Page 2
Therefore, Philips reserves the rights to revise this user guide or withdraw it at any time without prior notice. Philips provides this user guide «as is» and does not accept, except as required by applicable law, liability for any error, omission or discrepancy between this user guide and the product described.
Page 3
Go to previous menu Press Quickly return to idle Press and hold when browsing menus Lock/unlock the Press and hold keypad in idle mode. View the last call made Press Change the Press and hold language used language and press Access a function Press >...
1. Getting started ...1 Insert the SIM card ...1 Switch on the phone ...1 Set date and time ...2 Copy the SIM phonebook ...2 Charge the battery ...2 2. Main features ...4 Access and consult the phonebook ...4 Make a call ...4 Answer and end a call ...4 Change the ringer ...4 Activate the silence mode ...5...
Page 5
6. Mix music ... 18 How to..18 Getting started ... 18 Activate tracks ... 18 Change track melodies and instruments 19 Change the tempo ... 19 Record a mix ... 19 Start recording ... 19 Manage the recording ... 20 Create your own style and mix ...
Page 6
GPRS attach ... 37 Register again ... 38 Preferred list ... 38 Access settings ... 38 Time and date ... 39 Clock display ... 39 Set date ... 39 Date format ... 39 Time zone ... 40 Daylight saving ... 40 Set time ...
Page 7
Make a second call ... 81 Answer a second call ... 81 Answer a third call ... 82 Conference call ... 82 Explicit call transfer ... 83 Icons & symbols ... 84 Precautions ... 85 Troubleshooting ... 89 Philips authentic accessories ... 92...
1 • Getting started Read the safety instructions in the «Precautions» section before use. To use your phone, you must insert a valid SIM card supplied by your GSM operator or retailer. The SIM card contains your subscription, your mobile number, and memory in which you can store phone numbers and messages (see “Contacts”...
protect it from unauthorised use. It is preconfigured and communicated to you by your operator or retailer. To personalise the PIN code, see page 37. If you enter a wrong PIN code 3 times, your SIM card is blocked. To unblock it, you must request the PUK code from your operator.
Page 10
Once the battery and battery cover are clipped on the phone, plug the connector of the charger (supplied with the phone, in the box) into the LEFT hand socket at the base of the phone on one end, then plug it into a main AC power socket with easy access on the other end.
2 • Main features Access and consult the phonebook In idle mode, press the selected phonebook (in SIM or in Contacts phone), the content that appears on the screen may vary: see “Contacts” page 22 for details on this subject. To consult the phonebook during a call, press select List, press...
Lock / unlock the keypad You can lock the keypad to protect the keys from being pressed accidentally Keypad lock (e.g., when the phone is in your pocket). To lock the keypad, press and hold screen. To unlock the keypad, press and hold again.
Fotocall: see and hear who’s calling This feature is available only when selecting the phonebook in the phone (not the one in the SIM card). This feature allows you to link one or several names to a group. When a name in that group calls, it will appear along with the corresponding picture, and the melody defined for that group will ring.
We advise you to notify the caller if you intend to record the conversation you have with them and only record if they agree. You should also keep any recording private. 1 min. is the maximum recording time available (see “Sound recording” page 64). To record a conversation during a call: While one or several simultaneous calls are in progress, press...
3 • Menu tree The table below describe the complete menu tree (first to third levels) of your mobile phone, as well as the page reference you should refer to for more information concerning each feature or setting. Settings p29 Sounds p29 Silent / Ringer volume / Ringer / Messages Ringer / Equaliser / Key tones / Sounds...
Page 16
E-Mail p45 For each available mail box Settings / Open mailbox / Send mail Broadcast Message p53 Reception / Topics / District codes Instant message p54 MMS p55 Create an MMS / Receive an MMS / Manage folders / Settings Multimedia p63 Picture album p63 List of available pictures...
Page 17
Call information p71 Call settings p71 Call forward / Mailboxes / Auto redial / Any key answer / Call waiting / Caller ID Call list p72 Call list / Reset Call counters p73 GSM counters / GPRS counters Contacts p22 View names list Settings Delete all / Contacts select / Groups setting...
4 • Text or number entry Text can be entered in editing screens in two different ways: by using T9 ® predictive Text Input, or basic text input. Two other modes for numbers and punctuation marks, are also available. Icons appearing on the screen show the active text mode.
Basic text input If you wish to access the basic text input, select «Abc» basic text input using key. This method requires multiple key presses to reach the desired character: the letter «h» is the second letter on the key, so you must press it twice to enter «h». Using this mode requires you press a key as many times as is equal to the order of the letter.
5 • Taking pictures Your mobile phone features a digital camera that allows you to take pictures, store them in your phone, use them as wallpaper or send them to your friends and relatives. How to... Long press Activate /deactivate press the camera deactivate.
active, i.e. when the preview is displayed on the screen Press to access any of them. Camera mode Two modes are available: Normal According to ambiant light level, press between modes, which are reflected by the icons in the bottom of the screen (sun & moon). Picture resolution The default picture size of the standard format is 128 x...
With the self-timer If the self-timer option is On, press activate it (or press if the option is Off). The countdown starts at -10 seconds (this value cannot be changed). A beep is played 2 seconds before the picture is taken, then again when it’s actually shot.
As mentioned earlier, Foto Talk is also available from the Picture album menu. Receive a call When receiving a call while using the camera: Answering the call will quit any action linked to the camera: picture preview, picture shot, self- timer, options browsing, etc.
Picture resolution Allows you to choose a resolution available among the following: Q VGA (320 x 240 pixels), (160 x 120 pixels) and 128 x 128. The default mode 128 x 128. Taking pictures Picture quality Allows you to choose an image quality available SQ VGA among the following: Low, Medium, High.
6 • Mix music With BeDJ, you can create your own sound by using a predefined BeDJ style (as explained below), or any SP-MIDI or MIDI ring tones present in your phone, or that you downloaded via WAP, E-mail, etc. (refer to relevant chapters in the present user manual for complete information).
to open the track selection list. Key is always dedicated to the voice track. The activated track appears in orange, and the above table displays the name of the relevant melody and instrument. Change track melodies and instruments Press and hold keys track you would like to change.
Press to stop recording. The recording will stop automatically when the mix reaches 50 KB (approximately 2 min.). Capacity depends on the memory available in your phone: select Multimedia > Memory Status for memory information. Manage the recording As soon as you stop recording your mix, a window automatically opens and displays the following options for you to choose from: Allows you to record a new mix by...
From scratch When selecting Advanced, BeDJ opens a complete new set of empty tracks. Press and hold : the list of all the MIDI files present in your phone appears on the screen. Select one of them and press A new list appears, showing all tracks of the selected MIDI file (max.16).
7 • Contacts All operations described in this chapter require the relevant phonebook, whether in the SIM or in the phone to be selected. Your mobile phone has two phonebooks. The SIM phonebook is located on the SIM card and the number of entries depends on the card capacity.The second phonebook is built into the mobile’s memory and can hold up to 299 names.
can still use the phonebook of your SIM card, even though it features less fields of information. Phone’s phonebook Your mobile phone only manages one phonebook at a time and will ignore the information relative to the other one: e.g., if «Smith» is present in both phonebooks and if you delete it in the phone, it remains unchanged in the SIM.
Add a record in the phone’s phonebook Add a name field Press to enter the phonebook, select <New>, and then press Enter the last name of your contact and confirm by pressing , then enter their first name and confirm by pressing One of the two name fields can be empty, but not both.
Picture album and select a melody in the ringer list. When they call, you will truly be able to see and hear them. To use Fotocall, you need to be using the phonebook in the phone; if you are not already doing so, see “Copy the SIM phonebook”...
Page 33
Select and press . Choose the type of <New> field to be added and press number or text, then press Repeat steps 1 and 2 to add up to 6 fields to the same record. Make a short press on back to the previous menu, or a long press to go back to the idle mode.
Copy to SIM As mentioned earlier, entering names in the SIM phonebook can be useful if you Copy to SIM change phones frequently. If you copy phone numbers into the SIM card, your phonebook is always updated when switching phonebooks or when using another phone.
Page 35
the list (Mobile, Home, etc.). Press the next carousel and select Call. In all cases, press to hang up. Use Flash dial In idle mode, press and hold a key between Flash dial associated entry to access page 31): connection is established. Press hang up.
8 • Settings menu allows you to customise your Settings phone and change the settings related to each available option (sounds, time and date, security, etc.). The Profiles menu allows you to change several settings at once (see page 40). Sounds Silent Allows you to set the...
Key tones Allows you to set the key tones Off. Even when set Off, DTMF are played during calls (see page 80). Key tones Sounds Alerts Allows you to set alert beeps for the following items: Sounds Alerts - when an Event you programmed in your organiser is due,...
to be used as screen saver, only this picture will be displayed. Select and press Start delay value. When in idle mode, the screen saver will start according to the time limit you have set. Then select the Display period timing you have set will be applied between each picture of the slideshow.
Page 39
Select a key from Browse the list to select the function you wish to associate with this key (see list following). Press to confirm your choice. If the selected key is already set, you can reprogram it: select Settings > Hotkeys > a hotkey in the list. Press twice, select Change and press to the list of available functions.
Page 40
Activates the which extends the battery autonomy (animation off, vibra off, backlight Activ. Autonomy off, ringer volume medium). Direct access to the Calculator. Calculator Redials the last number called. Redial last no. Redials the number of the last call received. Reply last no.
Dials the number of your voice mailbox. Voice mail box Direct access to the Brick Game Opens the Games Subscription dependent Games Direct access to the Euro converter (from currency). -> Euro Direct access to the Euro converter (to currency). The Euro converter is available upon Euro ->...
Voice dial Voice dial allows you to quickly call a name from your phonebook: set a voice Voice Dial tag by recording a word that will call the corresponding name when pronounced. Select Settings > Voice dial Browse the list to select the call number to be set with a voice tag.
calls to this list via the Call restriction This feature is subscription dependent and requires a PIN2 code (see page 37). Call restriction Allows you restrict the calls to the list. In this case, you can only Names Call restriction access the names of the as opposed to the phonebook of the main menu.
Change codes Allows you to change your PIN 2 codes, as well as the call Change codes code. Depending on your SIM card, some features or options may require a PIN2 secret code. This is a second secret 4 to 8-digit code given to you by your operator.
energy consumption, however it will increase the connection delay. In spite of these settings, you must still select the bearer (GSM or GPRS) in the menus of each application to be used (e.g., WAP, MMS, e-mail, etc.). Register again Provides you with a list of the networks available in the area when the Register again mode is selected.
to enter an ISDN ISP number, OR ISDN No. to enter an analogic number. Analogic No. In both cases, enter the «+» sign followed by the number provided by your operator and press Contact your operator to know what type of number you should select.
Time zone The time zone and daylight savings are to be set first. You should then double-check date and time if previously set. To know which time zone you are in, we recommend you to check in an atlas or an encyclopedia.
Page 48
also long press this key to deactivate it and go back to the Personal settings. The settings listed in the column Personal, in the following table, are default settings preset during production. As you can change them, the personal settings in your phone may differ from the table. Each box of the table refers to the settings as stored in the...
9 • Messages item of the Send SMS menu allows you to: Send SMS • send a standard or customised short text message to someone, • edit the last message sent and send it again, • add an iMelody, pre-defined sounds, an anima- tion or a picture to your message.
Together with an attachment This option allows you to attach a sound, picture or animation to your message and press and attach it to your message. Depending on the type of file you want to attach, select Add graphic a bitmap image or an animation, and/or attach a melody.
the selected message, Delete of the sender if it is attached to Store number the message, if a melody was sent together Store melody with the SMS, if one or several graphics and/ Store graphic(s) or animations were sent together with the message, a number included in the message Extract...
Validity period This feature is subscription dependent. Allows you to select the length of time your message is to be stored in your Validity period SMS centre. This is useful when the recipient is not connected to the network (and thus cannot receive your message immediately).
Your phone might have been pre-configured. In this case, most parameters are already set and you don’t have to change them (except for Login, Password which are up to you when creating an e-mail address account). To enter text and numbers, including specific signs such as @ or%, see the characters table described page 12.
Page 54
Number: allows you to enter the phone number Phone provided by your ISP and needed to establish a connection. Press to select: to enter an ISDN ISP number, ISDN number to enter an analogic number, Analogue No. then press Contact your ISP to know what type of number you should select.
An e-mail account might be preconfigured with the name of your operator. In this case, its name cannot be changed. Press , select > Messages Settings > Account name and press Enter the new name in the edition window that appears and press Advanced The menus described in this section feature advanced...
Repeat steps 2 to 4 to add as many recipients as required. Select and press Validate list subject of your e-mail (you can leave this field empty) and press In the next window, enter the text of your e-mail (you can also leave this field empty). Press when you are ready to send your e-mail.
Page 57
your e-mails on your mobile phone (some operators send you a SMS when you receive a new e-mail). You must first download the headers from the server before retrieving the corresponding e-mails. Connect to the server Connection process Press and select Messages mail 1 E-mail 2...
Page 58
You can also press to access the e-mail header’s carousel and select Get mail from the available options. If the e-mail is too big (over 50 KB), it is rejected and the download is cancelled. Get and store attachments If the e-mail you have received contains attachments (JPEG picture, text file or another e-mail), they are characterised by a specific icon: Contains the details of the e-mail header (date...
Page 59
• The optimal size is 128 x 128 pixels, in order to be displayed correctly. We recommend you use a standard picture editing software to create the size of the picture you want. • Use a file name, a maximum of 10 characters. You can then add an extension such as «.jpg».
A new screen appears, that contains the subject of the received e-mail preceded with for «Reply». Press Enter the text of your mail, then press send it: select Send now and press your reply. Forward an e-mail In order to forward an e-mail to another recipient, you must first have downloaded it (see “Download e-mails”...
Instant message Allows you to set the Instant message When On, any short message (SMS) you receive is automatically displayed in idle mode. Scroll down to read it, and quickly reply by pressing twice: first to enter the edition screen, then to send your message.
10 • MMS Your mobile phone allows you to send receive messages), featuring texts, pictures and sounds. A multimedia message can be made of one slide (including text, sound and image), or of several: in this case, the message is played in a slide show, whether you send it to an e-mail address or to another mobile phone.
Although the picture preview when creating the MMS is (W)105 x (H)55 pixels, the maximum size of a picture you can send is (W)640 x (H)640 pixels. Warning! The bigger the picture size, the longer it will take to send it. A copyright-protected picture cannot be sent.
To save your message as a draft, that you can edit, complete and send later Save MMS on. MMS saved as drafts are stored in as draft > (see “Manage folders” Drafts page 59). To save your message as a template, that you can use as a basis for other Save as MMS (e.g., «Happy birthday»...
Receive an MMS Download and play an MMS When you receive an MMS, an alert message appears on the screen to inform you. If you activated the Automatic (see page 61), the message is automatically downloaded and placed in the Inbox. Select it in >...
Get and store attachments When playing an MMS as described in the previous section, press to access the following options: To switch back to automatic mode: the MMS is then played as a Play message continuous slide show. To move to the next or previous slide.
Lists the messages you have created but Not sent yet (e.g., if you have cancelled the sending procedure by pressing the key). - You can Open, of all these messages. Details Outbox - In addition, an MMS not yet sent can also be Re-sent you can...
Bearer This menu allows you to select the type of network used when launching a connection. Your mobile will only use the GSM network for connections. Your mobile will only use the GPRS GPRS network for connections. Your mobile will first try to connect to the GPRS network, then to the GPRS first GSM network if the GPRS network...
Page 69
Automatic (default automatically downloaded from the mode) server and placed in the Inbox, without you having to launch a connection. Select the message you have received in > and press Inbox This mode is deactivated when roaming. Delivery report This option can be set and informs you (via an SMS) whether your MMS was received or rejected.
11 • Multimedia Picture album JPEG pictures must have the correct size and format for your mobile phone to store and display them correctly. Please check “Get and store attachments” page 51 for complete information on this subject. This menu allows you to manage and display the pictures stored in your Picture Album mobile phone.
Select a sound and press to access the following options: it: press Rename Rename and press again. the selected sound. Delete Delete To send the selected sound via E-mail Send by Email (see “E-Mail” page 45 for details). Set as ringer To set the selected sound as Ringer.
BeDJ This menu allows you to launch BeDJ: press (see “Mix music” page 18 for BeDJ details). Multimedia Camera This menu allows you to activate the camera: press (see “Taking pictures” Camera page 13 for details).
12 • Games & Appli. Calculator This menu provides the following functions: Calculator Addition By pressing the Subtraction By pressing the Multiplication By pressing the Division By pressing the Equals By pressing the Enter the figures using the keypad. Calculator accuracy is to 2 decimal places and is rounded up to the higher decimal figure.
menu reminds you of events Set Reminder via alerts triggered at the chosen time. Move > , set the for this event and press Reminder This menu only applies to Meeting and ToDo events. Note that the reminder depends on the time set and displayed on the screen.
Deleting a repeated event • By selecting a past occurrence: select a past occurrences of an event and press event details appear, press and press to confirm: only the past occur- rences of the selected event are deleted. • By selecting a future occurrence: select a future occurrence of an event and press event details appear, press and press...
converter is available upon subscription and only in countries using the Euro. Brick Game This menu can be subscription dependent. As such its icon and content may vary. This menu gives you access to the brick game. The object of the game is to Brick Game destroy the bricks by hitting them with the ball.
DNS address Allows you to enter the DNS address of the external data network you want to connect to. Press confirm. Network account Allows you to select one of the data profiles you have defined in > Settings Access settings the list that appears, select the connection setting of your choice and press Auto-launch...
13 • Call information Call settings This menu allows you to set all the call options (call forward, waiting, etc.). Call settings Call forward Allows you to divert incoming calls either to your mailbox or to a number Call forward (whether in your phonebook or not) and applies to: Data...
Auto redial Allows you to set the auto redial Off. When and if the person you are Autoredial calling busy, automatically redials this number until a successful connection is made, or until the maximum number of attempts is reached (10). The phone emits one beep at the beginning of each attempt and one special beep if the connection is successful.
Call list From the main carousel, press select Call Info > Call list display the call list. Use Call list to scroll the list and press again to consult the date, time, number, call status of any selected call and to know if it was sent or received.
Allows you to activate or deactivate the systematic display of the length and/or Info at call end cost of each call when hanging up. Total cost This feature is subscription dependent. Allows you to display the accumulated cost and to set the counter to zero. It Total cost may be protected by PIN or PIN2 codes.
14 • WAP Your mobile phone supports services based on the Wireless Application Protocol (WAP). The built-in WAP browser allows you to access services supplied with your network, such as news, sports, weather, etc. Your mobile phone readily supports the WAP function if it is included in your subscription;...
Page 83
which will then replace the current one (see “Save as homepage” page 79). Bookmarks This menu allows you to store your favourite WAP site addresses, rename them if desired and access them quickly from the list. This can also be done while browsing: press access the Options, then select Bookmarks.
Page 84
Back to the Edit Homepage move to the address field and proceed the same way to change the address. Select Profile This menu allows you to select one of the available profiles, and to then define the connection settings for each of them: scroll to choose the profile of <...
Session info Allows you to display information about the current WAP session: security type, class, etc. Press go back one page. Current certificate Allows you to display the currently used security certificate. Press to go back one page. Rename Profile This menu allows you to rename the currently selected profile: enter the new name (an edit screen automatically appears), then press...
Page 86
The menus that are common to both Internet services and Options menus are described in the above section. Homepage Gives you direct access to the Homepage of the WAP site you are currently browsing. Back Brings you back to the previously browsed page. You must have browsed at least 2 pages for this option to be available.
15 • Operator services Most items of the Operator Services menu (e.g. Service numbers, Services +) are subscription- dependent and specific to operators: your mobile phone readily supports them if they are included in your subscription. Consequently, the menus shown following may or may not be available.
as a wait character. When you dial a number containing a wait character, your phone dials the first part (the phone number) and then waits for the call to be connected before sending the rest of the digits as DTMF tones. Any subsequent pause character is an ordinary pause that generates a delay of 2.5 seconds.
phone emits an alert beep and the screen displays waiting. To receive a second call, you must have: - subscribed to this feature, - deactivated the Call forward option for voice calls (see page 71), - activated the Call waiting option (see page 72). If you receive a second call, press •...
a second call as described in “Make a second call” above. When the second call is engaged, press select Conference. Repeat the above process until five members are connected. If there is an incoming call during the conference call and there are less than five members, you can accept this new call by pressing .
Icons & symbols In idle mode, several symbols can be displayed simultaneously. If the network symbol isn’t displayed, the network is not currently available. You may be in a bad reception area: move to a different location. - Your phone will not ring when Silent receiving a call.
Precautions Radio waves Your cellular mobile phone is a low power radio transmitter and receiver. When it is operating, it sends and receives radio waves. The radio waves carry your voice or data signal to a base station that is connected to the telephone network.
Page 93
standards Radio Telecommunications Terminal Equipment Directive 1999/5/EC. Always switch off your phone Inadequately protected or sensitive electronic equipment may be affected by radio energy. This interference can lead to accidents. Before boarding an aircraft and/or when packing the phone in your luggage: the use of mobile phones in an aircraft may be dangerous for the operation of the aircraft, disrupt the mobile phones network and may be illegal.
Page 94
140°F), moisture or caustic environments. You should only use Philips Authentic Accessories, as the use of any other accessories may damage your phone and will make all guarantees for your Philips phone null and void. • Make sure damaged parts are replaced immedi- ately by a qualified technician and that they are replaced with genuine Philips replacement parts.
Page 95
40°C. Environmental care following Philips has marked the battery and packaging with standard symbols designed to promote the recycling and appropriate disposal of your eventual waste. Battery: Packaging:...
Troubleshooting The phone does Remove and reinstall the battery (see page 1). Make sure not switch on you plugged the jack of the charger into connector (see “Charge the battery” page 2). Then charge the phone until the battery icon has stopped scrolling. Finally, unplug from charger and try to switch the...
Page 97
Your phone Press and hold doesn’t return switch off the phone, check that the SIM card and the to the idle battery are installed correctly, screen and switch it on again. This feature is network and Your phone subscription dependent. If the doesn’t display the phone network doesn’t send the...
Page 98
When Some features are network attempting to dependent. They are only available, therefore, if the use a feature in network or your subscription the menu, the supports them. Contact your mobile displays operator information on this subject. ALLOWED The display Check that the SIM card has shows INSERT been inserted in the right...
The provided software allows you to send faxes and SMS, download pictures and melodies. To maximise the performance of your Philips phone and not to void the warranty, always purchase Philips Authentic Accessories that are specially designed for use with your phone. Philips Consumer Electronics cannot be held liable for any damage due to use with non authorised accessories.
Page 100
KT12 4RQ, UK Identification mark: 0168 Le Mans, March 31, 2004 In case your Philips product is not working correctly or is defective, please return your phone to the place of purchase or to the Philips National Service Center.
