Owner’s manual carefully and be sure Leave this Owner’s Manual in a convenient place your gas grill is properly assembled, installed and for future reference.
-
Page 2: Table Of Contents
Amazon or other marketplace internet Recreational vehicles, ANSI A 119.2, and CSA Z240 retailer from any entity other than Monument Grills is not an original purchase and will not qualify for a warranty RV series recreational vehicle code, as applicable. -
Page 3: Safety Precautions
Safety Precautions A tank of approximately 12 inches in diameter by 18- • Have your LP gas tank filled by a reputable 1/2 inches high is the maximum size LP gas tank to propane gas dealer and visually inspected and use. - Page 4 WARNING Burner Flame Check A strong gas smell, or the hissing sound of gas indicates a serious problem with your gas grill or the LP gas tank. Failure to immediately follow the steps listed below could result in a fire or explosion that could cause serious bodily injury, death, or property damage.
-
Page 5: Hardware List
Contents for Hardware Pack The following table illustrates a breakdown of the hardware pack. It highlights what components are used in the various stages of assembly. Tools required for assembly Philips Head Screwdriver (not included). Note: The left and right sides of the grill are on your left and right as you face the front of the grill. Philips Head Screwdriver... -
Page 6: Assembly Diagram
Model 5506270 (K2114M1BAGA2S-1) / M405BZ Assembly Diagram... -
Page 7: Assembly List
Model 5506270 (K2114M1BAGA2S-1) / M405BZ Assembly List To make sure you obtain the correct replacement Important: Use only parts listed above. When parts for your gas grill, please refer to the part ordering parts, providing the following information: numbers on this page. 1. -
Page 8: Assembly Instructions
Assembly Instructions Figure 1 Please insert Locking Caster(No.22) into the Bottom plate(No.23). Half screw out the screws in the bottom plate, then put Side Panel,Right(No.18)and Side Panel,Left(No. 29)onto Figure 2 the relevant screw holes and screw tightly. - Page 9 4 × A Install Back Panel, Bottom(No.17) onto Figure 3 the relevant place with four A screws. Half screw out the screws in the bottom and side plates, then put Triangle Bracket(No.21) Figure 4 onto the relevant screw holes and screw tightly.
- Page 10 4 × F Install Cart Frame, Front(No.12) onto the relevant place with four F screws. Attention: magnet downward. Figure 5 Figure 6...
- Page 11 4 × A Figure 7 Screw the grill body and the cart tightly with four A screws. Half screw out the screw in the grill body, then put Side Shelf, Figure 8 Left(No.34) onto the relevant screw holes and screw tightly.
- Page 12 2 × A 2 × D Install Side Shelf, Left(No.34) onto grill body Figure 9 with A screw and D spacer. Half screw out the two big screws outside the grill body, then put Side Shelf, Right(No.14) Figure 10 onto the relevant screw holes and screw tightly.
- Page 13 2 × A 2 × D Screw Side Shelf,Right(No.14) tightly with Figure 11 A screw and D spacer inside the grill body. 1. Insert Side Shelf,Right(No.14), LED Lamp Panel(No.15) and Control Knob(No.16) as the figure shows. Figure 12 2. Insert the wire as the figure shows.
- Page 14 Half screw out the screw in Side Shelf,Right(No.14), Figure 13 then put it into the hole of Side Burner Igniter Wire(No.6) and screw tightly. 1× F cut of two white plastic tie. Figure 14 Fixed Regulator connecting piece on the Right plate with one F crew.
- Page 15 2 × C Put the Spindle Below Door Panel(No.24) into Figure 15 the relevant hole in the bottom plate. Figure 16 Install the Door Handle(No.27) onto the Front Door(No.25/26).
- Page 16 Figure 17 Install the Front Door(No.25/26) onto the Cart Bottom Shelf(No.23). 2× F 1. Install Grease Tray(No.30) onto Grease Box Bracket(No.31) with two F screws. 2. Put Grease Box(No.31) into Grease Box Bracket(No.32). Figure 18 3. Put the grease tray into the grill body.
- Page 17 Connect the Battery Wire. Figure 19 Paste the Battery Box(No.19) onto the side panel. Put Warming Rack(No.8), Cooking Grid(No.9/10), Figure 20 Flame Tamer(No.11/37) into the relevant place.
- Page 18 Install Gas-jar Fixing Line（No.20) onto the bottom plate. Pass bottle opener (No.35) through Side Panel,Left (No.29) and fix it Figure 21 on Bottle opener retainer (No.36).
- Page 19 Connecting LP Gas Tank to LP Grill 1. Place foot ring of 20 lb tank into the hole in bottom panel. Make sure the tank valve is in OFF Regulator Connection position.(Fig.21). 2. Check the tank valve to ensure it has proper external mating threads to fit the hose and regulator assembly provided.
-
Page 20: Lighting Instructions
Checking for LP gas leaks Never test for leaks with a flame. Prior to first use, at the beginning of each season, or every time your LP gas tank is changed, you must check for gas leaks. 1. Make a 50/50 (soap/water) mild soap solution. 2. - Page 21 If Grill Still Fails To Light WARNING 1. Check gas supply and connections for leaks. Check Never lean over the grill cooking area while that all wire connections are secure. lighting your gas grill. Keep your face and body a safe distance (at least 18 inches) from the 2.
-
Page 22: Cleaning And Maintenance
Cleaning and Maintenance Cleaning Exterior Stainless Steel Surfaces To ensure a proper working unit the following proper care and maintenance is suggested. •Weathering and extreme heat can cause exterior stainless steel surfaces to turn tan in color. Cleaning Cooking Grids Machine oils used in manufacturing process of We suggest you wash your cooking grids in a mild soap stainless steel can also cause this tanning color. -
Page 23: Troubleshooting
3. Inspect each burner for damage (cracks or holes) Regardless of which burner cleaning procedure you and if such damage is found, order and install a new use, we recommend you also complete the following burner. After installation check to ensure that gas steps to help prolong burner life. -
Page 24: Cooking Instruction
Cooking Instructions Indirect Cooking WARNING To cook indirectly, the food should be placed on the Do not leave the grill unattended. left or right side of your grill with the burner lit on the Your grill will get very hot. opposite side. -
Page 25: Cooking Chart
Grill Cooking Chart WARNING: To ensure that it is safe to eat,food must be cooked to the minimun internal temperatures listed in the table below. *United States Department of Agriculture...
