- Page 1 Quick Installation Guide for GPON Optical Network Router...
-
Page 2: Technical Specifications
Technical Specifications Power supply: 12 V DC, 2 A Power adapter input: 100 - 240 V AC, 50 - 60 Hz System power supply: See the nameplate on the device Ambient temperature: 0ºC to +40ºC Ambient humidity: 5% - 95% RH (non-condensing) ... -
Page 3: Product Overview
Product Overview Product Feature 4 Ethernet ports GPON Optical Network Router 2 POTS ports (ONR) 1 USB 2.0 port... -
Page 4: What's In The Box
1. What's in the box? Name How it looks like GPON ONR Cat5e cable Power adapter Phone cable... - Page 5 2. Suggested Placement of ONR Do not install GPON ONR outdoors or in cabinets which may be exposed to sun and rain. GPON ONR should be horizontally placed at an open area, such as on your work desk. Ports at the back of...
- Page 7 3. Connecting Cables and Devices to GPON ONR Power port USB port Two telephone ports Reset button Four ethernet ports+10G port Power on/off Fibre port...
- Page 8 Step 1: Follow instructions below to perform fibre patching. As fibre optic cables are made of glass, please do not bend sharply and ensure the bending diameter is larger than 60 mm. Step 2: Connect Cat5e cable (Blue) from the Ethernet port of your device to a LAN port.
- Page 9 Step 5: Connect the power adapter to GPON ONR's POWER port and your home electrical outlet. The POWER indicator on the GPON ONR should be green.
- Page 10 4. Configuring the GPON ONR 4.1 Logging in to the webpage for configuration Step 1: Connect your PC to the GPON ONR through the Ethernet port. Step 2: Ensure your PC is in dynamic IP address mode. Step 3: Enter http://192.168.1.254 in the address bar of Internet Explorer and press Enter.
- Page 11 Information (on the left pane) > SN (second tab) Step 2: Input the FTTH ID (Use FTTH ID provided by Singtel). Step 3: Click Apply. The GPON ONR will automatically reboot. For how to verify the service, refer to chapter 5.
- Page 12 5. Verifying Successfulness of Connection LED indicators on the GPON ONR provide status � information of each service connection. Each light mode indicates the successfulness of the connection listed in chapter 3 & 4: • Fibre connection is up if PON indicator is steady green.
-
Page 13: Resetting Factory Defaults
6. Resetting Factory Defaults What does it do? � To reset all the settings except the FTTH ID. How to reset? � Press Reset button by using a needle-like object and hold for more than 10 seconds. If LED indicator turns off and on, your ONR has been successfully restored to factory defaults. -
Page 14: Indicator Description
7. Indicator Description Indicator Status LED Description Steady green The ONR is powered on. The power supply is cut off. POWER Blinking red The ONR is upgrading. Steady red Hardware self-check failed or failed to start. Steady green Fibre connection is up. Fibre connection is down. - Page 15 Voice service is down or not available. Steady on Ethernet connection is in the normal state. LAN1– Blinking Data is being transmitted on the Ethernet port. LAN4 Ethernet connection is not set up. Steady on Internet service is OK. INTERNET Blinking Internet data is being transmitted.
