Gator frameworks GFW-AV-LCD-2 Quick Start Manual

716408532929
GFW-AV-LCD-2
Model UPC
GFW-AV-LCD-2 716408532929
Setup Instructions:
1
12"
Place tripod on flat, level
surface. Extend tripod
leg housing down
approximately 12" from
starting position to
create a wide, stable
base. The leg with
Frameworks logo should
be positioned forward so
it will be directly under
the TV display.
4
With the TV mounted,
adjust to the desired
screen height.
Finally, check that all
knobs are securely
tightened.
Call Customer Service For Order Information
1-813-221-4191
@
Visit Us Today Online
Description
Deluxe Tripod LCD/LED stand
2
With the center tube in
the down position,
attach the TV Mount
and fully tighten the
main star knob.
(Not Shown) Attach
VESA Mount to TV
according to the TV
Manufacturer's
guidelines.
NOTE: Max TV screen size is 48"
www.gatorframeworks.com
Color
Black
3
Attach VESA Mount to TV
Mount Assembly until it
CLICKS into place. Fully
tighten the small knob
on the VESA Mount to
complete the TV
attachment. Adjust the
forward pitch of the
mount to the desired
angle, and fully tighten
the knob.
NOTE: Shown without TV attached
Screen
VESA
45lb
100x100
max
200x200
23"-48"
• It is recommended to use
tripod weights if using with a
screen larger than 32 inches.
• Do not use in a windy
environment or place on an
uneven surface.
Rev. 1 - 3/18/2015
