Quick Start Guide
FSM-IMX636 Devkit
Quick Start Guide
2023-07-10
(Contents on Page 2)
Version 1.0a
www.framos.com
Contact Information
FRAMOS GmbH
Technical Support: support@framos.com
Website: https://www.framos.com
Unpack the IMX636 Devkit contents. The
1
front-end should ship pre-assembled.
NOTE Always read the user manual before operating.
To access the user manual, refer to step 6.
4
Connect the PixelMate™ to the FPA.
Connect by mating Pin 1 to Pin 1.
WARNING
Connect by mating pin 1 to pin 1 as illustrated.
Do not invert the pinout orientation during installation.
Failure to orient the connection as illustrated will lead to
permanent equipment damage.
Connect the PixelMate™ to the FRAMOS
2
Sensor Adapter (FSA). Connect by
mating Pin 1 to Pin 1.
WARNING
Connect by mating pin 1 to pin 1 as illustrated.
Do not invert the pinout orientation during installation.
Failure to orient the connection as illustrated will lead to
permanent equipment damage.
Prepare the processor board and power
5
on according to the manufacturers
instructions.
NOTE See NVIDIA® documentation for instructions.
Connect the FRAMOS Processor Adapter
3
(FPA) to the processor board.
With assembly complete, download and
6
install the required drivers and software.
www.framos.com/fsm-startup
