Dreo Aircrisp Pro - Smart Control Air Fryer Manual

Getting to Know Your Air Fryer

Control Panel

Control Panel

Operating Buttons

Power ON/OFF
  1. Press POWER to turn on the air fryer.
  2. Press POWER to start or pause cooking
  3. Press and hold POWER for 2 seconds to turn off the air fryer when it is on.

Preset Menu

Repeatedly press to select a preset.

Preheat

Press to preheat your air fryer.


Temperature +/-

Adjust the cook temperature.


Time +/-

Adjust the cook time.

Specifications

Model DR - KAF002
Voltage 220-240VAC, 50 / 60 Hz
Power 1500W
Capacity 3.8 Liter
Temperature Range 40°C - 200°C

Package Contents

1 x 3.8 Liter Air Fryer
1 x Non-Stick Plate
1 x Recipe Book
1 x Reference Guide
1 x User Guide

Product Diagram

Product Diagram

Using Your Air Fryer

Before First Use

There's plastic inside! Make sure to pull out and separate the baskets (on a countertop), and remove ALL plastic before plugging in.
Before First Use

Initial Use

Note:

  1. Before first use of your new Air Fryer, we strongly recommend you to clean and preheat the air fryer at 200°C for 15 minutes to remove any remaining odor.
  2. Then wash the non-stick plate and basket with hot, soapy water and a non-abrasive sponge.

  1. Tap to turn on.
  2. Tap MENU to select STEAK.
  3. Adjust time to 15 minutes.
  4. Tap to start.

Preheating

It is recommended to preheat before placing food into the air fryer unless your air fryer is already hot. Food will not cook thoroughly without preheating.

  1. Plug into an electrical outlet. Tap to turn on the air fryer.
  2. Press , the display will show default setting 200°C and 3 minutes.
  3. Optionally, you can press and to change the cooking temperature, the time will adjust accordingly.
  4. Press to start preheating.
    Preheating - Step 1
  5. When preheating is done, the air fryer will beep 3 times and the display will show "READY"
    Preheating - Step 2
The basket and plate will become very hot after the heating. Allow them to cool before taking them for cleaning.

Preset Default Settings

For general users, using a preset menu is the easiest way to air fry. Preset menus are programmed with an ideal time and temperature for cooking certain foods.

Symbol Preset Default Temperature
(°C)
Adjustable Temperature
(°C)
Default Time
(Min)
Adjustable Time
(Min)
Shake Reminder
French Fries 195 80~200 20 1~60 Y
Steak 200 80~200 10 1~60 -
Chicken 195 80~200 20 1~60 Y
Fish 175 80~200 10 1~60 -
Bread 175 80~200 8 1~60 Y
Vegetable 150 80~200 10 1~60 Y
Dehydrate 50 40~80 6 hour 1~72 hour -
Reheat 120 50~180 10 1~60 -

Note:

  1. Cooking time may vary as your desired flavor or thickness of ingredients, etc. You can check food during the cooking process.
  2. Shake reminder will alert you when 60% of the cooking time has passed, which is ideal for evenly cooking both sides of your food. The LED display will show "SHAKE" with 2 consecutive beep sounds that repeat 5 times.

Air Frying Under Preset

  1. Preheat your air fryer first.
  2. Place the ingredients in the air fryer after preheating is done and the display shows "READY".
  3. Repeatedly press to select a preset menu.
  4. Press to start air frying.
  5. Shake or flip the food following the prompt of the air fryer if a preset with shake reminder is selected. The LED display will show "SHAKE" with 2 consecutive beep sounds and repeating 5 times.
    Air Frying Under Preset - Step 1
  6. Once finished, the air fryer will beep 3 times and the display will show "END".
    Air Frying Under Preset - Step 2

Note:
You can adjust temp and time by pressing temperature +, temperature - and time +, time - during cooking process.

Manual Air Frying

  1. Preheat your air fryer first.
  2. Place the ingredients in the air fryer after preheating is done and the display shows "READY".
    Manual Air Frying - Step 1
  3. Repeatedly press to select a preferred preset menu.

    Note:
    If you would like to receive a shake reminder, select a preset with Shake Reminder.
  4. Adjust temperature and time by pressing and .
  5. Press to start air frying.
  6. Shake or flip the food following the prompt of the air fryer if a preset with shake reminder is selected. The LED display will show "SHAKE" with 2 consecutive beep sounds and repeating 5 times.
    Manual Air Frying - Step 2
  7. Once finished, the air fryer will beep 3 times and the display will show "END".
    Manual Air Frying - Step 3

Cooking Guide

  1. Don't overfill the basket, or the food will cook unevenly.
  2. Pat dry liquid-marinated food with a paper towel before air frying.
  3. To make your food crispier, you can spray or brush a small amount of oil on both sides of the food.
  4. Use presets with shake reminder for tossing ingredients or for the food that needs shaking/flipping during cooking.
  5. Checking food while air frying
    1. Checking food
      Take out the air fryer basket and check food, the air fryer will automatically pause.
    2. Resume cooking
      Place the basket back and the air fryer will resume the air frying.
  6. Cook time and temperature can be adjusted at any time during cooking. Simply press TIME or TEMP arrows to adjust the time or temperature.
  7. To convert recipes from a conventional oven, reduce the temperature by 10°C, and cut cooking time by 20%. Please check food frequently to avoid overcooking.
  8. An instant-read thermometer is recommended to use to monitor the internal temperature of proteins. After the cooking time is complete, remove food immediately to avoid overcooking.

More Functions

  1. Auto Standby
    The air fryer will automatically turn off if there is no button pressed in 5 minutes and the air fryer has no active air frying programs.
  2. Auto Pause/Resume
    The air fryer will automatically pause when the basket is removed. Reinsert the basket and cooking will resume.

Maintenance & Service

Cleaning and Maintenance

Unplug your air fryer and let it cool to room temperature before cleaning.
Cleaning and Maintenance

Non-Stick Plate (Dishwasher Safe)

  1. Use dishwasher for cleaning.
  2. Or wash the non-stick plate with hot, soapy water and a non-abrasive sponge. Soak if necessary.

Notes:

  1. Remove, disassemble and clean after each use.
  2. Ensure all grease and food debris are fully removed.

Air Fryer Basket

  1. Wash the baskets with hot, soapy water and a non-abrasive sponge. Soak if necessary.
    Cleaning Air Fryer Basket
  2. Or use dishwasher for cleaning.

Notes:

  1. Clean after each use.
  2. Ensure all grease and food debris are fully removed.

Heating Element

Use a soft brush to clean the heating element.
Cleaning Heating Element

Inside of the Air Fryer

Use a slightly moist, non-abrasive sponge or cloth to clean the inside of the air fryer. Do not immerse in water.
Cleaning Inside of the Air Fryer

Dry Before Using

Dry Before Using

Note:
It is recommended to use degreaser for efficient cleaning of remaining residue.

Customer Support

We're Here to Help!

If you encounter any issues or have any questions regarding your new product, please contact our helpful Customer Support Team.

uk-support@dreo.com

* Please have your order confirmation number ready before contacting Customer Support.


Scan or visit us on Facebook
to connect with us and explore top tips, latest recipes and new ideas.
Ask us anything and we're always ready to help.

@Dreo


Scan or visit dreo.com/warranty
to extend your warranty by registering your product. If you need any help, don't hesitate to email us to get expert support!

www.dreo.com

Troubleshooting

Problem Possible Solution
The air fryer will not turn on. Make sure the air fryer is plugged in.
Push the baskets securely into the air fryer.
Foods are not completely cooked. Place smaller batches of ingredients into the basket. If the basket is overstuffed, then ingredients will be undercooked.
Increase cooking temperature or time.
Foods are cooked unevenly.

Ingredients that are stacked on top of each other or close to each other need to be shaken during cooking.

The non-stick plate should be placed in the basket.

Foods are not crispy after air frying. Spraying or brushing a small amount of oil on foods can increase crispiness (see Cooking Guide).
Temperature won't go higher than 200°C. The max temperature is 200°C for STEAK only. Please refer to Preset Default Settings.
White smoke is coming out of the air fryer. The air fryer may produce some white smoke when you use it for the first time. This is normal.
Make sure the basket and the non-stick plate is cleaned properly and not greasy.
Frying greasy foods will cause oil leaks into the basket. This oil will produce white smoke. This is normal and should not affect cooking.
Dark smoke is coming out of the air fryer. Immediately unplug your air fryer. Food is burning. Wait for smoke to clear before pulling the basket out.
How do I pause or stop the cooking? Remove the basket from the unit to pause the cooking and place it back to resume. Press and hold POWER for 2 seconds to turn off the air fryer.
Is the basket safe to put on my countertop? Use caution when handling, and place on heat-safe surfaces only.
The Display shows Error Code "E1". There is an open circuit in the temperature monitor. Contact Customer Support.
The Display shows Error Code "E2". There is a short circuit in the temperature monitor. Contact Customer Support.

If your problem is not listed or still persists, contact our Customer Support at uk-support@dreo.com.

Important Safety Instructions

BEFORE USING THIS APPLIANCE READ ALL INSTRUCTIONS AND CAUTIONARY MARKINGS IN YOUR USER GUIDE AND ON THE APPLIANCE

When using an electrical appliance, basic precautions should always be followed, including the following:

burn hazard DO NOT touch hot surfaces. Use handle.

burn hazard DO NOT block any ventilation openings. Hot steam is released through air outlet. Keep your hands and face clear of openings.

To protect against electrical shock, do not immerse the appliance, cord, or plug in water or other liquid.

  1. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by person responsible for their safety.
  2. Check if the voltage indicated on the appliance corresponds to the local main voltage before you connect the appliance.
  3. DO NOT operate the appliance if the plug, the main cord or the appliance itself is damaged. Always make sure that the plug is inserted properly into a wall outlet.
  4. Close supervision is necessary when any appliance is used by or near children. Children should be supervised to ensure that they do not play with the appliance. Cleaning and user maintenance shall not be done by children unless they are older than 8 and supervised.
  5. DO NOT let the power cord hang over the edge of table or counter. Keep away from hot surfaces.
  6. DO NOT plug in the appliance or operate the control panel with wet hands.
  7. Never connect this appliance to an external timer switch or separate remote control system in order to avoid a hazardous situation. To disconnect, turn off the appliance, then remove plug from the wall outlet.
  8. Keep your air fryer away from flammable materials (curtains, tablecloth, etc.). Use on a flat, stable, heat-resistant surface away from heat sources or liquids.
  9. DO NOT place on a stove, near gas or electric burners, or in a heated oven.
  10. DO NOT place the appliance against a wall or other appliances. Leave at least 4 inches of free space on the back and sides and 4 inches of free space above the appliance.
  11. DO NOT use the appliance for any other purpose than described in this User Guide. The use of accessory attachments not recommended by the appliance manufacturer may cause injuries.
  12. DO NOT leave the appliance unattended while in use. Extreme caution must be used when moving an appliance containing hot oil or other hot liquids.
  13. DO NOT use outdoors.
  14. DO NOT place anything on top of your air fryer. DO NOT store anything inside your air fryer.
  15. After using the appliance, the metal cover inside is very hot, avoid contact with it after cooking. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts, and before cleaning the appliance.air fryer. DO NOT store anything inside your air fryer.
  16. Immediately unplug the appliance if you see dark smoke coming out of the appliance. Wait for the smoke emission to stop, before you remove the pan from the appliance.
  17. This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. DO NOT attempt to modify the plug in any way.

FOR HOUSEHOLD USE ONLY

READ AND SAVE THESE INSTRUCTIONS
