Page 1 INSTALLATION AND OPERATIONS MANUAL SICHARGE UC 150 UL Plug-in Dispenser January 2024 usa.siemens.com/sichargeuc...
Page 2 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Sections Introduction Safety instructions Description Application planning Installation Connecting Commissioning Operation Handling alarms and errors Maintenance and service Disposal Service and support Technical specifications Declaration of Conformity Abbreviations...
Page 3 The information in the relevant documentation must be observed. Trademarks All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Page 4: Table Of Contents
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Table of Contents Introduction FCC compliance About the operating instructions Open-source software Security Information Note regarding general data protection regulation Safety instructions Basic safety instructions The five safety rules for electrical work...
Page 5 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Transporting the dispenser Installation Safety instructions Floor mounting 5.2.1 Mounting the dispenser on the floor Wall mounting 5.3.1 Mounting the dispenser to the wall Connecting Safety instructions Connecting the power supply cable...
Page 6 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Overview "Emergency Stop" alarm message "Cabinet Door Opened" alarm message "Ground Fault Detection" alarm message Alarm messages in the alarm history Maintenance and service 10.1 Safety instructions 10.2 Maintenance plan 10.3...
Page 7: Introduction
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser SECTION 1 Introduction FCC compliance This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protections against harmful interference in a residential installation.
Page 8: About The Operating Instructions
We are liable for the product described, including the open-source software contained in it, pursuant to the conditions applicable to the product. Siemens accepts no liability for the use of the open-source software over and above the intended program sequence or for any faults caused by modifications to the software.
Page 9: Security Information
Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported and failure to apply the latest updates may increase customer exposure to cyber threats.
Page 10: Safety Instructions
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual SECTION 2 Safety instructions Basic safety instructions The SICHARGE UC dispenser meets all required technical standards and therefore provides the greatest possible product safety. To ensure the safety of all persons, systems and equipment at all times, adhere to the following basic safety instructions.
Page 11 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Intended use Intended use of the SICHARGE UC dispenser is limited exclusively to the charging of batteries of electric vehicles. The electric vehicle must be equipped with a CCS type 1 charging socket for this. The SICHARGE UC dispenser charges electric vehicles in accordance with the SAE J1772 and SAE J3105 standards.
Page 12 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Protection against electromagnetic fields The electromagnetic emission in the SICHARGE UC dispenser meets the requirements of the UL 2202 standard: Note Radio interferences The operation of this device can cause radio interferences in residential areas.
Page 13 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Alterations to the device The operating instructions describe all permissible alterations to the SICHARGE UC dispenser. Any other or additional changes are not permitted. Unauthorized modifications void the manufacturer’s warranty and the approvals of the device become invalid.
Page 14: The Five Safety Rules For Electrical Work
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual The five safety rules for electrical work NFPA 70E “Standard for Electrical Safety in the Workplace” prescribes safety rules for working in and on electrical systems. To ensure the safety of persons and property in accordance with the standards, always comply with the...
Page 15 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Safety signs on the packaging The following safety signs are attached to the packaging of the SICHARGE UC dispenser: Safety sign Meaning Marking of the center of gravity Warning of tipping hazard...
Page 16: Industrial Security
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual 2.4 Industrial Security Siemens AG provides products and solutions with industrial security functions that support the secure operation of plants, systems, machines and networks. Implement and maintain the industrial security concept In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement and continuously maintain a holistic, state-of-the-art industrial security concept.
Page 17: Identification Of The Device
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Identification of the device The nameplate clearly identifies the SICHARGE UC dispenser. To this end, the nameplate contains the identification data of the device, the manufacturer and the UL marking.
Page 18: Description
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual SECTION 3 Description Product overview The SICHARGE UC dispenser allows for the high power charging of vehicles powered by electricity. Thanks to the support of the open, universal charging standard CSS type 1, the SICHARGE UC dispenser charges a variety of vehicle models from different manufacturers both quickly and efficiently.
Page 19 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Different versions The SICHARGE UC dispenser is available in various versions. Therefore, the graphics are displayed with many options. The local SICHARGE UC dispenser may not include one of the options described.
Page 20: Overview Of Variants
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Overview of variants Overview of variants for floor mounting The following table shows a comparison of the basic version and the variant with all options available for floor mounting:...
Page 21 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Overview of variants for wall mounting The following table shows a comparison of the basic version and the variant with all options available for wall mounting. Wall mounting LED display...
Page 22: Structure Of A Sicharge Uc Dispenser
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Structure of a SICHARGE UC dispenser 3.3.1 External structure Structure, display and operator controls This figure shows the external structure, display and operator controls of the SICHARGE UC dispenser. For this example, we selected a floor-mounted dispenser.
Page 23 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Ventilation grilles for discharging the air of the air conditioner are installed on the rear. Ventilation grille of the air- conditioning unit Mounting bar for wall mounting Rear view LED display The SICHARGE UC dispenser can be equipped with an LED display.
Page 24 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual HMI screen The SICHARGE UC dispenser can be equipped with an HMI screen. The SIPLUS HMI KTP700 Basic has an HMI screen with a 7” display in widescreen format. The large viewing angle of the display makes it easier to recognize the operating information from different viewing directions.
Page 25: Internal Structure
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser 3.3.2 Internal structure The figure below shows the internal structure of the SICHARGE UC dispenser as well as the mounting variants on the floor and wall. LED display Air-conditioning unit...
Page 26 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Charging contacts To safely transmit the high charging power, the CCS1 connector of the charging cable uses the following charging contacts: Figure 3-2 Charging contacts Contact AC Power (L2, N)
Page 27 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Locking Charging mode 4 for DC charging according to the standard SAEJ1772 requires secure locking of the plug-in connection between the charging plug and the charging socket of the vehicle during the entire charging process.
Page 28: Electrical Protection Devices
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual 3.5 Electrical protection devices The SICHARGE UC dispenser is equipped with multiple electrical protection devices. Note No EMERGENCY OFF button on the SICHARGE UC dispenser The EMERGENCY OFF button is installed directly on the connected SICHARGE UC charging station.
Page 29 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Insulation monitoring Insulation monitoring is provided by the upstream SICHARGE UC charging station. To ensure that an electric vehicle is safe, the high-voltage electrical supply system of the vehicle must not be grounded with an electrically conductive material.
Page 30: Application Planning
• Documents • Password Note Disclaimer of liability Customers are responsible for safekeeping of the documents and objects received. Siemens is not obligated to reproduce transferred documents and objects. Siemens is not liable for the improper use of intelligent devices.
Page 31: Checking The Transport Packaging
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser 4.1.2 Checking the transport packaging Start the inspection of the transport packaging with a visual inspection of the tilt indicator. Checking the tilt indicator A tilt indicator is affixed to the transport packaging of the SICHARGE UC dispenser. To check the tilt status of the transported package, follow the instructions on the label.
Page 32: Unpackaging The Sicharge Uc Dispenser
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual 4.1.3 Unpackaging the SICHARGE UC dispenser Depending on the transport route, the carrier supplies the SICHARGE UC dispenser in different transport packaging. Therefore, the packaging does not look the same. Specifications for the disposal of the packaging material...
Page 33: Reporting Missing Delivery Components Or Transport Damage
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser 4.1.4 Reporting missing delivery components or transport damage If you discover that the delivery is incomplete or that there is transport damage, first document the damage. Then submit a damage report.
Page 34 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Selection criteria for a safe location Select the location of the SICHARGE UC dispenser so that all charging actions are safe. The user must be able to connect the vehicle without the use of extension cables. Therefore, the SICHARGE UC dispenser must be within close proximity of the supplied mounting surfaces.
Page 35 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Minimum clearances for floor mounting For operation and maintenance and to ensure proper ventilation of the SICHARGE UC dispenser, you must maintain the following minimum physical clearances (in mm), while also adhering to all building and installation codes:...
Page 36 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Minimum clearances for wall mounting For operation and maintenance and to ensure proper ventilation of the SICHARGE UC dispenser, you must maintain the following minimum clearances (in mm): Figure 4-4...
Page 37 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Electrical installation • Auxiliary voltage: The SICHARGE UC dispenser is designed for the connection to the low-voltage network (230 VAC) via the SICHARGE UC charging station. Connect the SICHARGE UC dispenser to the SICHARGE UC charging station using a properly sized supply line.
Page 38 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Bumper To protect the SICHARGE UC dispenser from the impact of other vehicles, install a bumper Bumper Vehicle SICHARGE UC dispenser Figure 4-6 Example: Correct position of bumper and SICHARGE UC dispenser Plan for bumpers based on the dimensions of the vehicles used.
Page 39: Preparing The Mounting Surface
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser 4.3 Preparing the mounting surface 4.3.1 Preparing for floor mounting To securely fasten the SICHARGE UC dispenser to the intended mounting surface on the floor, you must prepare the mounting surface.
Page 40 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Drill holes for fixing points on the floor To fasten the SICHARGE UC dispenser, the following drill holes must be available for the fixing points: Figure 4-8 Fixing points of the mounting plate Fixing to the floor The mounting material is not included in the scope of delivery.
Page 41: Preparing For Wall Mounting
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser 4.3.2 Preparing for wall mounting To securely fasten the SICHARGE UC dispenser to the intended mounting surface, you must prepare the mounting surface. CAUTION Secure work area Ensure a sufficiently large safety zone around the mounting surface. For example, use warning signs and barriers.
Page 42 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Installing anchors Using a hammer drill, drill six ¼” holes into the concrete wall. The minimum drill depth is 1 and ¼” deep. The drill template is shown below: After drilling the six holes, insert the ¼”...
Page 43: Storing The Dispenser
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser 4.4 Storing the dispenser Proper storage of the SICHARGE UC dispenser is a requirement for the safe operation of the device. NOTICE Damage to property due to improper storage In case of improper storage, there is a risk of damages to the SICHARGE UC dispenser, such as corrosion damage.
Page 44: Transporting The Dispenser
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Long-term storage NOTICE Material damage due to excessive storage time When the electronic components of the SICHARGE UC dispenser remain switched off for more than one year, the components may be subject to storage damages.
Page 45 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Note Transporting the SICHARGE UC dispenser on a transport pallet The transport pallet protects the SICHARGE UC dispenser from damages and makes transport easier. • Therefore, always transport the SICHARGE UC dispenser on the transport pallet.
Page 46 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Transporting the dispenser for wall mounting with lifting equipment The SICHARGE UC dispenser wall mounting is delivered with mounting rails on the rear of the device. 1. Mount the shackle into the holes on the right and left of the mounting rail.
Page 47: Installation
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser SECTION 5 Installation Safety instructions Observe the following safety instructions when installing the SICHARGE UC dispenser. DANGER Electric shock due to exposed electrical connections or components Before starting any installation work, check that the feeder cables have been de-energized and secured against being switched on again unintentionally.
Page 48 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual NOTICE Accident risks Avoid accidents and injuries as well as damages to vehicles and the SICHARGE UC dispenser. These include, for example, inattentiveness, slipping and tripping risks as well as vandalism.
Page 49: Floor Mounting
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Grounding instructions This unit is to be connected to a grounded, metal permanent wiring system; or an equipment-grounding conductor is to be run with circuit conductors and connected to an equipment-grounding terminal or lead on the SICHARGE UC charging station.
Page 50: Wall Mounting
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Mounting the SICHARGE UC dispenser To position the SICHARGE UC dispenser on the base area, follow these steps: 1. Position the SICHARGE UC dispenser on the mounting surface using the bolt anchors.
Page 51 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Required tools and fasteners To mount the SICHARGE UC dispenser, you need the following tools: • Torque wrench • Hexagonal socket The mounting material is not included in the scope of delivery.
Page 52: Connecting
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual SECTION 6 Connecting Safety instructions The installer is responsible for the electrical connection of the SICHARGE UC dispenser. The electrical connection of the SICHARGE UC dispenser must be done according to the relevant regulations (such as conductor cross section, fuses and ground connection).
Page 53 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser NOTICE Danger to life and damage to property due to loose power connections Insufficient tightening torques and vibrations lead to loose power connections. Loose power connec- tions can result in high voltages on exposed parts. Touching the parts can lead to serious injury or death.
Page 54: Connecting The Power Supply Cable
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Connecting the power supply cable To connect the SICHARGE UC dispenser to the SICHARGE UC charging station, connect the power supply cable to the L1 and N fuses of the SICHARGE UC dispenser.
Page 55 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Connecting the PE conductor First, connect the PE conductor of the power supply cable to the grounding connector: 1. Remove the sheath of the power supply cable to approximately 8 cm in length.
Page 56: Connecting The Dc Cable
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual 6.3 Connecting the DC cable To connect the SICHARGE UC dispenser to the SICHARGE UC charging station, connect the DC cable to the DC connectors of the SICHARGE UC dispenser.
Page 57 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Connect protective conductor First, connect the protective conductor of the DC cable to the grounding connector: Remove the sheath of the cable to connect the cable lug. Choose a cable lug for the appropriate conductor cross section.
Page 58: Connecting The Communication Cable
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual 6.4 Connecting the communication cable To connect the SICHARGE UC dispenser to the SICHARGE UC charging station, connect the Ethernet cable to the Ethernet switch of the SICHARGE UC dispenser.
Page 59 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Connecting the Ethernet or fiber-optic cable NOTICE Network connection The SICHARGE UC devices form a closed network. Do not establish a connection to other networks and devices. Observe the specifications for the routing of Ethernet cables in the section Location planning (Page 37).
Page 60: Commissioning
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual SECTION 7 Commissioning Switching on the dispenser To commission the SICHARGE UC dispenser, switch on the power supply of the SICHARGE UC charging station. WARNING Qualified personnel Only a qualified and trained electrician may work on the SICHARGE UC dispenser.
Page 61 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Preparing the SICHARGE UC dispenser for switch-on Switch on the following switching elements at the SICHARGE UC charging station for the power supply cable of the SICHARGE UC dispenser: •...
Page 62: Operation
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual SECTION 8 Operation Safety instructions Observe the following safety instructions for the safe operation of the SICHARGE UC dispenser. NOTICE Accident risks Avoid accidents and injuries as well as damages to vehicles and the SICHARGE UC dispenser. These include, for example, inattentiveness, slipping and tripping risks as well as vandalism.
Page 63 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Note Access to the EMERGENCY OFF button Ensure that only trained personnel operate the SICHARGE UC dispenser. To operate the EMERGENCY OFF button immediately in case of an emergency, these persons must be guaranteed access to the SICHARGE UC charging station.
Page 64: Plugging In The Charging Cable
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual NOTICE Damage due to unsuitable objects If you touch the HMI screen with unsuitable objects, you are significantly reducing the service life of the display. If there is severe damage, the HMI screen can also fail.
Page 65 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Plug in the charging cable Proceed as follows to plug in the charging cable: 1. Take the charging plug from the plug holder of the SICHARGE UC dispenser. 2. If you need more cable length, remove the cable from the cable holder.
Page 66: Monitoring The Charging Process
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual 8.3 Monitoring the charging process After you have connected the electric vehicle to the SICHARGE UC dispenser, the SICHARGE UC dispenser display automatically shows the "Start" menu. Several display elements provide precise information about the progress of the charging process.
Page 67 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Vehicle status display Using the vehicle status display, you can easily determine whether your vehicle is connected to the SICHARGE UC dispenser and is charging. Symbol Vehicle status The vehicle is not ready for charging.
Page 68 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Progress display The progress bar provides you with an overview of the charging process. The display element shows the individual steps of the charging process: Step Meaning Electric vehicle The electric vehicle was connected to the SICHARGE UC dispenser.
Page 69: Stopping Charging
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser 8.4 Stopping charging You can stop an active charging process at any time by pressing the “Stop charging” button. “Stop charging” button In the “Start” menu, the SICHARGE UC dispenser displays the “Stop charging” button: “...
Page 70: Unplugging The Charging Cable
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual 8.5 Unplugging the charging cable When the charging process is complete, the electric vehicle automatically unlocks the plug-in connection. You can then unplug the charging cable. DANGER Explosion or electric shock If you force the charging plug out of the charging socket, dangerous electric arcs can cause death or serious injury.
Page 71: Displaying Alarms
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser 8.6 Displaying alarms In case of an alarm, the SICHARGE UC dispenser stops the charging process. The HMI screen shows an alarm message in the full-screen mode or an alarm button in the “Start” menu.
Page 72 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual To access the “Alarms History” menu In the “Options” menu, press the “Alarms History” button. Figure 8-5 “Options” menu...
Page 73 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser “Alarm History” menu In the “Alarm History” menu, the SICHARGE UC dispenser lists all recorded alarms: Figure 8-6 “Alarm History” display...
Page 74: Operating The Service Menu
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Operating the Service menu 8.7.1 Selecting options Opening the “Options” menu To access the “Options” menu, press the following button on the “Start” menu: Figure 8-7 “Options” menu button “Options”...
Page 75: Checking Recorded Alarms
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Selecting options Use the option buttons to select the following option: Button Option Charger Ratings The HMI screen displays the charger part number and ratings of the unit. Last Session Energy...
Page 76 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual “Alarm History” menu The HMI screen displays a list of the recorded alarms in the “Alarm History” menu: Figure 8-9 List of recorded alarms For each recorded alarm, the HMI screen displays the time a and date s that the alarm...
Page 77: Restarting The Charging Process After An Alarm
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser 8.7.3 Restarting the charging process after an alarm When the SICHARGE UC dispenser triggers an alarm, the SICHARGE UC dispenser automatically switches off the power supply of the charging cable. The SICHARGE UC dispenser does not charge during the alarm state.
Page 78 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual “Alarm History” menu In the “Alarm History” menu, the SICHARGE UC dispenser shows the currently active alarm against a light blue background: Active alarm “Warning / Fault Acknowledgment” button Figure 8-10 “Alarm History”...
Page 79: Displaying Information About The Sicharge Uc Dispenser
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Deactivate alarm and start charging again To restart the charging process after an alarm, proceed as follows: 1. Press the “Warning / Fault Acknowledgment” button. 2. Press the main "Menu" button.
Page 80 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Figure 8-11 “Charger Session Info” menu...
Page 81: Displaying Energy Delivered During The Last Charging Session
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Voltage and current values For the SICHARGE UC dispenser, the HMI screen of the displays the following values: Value Meaning Input voltage A-N AC voltage measured in line conductor A-N...
Page 82 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual “Energy Delivered During Last Charging Session” menu The HMI screen displays the following information for the current charging process in the “Energy Delivered During Last Charging Session” menu: Figure 8-12 “Energy Meter” menu...
Page 83: Displaying The Current And Voltage Trend Of The Charging Process
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser 8.7.6 Displaying the current and voltage trend of the charging process Requirements • You have opened the “Options” menu. • In the “Options” menu, you have pressed the “Graphics” button.
Page 84 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Diagram area Display for actual value and setpoint of charging voltage Display for actual value and setpoint of charging current Figure 8-14 “EV Targets & DC Outputs” menu...
Page 85: Selecting Advanced Options
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Changing the diagram area To change the displayed diagram area, control the HMI screen with the following gestures: Gesture Function Move your finger on the display to the left The diagram area shifts to the right on the time axis.
Page 86 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Maximum output power limit Maximum output voltage/current Maximum alarm output voltage/current Bulk charge state of charge Figure 8-15 Parameter limits Parameter Limits The “Parameter limits” allows the user the option of changing limits on Output Power, Output Voltage and Current, and Alarm Output Current and Voltage.
Page 87 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Manual Control PID The following figure shows the Manual Control PID for controlling the selected SICHARGE UC dispenser. Dispenser Number Switch for automatic or manual test charging procedure Switch for DC converter manual...
Page 88: Sequential Charging Concept
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual 8.8 Sequential Charging Concept When equipped with two or more dispensers, the SICHARGE UC150 kW can charge one EV per dispenser sequentially. 8.8.1 Bulk Charge / Trickle Charge Scheme Depending on the battery characteristics, the charging process for a single EV can be prolonged.
Page 89: Sequential Charging Strategies
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser 8.8.2 Sequential Charging Strategies Although up to four dispensers can be connected to one charger, only one dispenser can actively charge an EV. If there are more than one EV plugged into the dispensers, the EVs will be placed in a queue to wait for their turns to be charged.
Page 90: Sequential Charging Example
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual 8.8.3 Sequential Charging Example The following is a representation of a sequential charging scenario when three dispensers are used. It is assumed that the bulk charge complete SoC is set as 85% and the interval between bulk charging sessions is set as 30 minutes here.
Page 91: Handling Alarms And Errors
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser SECTION 9 Handling alarms and errors Overview In case of an error, the SICHARGE UC dispenser automatically conducts an error diagnostics. Depending on the type of error, the SICHARGE UC dispenser issues different alarm messages. On the central HMI screen, the SICHARGE UC dispenser provides information through messages from the SICHARGE UC dispenser and the SICHARGE UC charging station.
Page 92 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual “Emergency Stop” alarm message The display shows the “Emergency Stop” alarm message in full screen mode: Figure 9-1 Alarm message EMERGENCY OFF state The EMERGENCY OFF function switches off the power supply of the charging cable. The charging process is stopped immediately.
Page 93: Cabinet Door Opened" Alarm Message
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser 9.3 “Cabinet’s Door Opened” alarm message When you open the cabinet door of a SICHARGE UC dispenser or the SICHARGE UC charging station, the display shows the following alarm message.
Page 94: Ground Fault Detection" Alarm Message
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual “Ground Fault Detection” alarm message To avoid a dangerous situation, the SICHARGE UC dispenser constantly monitors the insulation of the connected electric vehicle. If the insulation monitor detects a ground fault, the display shows an alarm message.
Page 95: Alarm Messages In The Alarm History
In the “Alarm History” menu, the charging station lists the following alarm messages (error handling steps that involve measuring or applying changes while SICHARGE UC is active should be performed by a local Siemens service representative): Main cabinet error codes...
Page 96 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Error Error OCPP Error Description Code Handling Category Low Input Voltage Shutdown Measure the level of the input voltage at the AC input breaker Undervoltage Measure the AC input voltage on the SinePower board...
Page 97 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Error Error OCPP Error Description Code Handling Category RL34-Output Diode Heatsink Fan Startup Alarm Measure the DC input to the fan InternalError Check for a broken wire or a loose connection...
Page 98 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Error Error OCPP Error Description Code Handling Category Q5-Primary Heater Trafo CB Opened Check feedback wire between PLC and Q5 for a broken wire or a OverCurrentFailure loose connection...
Page 99 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Error Error OCPP Error Description Code Handling Category Startup_Sequencer_Failure Check that K2 briefly closes on start up InternalError Check that K1 closes on start up Measure resistance of RBD1, RBD2 and RBD3...
Page 100 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Error Error OCPP Error Description Code Handling Category SinePower: CAN_Communication_Timeout_Error Check all ethernet connections in the dispenser InternalError Check Ethernet connection from dispenser to main cabinet Ensure Ethernet cables are routed according to installation and...
Page 101 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Error Error OCPP Error Description Code Handling Category Client_Communication_Fault[2] Communication between main cabinet and dispenser was InternalError interrupted. Check the network cables for loose connections Verify the dispenser A1-PLC is in RUN state (Green RUN/STOP LED)
Page 102 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Dispenser cabinet error codes Description Error Number Error Handling OCPP Error Category FRONTEND_DOOR Close the cabinet door completely InternalError Check wiring from SF20 to A1_PLC Check mounting of the door switch for proper function...
Page 103: Maintenance And Service
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser SECTION 10 Maintenance and service 10.1 Safety instructions To guarantee the safety of persons and equipment during maintenance and service of the SICHARGE UC dispenser, observe the following safety instructions.
Page 104 SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual WARNING Falling parts When working at an elevated height, watch out for falling parts, cables or plugs. CAUTION Risk of stumbling or slipping Keep the work area clean and tidy to prevent stumbling and slipping.
Page 105: Maintenance Plan
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser 10.2 Maintenance plan The following maintenance/service measures are necessary to maintain the functionality and operational safety of the SICHARGE UC dispenser. Maintenance of the dispenser should coincide with maintenance of the SICHARGE charging cabinet.
Page 106: Checking The Outside Of The Sicharge Uc Dispenser
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual 10.3 Checking the outside of the SICHARGE UC dispenser Maintenance interval After commissioning, carry out the tests at the following intervals: • 6 months after commissioning • 12 months after commissioning After the first year, carry out the tests every 12 months.
Page 107: Testing The Inside Of The Sicharge Uc Dispenser
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser 10.4 Testing the inside of the SICHARGE UC dispenser Maintenance interval • Testing every 12 months WARNING Qualified electrician Only a qualified and trained electrician may work on the SICHARGE UC dispenser.
Page 108: Servicing The Sicharge Uc Dispenser
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual 10.5 Servicing the SICHARGE UC dispenser 10.5.1 Cleaning the HMI screen The HMI screen is designed for low-maintenance operation. Clean the HMI screen regularly to ensure that the HMI screen is in perfect condition.
Page 109: Cleaning The Cabinet And The Charging Cable
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Cleaning the HMI screen Clean the HMI screen as follows: 1. Apply the cleaning agent on the cleaning cloth. 2. Start cleaning at the edge of the screen. 3. Wipe with the cleaning cloth from the edge of the screen to the inside.
Page 110: Cleaning The Ventilation Grille
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Cleaning the exterior surfaces of the cabinet • Wipe down the exterior surfaces of the SICHARGE UC dispenser with a damp cloth. • Then rub the SICHARGE UC dispenser dry.
Page 111 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Permitted cleaning agents and tools • Use only soft cleaning cloths. • Use a mild, non-corrosive cleaning agent, even in the case of heavy soiling. An example of mild detergent would be dishwashing liquid.
Page 112: Disposal
Parts for incineration or recovery Copper parts Materials recovery Circuit boards Landfill/discard Note: Because of safety reasons, consider the safety instructions in this operating manual. The product should be dismantled by qualified personnel. Please get in contact with your local Siemens service representative.
Page 113: Service And Support
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser SECTION 12 Service and Support Customer Support Phone For customer support, call us at +1 (855) 950-6339, option 9 Business Hours: Monday – Friday, 6:00 a.m. to 8:00 p.m., Eastern...
Page 114: Technical Specifications
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual SECTION 13 Technical specifications 13.1 Technical specifications Core statement Supply voltage input Voltage 230 V AC, 1 phase, +/- 10% Frequency 60 Hz DC output Rated power 100 ... 150 kW Current (maximum) 100 ...
Page 115 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Weight Floor-mounted with LED display 360 lb / 163 kg with skid Wall-mounted dispenser with LED display 290 lb / 132 kg Cable glands Outer cable diameter DC single wire (in / mm) 0.63 ...
Page 116: Charging The Current/Power Curve
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Connection plan Type Charging station Dispenser Outer cable diameter (in / mm) Description -F11 -F15 0.63 … 1.10 in / 16 … 28 mm DC single conductor -F12 -F16 0.63 …...
Page 117 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Power curve The following figure shows the power curve depending on the charging voltage: Figure 13-2 UC 150 charging station power curve...
Page 118: Declaration Of Conformity
• UL2231 Personnel Protection Systems for Electric Vehicle (EV) Supply Circuits: Particular Requirements for Protection Devices for Use in Charging System Safekeeping location of the Declaration of Conformity SIEMENS AG keeps the EU Declaration of Conformity of the charging station available for the responsible authorities at the following location: Legal Manufacturer Siemens Industry, Inc.
Page 119: List Of Abbreviations
Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser APPENDIX A List of abbreviations A.1 Abbreviations The following abbreviations are used in these instructions: Abbreviation Term Alternating Current Controller Area Network Combined Charging System Direct Current OCPP Open Charge Point Protocol...
Page 120: Index
SICHARGE UC 150 UL Plug-in Dispenser | Installation and Operations Manual Index Abbreviations, 119 Declaration of Conformity, 118 Alarm message Display, 23 Cabinet’s Door Opened, 93 Disposing Emergency Stop, 91 Packaging material, 112 Ground Fault Detection, 94 Alarm messages in the alarm history, 95...
Page 121 Installation and Operations Manual | SICHARGE UC 150 UL Plug-in Dispenser Packaging material Disposal, 112 Personal protective equipment, 11 Plug in the charging cable, 64 Power curve, 116 Preparing the base area, 39, 41 Product overview, 18 Qualified personnel, 11...
Page 122 This document contains a general description of available technical options only and its effectiveness will be subject to specific variables, Siemens Industry, Inc. including field conditions and project parameters. Siemens does not 3617 Parkway Ln. make representations, warranties, or assurances as to the accuracy or Peachtree Corners, GA 30092 completeness of the content contained herein.
