Mini wall mount vesa 200x200, 400x400, 600x400 led, lcd, pdp tv 32″ ~ 65″ (12 pages)
Summary of Contents for Samsung WMN750M/XC
Page 1
VESA 200 x 200, 400 x 300, 400 x 400, 600 x 400 LED, LCD, PDP TV 33 ″ ~ 65 ″ imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com Model Serial No.
Page 2
Assembly to Wall 200 mm (7.88″) 400 mm (15.75″) 600 mm (23.62″) Mini wall mount Concrete, Wood 13 mm (0.5″)
Page 3
Assembly to TV ■ 2019 TV Q90R ■ Q9FM 65″ S-2 (M8 x L35) ■ KS9500~KS9800 65″ ■ S-10 (M8 x L55) 2019 TV Q70R~Q85R ■ S-6 (M8 x L30) 2017 TV MU8000~MU9000 (Curved TV) ■ S-2 (M8 x L35) 2017 TV MU8000~MU9000 (Flat TV) 2017 Premium Curved TV 49 ″...
Page 4
■ S-6 (M8 x L30) 2016 TV KS8000~KS9000 2016 Premium Curved TV 49 ″ ~ 65 ″ 2016 Premium Flat TV 49" ~ 65" Holder ring Holder ring (supplied with the TV) (supplied with the TV) ■ 2019 TV Q60R, RU8900~RU7000 ■...
Page 5
■ 2018 QLED TV Q9FN 55″ ~ 65″ S-5 (M8 x L40) ■ 2018 8K TV Q900R 65″ Holder ring (supplied with the TV)
Page 7
(M5 x L65 mm-Wood) 40 mm 17 mm Ⅱ (1.57”) (0.67”) x 4 (M8 x L35) x 4 (M8 x L30) x 4 (M8 x L47) S-10 x 2 (M5 x L15) x4 (M8 x L42) x 4 (M8 x L55) 2T x 4 1T x 4 x 4 (M8 x L40)
Page 9
Assembly to TV ■ 2019 TV Q90R S-2 (M8 x L35) ■ 2017 QLED TV Q9F 65″ ■ 2016 LED TV KU6000 ■ 2016 LED TV K5100~K5300 ■ S-5 (M8 x L40) 2017 LED TV M5000 ■ 2016 LED TV KU6300 40″ ■...
Page 10
■ 2018 QLED TV Q9FN 55″ ~ 65″ S-5 (M8 x L40) ■ 2018 8K TV Q900R 65″ Holder ring (supplied with the TV)
